Sharp 14D1-S, 14D1-G, 14D1-W, 14D2-S, 14D2-G Service Manual

SERVICE MANUAL

14D1-S/G/W 14D2-S/G

SERVICE MANUAL

SX2T914D-1S//

COLOUR TELEVISION

Chassis No. GA-1AM

14D1-S/G/W

COLOUR TELEVISION

In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.

Ë

Multi 18 systems

Ë

Full Auto Channel Preset and Auto Channel Skip

Ë

100-CH Program Memory

Ë

CATV(Hyper Band) Ready <Used Frequency Synthesizer Tuner>

Ë

AVL(Sound Keeper) Function

Ë

Black Stretch Circuit

Ë

On Timer/Sleep T imer/Reminder Timer

Ë

Blue Back Noise Mute

MODELS 14D1-S/G/W, 14D2-S/G

» SPECIFICATIONS .............................................2

» IMPORTANT SERVICE NOTES ........................2

» ADJUSTMENT PRECAUTIONS........................3

» MEMORY MAP ................................................ 11

» GA1 HOTEL MODE APPLICATION ................15

» TROUBLE SHOOTING TABLE ........................15

» WAVEFORMS..................................................18

» SOLID STATE DEVICE BASE DIAGRAM .......20

» CHASSIS LA YOUT ..........................................21

» BLOCK DIAGRAM ........................................... 23

» DESCRIPTION OF SCHEMATIC DIAGRAM .. 28 » SCHEMA TIC DIAGRAM

Ë

CRT UNIT.....................................................29

MODELS

FEATURES

Ë Ë

Ë Ë Ë Ë

Ë

CONTENTS

Page

» PRINTED WIRING BOARD ASSEMBLIES.....34

» REPLACEMENT PARTS LIST

» PACKING OF THE SET...................................45

14D2-S/G

Front Headphone Terminal Front AV-In & Rear AV-In/Out Terminals (Front Priority) Colour Comb Filter(NTSC only) High Contrast Picture Hotel Mode Arabic/Chinese/English/French/Malay/Russian 6 Languages OSD White Temperature Adjustment

Ë

HEAD PHONE UNIT ....................................29

Ë

MAIN UNIT ................................................... 30

Ë

ELECTRICAL PARTS

MAIN UNIT ................................................... 39

CRT UNIT.....................................................42

HEAD PHONE UNIT ....................................43

Ë

SUPPLIED ACCESSORIES.........................43

Ë

PACKING PA RTS.........................................43

Ë

CABINET PARTS .........................................44

Page

The chassis in this receiver is partially hot. Use an isolation transformer between the line cord plug and power receptacle, when servicing this chassis. To prevent electric shock, do not remove cover. No user – serviceable parts inside. Refer servicing to qualified service personnel.

SHARP CORPORATION

WARNING

1

14D1-S/G/W

SPECIFICATIONS

Convergence .................................................................Self Convergence System

Focus...................................................................... Quadra-Potential Electrostatic

Sweep Deflection......................................................................................Magnetic

Intermediate Frequencies

Picture IF Carrier .................................................................................. 38.9MHz

Sound IF Carrier Frequency

6.5MHz .............................................................................................. 32.4MHz

6.0MHz .............................................................................................. 32.9MHz

5.5MHz .............................................................................................. 33.4MHz

Colour Sub-Carrier Frequency............................................................34.47MHz

Power Input ..................................................................... 110 ~ 240V AC 50/60 Hz

Power Consumption

14D1-S/G/W ................................................................................................ 58W

14D2-S/G.....................................................................................................62W

Audio Power Output Rating

14D1-S/G/W .................................................................................3.0W(at Max.)

14D2-S/G......................................................................................5.0W(at Max.)

Speaker

Size

14D1-S/G/W .................................................................. 5 x 9 cm Elliptic (1pc)

14D2-S/G.................................................................... 5 x 9 cm Elliptic (2 pcs)

Voice Coil Impedance........................................................... 16 ohms at 400 Hz

Aerial Input Impedance

VHF/UHF .......................................................................... 75 ohms Unbalanced

Receiving System.................................................... CCIR SECAM/PAL B, G,D,K,I

Tuner Ranges

VHF-Channels ..........................................E2(48.25MHz) thru E12(224.25MHz)

C1(49.75MHz) thru C12(216.25 MHz)

S1(105.25MHz) thru S36(423.25HMz)

UHF-Channels......................................E21(471.25MHz) thru E69(855.25MHz)

C13(471.25MHz) thru C57(863.25MHz)

S37(431.25MHz) thru S41(463.25MHz)

Dimensions

14D1-S/G/W ............................................................................. Width: 357.0mm

Height: 364.0mm

Depth: 370.5mm

Weight(approx): 9.5 kg

14D2-S/G.................................................................................. Width: 446.0mm

Height: 333.0mm

Depth: 362.0mm

Weight(approx): 9.2 kg

Cabinet material .................................................................................... All Plastics

Specifications are subject to change without prior notice.

IMPORTANT SERVICE NOTES

Maintenance and repairing of this receiver should be done by quali-

fied service personnel only .

SERVICE OF HIGH VOLTAGE SYSTEM AND PIC-

TURE TUBE

When servicing the high voltage system, remove static charge from it by

Connecting a 10K ohm Resistor in series with an insulated wire(such as a

test probe) between picture tube dag and 2nd anode lead. (AC line cord

should be disconnected from AC outlet.)

1. Picture tube in this receiver employs integral implosion protection.

2. Replace with tube of the same type number for continued safety.

3. Do not lift picture tube by the neck.

4. Handle the picture tube only when wearing shatterproof goggles and after discharging

the high voltage completely.

X-RAY

This receiver is designed so that any X-Ray radiation is kept to an absolute

Minimum. Since certain malfunctions or servicing may produce potentially

hazardous radiation with prolonged exposure at close range, the following

precautions should be observed:

1. When repairing the circuit, be sure not to increase the high voltage to more than 23.7kV(at

beam 0

µ

A) for the set.

2. To keep the set in a normal opeartion , be sure to make it function on 22.5kV

±

1.5kV(at

beam 800

µ

A) in the case of the set. The set has been factory - Adjusted to the above-

mentioned high voltage.

*If there is a possibility that the high voltage fluctuates as a result of the repairing,

never forget to check for such high voltage after the work.

3. Do not substitute a picture tube with unauthorizerd types and/or brands which may

cause excess X-ray radiation.

BEFORE RETURNING THE RECEIVER

Before returning the receiver to the user, perform the following safety Checks.

1. Inspect all lead dress to make certain that leads are not pinched or that hardware is not

lodged between the chassis and other metal parts in the receiver.

2. Inspect all protective devices such as non-metallic control knobs, insulating fishpapers,

cabinet backs, adjustment and compartment covers or shields, isolation resistor- ca-

pacity networks, mechanical insulators etc.

14D2-S/G

2-1 2-2

2

14D1-S/G/W

ADJUSTMENT PRECAUTIONS

This model's setting are adjusted in two different ways: through the I

2

C bus control and in the conventional

analog manner. The adjustments via the I

2

C bus control include preset-only items and variable data.

CAUTION: Make sure TV Set is in "Normal Condition" before switch to Service Mode for adjustment.

1. Setting the service mode by the microprocessor.

1. Short JA 137 & JA 138 for 1 second and release to switch to the service mode position, and the

microprocessor is in input mode. (Adjustment through the I2C bus control). (Use JWS Key to set as

well).

2. Press the CH DOWN / UP key on the remote controller to get ready to select the mode one by one.

3. Press the CH DOWN / UP key on the remote controller to select the modes reversibly one by one.

4. Using the VOLUME UP/ DOWN key on the remote controller, the data can be modified.

5. Short JA 137 & JA 138 for 1 second and release to switch to the normal mode (OFF) position, and the

microprocessor is in out of the service mode.

2. Factory Presetting.

1.Short JA 137 & JA 138 then turn "ON" the main power and release to switch to the Service Mode

position.Initial values are automatically preset, only when a new EEPROM is used (Judge with the first

4 bytes ).

2. The initial data are preset as listed in page 8, 9, & 10.

3. Make sure the data need modify or not (Initial data).

Note: Once the chassis has been assembly together and ready to be POWER ON for the FIRST TIME,

make sure to short JA137 & JA138 to switch to the service mode position first and then turn on the

main power switch (See 2-(1) above).

Precaution: If haven't done this initiation, it may possibly generate excessive Beam current.

3. For reference please check with memory map

(GA-1AM Series type RH-IX3368CE Attachment)

SERVICE MODE

(1) In the Service Mode, Key is used to select the mode in the following order.

AGC &

GEOMETRIC

MODE

↓

AGC TAKE OVER POINT (AGC)

↓

VERTICAL SLOPE (V-LIN)

↓

VERTICAL AMP (V-AMP)

↓

VERTICAL SHIFT (V-CENT)

↓

HORIZONTAL SHIFT (H-CENT)

↓

EAST-WEST WIDTH (H-SIZE)

↓

HORIZONTAL PARALLELOGRAM (EW//)

↓

EAST-WEST PARABOLA/WIDTH (PARA)

↓

EAST-WEST UPPER COR. PB (LOR(U))

↓

EAST-WEST LOWER COR. PB (COR(L))

↓

EAST -WEST TRAPEZIUM (TRAPE)

↓

HORIZONTAL BOW (HB)

↓

S-CORRECTION (S-COR)

WHITE POINT

ADJ.

MODE

↓

W.P RED STD. W.T. (DRI-RS)

↓

W.P. GREEN STD. W.T.(DRI-GS)

↓

W.P.BLUE STD. W.P. (DRI-BS)

↓

W.P. RED WARM W.P.(DRI-RC)

↓

W.P. GREEN WARM W.P.(DRI-GC)

↓

W.P. BLUE WARM W.P.(DRI-BC)

↓

W.P. RED COOL W.P.(DRI-RW)

↓

W.P. GREEN COOL W.P.(DRI-GW)

↓

W.P. BLUE COOL W.P. (DRI-BW)

SUB

ADJ.

MODE

↓

MAX VOLUME (SUB-VOL)

↓

SUB CONTRAST (SUB-CON)

↓

SUB COLOUR (SUB-COL)

↓

SUB BRIGHTNESS (SUB-BRI)

↓

SUB TINT (SUB-TINT)

↓

SUB SHARPNESS (SUB-SHP)

↓

MAX HOTEL VOLUME (HTL-VOL)

↓

HOTEL PROGRAM NO(HTL-PRG)

↓

OSD GRB REFERENCE (RGB)

↓

BLACK LEVEL OFFSET R(CUT-R)

↓

BLACK LEVEL OFFSET B(CUT-B)

↓

CATHODE DRIVE LEVEL(CDL)

FORWARD : CH DOWN KEY

REVERSE : CH UP KEY

* ( ) means OSD display.

FORWARD : CH DOWN KEY

REVERSE : CH UP KEY

AGC &

GEOMETRIC

MODE

WHITE POINT

ADJ.

MODE

SUB

ADJ.

MODE

Y-DELAY

ADJ.

MODE

MISC.

OPTION

MODE

IC

OPTION

MODE

OFFSET

ADJ.

MODE

14D2-S/G

3

3-1 3-2

14D1-S/G/W

Y-DELAY

ADJ.

