Sharp AN-SV100T User Manual
Sharp Projector
Ceiling-mount Rotating Module
MODEL
AN-SV100T
INSTRUCTION MANUAL
Included accessories
• Installation bracket
(x 1)
• Terminal cover (x 2)
• Anti-sway plate A (x 1) • Anti-sway plate B (x 2)
• Bolt M4-type
(10 mm) (x 4)
•
Instruction manual
(This manual)
• Screw M3-type
(10 mm) (x 2)
Contents
Introduction ............................................1
IMPORTANT SAFEGUARDS ..................3
System Dimensions ................................6
Attaching the Installation Bracket ..........8
Attaching the Ceiling-mount
Rotating Module ................................10
Attaching the Ceiling Mount to
the Ceiling .......................................... 12
Attaching the Anti-sway Plates ............15
Installing the Projector on the
Ceiling Mount .....................................17
Adjusting the Projection Angle .............18
Installation Examples............................19
Connecting the Cables .........................21
Attaching the Terminal Cover ...............22
Please read this installation adjustment
manual carefully to use the module
properly. Ask your dealer to install it.
• Be sure to keep this manual handy for
future reference.
IMPORTANT
• For your assistance in reporting the loss
or theft of your Ceiling-mount rotating
module, please record the Model and
Serial Number located on the top of the
Ceiling-mount rotating module and retain
this information.
SPECIAL NOTE FOR USERS IN THE U.K.
The mains lead of this product is fi tted with a non-rewireable (moulded) plug incorporating
a 10A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse
marked
of the plug, must be used.
Always refi t the fuse cover after replacing the fuse. Never use the plug without the fuse
cover fi tted.
In the unlikely event of the socket outlet in your home not being compatible with the plug
supplied, cut off the mains plug and fi t an appropriate type.
DANGER:
The fuse from the cut-off plug should be removed and the cut-off plug destroyed immediately and disposed of in a safe manner.
Under no circumstances should the cut-off plug be inserted elsewhere into a 13A socket
outlet, as a serious electric shock may occur.
To fi t an appropriate plug to the mains lead, follow the instructions below:
WARNING:
THIS APPARATUS MUST BE EARTHED.
IMPORTANT:
The wires in this mains lead are coloured in accordance with the following code:
As the colours of the wires in the mains lead of this apparatus may not correspond with
the coloured markings identifying the terminals in your plug proceed as follows:
The wire which is coloured green-and-yellow must be connected to the terminal in the
x
The wire which is coloured blue must be connected to the terminal which is marked
x
The wire which is coloured brown must be connected to the terminal which is marked
x
or and of the same rating as above, which is also indicated on the pin face
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
plug which is marked by the letter E or by the safety earth symbol
or green-and-yellow.
with the letter N or coloured black.
with the letter L or coloured red.
Model No.:
Serial No.:
or coloured green
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED ELECTRICIAN.
Authorized representative responsible for the European Union Community Market
SHARP ELECTRONICS (Europe) GmbH
Sonninstraße 3, D-20097 Hamburg
ii
E.U. ONLY
Before using the product, please read this instruction manual carefully.
Introduction
WARNING:
To reduce the risk of fi re or electric shock, do not
ENGLISH
expose this product to rain or mois ture.
See top of the ceiling-mount rotating module.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
REFER SERVICING TO QUALIFIED SERVICE
DO NOT OPEN.
PERSONNEL.
The lightning fl ash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence
of uninsulated “dangerous voltage”
within the product's enclosure that may
be of suffi cient magnitude to constitute
a risk or electric shock to persons.
The exclamation point within a triangle
is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
WARNING:
This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
WARNING:
FCC Regulations state that any unauthorized changes or modifi cations
to this equipment not expressly approved by the manufacturer could
void the user's authority to operate this equip ment.
U.S.A. ONLY
INFORMATION
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the operation manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at
his own expense.
U.S.A. ONLY
1
For instructions in English, German, French, Spanish, Italian, Dutch, Swedish, Portuguese,
Chinese, Korean and Arabic on how to install this product with your projector, refer to the
operation manuals in the CD-ROM supplied with the projector.
Anleitungen in Englisch, Deutsch, Französisch, Spanisch, Italienisch, Niederländisch,
Schwedisch, Portugiesisch, Chinesisch, Koreanisch und Arabisch, wie man dieses Produkt
bei Ihrem Projektor installiert, fi nden Sie in den Betriebsanleitungen auf der CD-ROM, die mit
dem Projektor geliefert wurde.
Consultez les modes d'emploi dans le CD-ROM fourni avec le projecteur, pour les instructions
de fonctionnement en anglais, allemand, français, espagnol, italien, néerlandais, suédois,
portugais, chinois, coréen et arabe sur la procédure d’installation de ce produit avec votre
projecteur.
