Sharp 903 User Manual

Introduction

Congratulations on your new 3G/UMTS 903SH phone.

About This User Guide

This user guide is carefully designed to help you learn about your phone’s features and operations quickly and effectively.

NOTICE

• We strongly recommend th at you keep separate permanent written records of all important data. Data may be lost or altered in virtually any electronic memory product under certain circumstances. Therefore, we assume no responsibility for data lost or otherwise rendered unusable, whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired or any other cause.

• We assume no responsibility, directly or indirectly, for financial losses or claims from third parties resulting from the use of this product and any of its functions, such as stolen credit card numbers, the loss or alteration of stored data, etc.

• All company and/or product names are trademarks and/or registered trademarks of their respective holders.

• Screen layout may differ from that illustrated in this user guide. The information described in this user guide is subject to change without notice.

• All the functions described in this user guide may not be supported by all networks.

• We assume no responsibility for downloaded contents, information, etc. from the network.

• Occasionally, a few black or bright pixels may appear on the screen. Please note that this will not have any impact on any of the features or on performance.

According to copyright laws, the reproduction, alteration and use of material which is protected by copyright (music, pictures, etc.) is only permitted for personal or private use. If the user is not in possession of more extensive copyright or has not received the explicit permission from th e copyright owner to reproduc e, alter or use a copy which has been made or modified in this way, this is considered to be a violation of the copyright laws and gives the copyright owner the right to claim for damages. For this reason, avoid the illegal use of material which is protected by copyright.

Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries.

Introduction 1

Powered by JBlend™ Copyright 1997-2005 Aplix Corporation. All rights reserved. JBlend and all JBlend-based trademarks and logos are trademarks or registered trademarks of Aplix Corporation in Japan and other countries.

Licensed by Inter Digital Technology Corporation under one or more of the following United States Patents and/or their domestic or foreign counterparts and other patents pending, including U.S. Patents: 4,675,863: 4,779,262: 4,785,450: 4,811,420: 5,228,056: 5,420,896: 5,799,010: 5,166,951: 5,179,571 & 5,345,467

T9 Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Australian Pat. No. 727539; Canadian Pat. No. 1,331,057; United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro. Pat. No. 0 842 463 (96927260.8) DE/DK, FI, FR, IT, NL,PT.ES,SE,GB; Republic of Korea Pat. Nos. KR201211B1 and KR226206B1; and additional patents are pending worldwide.

/Micro3D Edition™

is a registered trademark of HI Corporation

miniSD™ is a trade mark of SD Card Association.

is a registered trademark of RealNetworks, Inc.

Bluetooth is a trademark of the Bluetooth SIG, Inc.

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sharp is under license. Other trademarks and trade names are those of their respective owners.

Contains Macromedia Copyright © 1995-2005 Macromedia, Inc. All rights reserved. Macromedia, Flash, Macromedia Flash, and Macromedia Flash Lite are trademarks or registered trademarks of Macromedia, Inc. in the United States and other countries.

Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations ; 4,901,307 5,490,165 5,056,109 5,504,773 5,101,501 5,506,865 5,109,390 5,511,073 5,228,054 5,535,239 5,267,261 5,544,196 5,267,262 5,568,483 5,337,338 5,600,754 5,414,796 5,657,420 5,416,797 5,659,569 5,710,784 5,778,338

Flash™ technology by Macromedia, Inc.

CP8 PATENT

2Introduction

This product is licensed under the MPEG-4 Visual Patent Portfolio License for the personal and non-commercial use of a consumer to (i) encode video in compliance with the MPEG-4 Video Standard (“MPEG-4 Video”) and/or (ii) decode MPEG-4 Video that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a licensed video provider. No license is granted or implied for any other use. Additional information may be obtained from MPEG LA. See http://www.mpegla.com.

This product is licensed under the MPEG-4 Systems Patent Portfolio License for encoding in compliance with the MPEG-4 Systems Standard, except that an additional license and payment of royalties are necessary for encoding in connection with (i) data stored or replicated in physical media which is paid for on a title by title basis and/or (ii) data which is paid for on a title by title basis and is transmitted to an end user for permanent storage and/or use. Such additional license may be obtained from MPEG LA, LLC. See http://www.mpegla.com for additional details.

MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.

Useful Functions and Services

Your phone offers you the following features:

• Video calls. You can talk while viewing each other on respective screens.

• 3D and colour Java™ games and applications with a graphic accelerator. You can also download various games and applications from Vodafone via the mobile Internet.

• A built-in digital camera for taking pictures and video clips.

• A message function for reading and creating SMS messages.

• MMS (Multimedia Messaging Services) for personalising your phone in various ways.

• Email for sending up to 300 KB and receiving mail with attachments.

• A colour WAP browser for accessing information on the mobile Internet.