MODE

↓

Y-D TIME FOR PAL (TV) (DL-PT)

↓

Y-D TIME FOR SECAM (TV) (DL-ST)

↓

Y-D TIME FOR N358 (TV) (DL-3T)

↓

Y-D TIME FOR N443 (TV) (DL-4T)

↓

Y-D TIME FOR B/W (TV) (DL-TV)

↓

Y-D TIME FOR PAL (AV) (DL-PA)

↓

Y-D TIME FOR SECAM (AV) (DL-SA)

↓

Y-D TIME FOR N358 (AV) (DL-3A)

↓

Y-D TIME FOR N443(AV) (DL-4A)

↓

Y-D TIME FOR B/W (AV) (DL-AV)

*(Y-D : Y-DELAY)

OFFSET

ADJ.

MODE

↓

COLOUR OFFSET (PAL) (COL-OP)

↓

COLOUR OFFSET (SECAM) (COL-OS)

↓

COLOUR OFFSET (NTSC358) (COL-O3)

↓

COLOUR OFFSET (NTSC443) (COL-O4)

↓

SHARPNESS OFFSET (PAL) (SHP-OP)

↓

SHARPNESS OFFSET (SECAM) (SHP-OS)

↓

SHARPNESS OFFSET (NTSC358) (COL-O3)

↓

SHARPNESS OFFSET (NTSC443) (COL-O4)

IC

OPTION

MODE

↓

VERTICAL SCAN DISABLE(VSD)

↓

BLACK STRETCH (BKS)

↓

AUTO V OLUME LEVELING(A VL)

↓

FAST FILTER IF-PLL(FFI)

↓

ENABLE VERTICAL GUARD (EVG)

↓

EHT TRACKING MODE (EHT)

↓

OVERSCAN SWITCH OFF(OSO)

↓

AUTO COLOUR LIMIT(ACL)

↓

FORCED COLOUR LIMIT(FCO)

MISC.

OPTION

MODE

↓

SOUND SYSTEM M (S-M)

↓

SOUND SYSTEM DK (S-DK)

↓

SOUND SYSTEM I (S-I)

↓

SOUND SYSTEM BG (S-BG)

↓

PLAYBACK SECAM (P-SECAM)

↓

FE (RF) NTSC 3.58 (F-N358)

↓

FE (RF) NTSC 4.43 (F-N443)

↓

FE (RF) SECAM (F-SECAM)

↓

VIDEO MUTE AT IDENT LOSS (VMI)

↓

VIDEO MUTE AT PROGRAM

/SOURCE CHANGE (VMC)

↓

HOTEL MODE (HTL)

↓

REDUCED FM DEMODULATION

GAIN FOR BTSC SIGNAL (BTSC)

↓

A

↓

NUMBER OF EXT AV SOURCE (AV)

↓

FM WINDOW SELECTION (FMWS)

↓

SOUND MUTE BIT 0 (SM0)

↓

SOUND MUTE BIT 1 (SM1)

↓

THAI LANGUAGE (THA)

↓

ARABIC LANGUAGE (ARA)

↓

MALAY LANGUAGE (MAL)

↓

CHINESE LANGUAGE (CHI)

↓

FRENCH LANGUAGE (FRE)

↓

RUSSIAN LANGUAGE (RUS)

↓

FORCED V-SYNC SLICING LEVEL(FSL)

↓

SYNC OF OSD (HP2)

↓

TUNER SELECTION (CPT)

↓

B

↓

BILINGUAL(BIL)

↓

IF AGC SPEED BIT 0 (AGC0)↓IF AGC SPEED BIT 1 (AGC1)

↓

FOA Time Constant-RF (FOA-FE)

↓

FOB Time Constant-RF (FOB-FE)

↓

FOA Time Constant-AV (FOA-AV)

↓

FOB Time Constant-AV (FOB-AV)

↓

LED BLINK SPEED (LED-F)

↓

VOLUME CONTROL TABLE (MSA)

↓

OUTPUT VERTICAL GUARD (NDF)

B

* Direct Key-in for Service Item in Service Mode

RC COMMAND SERVICE-ITEM

FUNCTION AGC

CONTRAST DOWN V-LIN

COLOUR DOWN V-AMP

BRIGHTNESS DOWN V-CENT

TINT DOWN H-CENT

SHARPNESS DOWN EW / /

SYSTEM HB

BLUEBACK S-COR

TIMER SUB-VOL

CONTRAST UP SUB-CON

COLOUR UP SUB-COL

BRIGHTNESS UP SUB-BRI

TINT UP SUB TINT

SHARPNESS UP SUB-SHP

14D2-S/G

4

4-1 4-2

14D1-S/G/W

EEPROM ITEMS OSD DATA LENGTH

INITIAL DATA

FIX/ADJ REMARK

AGC TAKE OVER POINT AGC 0~63 14 ADJ

VERTICAL SLOPE V-LIN 0~63 32 ADJ

VERTICAL AMPLITUDE V-AMP 0~63 32 ADJ

VERTICAL SHIFT V-CENT 0~63 32 ADJ

HORIZONTAL SHIFT H-CENT 0~63 32 ADJ

EAST-WEST WIDTH H-SIZE 0~63 32 *FIX

HORIZONTAL PARALLELOGRAM EW// 0~63 32 *FIX

EAST-WEST PARABOLA/WIDTH PARA 0~63 32 *FIX

EAST-WEST UPPER CORNER PARABOLA COR (U) 0~63 32 *FIX

EAST-WEST LOWER CORNER PARABOLA COR (L) 0~63 32 *FIX

EAST-WEST TRAPEZIUM TRAPE 0~63 32 *FIX

HORIZONTAL BOW HB 0~63 32 *FIX

S-CORRECTION S-COR 0~63 0 (17) *FIX

WHITE POINT RED STD WHITE TEMP DRI-RS 0~63 32 *FIX

WHITE POINT GREEN STD WHITE TEMP DRI-GS 0~63 32 ADJ

WHITE POINT BLUE STD WHITE TEMP DRI-BS 0~63 32 ADJ

WHITE POINT RED COOL WHITE TEMP DRI-RC 0~63 25 ADJ *3

WHITE POINT GREEN COOL WHITE TEMP DRI-GC 0~63 32 ADJ (DRI-GS)-7 DATA*3

WHITE POINT BLUE COOL WHITE TEMP DRI-BC 0~63 32 ADJ

SAME AS (DRI-BS) DATA

WHITE POINT RED WARM WHITE TEMP DRI-RW 0~63 32 *FIX

WHITE POINT GREEN WARM WHITE TEMP DRI-GW 0~63 32 ADJ (DRI-GS)-7 DATA

WHITE POINT BLUE WARM WHITE TEMP DRI-BW 0~63 32 ADJ (DRI-BS)-7 DATA

MAX VOLUME SUB-VOL 0~63 63 *FIX

SUB CONTRAST SUB-CON 0~63 63 (52) *FIX

SUB COLOUR SUB-COL 0~63 32 ADJ

SUB BRIGHTNESS SUB-BRI 0~63 32 ADJ

SUB TINT SUB-TINT 0~63 32 ADJ

SUB SHARPNESS SUB-SHP 0~63 32 (20) *FIX

MAX HOTEL VOLUME HTL-VOL 0~63 32 *FIX

HOTEL PROGRAM NUMBER HTL-PRG

0~99 OR>99FOR NONE

255 *FIX

OSD GRB REFERENCE RGB 0~15 15 (6) *FIX

BLACK LEVEL OFF-SET R CUT-R 0~63 32 ADJ

BLACK LEVEL OFF-SET G CUT-G 0~63 32 ADJ

CATHODE DRIVE LEVEL CDL 0~15 0 (5) *FIX

Y-DELAY TIME FOR PAL(TV) [YD] DL-PT 0~15 12 *FIX

Y-DELAY TIME FOR SECAM(TV) [YD] DL-ST 0~15 15 *FIX

Y-DELAY TIME FOR N358 (TV) [YD] DL-3T 0~15 12 *FIX

Y-DELAY TIME FOR N443 (TV) [YD] DL-4T 0~15 12 *FIX

Y-DELAY TIME FOR B/W (TV) [YD] DL-TV 0~15 12 *FIX

Y-DELAY TIME FOR PAL (AV) [YD] DL-PA 0~15 12 *FIX

Y-DELAY TIME FOR SECAM (AV) [YD] DL-SA 0~15 15 *FIX

Y-DELAY TIME FOR N358 (AV) [YD] DL-3A 0~15 12 *FIX

Y-DELAY TIME FOR N443 (AV) [YD] DL-4A 0~15 12 *FIX

Y-DELAY TIME FOR B/W (AV) [YD] DL-AV 0~15 12 *FIX

COLOUR OFFSET (PAL) COL-OP 0~15 8 ADJ *6

COLOUR OFFSET (SECAM) COL-OS 0~15 8 ADJ *6

COLOUR OFFSET (NTSC358) COL-O3 0~15 4 ADJ *6

COLOUR OFFSET (NTSC443) COL-O4 0~15 4 ADJ *6

SHARPNESS OFFSET (PAL) SHP-OP 0~15 8 *FIX

SHARPNESS OFFSET (SECAM) SHP-OS 0~15 4 *FIX

SHARPNESS OFFSET (NTSC358) SHP-O3 0~15 12 (8) *FIX

AFTER SHORT JA 137 & JA 138 ,AND TURN ON THE MAIN POWER SWITCH,READ DATA FROM EEPROM

ADDRESS 00H ~ 03H,AND COMPARE TO THE LIST BELOW, IF DIFFERENT, INITIALIZE THE EEPROM.

Address : Data Address : Data

00H : 55H 02H : 43H

01H : 4FH 03H : A1H

EEPROM ITEMS OSD DATA LENGTH

INITIAL DATA

FIX/ADJ REMARK

SHARPNESS OFFSET (NTSC443) SHP-O4 0~15 8 *FIX

VERTICAL SCAN DISABLE VSD

0(DISABLE)/1(ENABLE)

0 *FIX

BLACK STRETCH BKS

0(DISABLE)/1(ENABLE)

1 *FIX

AUTOMATIC VOLUME LEVELING AVL

0(DISABLE)/1(ENABLE)

1 *FIX

FAST FILTER IF-PLL FFI

0(DISABLE)/1(ENABLE)

0 *FIX

ENABLE VERTICAL GUARD (RGB BLANKING)

EVG

0(DISABLE)/1(ENABLE)

1 *FIX

EHT TRACKING MODE (HCO) EHT

0(DISABLE)/1(ENABLE)

1 *FIX

OVERSCAN SWITCH OFF OSO

0(DISABLE)/1(ENABLE)

0 *FIX

AUTO COLOUR LIMIT ACL

0(DISABLE)/1(ENABLE)

0 *FIX

FORCED COLOUR LIMIT FCO

0(DISABLE)/1(ENABLE)

0 *FIX

SOUND SYSTEM M S-M

0(DISABLE)/1(ENABLE)

0 *FIX

SOUND SYSTEM DK S-DK

0(DISABLE)/1(ENABLE)

1 *FIX

SOUND SYSTEM I S-I

0(DISABLE)/1(ENABLE)

1 *FIX

SOUND SYSTEM BG S-BG

0(DISABLE)/1(ENABLE)

1 *FIX

PLAYBACK SECAM P-SECAM

0(DISABLE)/1(ENABLE)

1 *FIX

FE (RF) NTSC 3.58 F-N358

0(DISABLE)/1(ENABLE)

0 *FIX

FE (RF) NTSC 4.43 F-N443

0(DISABLE)/1(ENABLE)