Si desea consultar las instrucciones en inglés, alemán, francés, español, italiano, holandés,
sueco, portugués, chino, coreano y árabe sobre cómo instalar este producto con su
proyector, consulte los manuales de manejo en el CD-ROM suministrado con el proyector.
Per le istruzioni in inglese, tedesco, francese, spagnolo, italiano, olandese, svedese,
portoghese, cinese, coreano e arabo su come installare questo prodotto con il proiettore,
fare riferimento ai manuali di istruzioni contenuti nel CD-ROM in dotazione al proiettore.
Raadpleeg voor instructies in het Engels, Duits, Frans, Spaans, Italiaans, Nederlands,
Zweeds, Portugees, Chinees, Koreaans en Arabisch over het installeren van dit product met
uw projector de gebruiksaanwijzingen in de met de projector meegeleverde CD-ROM.
För instruktioner på engelska, tyska, franska, spanska, italienska, holländska, svenska,
portugisiska, kinesiska och arabiska om hur denna produkt installeras med din projektor, se
bruksanvisningen på CD-ROM-skivan som tillhandahålls med projektorn.
Para obter instruções em Inglês, Alemão, Francês, Espanhol, Italiano, Holandês, Sueco,
Português, Chinês, Coreano e Árabe sobre como instalar este produto com o projetor,
consulte os manuais de operação existentes no CD-ROM fornecido com o projetor.
2
IMPORTANT SAFEGUARDS
CAUTION: Please read all of these instructions before you operate this
product and save these instructions for later use.
Electrical energy can perform many useful functions. This product has been engineered
and manufactured to assure your personal safety. BUT IMPROPER USE CAN RESULT IN
POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS. In order not to defeat the
safeguards incorporated in this product, observe the following basic rules for its
installation, use and servicing.
1. Read Instructions
All the safety and operating instructions
should be read before the product is
operated.
2. Retain Instructions
The safety and operating instructions
should be retained for future reference.
3. Heed Warnings
All warnings on the product and in the
operating instructions should be adhered to.
4. Follow Instructions
All operating and use instructions should
be followed.
5. Cleaning
Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
6. Attachments
Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
7. Water and Moisture
Do not use this product near water–for
example, near a bath tub, wash bowl, kitchen
sink, or laundry tub; in a wet basement; or
near a swimming pool; and the like.
8. Accessories
Do not place this product on an unstable
cart, stand, tripod, bracket, or table. The
product may fall, causing serious injury to a
child or adult, and serious damage to the
product. Use only with a cart, stand, tripod,
bracket, or table recommended by the
manufacturer, or sold with the product. Any
mounting of the product should follow the
manufacturer's instructions, and should use a
mounting accessory recom mended by the
manufacturer.
9. Transportation
A product and cart
combination should be
moved with care. Quick
stops, excessive force, and
uneven surfaces may
cause the product and cart
combination to overturn.
10. Ventilation
Slots and openings in the cabinet are provided
for ventilation to ensure reliable operation of
the product and to protect it from overheating,
and these openings must not be blocked or
covered. The open ings should never be
blocked by placing the product on a bed, sofa,
rug, or other similar surface. This prod uct
should not be placed in a built-in installation
such as a book case or rack unless proper
ventilation is provided or the manufacturer's
instruc tions have been adhered to.
11. Power Sources
This product should be operated only from
the type of power source indicated on the
marking label. If you are not sure of the
type of power supply to your home, consult
your product dealer or local power
company. For products intended to operate
from battery power, or other sources, refer
to the operating instructions.
12. Grounding or Polarization
This product is provided with one of the
following types of plugs. If the plug should
fail to fi t into the power outlet, please contact
your electrician.
Do not defeat the safety purpose of the plug.
a. Two-wire type (mains) plug.
b. Three-wire grounding type (mains) plug
with a grounding terminal.
This plug will only fi t into a grounding
type power outlet.
13. Power-Cord Protection
Power-supply cords should be routed so
that they are not likely to be walked on or
pinched by items placed upon or against
them, paying particular attention to cords
at plugs, convenience receptacles, and the
point where they exit from the product.
14. Lightning
For added protection for this product during
a lightning storm, or when it is left
unattended and unused for long periods of
time, unplug it from the wall outlet and
disconnect the cable system. This will
pre vent damage to the product due to
lightning and power-line surges.
3
15. Overloading
Do not overload wall outlets, extension cords,
or integral convenience receptacles as this
can result in a risk of fi re or electric shock.
16. Object and Liquid Entry
Never push objects of any kind into this
product through openings as they may touch
dangerous voltage points or short-out parts
that could result in a fi re or electric shock.