• Your own ringtones and ringvideos. You can use downloaded sound or video clip files as a ringtone or ring video clip.

• A music player that can play back MP3, AAC and AAC+ format sound files.

• Playback of the downloaded sound and video clip files.

• A voice recorder function for recording and playing back voice clips.

•A Bluetooth

wireless technology interface for establishing contact and transmitting data with certain devices. You can transmit pictures, sounds, and video clips to OBEX-enabled phones.

• An Infrared interface for data communication. You can transmit pictures, sounds and video clips to OBEX-enabled phones.

• A data synchronisation function for updating Contacts List entries on the Internet.

• A schedule alarm for creating and sending schedule entries with alarm settings.

• Video output. You can connect your phone to other devices, such as TVs or videos set to output, and display Java™ data, images, or video clips.

• With the built-in digital camera, you can read texts and barcodes, and create QR codes.

• A miniSD™ memory card slot that expands connectivity with a PC using the memory card.

Introduction 3

Introduction .......................................................................1

Your Phone ........................................................................7

Getting Started ..................................................................8

Inserting the SIM Card and the Battery .......................11

Removing the SIM Card and the Battery .....................12

Charging the Battery .................................................13

Inserting the Memory Card ........................................14

Removing the Memory Card ......................................14

Connecting the Stereo Handsfree ...............................15

Turning Your Phone On and Off .................................15

Keypad Lock .............................................................15

Display Indicators .....................................................16

Opening Your Phone .................................................17

Navigating Functions ......................................................19

Using in the Normal Position of the Display .................19

Voice Call/Video Call Functions ......................................20

Making a Voice Call ..................................................20

Speed Dialling ..........................................................21

Redialling .................................................................21

Answering a Voice Call ..............................................21

In Call Menu (Voice Call) ............................................22

Making a Video Call ..................................................25

Answering a Video Call ..............................................26

In Call Menu (Video Call) ...........................................26

4 Contents

Entering Characters ....................................................... 29

Changing the Input Language ................................... 30

Changing the Input Mode ......................................... 30

My Dictionary .......................................................... 30

Using Templates ...................................................... 31

Using the Menu .............................................................. 32

Main Menu .............................................................. 32

Shortcut Keys .......................................................... 33

Contacts List ................................................................... 34

Changing the Name Order ........................................ 34

Changing the List Displayed ..................................... 34

Selecting the Storage Memory .................................. 34

Sorting the Contacts List Entries ............................... 35

Add New Contact ..................................................... 35

Viewing My Contact Details ...................................... 35

Copying Contacts List Entries between SIM Card and

Handset .................................................................. 35

Finding a Name ....................................................... 36

Dialling from the Contacts List .................................. 36

Editing Contacts List Entries ..................................... 36

Assigning a Ringtone or a Ring Video Clip to Each

Entry ....................................................................... 37

Deleting Contacts List Entries ................................... 37

Manage Category ..................................................... 37

Contact Groups ........................................................ 38

Memory Status ......................................................... 39

Speed Dial List .........................................................39

Sending a Contacts List Entry ....................................39

Receiving a Contacts List Entry .................................. 39

Sending a Voice Clip Message or Video Clip Message

Using an Address from the Contacts List ....................40

Synchronising Contacts List Entries with those on the

Internet .................................................................... 40

Camera ............................................................................41

Taking Pictures ........................................................ 41

Recording Video Clips ...............................................42

Using the Options Menu in the Viewer Position of the

Display ....................................................................42

Common Functions in the Photo and Video Camera

Modes .....................................................................42

Functions in the Photo Camera Mode ........................ 45

Functions in the Video Camera Mode .........................47

Messaging ....................................................................... 49

SMS ........................................................................49

MMS ....................................................................... 49

Email .......................................................................49

Creating a New Message ..........................................50

Messaging Settings ..................................................55

Vodafone live! ................................................................. 59

Navigating a WAP Page ............................................60

Music ............................................................................... 62

Music Player ............................................................62

My Items ..........................................................................64

Pictures ...................................................................64

Sounds & Ringtones .................................................65

Videos .....................................................................66

Other Documents .....................................................66

Common Option Menus ............................................67

Games & Applications ...............................................70

Text Templates .........................................................70

Memory Status .........................................................70

Entertainment .................................................................71

Games & Applications ...............................................71

Settings ...................................................................73

TV & Video ...............................................................75

Organiser & Tools ...........................................................79

Calendar ..................................................................79

Alarms .....................................................................82

Calculator ................................................................83

Voice Recorder .........................................................84

Scanner ...................................................................85

E-Book ....................................................................86

Stopwatch ................................................................87

Tasks ......................................................................87

World Clock .............................................................89

Countdown Timer .....................................................89

Expenses Memo .......................................................89

Phone Help ..............................................................90

Contents 5

SIM Application ...............................................................91