1 *FIX

FE (RF) SECAM F-SECAM

0(DISABLE)/1(ENABLE)

1 *FIX

VIDEO MUTE AT IDENT LOSS VMI

0(DISABLE)/1(ENABLE)

1 *FIX

VIDEO MUTE AT PROGRAM/SOURCE CHANGE

VMC

0(DISABLE)/1(ENABLE)

1 *FIX

HOTEL MODE HTL

0(DISABLE)/1(ENABLE)

0 *FIX

REDUCED FM DEMODULATOR GAIN FOR BTSC SIGNAL

BTSC

0(DISABLE)/1(ENABLE)

0 *FIX

NUMBER OF EXTERNAL AV SOURCE AV

0 FOR1 AV/1 FOR 2AV

1 (0) *FIX

FM WINDOW SELECTION FMWS

0(DISABLE)/1(ENABLE)

0 *FIX

SOUND MUTE BIT 0 SM0

0(DISABLE)/1(ENABLE)

1 *FIX

SOUND MUTE BIT 1 SM1

0(DISABLE)/1(ENABLE)

0 *FIX

THAI LANGUAGE THA

0(DISABLE)/1(ENABLE)

0 *FIX

ARABIC LANGUAGE ARA

0(DISABLE)/1(ENABLE)

1 *FIX

MALAY LANGUAGE MAL

0(DISABLE)/1(ENABLE)

1 *FIX

CHINESE LANGUAGE CHI

0(DISABLE)/1(ENABLE)

1 *FIX

FRENCH LANGUAGE FRE

0(DISABLE)/1(ENABLE)

1 *FIX

RUSSIAN LANGUAGE RUS

0(DISABLE)/1(ENABLE)

1 *FIX

FORCED V-SYNC SLICING LEVEL FSL

0(DISABLE)/1(ENABLE)

0 *FIX

SYNC OF OSD HP2

0(DISABLE)/1(ENABLE)

0 *FIX

TUNER SELECTION (0:SHARP/ALPS;1:MURATA)

CPT

0(DISABLE)/1(ENABLE)

0 *FIX

BILINGUAL BIL

0(DISABLE)/1(ENABLE)

0 *FIX

IF AGC SPEED BIT 0 AGC0

0(DISABLE)/1(ENABLE)

1 *FIX

IF AGC SPEED BIT 1 AGC1

0(DISABLE)/1(ENABLE)

0 *FIX

PHI-1 TIME CONSTANT (RF) FOA-FE

0(DISABLE)/1(ENABLE)

0 *FIX

PHI-1 TIME CONSTANT (RF) FOB-FE

0(DISABLE)/1(ENABLE)

0 *FIX

PHI-1 TIME CONSTANT (OFF AIR) FOA-AV

0(DISABLE)/1(ENABLE)

1 *FIX

PHI-1 TIME CONSTANT (OFF AIR) FOB-AV

0(DISABLE)/1(ENABLE)

1 *FIX

LED BLINK SPEED LED_F

0(DISABLE)/1(ENABLE)

0 (1) *FIX

VOLUME CONTROL PWM TABLE MSA

0(DISABLE)/1(ENABLE)

0 (1) *FIX

OUTPUT VERTICAL GUARD NDF

0(DISABLE)/1(ENABLE)

0 (1) *FIX

NOTE :

1) *FIX: PLEASE DO NOT CHANGE FIXED DATA WITHOUT SPECIFIC INSTRUCTION.

Please set the EEPROM initial data according to the value in parenthesis ( ) before adjustment.

2) *3: 12300˚K DEGREE COLOUR TEMP MINUS 7, DRI-RC=25, DRI-GC=(DRI-GS)-7

18000˚K DEGREE COLOUR TEMP MINUS 5, DRI-RC=27, DRI-GC=(DRI-GS)-5

3) *6: ADJUST COLOUR OFFSET AFTER ADJUST SUB-COLOUR.

COLOUR OFFSET (PAL) COL-OP : 8 ------> 14

COLOUR OFFSET (SECAM) COL-OS : 8 ------> 14

COLOUR OFFSET (NTSC358) COL-O3 : 4 ------> 10

COLOUR OFFSET (NTSC443) COL-O4 : 4 ------> 10

14D2-S/G

5

5-1 5-2

14D1-S/G/W

MCL1

CH-NO Fv (MHz) SOUND SYS

0 41.10

1 48.25 B/G

2 62.25 B/G

3 77.25 D/K

4 175.25 B/G

5 182.25 B/G

6 183.25 D/K

7 191.25 D/K

8 196.25 B/G

9 199.25 M

10 210.25 B/G

11 224.25 B/G

12 471.25 B/G

13 487.25 I

14 503.25 B/G

15 575.25 B/G

16 583.25 B/G

17 599.25 B/G

18 621.25 M

19 639.25 D/K

20 703.25 B/G

21 735.25 I

22 767.25 B/G

23 815.25 B/G

24 855.25 I

25 855.25 B/G

26 55.25 M

27 83.25 M

28 183.25 M

29 193.25 M

30 217.25 M

31 471.25 M

32 477.25 M

33 693.25 M

34 41.10

35 112.25 B/G

36 168.25 B/G

37 41.10

38 294.25 B/G

39 463.25 B/G

40 41.10

41 647.25 B/G

42 663.25 B/G

43 679.25 B/G

44 174.95 B/G

45 175.55 B/G

46 41.10

99 41.10

INITIAL SETTING

(1). In service mode, After execute select POS 1, store the following tuning data in E

2

PROM.

Note: All sound system of following channels will be set to B/G or I after pressing INITIAL KEY 2, 3 or 4.

""

"

SHIPPING SETTING & CHECKING

(1) The following default data has been factory-set for the E

2

PROM.

ITEMS DATA SETTING

LAST PROGRAM/CHANNEL 1

FLASHBACK PROGARM/CH 1

DIGIT 1

C-SYSTEM AUTO

S-SYSTEM *1

SKIP OFF

AFC ON

VOLUME 1

CONTRAST 60 (MAX)

COLOUR 0 (CENTER)

BRIGHTNESS 0 (CENTER)

TINT 0 (CENTER)

SHARPNESS 0 (CENTER)

WHITE TEMP STANDARD

REMINDER TIMER In-active, "--:--"

ON TIMER In-active, "--:--"

OFF TIMER In-active, "--:--"

LAST POWER POWER-ON

LANGUAGE *1

BLUE BACK MUTE ON

HOTEL MODE OFF

0 CHANNEL SKIP ON

LAST TV/AV TV

*1: Please refer defaults for LANGUAGE and SOUND SYSTEM per MODEL as follows,

LANGUAGE QTY: ENGLISH/CHINESE/FRENCH/ARABIC/MALAY/RUSSIAN

MODEL Geomagnetism (H,V) nT Background Lang. S-SYS Lang. QTY

HONG KONG) "30,000" "20,000" 12300K CHINESE I 6

(SINGAPORE) "-10,000" "40,000" 12300K ENGLISH B/G 6

(MID EAST) "30,000" "20,000" 12300K ARABIC B/G 6

(AFRICA) "-10,000" "40,000" 12300K ENGLISH B/G 6

FACTORY SETTINGS BY MODELS (Reference: Geomagnetism Adjustment)

INITIAL LANGAUGE SOUND SYSTEM

2 CHINESE I

3 ENGLISH B/G

4 ARABIC B/G

14D2-S/G

6

6-1 6-2

14D1-S/G/W

PIF ADJUSTMENT

No. Adjusting point Adjusting procedure/conditions Waveform and others

Tuner IFT

( PRESET )

1 1. Get the tuner ready to receive the CH. E - 9

signal,but with no signal input.

Adjust the PLL data.

2. Connect the sweep generator's output cable to

the tuner antenna. ( RF SWEEP )

3. Adjust the sweep generator's to 80dBuV.

4. Connect the response lead ( use LOW IMPED-

ANCE probe with wave detector ; see Fig.1 ) to

the tuner's IF output terminal. ( This terminal

must have the probe alone connected ).

5. Set the RF AGC to 0 - 6 V with no saturation with

the waveform.

6. Adjust the tuner IF coil to obtain the waveform as

shown in Fig. 2.

Note:Be sure to keep the tuner cover in position

during this adjustment.

RF-AGC

TAKE OVER

POINT AD-

JUSTMENT

(I

2

C BUS

CONTROL)

1. Receive "PAL COLOUR BAR" signal.

» Signal Strength: 57 ± 1 dBµV (75 ohm open)

2. Connect the oscilloscope to TP201(Tuner’s AGC

Terminal) as shown in Fig. 3.

3. Call "AGC" mode in service mode. Adjust the

"AGC" bus data to obtain the Tuner output pin

drop 0.1V below maximum voltage.

4. Change the antenna input signal to 63~67dBµV,

and make sure there is no noise.

5. Turn up the input signal to 90~95 dBµV to be sure

that there is no cross modulation beat.

Note: For the 50 ohm signal

strength gauge, when not

using 50/75 impedance

adapter, signal strength is

52

±

1dB

µ

V(75 ohm open), in-

stead of 57

±

1dB

µ

V (75 ohm

open).

Precaution: The loss of using

impedance adapter

2

Fig. 3

Fig.1

Fig.2

» Bias box: About 4.5 V

Oscilloscope

0.1V

TV Set

Bias box

TP210+

+

–

E-9 CH

P C

10k

100k

1n60

75ohm

IF OUT

-1.5+/-0.8dB

1000p

Oscilloscope

ADJUSTMENT PRECAUTION:

Make sure TV Set is in "Normal Condition" before switch to service mode for adjust-

ment.

PURITY ADJUSTMENT

No. Adjusting point Adjusting procedure/conditions Waveform and others

PURITY ADJ. 1. Receive the GREEN-ONLY signal. Adjust the

beam current to about 500 µA.

2. Degauss the CRT enough with the degausing coil.

Note: Follow the Job Instruction Sheet to ad-

just the magnetic field.

3. Maintain the purity magnet at the zero magnetic

field and keep the static convergence roughly

adjusted.

4. Observe the points a, b as shown in Fig. 4-1

through the microscope. Adjust the landing to the

rank A requirements.

5. Orient the raster rotation to 0 eastward.

6. Tighten up the deflection coil screws.

» Tightening torque: 108 ± 20 N (11 ± 2 kgf)

7. Make sure the CRT corners landing meet the A

rank requirements. If not, stick the magnet sheet

to correct it.

Note: This adjustment must be done after

warming up the unit for 30 minutes or

longer with a beam current over 500

µ

A.

* For the following colours press R/C RGB key to

change.

1

* Press R/C RGB key for 1 sec-

ond in NORMAL MODE, the

colour will change to RGB mono

colour mode.

The TEXT Key "R. G. Cy" Key

can be directly use to change

to other colours screen.

a

b

A

B

A

B

A = B

Rank "A"

(on the right of the CRT)

Rank "A"

(on the left of the CRT)

Fig. 4-1

Fig. 4-2

Fig. 4-3

Green-only

Blue-only

Red-only

Signal-colour

screen cleared

14D2-S/G

7

7-1 7-2

14D1-S/G/W

CONVERGENCE ADJUSTMENT

No. Adjusting point Adjusting procedure/conditions Waveform and others

CONVERGENC

ADJ.

( To be done

after the purity

adjustment.