Never spill liquid of any kind on the product.
17. Servicing
Do not attempt to service this product
yourself as opening or removing covers
may expose you to dan ger ous voltage or
other hazards. Refer all servicing to
qualifi ed service personnel.
18. Damage Requiring Service
Unplug this product from the wall outlet
and refer servicing to qualifi ed service
personnel under the following conditions:
a. When the power-supply cord or plug is
damaged.
b. If liquid has been spilled, or objects
have fallen into the product.
c. If the product has been exposed to rain
or water.
d. If the product does not operate normally
by following the operating instructions.
Adjust only those con trols that are
covered by the operating instructions,
as an improper adjustment of other
controls may result in damage and will
often require extensive work by a
qualifi ed technician to restore the
product to normal operation.
e. If the product has been dropped or
damaged in any way.
f. When the product exhibits a distinct
change in performance, this indicates a
need for service.
19. Replacement Parts
When replacement parts are required, be
sure the service technician has used
replace ment parts specifi ed by the
manufacturer or have the same
characteristics as the original part.
Unauthorized substitutions may result in
fi re, electric shock, or other hazards.
20. Safety Check
Upon completion of any service or repairs
to this product, ask the service technician
to per form safety checks to determine that
the product is in proper operating
condition.
21. Wall or Ceiling Mounting
This product should be mounted to a wall
or ceiling only as recommended by the
manufacturer.
22. Heat
This product should be situated away from
heat sources such as radiators, heat
registers, stoves, or other products
(including amplifi ers) that produce heat.
Using the product in other countries
The power supply voltage and the shape of
■
the plug may vary depending on the region
or country you are using the product in.
When using the product overseas, make
sure you use an appropriate power cord for
the country you are in.
4
To Ensure Safe Operation
Make sure that the ceiling where the projector will be installed has suffi cient strength. If it does
■
not, reinforce it as necessary. When installing, use only the installation materials supplied with
the projector (specifi ed above). If the ceilling strength is insuffi cient or if the screw length is too
short, the installation may be insecure and lead to falling and even injury.
Ask your dealer or service shop to install the ceiling mount. Sharp will assume no responsibility
■
whatsoever if inadequate installation causes your projector or attached devices to fall out of place .
■
Do not hang on to the projector and do not hang or place heavy objects on the projector. This may
lead to injury or damage to the projector.
[About this manual]
This manual uses the installation of Sharp Projector XG-SV100W series. For questions
concerning the installation of products other than the XG-SV100W, please contact a
Sharp Authorized Projector Dealer or Service Center.
Notes on installation
Install your projector in a location where it
will not be exposed to too much humidity
or dust.
Avoid installing your projector in an area with
excessive humidity, dust, oily fumes and
cigarette smoke. Doing so will soil the lens,
mirrors and other optical parts, and result in
blurring or dimming of the projected picture.
Do not let direct sunlight or other bright
light hit your projection screen.
If direct or bright external light falls on the
screen, the projected picture will become pale
and diffi cult to see. For rooms with incoming
light, always close the curtains.
Avoid using or storing your projector in
locations of high or low temperature.
Operating temperature range: 5°C to 35°C
Storage temperature range: -20°C to 60°C
5
System Dimensions
The AN-TK201 or AN-TK202 ceiling mount can be installed onto the system.
■
The dimensional drawing is for the installation of the XG-SV100W. For installation dimensions
■
of other Sharp projectors, please contact a Sharp Authorized Projector Dealer or Service
Center.
When installed with the AN-TK202
Top View
33/4 (95)
ø9
/4 (95)
3
3
/64 (190)
31
7
ø10.5
35
3
Front View
ø260
89/32 (210)
10°
10°
763/64 (202.5) 7 63/64 (202.5)
59
5
/64 (150)
1561/64 (405)
731/64 (190)
/64 (90)
8
7
3
/32 (180)
9
/32 (210)
M8 bolt (x4)
/64
(23)
59
Specifi cations
Height
(From lens center*
Adjustment
Range
R4.5
to top surface)
Vertical angle ±10°
Horizontal angle ±10°
Tilt angle ±10°
33
/64 (13)
/64
25
1
10°
10°
Weight
(AN-TK202 + AN-SV100T)
(35)
/8 (92)
/64 (70)
5
49
* When the lens shift is located at the center
3
2
position.