Settings ...........................................................................92

Profiles ....................................................................92

Setting the Display ....................................................96

Sound Settings .........................................................99

Date & Time .............................................................99

Language Setting ....................................................100

Call Settings ...........................................................101

Video Call Settings ..................................................105

Security .................................................................106

Master Reset ..........................................................107

Call Log ..........................................................................108

Call Timers .............................................................108

Data Counter ..........................................................108

Call Costs ...............................................................109

Connectivity ...................................................................110

Bluetooth ...............................................................110

Infrared ..................................................................112

Network Settings ....................................................113

Flight Mode ............................................................114

Internet Settings .....................................................114

Memory Card .........................................................115

Connecting 903SH to Your PC .......................................117

System Requirements .............................................117

3G/GSM Modem .....................................................117

Handset Manager ...................................................118

Software Installation ................................................118

Note ......................................................................118

Troubleshooting ........................................................... 119

Safety Precautions and Conditions of Use .................. 121

CONDITIONS OF USE .............................................. 121

ENVIRONMENT ...................................................... 123

PRECAUTIONS CONCERNING VEHICLE USE ............. 124

SAR ...................................................................... 124

PRECAUTIONS FOR USE IN USA .............................. 125

Specifications and Optional Accessories .................... 126

Specifications ........................................................ 126

Optional Accessories .............................................. 126

Index ............................................................................. 127

List of Menu Functions ................................................. 129

6 Contents

Your Phone

Please check the following carefully. Your phone should come complete with:

• 3G (UMTS)/GSM 900/1800/1900/GPRS phone

• Lithium-Ion Battery

• Battery Cover

• AC Charger

•Stereo Handsfree

•User Guide

• Quick Start Guide

• CD-ROM

• miniSD™ Memory Card

• Video Cable

Your Phone 7

Getting Started

5 6 7

8 Getting Started

14 15

16 17

24 25 26

27 28 29

1. Earpiece

2. Navigation Keys (Arrow Keys):

a b c d Moves cursor to highlight a menu

item, etc.

Up/Down arrow keys: Displays Contacts List entries in

standby.

Left arrow key: Displays the message inbox in

standby.

Right arrow key: Displays the monthly or weekly

calendar in standby.

3. Centre Key: Displays Main menu in standby, and executes functions.

4. Left Soft Key:

5. Send/Redial Key:

6. Shortcut Key:

7. Voicemail Key:

8. * /Shift Key:

Executes the function in the lower left of the screen. Displays Messaging menu in standby.

Makes or accepts calls, displays the call logs in standby.

Opens the shortcut menu to access the desired applications.

Press and hold to connect to the Voicemail centre (depending on the SIM card).

Switches character case between four modes: Abc, ABC, 123 and abc on the text entry screen. Press in standby to enter P, ?, – or *. Press and hold in standby to lock the keypad.

9. Sub Camera (Internal Camera)

10. Main Display

11. Microphone (for the viewer position of the display)

12. Right Soft Key:

Executes the function in the lower right of the screen. Accesses “Vodafo ne live!” by opening the browser in standby.

13. End/Power Key:

Ends a call and turns power on/off.

14. Clear/Back Key:

15. Music Key:

Clears the characters to the left of the cursor, returns to the previous screen, etc.

Displays Music menu in standby.

16. Keypad

17. #/Silent Key:

Displays symbol screen on the text entry screen. Press and hold to switch languages on the text entry screen. Turns the flash /auxiliary light on or off in camera mode. Press and hold in standby to switch Profiles settings between the mode most recently activated and Silent mode.

Getting Started 9

18. Microphone

19. Camera (External Camera)

20. Battery Cover

21. Built-in Aerial: Warning: Do not cover the top of the

phone with your hand when in use as this may interfere with the performance of the built-in aerial.

22. Mobile Light: Used as a flash or an auxiliary light in camera mode.

23. Infrared Port: Sends and receives data via infrared.

24. Stereo Speakers

25. Small Light: Used for the battery charge indicator,

Event Light and Status Light.

26. Side Keys (V/W): (These two keys work in reverse with the viewer position of the display.) Moves the highlight up or down. Press in standby or during a call to increase or decrease the earpiece volume.

27. Menu Key:

Executes the function in the lower left of the screen in the viewer position of the display.

28. Camera Key:

Displays the Main menu when pressed in standby, then executes a highlighted function in the viewer position of the display. Press and hold to activate the camera. Press during an incoming call alert to answer the call in the viewer position of the display.

29. Cancel Key:

Executes the function in the lower right of the screen in the viewer position of the display. Press and hold in standby to turn the mobile light on. You can change the light colours by pressing V or W when the mobile light is on. Press and hold to reject an incoming call. Press during an incoming call alert to send a busy tone to the caller in the viewer position of the display. Press to end the call in the viewer position of the display.

