DIGITAL COPIER : AR-5132/5040
Date
:
Mar. 24, 1998
CHANGE IN THE 500 TRAY COPY PAPER FEEDING UNIT CARRIED OUT
AS A MEASURE TO ESTABLISH INTERCHANGEABILITY OF PARTS
BETWEEN MODELS.
1.Model Name: AR-5132/5040
2.General: The change in the 500 tray copy paper feeding unit described below has been carried
out as a measure to establish interchangeability of parts between models.
No. : ARE-080
(Old) (New)
DUNT-6546FC13 → DUNT-6923FCZZ
Please refer to the following pages for details concerning the composition parts of the
new unit.
3.Interchangeability:
4.Action: From the start of 1998 February production.
Parts (unit assemblies) are interchangeable between old and new units.
∗ [It is important to note that unit assembly parts (individual parts) are not
interchangeable, and it is therefore necessary to exercise caution when carrying
out replacement operations.]
SHARP CORPORATION Reprography Division
1/4
Green
C
∗ 500 paper feeding unit
2/4
Ref.
No.
Model
name
Version P/G No.
Current parts New parts
Parts code Parts code
Price
rank
Parts name
Effec-
tive
time
Inter-
change-
ability
Note
AR-5040
AR-5132
41 -901
All
25 -901
44 -33
∗ -1
∗ -2
∗ -3
∗ -4
∗ -5
∗ -6
∗ -7
∗ -8
∗ -9
∗ -10
∗ -11
∗ -12
∗ -13
∗ -14
∗ -15
∗ -16
∗ -17
∗ -18
∗ -19
∗ -20
DUNT-6546FC13 DUNT-6923FCZZ BM 500 paper feeding unit
---- NROLR1219FCZZ AL Pick up roller
---- NGERH1263FCZZ AC Pick up roller gear
---- NSFTZ2483FCZZ AE CG pick up roller shaft
---- XRESP50-06000 AA E type ring
---- NGERH1274FCZZ AC Idle gear
---- LSTPP0279FCZZ AB Stopper
---- MLEVP0761FCZZ AD Pick up roller lever L
---- NROLR1218FCZZ AL Paper feeding roller
---- NGERH1275FCZZ AM Paper feeding roller gear
---- MLEVP0762FCZZ AD Pick up roller lever R
---- XRESP70-08000 AA E type ring
---- NBRGP0549FCZZ AC Bearing
---- NSFTZ2485FCZZ AP Paper feeding roller shaft
---- MSPRC2658FCZZ AC PF earth spring
---- VHPGP1A71A1-1 AG Photo sensor
---- MLEVP0588FCZZ AB Solenoid lever
---- MSPRC2699FCZZ AC Solenoid lever spring
---- LPINS0317FCZZ AB Spring pin
---- MARMP0250FCZZ AC Solenoid arm
---- RPLU-0327FCZZ AQ Pick up solenoid
1
1st lot
’98/2
6
3/4
Ref.
Model
name
Version P/G No.
No.
∗ -21
∗ -22
∗ -23
∗ -24
∗ -25
∗ -26
∗ -27
∗ -28
∗ -29
∗ -30
∗ -31
∗ -32
∗ -33
∗ -34
∗ -35
∗ -36
∗ -37
∗ -38
∗ -39
∗ -40
∗ -41
∗ -42
∗ -43
<Interchange>
1. Interchangeable. 4. Not interchangeable.
2. Current type can be used in place of new type.
New type cannot be used in place of current type.
3. Current type cannot be used in place of new type.
New type can be used in place of current type.
Parts marked with ‘‘ ’’ is important for maintaining the safety of the set. Be sure to replace these parts with
specified ones for maintaining the safety and performance of the set.
Current parts New parts
Parts code Parts code
---- DHAI-2049FCZZ AQ Paper feeding harness 1.2
---- XEBSD30P12000 AA Screw
---- PCLC-0279FCZZ AV PF clutch
---- LBRC-0048FCZ2 AQ Main bracket
---- LPLTM4057FCZ1 AH Reinforce plate
---- MSPRP2362FCZZ ACC Earth spring N
---- XEBSD30P08000 AA Screw
---- MLEVP0695FCZZ
---- MLEVP0601FCZZ Sensor lever
---- PGIDM1825FCZZ AN Lower guide
---- XEBSD40P10000 AA Screw
---- NROLR1229FCZZ AL Reverse roller
---- LPLTM5457FCZZ AE PF pressure plate
---- MSPRC2674FCZZ AC Pressure spring
---- CCLR-0372FC01 AH Coller
---- PCOVP1142FCZZ AC Cover
---- MSPRC2382FCZZ AG Spring
---- PCLR-0373FCBZ AD Coller
---- NSFTZ2484FCZZ AF Reverse roller shaft
---- XPSSJ20-15000 AA
---- LPINS0319FCZZ AB
---- LPLTM4057FCZZ AF Reinforce plate
---- XHBSE40P08000 AA Screw
Price
rank
AC
5. Interchangeable if replaced with same types of
related parts in use.
6. Others.
Parts name
H paper feeding lever
Spring pin
Effec-
tive
time
1st lot
’98/2
Inter-
change-
ability
6
Note
4/4