ø10.5
28.4 cm
(Fixed)
12.0 lb s
(5.4 kg)
Side View
ø260
35/8 (92)
/64
25
(35)
1
/16 (84)
5
3
/64
9
(29)
1
/64
/32 (219.8)
41
21
(16.3)
8
/16 (284)
3
11
/64 (119.5)
45
/16 (344.5)
9
4
/32
13
(10.2)
13
/64
9
(54)
2
/64 (114.5)
33
/64
4
25
(60.5)
2
10°
10°
715/16 (201.5)
16 (406.5)
/64
(20)
51
/16 (84)
/32 (64)
5
3
17
2
5
8
/64 (205)
6
When installed with the AN-TK201
Top View
ø9
ø10.5
Front View
ø260
35/8 (92)
10°
10°
763/64 (202.5) 7 63/64 (202.5)
1561/64 (405)
77/8 (200)
1
/16 (230)
9
Specifi cations
Height
(From lens center*
R4.5
Adjustment
Range
to top surface)
Vertical angle ±10°
Horizontal angle ±10°
43
/64
(17)
Weight
Tilt angle ±10°
(AN-TK201 + AN-SV100T)
/8 (200)
/16 (230)
7
1
7
* When the lens shift is located at the center
9
position.
77/8 (200)
ø10.5
Side View
/64 (998 – 1598)
59
/16 (1058.5 – 1658.5)
5
/64 – 62
19
39
/64 – 65
43
41
/64
25
(35)
1
/64
9
/64
(29)
(23)
59
1
/64
41
(16.3)
/64 (119.5)
45
4
/32
13
(10.2)
/64
9
(54)
2
/64 (114.5)
33
/64
4
25
(60.5)
2
10°
10°
715/16 (201.5)
16 (406.5)
99.8 - 159.8 cm
(Adjustable in 3
cm increments)
17.5 lb s
(7.9 kg)
M8 bolt (x4)
/32
1
(51.6)
2
ø38.1
ø260
ø35
5
8
/64 (205)
/32
17
2
/64 (798 – 1398)
3
/64 – 55
27
31
(64)
/16 (814.3 – 1414.3)
11
/16 – 55
/64 (933.8 – 1533.8)
1
25
32
/64 – 60
49
36
7
Attaching the Installation Bracket
Remove the bolts (x4) attached to the ceiling-mount rotating module.
Place the installation bracket on the ceiling-mount rotating module so
that it is aligned with the bracket installation holes on module.
8
Using the bolts (x4) removed from the ceiling-mount rotating module,
attach the installation bracket to the module.
First, lightly screw all four bolts and then tighten them fi rmly.
9
Attaching the Ceiling-mount Rotating Module
Turn over the projector and place it upside down on a fl at surface.
Remove the connector cover.
Place the ceiling-mount rotating module on the bottom of the
projector so that it is aligned with the module installation holes on the
projector. (Make sure the three position-setting pins on the module
are inserted into the position-setting holes on the projector.)
10
Using the supplied bolts, attach the ceiling-mount rotating module to
the projector.
First, lightly screw all four bolts and then tighten them fi rmly.
11
Attaching the Ceiling Mount to the Ceiling
When installed with the AN-TK201
Attach the ceiling mount to the ceiling.
Washer
Mounting bolt (M8-type)
•
First, lightly screw an installation bolt into the smallest hole and then proceed, doing the same
for the holes
Use M8-type bolts. (Bolt type may vary depending on the method of installation.)
•
Use the washers supplied with the ceiling mount.
•
, and . Once the position has been decided, fi rmly tighten all four bolts.
12
Caution
Ask your dealer or service shop to install the ceiling mount. Sharp will assume no responsibility
•
whatsoever if inadequate installation causes your projector or attached devices to fall out of
place.
Attach the height-adjustment pole to the ceiling mount.
Pin hole
Sleeve
1. Insert the height-adjustment pole into the ceiling mount.
2. Fix the pole in place with the sleeve and pole-fi xing bolt
screen.
3. Lock the bolt in place with the securing nut
4. Screw in the two stabilizing screws
5. Tighten the securing nut
fi rmly and fi t the pin into the hole on the pole-fi xing bolt.
.
.
, according to the height of the
13
Attaching the Ceiling Mount to the Ceiling (Continued)
When installed with the AN-TK202
Attach the ceiling mount to the ceiling.
•
First screw a bolt into the hole (smallest hole) and tighten it enough to keep the mount in place.
Then, do the same for the holes
Position the four corners correctly, and then tighten all bolts fi rmly.
•
Use M8-type bolts. (Bolt type may vary depending on the method of installation.)
•
Use the washers supplied with the ceiling mount.
Caution
Ask your dealer or service shop to install the ceiling mount. Sharp will assume no responsibility
•
whatsoever if inadequate installation causes your projector or attached devices to fall out of
place.
, and .
To the dealer or serviceman
For the customer's safety, reinforce the
point of installation so that it is strong
enough to bear the weight of the whole
system before installing it.
Info
•
Only qualifi ed servicemen should install the
projector. Never let the customer install the
system by him/herself.
14
Loading...