30. Memory Card Slot Cover

31. VIDEO OUT/Stereo Handsfree Connector External Connector

32.

: Used to connect either the charger or

a USB data cable.

10 Getting Started

Inserting the SIM Card and the Battery

1. Slide off the battery cover ( ).

3. Hold the battery so that the metal contacts of the battery are

facing down, slide the guides on the top of the battery into the battery slot ( ), and then insert it ( ).

2. Slide the SIM card into the SIM holder.

SIM card

4. Replace the battery cover.

Note

• Make sure that only 3V SIM cards are used.

• Make sure that the standard accessory battery (XN-1BT70) is

used.

Getting Started 11

Removing the SIM Card and the Battery

1. Ensure that the phone is turned off and that the charger and

other accessories are disconnected. Slide off the battery cover.

2. Lift the battery using the protruding edge and remove the

battery from the phone.

3. Hold down gently while sliding the SIM card out of the SIM

holder ( ).

Battery Disposal

The device is battery-powered. In order to protect the environment, please read the following points concerning battery disposal:

• Take the used batter y to your local waste depot, dealer o r customer

service centre for recycling.

• Do not expose the used battery to a naked flame, immerse in water

or dispose with the household waste.

12 Getting Started

Charging the Battery

You must charge the battery for at least 140 minutes before using your phone for the first time.

Using the Charger

1. Open the cover of the external connector, connect the charger

to the external socket located at the bottom of the phone by pressing both sides indicated with arrows, and connect to an AC outlet.

Small light

The small light turns on. Standard charging time: Approx. 140 minutes Charging temperature: 5°C - 35°C

Note

• Charging time may vary depending on the state of the battery and

other conditions. (See “Battery” on page 121.)

To Disconnect the Charger

When charging is complete, the small light turns off.

1. Unplug the charger from the AC outlet, then unplug the

charger connector from the phone.

2. Close the cover.

Note

• Do not use any non-approved chargers as they may damage your

phone and invalidate any warranties, see “Battery” on page 121 for details.

To Charge Using the Cigarette Lighter Charger

The optional cigarette lighter charger supplies power for charging from the cigarette lighter socket of a car.

Battery Level Indicator

The current battery level is displayed in the upper right of the main display.

Getting Started 13

Low Battery during Use

When the battery is running low, an alarm will sound and “ ” is displayed on the main display.

If you are using your phone and you hear the low battery alarm, attach your charger as soon as possible. The phone may not be able to continue normal operation if you continue to use it.

Battery Indicators Charge Level

Sufficiently charged Charging recommended Charging required Empty

Inserting the Memory Card

1. Turn off the phone.

2. Open the memory card slot cover and insert the card with the

label side facing up.

3. Insert the memory card all the way in until it clicks.

4. Close the cover.

Note

• Make sure that the phone is turned off before inserting the memory

card.

• Be sure to insert the card in the correct direction and orientation.

• Do not open the memory card cover while the memory card is

being formatted or written to. The card may be damaged beyond use.

• Keep all memory cards out of the reach of small children.

Tip

• You see the following indicators when the memory card is in use:

: Appears when the card is inserted. : Appears when the card is damaged or unusable. : Appears when the card is being written or read. : Appears when the card is being formatted.

Removing the Memory Card

1. Open the memory card slot cover and slightly push the card so

it pops out. Remove the card and close the cover.

Note

• Make sure that the phone is turned off before removing the

memory card.

• Do not remove the memory card while the memory card is being

formatted or written to.

14 Getting Started

Connecting the Stereo Handsfree

1. Open the cover of the Stereo Handsfree Connector.

2. Connect the Stereo Handsfree.

Turning Your Phone On and Off

To turn the power on or off, press and hold F for approximately 2 seconds.

To Enter the PIN Code

If activated you are asked to enter a PIN (Personal Identification Number) code and handset lock code after turning on your phone.

1. Enter your PIN code.

The PIN code is 4 to 8 digits.

2. Press .

Note

• If your PIN code is entered incorrectly three times in a row, the SIM

card is locked. See “Enabling/Disabling the PIN Code” on page 106.

• If the clock settings have not been entered, the date and time entry

screen is displayed (p. 99).

To Copy All Contacts List Entries from the SIM Card

When you insert the SIM card into your phone for the first time and start the Contacts List application, you are asked whether you wish to copy Contacts List entries on the SIM card. Follow the on-screen instructions, or you can do it later using the Contacts List menu as follows:

→

“Contacts”

“Manage Contacts” → “Copy All Entries”

1. Select “From SIM to Handset”.

Keypad Lock

You can lock the keypad to prevent it from being pressed accidentally.