1. Receive the "Crosshatch Pattern" signal.

2. Using the remote controller, call NORMAL mode.

STATIC CONVERGENCE

1. Turn the 4-pole magnet to a proper opening an-

gle in order to superpose the blue and red col-

ours.

2. Turn the 6-pole magnet to a proper opening an-

gle in order to superpose the green colour over

the blue and red colours.

DYNAMIC CONVERGENCE

1. Adjust the convergence on the fringes of the

screen in the following steps.

a) Fig. 5-1: Drive the wedge at point "a" and swing

the deflection coil upward.

b) Fig. 5-2: Drive the wedge at points "b" and "c"

and swing the deflection coil downward.

c) Fig. 5-3: Drive the "c" wedge deeper and swing

the deflection coil rightward.

d) Fig. 5-4: Drive the "b" wedge deeper and swing

the deflection coil leftward.

2. Fix all the wedges on the CRT and apply glass

tape over them.

3. Apply lacquer to the deflection yoke lock screw,

magnet unit (purity, 4-pole, 6-pole magnets) and

magnet unit lock screw.

Finally received the Red-only and Blue-only sig-

nals to make sure there is no other colours on the

screen.

1

RGB

BGR

RGB

BGR

RGB

BGR

Lacquer

Wedge "a"

Wedge

"b"

Wedge

"c"

About

100°

About

100°

4-pole magnet

6-pole magnet

CRT neck

Note***

Lacquer

Purity magnet

Fig. 5-1

Fig. 5-2

Fig. 5-3

Fig. 5-4

Note***

SAMSUNG CRT : 32mm

CPT CRT : 35mm

TOSHIBA CRT : 35mm

CRT CUT-OFF, BACKGROUND AND SUB-CONTRAST ADJUSTMENT

No. Adjusting point Adjusting procedure/conditions Waveform and others

CRT CUTOFF

ADJUSTMENT

(I

2

C BUS

CONTROL)

Remark

1. Before CRT cutoff adjustment, SUB-BRIGHT,

DRI-RS/RW/RC, DRI-GS/GW/GC, DRI-BS/BW/

BC, CUT-R and CUT-G must be INITIAL DATA.

2. CRT Cutoff adjustment must be done inside a

dark room.

1. Switch TV to VIDEO mode,BLUE BACK OFF, with

NO VIDEO signal.

2. Press R/C to set Picture Normal condition.

3. First, off the screen by adjust screen variable re-

sistor.

*4. Next, checking AKB circuit function by slowly in-

crease screen variable resistor until colour raster

suddenly on and off (AKB start function).

5. Then continue adjust until retrace line appear.

6. Finally, slowly decrease the screen variable re-

sistor until screen retrace line cut off. (Not Raster)

Note :

Must confirm the AKB function in set before con-

tinue the next adjustment.

1

SUB-BRIGHT-

NESS

ADJUSMENT

(I

2

C BUS

CONTROL)

1. Call " SUB-BRI" in service mode. (Receive Cross-

hatch pattern with 5 black level windows)

*(2) Adjust the " SUB BRIGHT " bus data in order

that the line 1and 2 have the same darkness

wherelse line 3 is one step (data) brighter than

line 2. Finally data minus 1 to make line 1, 2,

and 3 are in same level (darkness).

2

Line 3 is one step (data)

brighter than line 2

t

3.3Vdc

0

WHITE BAL-

ANCE SERV-

ICE MODE

ADJ. (I

2

C BUS

CONTROL)

1. Receive the "WHITE" pattern with BURST signal.

2. Press R/C to set Picture NORMAL condition.

3. Connect the DC miliammeter between TP602

(-) TP603 (+).

4. Check Beam current should be around 800 µA.

5. Set it to service mode and adjust the DRI-GS, &

DRI-BS data to have a colour temperature of

12300°K or 18000°K ( white ). * Note .

6. Receive "WHITE" pattern, WITH BURST signal,

and set BRIGHTNESS Y by generator, to **10

cd/m2 (MINOLTA CA-100) by reducing

LUMINATE Y signal.

7. Adjust "CUT-R" & "CUT-G" to get desired colour

temperature #. Then go back NORMAL mode

(HIGH BRIGHT**) to check colour temperature.

If out of range, back to (1).

Note: This adjustment must be done after

warming up the unit for 30 minutes or

longer with a beam current over 500

µ

A.

* ADJUST DRI-GC/GW, DRI-BC/BW as following

DATA, after finishing DRI-BS and DRI-GS DATA

ADJUSTMENT.

DRI-RW = 32 (FIXED), DRI-RS = 32 (FIXED)

DRI-BC = "DRI-BS"

(For 12300°K And 18000°K Condition)

3

# 12300°K X: 0.272

Y: 0.275

# 18000°K X: 0.255

Y: 0.255

(MINOLTA COLOUR ANALYZER

CA-100)

*Note: Above Data can be UP/

DOWN by Volume key.

LOW HIGH

14" 10cd/m2 200cd/m2

*Alternative Procedure

(1) Step (1), (2), (3) and (4) are

same as beside procedure.

(2) Then continue adjust until re-

trace line appear and make sure

the colour appear whether red,

green or blue.

(3) Connect the oscilloscope to

related test points as below

which is based on colour appear

at (2) RED = TP47R, GREEN =

TP47G, BLUE = TP47B.

(4) Then adjust Screen VR until the

tip of signal reach 3.3Vdc.

* 12300°K DRI-GW="DRI-GS"-7

DRI-BW="DRI-BS"-7

DRI-GC="DRI-GS"-7

DRI-RC=25

* 18000°K DRI-GW="DRI-GS"-7

DRI-BW="DRI-BS"-7

DRI-GC="DRI-GS"-5

DRI-RC=27

1

2

1 2 3 4 5

14D2-S/G

8

8-1 8-2

14D1-S/G/W

HORIZONT AL AND VERTICAL DEFLECTION LOOP ADJUSTMENT

No. Adjusting point Adjusting procedure/conditions Waveform and others

V-SLOPE (I

2

C

BUS CON-

TROL)

V-SHIFT-50

(I

2

C BUS

CONTROL)

V-AMP50 (I

2

C

BUS CON-

TROL)

H-SHIFT (50)

(H-CENTER)

S-CORREC-

TION (I

2

C BUS

CONTROL)

SUB-SHARP-

NESS

Focus

1. Receive Monoscope Pattern Signal.

2. Call the "V-LIN" mode.

3. Increase or decrease "V-LIN" by Volume key till

the horizontal line in the center of monoscope is

just at the position where the blanking starts.

1. Call the "V-CENT" mode.

2. Increase or decrease "V-CENT" by Volume key

till the picture is centered.

1. Call the "V-AMP" mode.

2. Increase or decrease "V-AMP" by Volume key to

set overscan of 9.5% typical.

Adjustment Spec 9.5% range +1% -0%.

1. Call the "H-CENT" mode.

2. Increase or decrease "H-CENT" by Volume key

to center the picture horizontal.

1. SET DATA TO 17.

* Check the E-5 CH Monoscope Pattern then re-

adjust V-Slope, V-Shift and V-Amp to makesure

adjustment is in acceptable Ring-Shaped.

1. SET DATA TO 20.

1

2

3

4

5

1. Receive the "Monoscope Pattern" signal.

2. Press R/C to set Picture NORMAL condition.

3. Adjust the focus control to get the best focusing.

1

PAL CHROMA ADJUSTMENT

No. Adjusting point Adjusting procedure/conditions Waveform and others

SUB COLOUR

(I

2

C BUS

CONTROL)

1. Receive the "PAL Colour Bar" signal.

2. Press R/C to set Picture Normal condition.

3. Connect the oscilloscope to

Red cathode(D881 Cathode).

» Range : 20 V/div. (AC) (Using 10:1 probe)

» Sweep time : 10 µsec/div.

4. Using the R/C call "SUB COL" in SERVICE mode.

Adjust SUB COLOUR bus data, so that the 75%

White & Red portions of PAL Color Bar be at the

same level shown as Fig. 1-1.

5. Clear the SERVICE mode.

1

Cy

G

B

W

Y 100%W

75%

Mg R

Fig. 1-1

CRT CUT-OFF, BACKGROUND AND SUB-CONTRAST ADJUSTMENT

(Continued)

No. Adjusting point Adjusting procedure/conditions Waveform and others

Max

beam check

1. Receive the "Monoscope Pattern" signal.

2. Press R/C to set Picture NORMAL condition.

3. Connect the DC miliammeter between TP603 (+)

& TP602 (–).

(Full Scale: 3 mA Range)

4. Beam current must be within 800 ± 100 µA.(14")

4

6

No. Adjusting point Adjusting procedure/conditions Waveform and others

SUB-TINT (I

2

C

BUS CON-

TROL)

1. Receive the "NTSC 3.58 Colour Bar" signal thru

AV in.

2. Connect the oscilloscope to TP47B (P882 pin 5)

BLUE-OUT.

» Range : 100mV/div. (AC)(Use Probe 10:1)

» Sweep time : 10 µsec/div.

3. Call the "SUB-TINT" mode in service mode. Ad-

just the "SUB-TINT" bus data to obtain the wave-

form shown as Fig. 1-1.

4. Clear the SERVICE mode.

1

Fig. 1-1

NTSC CHROMA ADJUSTMENT

No. Adjusting point Adjusting procedure/conditions Waveform and others

BEAM PRO-

TECTOR

1. Receive "Monoscope Pattern" signal.

2. Set CONTRAST MAX.

3. Set BRIGHT MAX.

4. During the Collector & Emitter of Q883/5/7 short,

make sure the protector ON and switch to standby

mode.

1 * Select one of Q883/5/7 to do

each short test.

H•V PROTEC-

TOR

1. Receive "Monoscope Pattern" signal.

2. Connect output of Bias Box to D603 cathode

(R610 side).

3. Set voltage of Bias Box to 18V and make sure

the protector is not work.

4. Set voltage of Bias Box to 27V, and make sure

the protector is work.

2

Other

protectors

1. Once finish rectified Electrolytic Capacitor short

testing in +B line, check all possible damaged

components on +B line.

(Use random selected set for inspection)

3

PROTECTOR OPERATION CHECKING

No. Adjusting point Adjusting procedure/conditions Waveform and others

VIDEO AND

AUDIO

OUTPUT

CHECK

1. Receive the "PAL Color Bar" signal (100% White

Color Bar, Sound 400 Hz 100% Mod).

2. Terminate the Video output with a 75 ohm imped-

ance. Make sure the output is as specified (1.0

Vp-p ±3 dB).

3. Terminate the Audio output with a 10k ohm im-

pedance. Make sure the O/P is as specified

(1.76 Vp-p ±3 dB).

1

VIDEO AND

AUDIO INPUT

CHECK

1. Using the TV/AV key on the remote controller,

make sure that the modes change in order of TV ,

AV & TV again and the video & audio output are

according to the input terminal for each mode.If

connect input to Front and Rear AV terminal, in-

put terminal of Front AV will be selected.

2

A/V INPUT AND OUTPUT CHECKING

W

Y

Cy G Mg R

B

SAME LEVEL

14D2-S/G

9

9-1 9-2

14D1-S/G/W

FUNCTION OPERATION CHECKING (VIDEO AND AUDIO)

No. Adjusting point Adjusting procedure/conditions Waveform and others

CONTRAST

key

1. Receive "Monoscope Pattern" signal.

2. Set P-Mode to select CONTRAST.

3. Press Volume Up/Down key to check whether the

CONTRAST effect is OK or not.