Locking the Keypad

1. Press and hold P in standby.

To unlock, press and hold P.

Tip

• Emergency numbers (112, etc.) can be entered and dialled

regardless of the keypad lock.

Getting Started 15

Display Indicators

Indicator area

Left soft key

1. / : Strength of received signal/Service out of range

Centre key

: 3G (UMTS)/GPRS : GSM/GPRS

: Roaming outside network

Right soft key

2. : Flight mode

3. : Data exchange with external device

4. / : Connection to the server [established/

communicating]

5. / : Voice call [incoming/in progress]

6. / / : Video call communication mode enabled [voice and

video/voice/video]

7. / : Alerts [text message and multimedia message/

Email]

8. : “Voice Calls” diverts set to “Always”

9. / / : WAP/OTA provisioning alerts [WAP alert/OTA

provisioning alert/WAP and OTA provisioning alerts]

10. : Memory card inserted

11. ////:

Connection status [USB cable/Infrared exchanging information/ Bluetooth wireless setting [enabled (in standby or except in standby)/exchanging information/talking with the Bluetooth headset]]

12. / : Java™ application [executed (colour)/suspended

(grey)]

16 Getting Started

13. : Secure WAP page displayed

14. ////: Silent/vibration setting [silent/increasing volume/ vibration enabled/silent and vibration enabled/ increasing volume and vibration enabled]

15. / / : Speaker mode [speaker phone/speaker activated/ microphone muted]

16.(No display)/////: Current profile [Normal/Meeting/Activity/Car/ Headset/Silent]

17. : Battery level

18. : Mobile light enabled

19. : Daily alarm enabled

20. / : Schedule entry enabled [with/without reminder alarm]

21. : Outbox contains unsent messages [text message/ multimedia/Email]

22. : Voicemail message alert

23. : Function Lock enabled

24. : Keypad Lock enabled

25. /(blank): Infrared setting [enabled/disabled]

26. : Secret mode set to “On”

Opening Your Phone

Your phone can be opened in the following three positions: normal, self-portrait and viewer positions.

Normal Position ( )

1. Open the phone until the display stops as illustrated.

Getting Started 17

Self-portrait Position ( )

2. Turn the display 180° clockwise.

Use this position to take a self-portrait with the external camera. Do not turn the display anticlockwise as this may damage it.

Viewer Position ( )

3. Close the main display toward the keypad.

Note

• Operations of V and W are reversed in the viewer position of the

display.

• Keypad operations cannot be performed in the viewer position of

the display.

• Be careful not to carry the phone in the viewer position of the

display as this may damage the display.

18 Getting Started

Navigating Functions

Using in the Normal Position of the Display

All applications are accessed from the Main menu. To open the Main menu, press the centre key ( ) in standby.

To launch applications, you will need to highlight menu items, and make selections. To select a menu item (indicated in quotation marks), move the cursor using a, b, c and d, and press to select.

In certain procedures, you will need to press one of the soft keys (indicated in square brackets), which are displayed in the lower left and right of the screen. Press the corresponding soft key (A or C).

To return to the previous screen, press the right soft key if it displays

Back. To close the Main menu, press the right soft key if it displays Exit.

Each section in this user guide starts with a list of items you will need to select in order (indicated in italics) before performing the procedures shown. Select each item to reveal the next set of items that you have to choose from. Open subsection items after opening those listed in the main section.

Example:

→

“Contacts”

“Contacts List” → “Add New Contact”

Using in the Viewer Position of the Display

Available keys in viewer position of the display are V, W, X, Y and Z.

To open the Main menu, press Y in standby. To select a menu item (indicated in quotation marks), press V or W,

and press Y to select. In certain procedures, you will need to press one of the soft keys

(indicated in square brackets), which are displayed in the lower left and right of the screen. The left soft key is X and the right soft key is Z.

The side keys function in camera mode as follows:

: Zoom-in/Zoom-out

V/W X: Options Y: Capture Z: Switches between the photo camera and video camera

modes.

Navigating Functions 19

Voice Call/Video Call Functions

Making a Voice Call

1. Enter the area code and the phone number you wish to dial

and press D to dial.

If you enter the wrong number, press U to delete the number to the left of the cursor.

Emergency Calls

1. Enter 112 (international emergency number) using the keypad

and press D to dial.

Note

• Emergency calls may not be able to be made on all mobile phone

networks when cer tain network services and/or phone features are in use. Contact your service provider for more information.

• This emergency number can normally be used to make an

emergency call in any country, with or without a SIM card inserted, if a 3G (UMTS)/GSM network is within range.

International Calls

1. Press and hold Q until a + (international dialling prefix)

sign is displayed.

2. Enter the country code, followed by the area code (without the

leading zero) and the phone number, and press D to dial.

Adding an Entered Phone Number to the Contacts List

1. After entering a phone number, press [Options] and select

“Save Number”.

For details on creating a new entry, see “Add New Contact” on page 35.

Showing or Hiding My Phone Number on the Display of the Called Party

1. After entering a phone number, press [Options] and select

“Show My ID” or “Hide My ID”.

Making a Call Using the Contacts List in the Viewer Position of the Display

1. Press Y.

2. Select “Contacts”.

3. Select “Contacts List”.

4. Select the entry you wish to call.

5. Select the phone number.

6. Select “Call” to dial.

To end a call, press Z.

20 Voice Call/Video Call Functions

Speed Dialling

Up to 8 phone numbers from the Contacts List memory (Handset and SIM) can be assigned to speed dials. You can call the numbers using the digit keys (G to O). The phone number of the Voicemail centre is assigned to G.

For details on setting the speed dial list, see “Speed Dial List” on page 39.

1. To dial a number using the speed dial, press and hold any of

the digit keys (G to O).

The phone number saved in the speed dial list is dialled.

Redialling

You can redial numbers in the call log. Select from specific categories or “All Calls”. Specific categories contain up to 30 numbers and the “All Calls” list contains up to 90.

1. Press D in standby.

2. Select the category from “All Calls”, “Dialled Numbers”,

“Missed Calls” or “Received Calls”.

To switch logs, press c or d.

3. Highlight the phone number you wish to call.

4. Press D to redial the call.

Answering a Voice Call

When an incoming call is detected, the phone rings.

1. Press D, or press [Options] and select “Answer” to

answer the call.

Or press any key except F, U and [Busy] when the “Any Key Answer” function is enabled. Set the Any Key Answer function in the profile of each mode (p. 96).

Tip

• If you have subscribed to the Calling Line Identification (CLI) service

and the caller’s network sends the number, the caller’s number is displayed on the screen. If the caller’s name and number are saved in the Contacts List, the caller’s name and phone number are displayed on the screen.

• If the number is a restricted number, the display shows “Withheld”.

• When you receive a call from the person whose picture is

registered in the Contacts List, the picture, name and phone number are displayed.

Voice Call/Video Call Functions 21

Answering a Call in the Viewer Position of the Display

1. Press X or Y to answer the call.

To end a call, press Z. To reject the incoming call, press and hold Z.

Rejecting an Incoming Call

1. Press F while the phone is ringing to reject a call you do not

wish to answer.

Letting the Caller Know You are Unavailable

1. Press [Busy] while the phone is ringing to send a busy tone to

the caller.

In Call Menu (Voice Call)

Your phone has additional functions available while a call is in progress.

Adjusting the Earpiece Volume

You can adjust the earpiece volume (and handsfree volume, if connected) from five levels.

1. Press V or W to display the Earpiece Volume screen.

2. Press V (or a/d) to increase the volume of the call or press

W (or b/c) to decrease the volume.

3. Press when the volume is set to the desired level.

Tip

• In the viewer position of the display, press X or Y to display

the in call menu.

• In the viewer position of the display, use V or W to increase or

decrease the earpiece volume. Operations of these keys are reversed in the viewer position.

Turning the Speakers On and Off

You can talk via the loudspeakers on the sides of the phone when it is on.

1. During a call, press [Options] and select “Loudspeaker On”.

Putting a Call on Hold

This function allows you to manage two calls at the same time. If you wish to make another call while you are talking to someone, you can put the current call on hold to call someone else.

22 Voice Call/Video Call Functions

To Make Another Call during a Call

1. During a call, press [Options] and select “Hold”.

The current call is put on hold.

2. Press [Options] and select “Dial New Number”.

3. Enter the phone number you wish to make another call to, then

press D.

Tip

• You can also make another call by entering the phone number

during a call instead of step 1. The current call is automatically put on hold.

Accessing SMS/MMS Menu during a Call

1. During a call, press [Options] and select “Messaging”.

The following options are available: “Create Message” to make an SMS and MMS, or “Inbox”, “Sent” or “Drafts” to access these folders. For details on SMS, see “SMS” and “MMS” on page 49.

Call Waiting

This service notifies you of another incoming call while you have a call in progress.

1. During a call, press [Options] and select “Hold & Answer” to

answer the second call.

The first call is put on hold and you can now talk to the second caller.

Note

• You need to set “Call Waiting” to “On” if you wish to use the Call

Waiting service (p. 102).

• Call Waiting service may not be available on all networks. Contact

your service provider for more information.

• If you do not wish to answer the second call, press [Options] and

select “Busy” in step 1. If “Reject” is selected, the log of the second call is saved as a missed call.

Conference Call

Conference call is a call with more than 2 participants. You may include up to 5 participants in a conference call.