1

1. Receive "Color Bar" signal.

2. Set P-Mode to select COLOUR.

3. Press Volume Up/Down key to check whether

the COLOUR effect is OK or not.

2

COLOUR key

BRIGHTNESS

key

1. Receive "Monoscope Pattern" signal.

2. Set P-Mode to select BRIGHTNESS.

3. Press Volume Up/Down key to check whether

the BRIGHTNESS effect is OK or not.

3

TINT key 1. Receive the "NTSC Colour Bar" signal thru AV in.

2. Set P-Mode to select TINT.

3. Press Volume Up/Down key to check TINT, UP

for GREEN direction and DOWN for PURPLE di-

rection whether is OK or not.

4

SHARPNESS

Key

1. Receive "Monoscope Pattern" signal.

2. Set P-mode to select SHARPNESS.

3. Press Volume Up/Down key to check whether

the SHARPNESS effect is OK or not.

5

WHITE TEMP 1. Receive "Monoscope Pattern" signal.

2. Set FUNCTION to select WHITE TEMP.

3. Press Volume Up/Down key to check WHITE

TEMP Option, STANDARD:

NORMAL SETTING, WARM for more REDDISH

direction changing, COOL for more BLUISH di-

rection changing.

8

NORMAL Key7

1. Once in PICTURE Mode, and theNORMAL key

is pressed, all the settings will be present to nor-

mal setting.

(Normal setting value for every mode).

» CONTRAST : MAX

» COLOUR : CENTER

» BRIGHTNESS : CENTER

» TINT : CENTER

» SHARPNESS : CENTER

Notes:If nothing is display

mean contrast, colour, bright,

tint, sharpness are all in nor-

mal setting.

CH DISPLAY

COLOUR

1. All Ch (1~99) will have an OSD display of the

channel number in green colour under AFT ON

condition.

6

FUNCTION OPERATION CHECKING (VIDEO AND AUDIO)

(Continued)

No. Adjusting point Adjusting procedure/conditions Waveform and others

COLOUR

SYSTEM

1. Receive the "PAL COLOUR BAR" signal, press

the COLOUR SYSTEM key to select modes ex-

cept PAL, check the COLOUR is not working prop-

erly. Then, select the "PAL" mode. Check again

its colour so that it is working properly.

2. Receive "SECAM COLOUR BAR" signal, press

COLOUR SYSTEM key to select modes except

SECAM, check the COLOUR is not working prop-

erly. Then, select the "SECAM" mode. Check

again its colour so that it is working properly.

3. Receive "NTSC 4.43/3.58 COLOUR BAR" signal

thru AV, press COLOUR SYSTEM key to select

modes except N4.43/3.58, check the COLOUR

is not working properly. Then, select the "NTSC

4.43/3.58" mode. Check again its colour so that it

is working properly.

9

OSD LAN-

GUAGE

QUANTITY

CHECK

Check OSD LANGUAGE quantity and type as Eng-

lish, Russian, Chinese, French, Arabic and Malay.

12

1. Receive "PAL COLOUR BAR" signal.

2. Turn up the volume control to maximum, make

sure the sound is heard from the speakers. Then

put the unit in no signal state.

3. Check the sound mute is effective.

4. Finally turn sound level of CTV to minimum.

SOUND

SYSTEM

10 1. Receive "PAL-D/K" signal, press the "SOUND

SYSTEM" to select B/G, I. Check the sound out-

put is not working properly. Select D/K and check

the sound output to make sure it is working prop-

erly.

2. Receive "PAL-I" signal, press the "SOUND SYS-

TEM" to select B/G, D/K. Check the sound output

is not working properly. Select I and check the

sound output to make sure it is working properly.

3. Receive "PAL-B/G" signal, press the "SOUND

SYSTEM"to select I, D/K. Check the sound out-

put is not working properly. Select B/G and check

the sound output to make sure it is working prop-

erly.

NOISE MUTE

CHECKING

11

14D2-S/G

10

10-1 10-2

14D1-S/G/W

MEMORY MAP

ADDRESS

DATA

00

PASS WORD

55 00-FF

01

PASS WORD

4F 00-FF

02

PASS WORD

43 00-FF

03

PASS WORD

A1 00-FF

040506

AGC TAKE-OVER

0E 00-3F

07

V-SLOPE

20 00-3F

08

V-AMPLITUDE

20 00-3F

09

V-CENTER

20 00-3F

0A

H-CENTER

20 00-3F

0B

H-SIZE

20 00-3F

0C

EW-PARALLELOGRAM

20 00-3F

0D

EW-PARABOLA/WIDTH

20 00-3F

0E

EW-UPPER CORNER

20 00-3F

0F

EW-LOWER CORNER

20 00-3F

10

EW-TRAPEZIUM

20 00-3F

11

HORIZONTAL-BOW

20 00-3F

12

S-CORRECTION

00 00-3F

131415

16

DRIVE-R (STANDARD)

20 00-3F

17

DRIVE-G (STANDARD)

20 00-3F

18

DRIVE-B (STANDARD)

20 00-3F

19

DRIVE-R (WARM)

20 00-3F

1A

DRIVE-G (WARM)

20 00-3F

1B

DRIVE-B (WARM)

20 00-3F

1C

DRIVE-R (COOL)

19 00-3F

1D

DRIVE-G (COOL)

20 00-3F

1E

DRIVE-B (COOL)

20 00-3F

1F

202122

SUB-VOLUME

3F 00-3F

23

SUB-CONTRAST

3F 00-3F

24

SUB-COLOUR

20 00-3F

25

SUB-BRIGHTNESS

20 00-3F

26

SUB-TINT

20 00-3F

27

SUB-SHARPNESS

20 00-3F

28

HTL-VOLUME

20 00-3F

29

HTL-POSITION

FF 00-FF

2A

2B

2C

2D

OSD-REFERENCE

0F 00-0F

2E

CUTOFF LEVEL -OFFSET R

20 00-3F

2F

CUTOFF LEVEL -OFFSET G

20 00-3F

30

CATHODE DRIVE LEVEL

00 00-0F

31

Y-DELAY (TV PAL)

0C 00-0F

32

Y-DELAY (TV SECAM)

0F 00-0F

33

Y-DELAY (TV N358)

0C 00-0F

34

Y-DELAY (TV N443)

0C 00-0F

35

Y-DELAY (TV BW)

0C 00-0F

36

Y-DELAY (AV PAL)

0C 00-0F

37

Y-DELAY (AV SECAM)

0F 00-0F

38

Y-DELAY (AV N358)

0C 00-0F

39

Y-DELAY (AV N443)

0C 00-0F

3A

Y-DELAY (AV BW)

0C 00-0F

3B

COLOUR-OFFSET (PAL)

08 00-0F

3C

COLOUR-OFFSET (SECAM)

08 00-0F

3D

COLOUR-OFFSET (N358)

04 00-0F

3E

COLOUR-OFFSET (N443)

04 00-0F

3F

SHARPNESS-OFFSET (PAL)

08 00-0F

MODEL MODEL

LETTER NO. LETTER NO.

(1) 20th August

2001:Change of

range & default.

MICON EEPROM EEPROM CHASSIS CTV FINAL

LAST INITIAL

SETTING DATA

(HEX) D7 D6 D5 D4 D3 D2 D1 D0

DEFAULT RANGE

WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE

REMARK

ADDRESS

DATA

(HEX) D7 D6 D5 D4 D3 D2 D1 D0

40

SHARPNESS-OFFSET (SECAM)

04 00-0F

41

SHARPNESS-OFFSET (N358)

0C 00-0F

42

SHARPNESS-OFFSET (N443)

08 00-0F

43

44

FCO ACL OSO EHT EVG FFI AVL BKS

00-FF

45

SECAM N443 N358

PB-SECAM

BG I DK M

00-FF

46

SM1 SM0 FMWS AV BTSC HTL VMC VMI

00-FF

47

HP2 FSL RUS FRA CHN MLY ARB THA

00-FF

48

AGC1 AGC0 BIL CPTFOB-AV FOA-AV FOB-FE FOA-FE

NDF MSA LED-F

00-FF

00-03

49

4A4B4C

VOLUME

01 00-3C

4D

CONTRAST

3C 00-3C

4E

COLOUR

1E 00-3C

4F

BRIGHTNESS

1E 00-3C

50

TINT

1E 00-3C

51

SHARPNESS

1E 00-3C

525354

55

POSITION/AV1/AV2

01 00-FF

56

FAV-POS A

0A 00-FF

57

FAV-POS B

14 00-FF

58

FAV-POS C

1E 00-FF

59

FAV-POS D

28 00-FF

5A5B5C

LAST POWER MODE

00 00-01

5D

WHITE-TEMP

00 00-02

5E

BLUE BACK

00 00-01

5F

LANGUAGE

00 00-07

60

LAST DIGIT MODE (1 OR 2)

00 00-01

61

62

SKIP 0 SKIP 1 SKIP 2 SKIP 3 SKIP 4 SKIP 5 SKIP 6 SKIP 7

80 00-FF

63

SKIP 8 SKIP 9 SKIP 10 SKIP 11 SKIP 12 SKIP 13 SKIP 14 SKIP 15

00 00-FF

64

SKIP 16 SKIP 17 SKIP 18 SKIP 19 SKIP 20 SKIP 21 SKIP 22 SKIP 23

00 00-FF

65

SKIP 24 SKIP 25 SKIP 26 SKIP 27 SKIP 28 SKIP 29 SKIP 30 SKIP 31

00 00-FF

66

SKIP 32 SKIP 33 SKIP 34 SKIP 35 SKIP 36 SKIP 37 SKIP 38 SKIP 39

00 00-FF

67

SKIP 40 SKIP 41 SKIP 42 SKIP 43 SKIP 44 SKIP 45 SKIP 46 SKIP 47

00 00-FF

68

SKIP 48 SKIP 49 SKIP 50 SKIP 51 SKIP 52 SKIP 53 SKIP 54 SKIP 55

00 00-FF

69

SKIP 56 SKIP 57 SKIP 58 SKIP 59 SKIP 60 SKIP 61 SKIP 62 SKIP 63

00 00-FF

6A

SKIP 64 SKIP 65 SKIP 66 SKIP 67 SKIP 68 SKIP 69 SKIP 70 SKIP 71

00 00-FF

6B

SKIP 72 SKIP 73 SKIP 74 SKIP 75 SKIP 76 SKIP 77 SKIP 78 SKIP 79

00 00-FF

6C

SKIP 80 SKIP 81 SKIP 82 SKIP 83 SKIP 84 SKIP 85 SKIP 86 SKIP 87

00 00-FF

6D

SKIP 88 SKIP 89 SKIP 90 SKIP 91 SKIP 92 SKIP 93 SKIP 94 SKIP 95

00 00-FF

6E

SKIP 96 SKIP 97 SKIP 98 SKIP 99

00 00-FF

6F

7071727374

TUNING FREQUANCY (HIGHER PART)

S-SYS

POS 0

75

TUNING FREQUANCY (LOWER PART)

000:BG

76

S-SYS AFT (auto) C-SYS

001:I

77

TUNING FREQUANCY (HIGHER PART)

010:DK

POS 1

78

TUNING FREQUANCY (LOWER PART)

011:M

79

S-SYS AFT (auto) C-SYS

7A

TUNING FREQUANCY (HIGHER PART)

AFT

POS 2

7B

TUNING FREQUANCY (LOWER PART)

0:OFF

7C

S-SYS AFT (auto) C-SYS

1:ON

7D

TUNING FREQUANCY (HIGHER PART)

POS 3

7E

TUNING FREQUANCY (LOWER PART)

7F

S-SYS AFT (auto) C-SYS

MODEL MODEL

LETTER NO. LETTER NO.