To Make a Conference Call

You must have one active call and one held call.

1. During a call, press [Options] and select “Multi Party”.

2. Select “Conference All” to join the conference call.

3. Press F to end the conference call.

Voice Call/Video Call Functions 23

Note

• The conference call service may not be available on all networks.

Contact your service provider for more information.

• You have more options for the Conference call in step 2:

• To put all participants on hold, select “Hold All”.

• To put all participants except the current call on hold, select

“Private”.

• To end the call with all participants, select “End Active Call(s)”

or “End Held Call(s)”.

• To reject adding more participants to the current party, press

[Options] and select “Reject”, or you can send the busy tone by selecting “Busy”.

To Add New Participants to the Conference Call

1. Press [Options] and select “Dial New Number”.

2. Enter the number you wish to include in the conference call

and press D to dial.

3. Press [Options] and select “Multi Party”.

4. Select “Conference All” to join the conference call.

If you wish to add other participants, repeat steps 1 to 4.

To End the Call with a Conference Call Participant

1. During a conference call, highlight the person that you wish to

disconnect from the conference call.

2. Press [Options] and select “End This Call”.

To Have a Private Conversation with One of the Participants

If you wish to have a private conversation with one of the participants, you may select the participant from the conference list and put the other participants on hold.

1. During a conference call, select the person that you wish to

talk to.

2. Press [Options] and select “Multi Party”.

3. Select “Private”.

4. Once you have finished the private conversation, press

[Options] and select “Multi Party”.

5. Select “Conference All” to return to the conference call.

Muting the Microphone

1. During a call, press [Mute].

To use the microphone again, press [Unmute].

24 Voice Call/Video Call Functions

Making a Video Call

Note

• Use this function with only the video call enabled phones.

• Make sure that the battery is fully charged and the signal is strong

before using this function.

• Turn the loudspeakers on or use a switch-equipped Stereo

Handsfree or handsfree kit so that you can talk while looking at the video call screen on the main display.

Making a Video Call

1. Enter the area code and the phone number you wish to dial.

2. Press [Options] and select “Video Call” or press and hold D

to dial.

If you enter the wrong number, press U to delete the number to the left of the cursor. When the line is connected, the image of the called party is displayed upper on the screen, and yours lower left.

Tip

• If the called party’s phone is not video call enabled, you can press

F and enter the phone number again to make a voice call.

• When the call ends, the last call cost is displayed.

Status Indicators

1. Sub screen for your image

2. Elapsed time

3. Main screen for the calling party’s screen

4. Calling party’s name or phone number

Voice Call/Video Call Functions 25

Answering a Video Call

When an incoming call is detected, the phone rings.

1. Press D to answer the call with video or press [Options] and

select “Hide Picture” to answer with voice only.

Tip

• When the call ends, the call cost is displayed.

• If you have subscrib ed to the Calling Line Identification (CLI) service

and the caller’s network sends the number, the caller’s number is displayed on the screen. If the caller’s name and number are saved in the Contacts List, the caller’s name is displayed on the screen.

Rejecting an Incoming Call

1. Press F while the phone is ringing to reject a call you do not

wish to answer.

Letting the Caller Know You are Unavailable

1. Press [Busy] while the phone is ringing to send a busy tone to

the caller of an incoming call letting them know that you cannot answer the call.

In Call Menu (Video Call)

Muting the Microphone

1. During a video call, press [Mute].

To use the microphone again, press [Unmute].

Swapping Images

You can swap images between the main and sub screens.

1. During a video call, press [Options] and select “Switch

Images”.

Tip

• You can also swap images between the main and sub screens by

pressing during a video call.

Changing the Image of Yourself

1. During a video call, press [Options] and select “Camera

Picture”.

2. Select “Internal Camera”, “External Camera” or “Alternative

Image”.

“Internal Camera”: The image through the sub camera is

displayed and sent to the caller.

“External Camera”: The image through the camera is

displayed and sent to the caller.

“Alternative Image”: The camera is turned off and the

image selected in “Alternative Image” of “Video Call Settings” is used.

Tip

• You can also switch the image shown to the caller by pressing c or d during a video call.

26 Voice Call/Video Call Functions

Using the Optical Zoom Function

The optical zoom enables you to zoom the picture more clearly by the actual zooming action of the optical lens. The optical zoom is used up to the [×2] zooming ratio. If the zoom exceeds [×2], the digital zoom is used to further magnify.

1. During a video call, press [Options] and select “Enable Opt.

Zoom”.

2. Press a or b.

Turning the Speakers On and Off

You can talk via the loudspeakers on the sides of the phone when it is on.

1. During a video call, press [Options] and select “Loudspeaker

On”.

Note

• In a high-noise environment, you may not be able to continue a

call, or make a clear call. We recommend that you use the Stereo Handsfree.

• With this option, there may be interruption if you increase the

earpiece volume. We recommend that you decrease the earpiece volume or use the Stereo Handsfree.

Video Call Settings

To Adjust the Quality of the Incoming or Outgoing Image

You can adjust the quality of the called party’s or caller’s image.

1. During a video call, press [Options] and select “Video Call

Settings”.

2. Select “Incoming Picture Quality” or “Outgoing Picture

Quality”.

3. Select “Normal”, “Quality Priority” or “Frame Rate Priority”.

“Normal”: The standard quality is used. “Quality Priority”: The quality of the picture takes

precedence over the frame rate.

“Frame Rate Priority”: The frame rate takes precedence over

the quality.

Voice Call/Video Call Functions 27

To Turn the Backlight On or Off

You can turn on the backlight of your screen.

1. During a video call, press [Options] and select “Video Call

Settings”.

2. Select “Backlight”.

3. Select “Always On”, “Always Off” or “As Normal Setting”.

When “Always On” is selected, the backlight will always be on during a video call. When “As Normal Setting” is selected, the backlight will time out depending on the Backlight setting (p. 98).

To Adjust the Video Exposure

1. During a video call, press [Options] and select “Video Call

Settings”.

2. Select “Exposure”.

3. Press a or b.

Mirror Image

During a video call, you can reverse your image on the sub screen.

1. During a video call, press [Options] and select “Video Call

Settings”.

2. Select “Mirror Image”.

3. Select “On” or “Off”.

To Change the Sub Camera Image to the Alternative Image

During a video call, you can switch the image shown to the caller between the sub camera image and an alternative image or display an image while putting a call on hold from the saved picture files.

1. During a video call, press [Options] and select “Video Call

Settings”.

2. Select “Alternative Image” or “Hold Guidance Picture”.

3. Select “Preset Picture” or “My Pictures”.

28 Voice Call/Video Call Functions

Entering Characters

When entering characters to create Contacts List entries, text messages or multimedia messages, etc., press the corresponding keys.

In multi-tap input method, press each key until the desired character is displayed. For example, press H once for the letter A or twice for the letter B.

Table of Characters

Pressing each key scrolls characters in the following o rder. The order varies depending on the language selected.

English Mode

Key

G H

I J K L M N

Upper Case

Characters

. (full-stop) , (comma) - (hyphen) ? ! ’ (apostrophe) @ :1

ABC2 abc2 2

DEF3 def3 3

GHI4 ghi4 4

JKL5 jkl5 5

MNO6 mno6 6

PQRS7 pqrs7 7

TUV8 tuv8 8

Lower Case

Characters

Numeric

Key

O Q

WXYZ9 wxyz9 9

(space) + = < > € £ $ ¥ % & 0 0

Switches character case between four modes: Abc, ABC, 123 and abc.

.,?!:;-+#∗ @' " ( )_&€£$ %/ ˜ <>§=\ | ¥

¿¡^[ ]{ }¤ÅÄ

Æ еджаЗЙийм

СсЦШцштЯЬь

ù ∆ΦΓΛΩΠΨΣΘ

Ξ (space) ↵

G-O

Upper Case

Characters

Press and hold to enter numbers 1 - 9 and 0.

Lower Case

Characters

: Press and hold t o shift between multi-tap and T9

: Press and hold to display the Input Language

mode.

screen.

Numeric

Entering Characters 29

Changing the Input Language

1. On the text entry screen, press [Options] and select “Input

Language”.

2. Select the desired language.

Symbols and Punctuation

1. On the text entry screen, press [Options] and select “Add

Symbol”.

2. Select the desired symbol.

Changing the Input Mode

T9 Text Input

T9 text input method is a shortcut to enter text easily and quickly.

1. On the text entry screen, press and hold P to enter T9

mode.

2. Press [Options] and select “Input Mode”.

3. Select the input mode (Abc, ABC, 123, abc).

4. Press each key once for any letter you require on that key.

To enter the word “How”, press J L O.

5. If the word shown isn’t the one you want, press a or b until

you highlight the correct one.

6. Press to select the word.

Note

• If the correct word is not shown in step 5, enter the correct word

again after switching to the multi-tap input method.

Tip

• If you press Q instead of step 6, a space is inserted next to the

selected word.

30 Entering Characters

My Dictionary

You can create your own word list for T9 text input.

1. On the text entry screen in T9 mode, press [Options] and select

“My Dictionary”.

2. Select “Add New Word” and enter a new word.

Editing a Word in the List

1. On the text entry screen in T9 mode, press [Options] and select

“My Dictionary”.

2. Highlight the desired word.

3. Press [Options] and select “Edit”.

4. Modify the word.

+ 100 hidden pages