1B

DE

53

3E

C4

00

MICON EEPROM EEPROM CHASSIS CTV FINAL

LAST INITIAL

SETTING DATA

DEFAULT RANGE

WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE

REMARK

(1) 20th August 2001:

Added 3 new items.

14D2-S/G

11

11-1 11-2

14D1-S/G/W

ADDRESS

DATA

(HEX) D7 D6 D5 D4 D3 D2 D1 D0

80

TUNING FREQUANCY (HIGHER PART)

POS 4

81

TUNING FREQUANCY (LOWER PART)

82

S-SYS AFT (auto) C-SYS

83

TUNING FREQUANCY (HIGHER PART)

POS 5

84

TUNING FREQUANCY (LOWER PART)

85

S-SYS AFT (auto) C-SYS

86

TUNING FREQUANCY (HIGHER PART)

POS 6

87

TUNING FREQUANCY (LOWER PART)

88

S-SYS AFT (auto) C-SYS

89

TUNING FREQUANCY (HIGHER PART)

POS 7

8A

TUNING FREQUANCY (LOWER PART)

8B

S-SYS AFT (auto) C-SYS

8C

TUNING FREQUANCY (HIGHER PART)

POS 8

8D

TUNING FREQUANCY (LOWER PART)

8E

S-SYS AFT (auto) C-SYS

8F

TUNING FREQUANCY (HIGHER PART)

POS 9

90

TUNING FREQUANCY (LOWER PART)

91

S-SYS AFT (auto) C-SYS

92

TUNING FREQUANCY (HIGHER PART)

POS 10

93

TUNING FREQUANCY (LOWER PART)

94

S-SYS AFT (auto) C-SYS

95

TUNING FREQUANCY (HIGHER PART)

POS 11

96

TUNING FREQUANCY (LOWER PART)

97

S-SYS AFT (auto) C-SYS

98

TUNING FREQUANCY (HIGHER PART)

POS 12

99

TUNING FREQUANCY (LOWER PART)

9A

S-SYS AFT (auto) C-SYS

9B

TUNING FREQUANCY (HIGHER PART)

POS 13

9C

TUNING FREQUANCY (LOWER PART)

9D

S-SYS AFT (auto) C-SYS

9E

TUNING FREQUANCY (HIGHER PART)

POS 14

9F

TUNING FREQUANCY (LOWER PART)

A0

S-SYS AFT (auto) C-SYS

A1

TUNING FREQUANCY (HIGHER PART)

POS 15

A2

TUNING FREQUANCY (LOWER PART)

A3

S-SYS AFT (auto) C-SYS

A4

TUNING FREQUANCY (HIGHER PART)

POS 16

A5

TUNING FREQUANCY (LOWER PART)

A6

S-SYS AFT (auto) C-SYS

A7

TUNING FREQUANCY (HIGHER PART)

POS 17

A8

TUNING FREQUANCY (LOWER PART)

A9

S-SYS AFT (auto) C-SYS

AA

TUNING FREQUANCY (HIGHER PART)

POS 18

AB

TUNING FREQUANCY (LOWER PART)

AC

S-SYS AFT (auto) C-SYS

AD

TUNING FREQUANCY (HIGHER PART)

POS 19

AE

TUNING FREQUANCY (LOWER PART)

AF

S-SYS AFT (auto) C-SYS

B0

TUNING FREQUANCY (HIGHER PART)

POS 20

B1

TUNING FREQUANCY (LOWER PART)

B2

S-SYS AFT (auto) C-SYS

B3

TUNING FREQUANCY (HIGHER PART)

POS 21

B4

TUNING FREQUANCY (LOWER PART)

B5

S-SYS AFT (auto) C-SYS

B6

TUNING FREQUANCY (HIGHER PART)

POS 22

B7

TUNING FREQUANCY (LOWER PART)

B8

S-SYS AFT (auto) C-SYS

B9

TUNING FREQUANCY (HIGHER PART)

POS 23

BA

TUNING FREQUANCY (LOWER PART)

BB

S-SYS AFT (auto) C-SYS

BC

TUNING FREQUANCY (HIGHER PART)

POS 24

BD

TUNING FREQUANCY (LOWER PART)

BE

S-SYS AFT (auto) C-SYS

BF

TUNING FREQUANCY (HIGHER PART)

POS 25

MODEL MODEL

LETTER NO. LETTER NO.

MICON EEPROM EEPROM CHASSIS CTV FINAL

LAST INITIAL

SETTING DATA

DEFAULT RANGE WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE

REMARK

ADDRESS

DATA

(HEX) D7 D6 D5 D4 D3 D2 D1 D0

C0

TUNING FREQUANCY (LOWER PART)

POS 25

C1

S-SYS AFT (auto) C-SYS

C2

TUNING FREQUANCY (HIGHER PART)

POS 26

C3

TUNING FREQUANCY (LOWER PART)

C4

S-SYS AFT (auto) C-SYS

C5

TUNING FREQUANCY (HIGHER PART)

POS 27

C6

TUNING FREQUANCY (LOWER PART)

C7

S-SYS AFT (auto) C-SYS

C8

TUNING FREQUANCY (HIGHER PART)

POS 28

C9

TUNING FREQUANCY (LOWER PART)

CA

S-SYS AFT (auto) C-SYS

CB

TUNING FREQUANCY (HIGHER PART)

POS 29

CC

TUNING FREQUANCY (LOWER PART)

CD

S-SYS AFT (auto) C-SYS

CE

TUNING FREQUANCY (HIGHER PART)

POS 30

CF

TUNING FREQUANCY (LOWER PART)

D0

S-SYS AFT (auto) C-SYS

D1

TUNING FREQUANCY (HIGHER PART)

POS 31

D2

TUNING FREQUANCY (LOWER PART)

D3

S-SYS AFT (auto) C-SYS

D4

TUNING FREQUANCY (HIGHER PART)

POS 32

D5

TUNING FREQUANCY (LOWER PART)

D6

S-SYS AFT (auto) C-SYS

D7

TUNING FREQUANCY (HIGHER PART)

POS 33

D8

TUNING FREQUANCY (LOWER PART)

D9

S-SYS AFT (auto) C-SYS

DA

TUNING FREQUANCY (HIGHER PART)

POS 34

DB

TUNING FREQUANCY (LOWER PART)

DC

S-SYS AFT (auto) C-SYS

DD

TUNING FREQUANCY (HIGHER PART)

POS 35

DE

TUNING FREQUANCY (LOWER PART)

DF

S-SYS AFT (auto) C-SYS

E0

TUNING FREQUANCY (HIGHER PART)

POS 36

E1

TUNING FREQUANCY (LOWER PART)

E2

S-SYS AFT (auto) C-SYS

E3

TUNING FREQUANCY (HIGHER PART)

POS 37

E4

TUNING FREQUANCY (LOWER PART)

E5

S-SYS AFT (auto) C-SYS

E6

TUNING FREQUANCY (HIGHER PART)

POS 38

E7

TUNING FREQUANCY (LOWER PART)

E8

S-SYS AFT (auto) C-SYS

E9

TUNING FREQUANCY (HIGHER PART)

POS 39

EA

TUNING FREQUANCY (LOWER PART)

EB

S-SYS AFT (auto) C-SYS

EC

TUNING FREQUANCY (HIGHER PART)

POS 40

ED

TUNING FREQUANCY (LOWER PART)

EE

S-SYS AFT (auto) C-SYS

EF

TUNING FREQUANCY (HIGHER PART)

POS 41

F0

TUNING FREQUANCY (LOWER PART)

F1

S-SYS AFT (auto) C-SYS

F2

TUNING FREQUANCY (HIGHER PART)

POS 42

F3

TUNING FREQUANCY (LOWER PART)

F4

S-SYS AFT (auto) C-SYS

F5

TUNING FREQUANCY (HIGHER PART)

POS 43

F6

TUNING FREQUANCY (LOWER PART)

F7

S-SYS AFT (auto) C-SYS

F8

TUNING FREQUANCY (HIGHER PART)

POS 44

F9

TUNING FREQUANCY (LOWER PART)

FA

S-SYS AFT (auto) C-SYS

FB

TUNING FREQUANCY (HIGHER PART)

POS 45

FC

TUNING FREQUANCY (LOWER PART)

TUNING FREQUANCY (HIGHER PART)

TUNING FREQUANCY (LOWER PART)

FD

S-SYS AFT (auto) C-SYS

FE

POS 46

FF

MODEL MODEL

LETTER NO. LETTER NO.

MICON EEPROM EEPROM CHASSIS CTV FINAL

LAST INITIAL

SETTING DATA

DEFAULT RANGE

WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE

REMARK

14D2-S/G

12-1 12-2

12

14D1-S/G/W

ADDRESS

DATA

(HEX) D7 D6 D5 D4 D3 D2 D1 D0

100

POS 46

101

TUNING FREQUANCY (HIGHER PART)

POS 47

102

TUNING FREQUANCY (LOWER PART)

103

S-SYS AFT (auto) C-SYS

104

TUNING FREQUANCY (HIGHER PART)

POS 48

105

TUNING FREQUANCY (LOWER PART)

106

S-SYS AFT (auto) C-SYS

107

TUNING FREQUANCY (HIGHER PART)

POS 49

108

TUNING FREQUANCY (LOWER PART)

109

S-SYS AFT (auto) C-SYS

10A

TUNING FREQUANCY (HIGHER PART)

POS 50

10B

TUNING FREQUANCY (LOWER PART)

10C

S-SYS AFT (auto) C-SYS

10D

TUNING FREQUANCY (HIGHER PART)

POS 51

10E

TUNING FREQUANCY (LOWER PART)

10F

S-SYS AFT (auto) C-SYS

110

TUNING FREQUANCY (HIGHER PART)

POS 52

111

TUNING FREQUANCY (LOWER PART)

112

S-SYS AFT (auto) C-SYS

113

TUNING FREQUANCY (HIGHER PART)

POS 53

114

TUNING FREQUANCY (LOWER PART)

115

S-SYS AFT (auto) C-SYS

116

TUNING FREQUANCY (HIGHER PART)

POS 54

117

TUNING FREQUANCY (LOWER PART)

118

S-SYS AFT (auto) C-SYS

119

TUNING FREQUANCY (HIGHER PART)

POS 55

11A

TUNING FREQUANCY (LOWER PART)

11B

S-SYS AFT (auto) C-SYS

11C

TUNING FREQUANCY (HIGHER PART)

POS 56

11D

TUNING FREQUANCY (LOWER PART)

11E

S-SYS AFT (auto) C-SYS

11F

TUNING FREQUANCY (HIGHER PART)

POS 57

120

TUNING FREQUANCY (LOWER PART)

121

S-SYS AFT (auto) C-SYS

122

TUNING FREQUANCY (HIGHER PART)

POS 58

123

TUNING FREQUANCY (LOWER PART)

124

S-SYS AFT (auto) C-SYS

125

TUNING FREQUANCY (HIGHER PART)

POS 59

126

TUNING FREQUANCY (LOWER PART)

127

S-SYS AFT (auto) C-SYS

128

TUNING FREQUANCY (HIGHER PART)

POS 60

129

TUNING FREQUANCY (LOWER PART)

12A

S-SYS AFT (auto) C-SYS

12B

TUNING FREQUANCY (HIGHER PART)

POS 61

12C

TUNING FREQUANCY (LOWER PART)

12D

S-SYS AFT (auto) C-SYS

12E

TUNING FREQUANCY (HIGHER PART)

POS 62

12F

TUNING FREQUANCY (LOWER PART)

130

S-SYS AFT (auto) C-SYS

131

TUNING FREQUANCY (HIGHER PART)

POS 63

132

TUNING FREQUANCY (LOWER PART)

133

S-SYS AFT (auto) C-SYS

134

TUNING FREQUANCY (HIGHER PART)

POS 64

135

TUNING FREQUANCY (LOWER PART)

136

S-SYS AFT (auto) C-SYS

137

TUNING FREQUANCY (HIGHER PART)

POS 65

138

TUNING FREQUANCY (LOWER PART)

139

S-SYS AFT (auto) C-SYS

13A

TUNING FREQUANCY (HIGHER PART)

POS 66

13B

TUNING FREQUANCY (LOWER PART)

13C

S-SYS AFT (auto) C-SYS

13D

TUNING FREQUANCY (HIGHER PART)

POS 67

13E

TUNING FREQUANCY (LOWER PART)

13F

S-SYS AFT (auto) C-SYS

MODEL MODEL

LETTER NO. LETTER NO.

MICON EEPROM EEPROM CHASSIS CTV FINAL

LAST INITIAL

SETTING DATA

DEFAULT RANGE

WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE

REMARK

ADDRESS

DATA

(HEX) D7 D6 D5 D4 D3 D2 D1 D0

140

TUNING FREQUANCY (HIGHER PART)

POS 68

141

TUNING FREQUANCY (LOWER PART)

142

S-SYS AFT (auto) C-SYS

143

TUNING FREQUANCY (HIGHER PART)

POS 69

144

TUNING FREQUANCY (LOWER PART)

145

S-SYS AFT (auto) C-SYS

146

TUNING FREQUANCY (HIGHER PART)

POS 70

147

TUNING FREQUANCY (LOWER PART)

148

S-SYS AFT (auto) C-SYS

149

TUNING FREQUANCY (HIGHER PART)

POS 71

14A

TUNING FREQUANCY (LOWER PART)

14B

S-SYS AFT (auto) C-SYS

14C

TUNING FREQUANCY (HIGHER PART)

POS 72

14D

TUNING FREQUANCY (LOWER PART)

14E

S-SYS AFT (auto) C-SYS

14F

TUNING FREQUANCY (HIGHER PART)

POS 73

150

TUNING FREQUANCY (LOWER PART)

151

S-SYS AFT (auto) C-SYS

152

TUNING FREQUANCY (HIGHER PART)

POS 74

153

TUNING FREQUANCY (LOWER PART)

154

S-SYS AFT (auto) C-SYS

155

TUNING FREQUANCY (HIGHER PART)

POS 75

156

TUNING FREQUANCY (LOWER PART)

157

S-SYS AFT (auto) C-SYS

158

TUNING FREQUANCY (HIGHER PART)

POS 76

159

TUNING FREQUANCY (LOWER PART)

15A

S-SYS AFT (auto) C-SYS

15B

TUNING FREQUANCY (HIGHER PART)

POS 77

15C

TUNING FREQUANCY (LOWER PART)

15D

S-SYS AFT (auto) C-SYS

15E

TUNING FREQUANCY (HIGHER PART)

POS 78

15F

TUNING FREQUANCY (LOWER PART)

160

S-SYS AFT (auto) C-SYS

161

TUNING FREQUANCY (HIGHER PART)

POS 79

162

TUNING FREQUANCY (LOWER PART)

163

S-SYS AFT (auto) C-SYS

164

TUNING FREQUANCY (HIGHER PART)

POS 80

165

TUNING FREQUANCY (LOWER PART)

166

S-SYS AFT (auto) C-SYS

167

TUNING FREQUANCY (HIGHER PART)

POS 81

168

TUNING FREQUANCY (LOWER PART)

169

S-SYS AFT (auto) C-SYS

16A

TUNING FREQUANCY (HIGHER PART)

POS 82

16B

TUNING FREQUANCY (LOWER PART)

16C

S-SYS AFT (auto) C-SYS

16D

TUNING FREQUANCY (HIGHER PART)

POS 83

16E

TUNING FREQUANCY (LOWER PART)

16F

S-SYS AFT (auto) C-SYS

170

TUNING FREQUANCY (HIGHER PART)

POS 84

171

TUNING FREQUANCY (LOWER PART)

172

S-SYS AFT (auto) C-SYS

173

TUNING FREQUANCY (HIGHER PART)

POS 85

174

TUNING FREQUANCY (LOWER PART)

175

S-SYS AFT (auto) C-SYS

176

TUNING FREQUANCY (HIGHER PART)

POS 86

177

TUNING FREQUANCY (LOWER PART)

178

S-SYS AFT (auto) C-SYS

179

TUNING FREQUANCY (HIGHER PART)

POS 87

17A

TUNING FREQUANCY (LOWER PART)

17B

S-SYS AFT (auto) C-SYS

17C

TUNING FREQUANCY (HIGHER PART)

POS 88

17D

TUNING FREQUANCY (LOWER PART)

17E

S-SYS AFT (auto) C-SYS

17F

POS 89

MODEL MODEL

LETTER NO. LETTER NO.

MICON EEPROM EEPROM CHASSIS CTV FINAL

LAST INITIAL

SETTING DATA

DEFAULT RANGE

WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE

REMARK

14D2-S/G

13-1 13-2

13

14D1-S/G/W

ADDRESS

DATA

(HEX) D7 D6 D5 D4 D3 D2 D1 D0

180

POS 89

181

182

TUNING FREQUANCY (HIGHER PART)

POS 90

183

TUNING FREQUANCY (LOWER PART)

184

S-SYS AFT (auto) C-SYS

185

TUNING FREQUANCY (HIGHER PART)

POS 91

186

TUNING FREQUANCY (LOWER PART)

187

S-SYS AFT (auto) C-SYS

188

TUNING FREQUANCY (HIGHER PART)

POS 92

189

TUNING FREQUANCY (LOWER PART)

18A

S-SYS AFT (auto) C-SYS

18B

TUNING FREQUANCY (HIGHER PART)

POS 93

18C

TUNING FREQUANCY (LOWER PART)

18D

S-SYS AFT (auto) C-SYS

18E

TUNING FREQUANCY (HIGHER PART)

POS 94

18F

TUNING FREQUANCY (LOWER PART)

190

S-SYS AFT (auto) C-SYS

191

TUNING FREQUANCY (HIGHER PART)

POS 95

192

TUNING FREQUANCY (LOWER PART)

193

S-SYS AFT (auto) C-SYS

194

TUNING FREQUANCY (HIGHER PART)

POS 96

195

TUNING FREQUANCY (LOWER PART)

196

S-SYS AFT (auto) C-SYS

197

TUNING FREQUANCY (HIGHER PART)

POS 97

198

TUNING FREQUANCY (LOWER PART)

199

S-SYS AFT (auto) C-SYS

19A

TUNING FREQUANCY (HIGHER PART)

POS 98

19B

TUNING FREQUANCY (LOWER PART)

19C

S-SYS AFT (auto) C-SYS

19D

TUNING FREQUANCY (HIGHER PART)

POS 99

19E

TUNING FREQUANCY (LOWER PART)

19F

S-SYS AFT (auto) C-SYS

1A0

AV1

1A1

1A2

(auto) C-SYS

1A3

AV2

1A4

1A5

(auto) C-SYS

1A6

1A7

1A8

1A9

1AA

1AB

1AC

1AD

1AE

1AF

1B0

1B1

1B2

1B3

1B4

1B5

1B6

1B7

1B8

1B9

1BA

1BB

1BC

1BD

1BE

1BF

MODEL MODEL

LETTER NO. LETTER NO.

TUNING FREQUANCY (LOWER PART)

S-SYS AFT (auto) C-SYS

MICON EEPROM EEPROM CHASSIS CTV FINAL

LAST INITIAL

SETTING DATA

DEFAULT RANGE

WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE

REMARK

ADDRESS

DATA

MICON EEPROM EEPROM CHASSIS CTV FINAL

LAST INITIAL

SETTING DATA

(HEX) D7 D6 D5 D4 D3 D2 D1 D0

DEFAULT RANGE

WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE

REMARK

1C0

1C1

1C2

1C3

1C4

1C5

1C6

1C7

1C8

1C9

1CA

1CB

1CC

1CD

1CE

1CF

1D0

1D1

1D2

1D3

1D4

1D5

1D6

1D7

1D8

1D9

1DA

1DB

1DC

1DD

1DE

1DF

1E0

1E1

1E2

1E3

1E4

1E5

1E6

1E7

1E8

1E9

1EA

1EB

1EC

1ED

1EE

1EF

1F0

1F1

1F2

1F3

1F4

1F5

1F6

1F7

1F8

1F9

1FA

1FB

1FC

1FD

1FE

1FF

MODEL MODEL

LETTER NO. LETTER NO.

14D2-S/G

14-1 14-2

14

14D1-S/G/W

TROUBLE SHOOTING TABLE

NO RASTER

Blown out.

Replace the fuse.

Check IC701, D701 and

C705.

The fuse is again blown out.

Does horizontal circuit

oscillate ?

Check Q752 and IC801.

D1001 (Power LED Red

dimly) turns on or turns

ON/OFF.

Check T701 pin (11) voltage

(Approx. 310V at 220V AC)

Check F701.

Check Secondary Main+B

(Approx. 130V)

Check CRT connector

K1-K5 bias.

Check

C878.

Check

IC801.

Checking the

protector circuit.

Check R618 and R619.

D1001 (Power LED Red

brightly) turns on.

Check D751

Check R701 and R707

14D2-S/G

15-1 15-2

15

14D1-S/G/W

TROUBLE SHOOTING TABLE (Continued)

NO PICTURE, NO SOUND

Does noise signal appear at

pin (44) of IC801 ?

NO SOUND

No snow noise.

Does noise or signal appear at pin (40)

of IC801 ?

Noise increases but no signal is

received.

Check the tuner supply voltage LB must

be approx. 5V. BT must be approx, 32V.

And CH preset data check.

Check the tuner AGC

(TP201).

Does noise or

signal appear at

pin (38) of IC801 ?

Check IC801 and

its related circuit.

Does noise or

signal appear at

pins (23) and

(24)of IC801.

Check Q251, Q252

and related circuit.

Check pin (37)of

IC801 and related

circuit.

Check pin (1) of

SF201 and Tuner

related circuit.

Check IC801.

Check C356,

C359 and

peripheral circuit.

Check pin (27) of

IC801, Tuner and

related circuit.

Check pin(38) of

IC801.

Does the noise level increase at max.

Contrast, Brightness and Sound controls ?

CIRCUITS TO BE CHECKED:

» Tuner.

» PIF.

» Automatic Gain Control.

» (5V), (32V) Power Source.

CIRCUITS TO BE CHECKED:

» Sound system pins (28), (29)

and (44) of IC801.

» Sound Detector Circuit.

» Sound Switch and Att.

Control.

» Audio Output Circuit.

Does signal appear at pins

(2) and (4) of IC302 ?

Check P302,P303 connector

of IC302 and peripheral

circuit.

Check Q321, pins(4) and (6)

of IC801 and peripheral

circuit.

Does signal appear at pins(28)

and (29) of IC801?

TROUBLE SHOOTING TABLE

(Continued)

NEITHER VERTICAL NOR

HORIZONTAL SYNCHRONIZATION

CIRCUIT TO BE CHECKED:

» Sync. Separator Circuit.

NO VERTICAL SCAN

Vertical linearity and size is

abnormal.

Check pins(33) and (34) of

IC801.

DEFECTIVE VERTICAL AMP.

AND VERTICAL LINEARITY

Readjust vertical size.

(Bas Data)

Check IC501.

Check C505 and C509.

Check IC501.

Check R501, R503, R512,

R521, R533 and C533.

14D2-S/G

16

16-1 16-2

14D1-S/G/W

TROUBLE SHOOTING TABLE

(Continued)

NO SPECIFIC COLOUR

Is some colour produced in

B/W broadcast reception ?

Is the white balance properly

adjusted ?

Readjust the white balance.

The picture colour is yellow.

The picture colour is magenta.

The picture colour is cyan.

Check Q871, Q883 and their

adjacent circuits.

Check Q870, Q885 and their

adjacent circuits.

Check Q872, Q887 and their

adjacent circuits.

Check IC801 and bias

control circuit.

NO SPECIFIC COLOUR

“PAL”/“SECAM”

(NO COLOUR SYNCHRONIZATION)

Check IC801, R801, R802,

R803, D804, D805, D806

and Q801.

Check X1001.(12MHz)

14D2-S/G

17

17-1 17-2

14D1-S/G/W 14D2-S/G

WAVEFORMS(14D1-S/G/W)

1) 1.0 Vp-p 3) 3.10 Vp-p (H) 4) 3.10 Vp-p (H)2) 3.00 Vp-p (H)

6) 78.4 Vp-p (H)

5) 70.0 Vp-p (H)

8) 3.2 Vp-p (H) 9) 2.32 Vp-p (H) 10) 122 Vp-p (H)7) 79.2 Vp-p (H)

11) 8.8 Vp-p (H) 13) 110 Vp-p (H) 14) 1100Vp-p (H) 15) 480 Vp-p (H)12) 50 Vp-p (H)

16) 28 Vp-p (H) 17) 2.08 Vp-p (H)

18

WAVEFORMS(14D2-S/G)

14D1-S/G/W 14D2-S/G

1) 1.0 Vp-p 3) 3.10 Vp-p (H) 4) 3.10 Vp-p (H)2) 3.00 Vp-p (H)

6) 78.4 Vp-p (H)

5) 70.0 Vp-p (H)

8) 3.2 Vp-p (H) 9) 2.32 Vp-p (H) 10) 122 Vp-p (H)7) 79.2 Vp-p (H)

11) 8.8 Vp-p (H) 13) 110 Vp-p (H) 14) 1.1 kVp-p (H) 15) 480 Vp-p (H)12) 50 Vp-p (H)

16) 28 Vp-p (H) 17) 2.08 Vp-p (H)

19

14D1-S/G/W 14D2-S/G

SOLID STATE DEVICE BASE DIAGRAM

TOP VIEW

85

1

4

CAT24W04 (BR24C04) (M24C04W)

64 33

132

IX3368CE

SIDE VIEW

BASE COLLECTOR EMITTER

TX0110BM TX0124BM 2SC3198

BASE COLLECTOR EMITTER

2SC3207

COLLECTOR

ZR

BASE EMITTER

D601A

COLLECTOR

:BR:

BASE EMITTER

B709A

+ ~ ~ -

DX0111PE

BCE

PX0013PE

2SD2586

STRG5653

CATHODE ANODE (RED)

135

24

AN5522

123

19

AN7523

KA7808A

9

20

MODEL 14D1-S/G/W CHASSIS LAYOUT

14D1-S/G/W 14D2-S/G

21

14D1-S/G/W 14D2-S/G

MODEL 14D2-S/G CHASSIS LAYOUT

22

BLOCK DIAGRAM:CRT UNIT

14D1-S/G/W 14D2-S/G

BLOCK DIAGRAM:HEADPHONE UNIT

23

14D1-S/G/W 14D2-S/G

24~25

MODEL 14D1-S/G/W BLOCK DIAGRAM:MAIN UNIT

14D1-S/G/W 14D2-S/G

26~27

MODEL 14D2-S/G BLOCK DIAGRAM:MAIN UNIT

14D1-S/G/W 14D2-S/G

DESCRIPTION OF SCHEMATIC DIAGRAM

SAFETY NOTES:

1. DISCONNECT THE AC PLUG FROM THE AC OUTLET BEFORE REPLACING PAR TS.

2. SEMICONDUCTOR HEAT SINKS SHOULD BE REGARDED AS POTENTIAL SHOCK HAZARDS WHEN THE CHASSIS IS OP-

ERATING.

IMPORTANT SAFETY NOTICE:

PARTS MARKED WITH " å " ( ) ARE IMPOTANT FOR MAINT AINING THE SAFETY OF THE SET. BE SURE TO REPLACE THESE PARTS WITH SPECIFIED ONES FOR MAINTAINING THE SAFETY AND PERFORMANCE OF THE SET.

SERVICE PRECAUTION:

THE AREA ENCLOSED BY THIS LINE ( CONNECTED WITH AC MAINS VOLTAGE. WHEN SERVICING THE AREA, CONNECT AN ISOLA TING TRANSFORMER BETWEEN TV RECEIVER AND AC LINE TO ELIMINATE HAZARD OF ELECTRIC SHOCK.

—– - —–

) IS DIRECTLY

NOTES:

1. The unit of resistance "ohm" is omitted. (K = 1000 ohms, M = Mega ohm).

2. All resistors are 1/10 watt, unless otherwise noted.

3. All capacitors are µF, unless otherwise noted. (P = µµF).

VOLTAGE MEASUREMENT CONDITIONS:

1. Voltages in parenthesis measured with no signal.

2. Voltages without parenthesis measured with 3mV B & W or Colour signal.

3. All the voltages in each point are measured with VTVM.

WAVEFORM MEASUREMENT CONDITIONS:

1. The colour bar generator signal of 2.0V peak applied at of Base Video Buffer Amp. Q252.

2. Approximately 4V AGC bias .

28

SCHEMATIC DIAGRAM:CRT UNIT

J

I

H

G

14D1-S/G/W 14D2-S/G

F

SCHEMATIC DIAGRAM:HEADPHONE UNIT

E

D

C

B

A

12345678910

29

14D1-S/G/W 14D2-S/G

30~31

1234567891011 12 13 14 15 16 17 18 19 20

A

B

C

D

E

F

G

H

I

J

SCHEMATIC DIAGRAM:MAIN UNIT

(14D1-S/G/W)

14D1-S/G/W 14D2-S/G

1234567891011 12 13 14 15 16 17 18 19 20

A

B

C

D

E

F

G

H

I

J

32~33

SCHEMATIC DIAGRAM:MAIN UNIT

(14D2-S/G)

14D1-S/G/W 14D2-S/G

1234567891011 12 13 14 15 16 17 18 19 20

A

B

C

D

E

F

G

H

I

J

34~35

PWB-A: MAIN UNIT (WIRING SIDE)

PRINTED WIRING BOARD ASSEMBLIES

14D1-S/G/W 14D2-S/G

1234567891011 12 13 14 15 16 17 18 19 20

A

B

C

D

E

F

G

H

I

J

36~37

PWB-A: MAIN UNIT (Chip Parts Side)

14D1-S/G/W 14D2-S/G

J

I

H

G

PWB-B: CRT UNIT (WIRING SIDE)

F

E

PWB-B: CRT UNIT (Chip Parts Side)

D

C

PWB-C: HEADPHONE UNIT (WIRING SIDE)

B

RJ62

R370

RJ61

R371

RJ60

A

PWB-B: HEADPHONE UNIT (Chip Parts Side)

12345678910

38

Ref. No. Part No. ★ Description Code

REPLACEMENT PARTS LIST

PARTS REPLACEMENT

Replacement parts which have these special safety characteristics are identified in this manual; electrical components having such features are identified by "å" in the Replacement Parts Lists. The use of a substitute replacement part which does not have the same safety characteristics as the factory recommended replacement parts shown in this service manual may create shock, fire or other hazards.

"HOW TO ORDER REPLACEMENT PARTS"

To have your order filled promptly and correctly, please furnish the following informations.

1. MODEL NUMBER 2. REF. NO.

3. PART NO. 4. DESCRIPTION

MARK : SPARE PARTS-DELIVERY SECTION.

Ref. No. Part No. ★ Description Code

PICTURE TUBE

å VB37GDA86X/1E R Picture Tube CB å RCiLG0095PEZZ R Degaussing Coil AH å DY601 RCiLH0225PEZZ R Deflection Yoke AX

PWB-A DUNTKB508WEA4 - Main Unit (14D1-S/G) — PWB-A DUNTKB508WEA5 - Main Unit (14D2-S/G) — PWB-A DUNTKB508WEA8 - Main Unit (14D1-W) — PWB-B DUNTKB509WEA4 - CRT Unit (14D1-S/G) — PWB-B DUNTKB509WEA5 - CRT Unit (14D2-S/G) — PWB-B DUNTKB509WEA8 - CRT Unit (14D1-W) — PWB-C DUNTKB510WEA3 - Headphone Unit —

PMAGF3045CEZZ R Magnet AG QEARC1422PEZZ R Ground-part AD

PRINTED WIRING BOARD ASSEMBLIES

(NOT REPLACEMENT ITEM)

14D1-S/G/W 14D2-S/G

Ref. No. Part No. ★ Description Code

DUNTKB508WEA4(14D1-S/G) DUNTKB508WEA5(14D1-S/G) DUNTKB508WEA8(14D1-W)

PWB-A MAIN UNIT

TUNER

å TU201 VTUCTF5511+++ R VHF Tuner AZ

INTEGRATED CIRCUITS

IC302 VHiAN7523++-1 R AN7523 AH

å IC501 VHiAN5522++-1 R AN5522 AH

IC601 VHiKA7808AP-1 R KIA7808API AE IC701 VHiSTRG5653-1 R STR-G5653 AQ IC801 RH-iX3368CEN6 R I.C. BE IC1005 VHiCAT24W04-1 R I.C. AE

TRANSISTORS

Q251 VS2SD601A//-1Y R 2SD601A(14D1-S/G/W) AC Q251 VS2PD601AR/-1Y R 2PD601AR(14D2-S/G) AB Q252 VS2PC1815G+-1+ R 2PC1815G AC Q302 VS2SD601A//-1Y R 2SD601A (14D1-S/G/W) AC Q302 VS2PD601AR/-1Y R 2PD601AR (14D2-S/G) AB Q321 VS2SD601A//-1Y R 2SD601A (14D1-S/G/W) AC Q321 VS2PD601AR/-1Y R 2PD601AR (14D2-S/G) AB Q352 VS2SD601A//-1Y R 2SD601A (14D1-S/G/W) AC Q352 VS2PD601AR/-1Y R 2PD601AR (14D2-S/G) AB Q501 VS2PC1815G+-1+ R 2PC1815G AC Q601 VS2SC3207//-1+ R 2SC3207 AC Q602 VS2SD2586//1E R 2SD2586 AM Q603 VS2PC1815G+-1+ R 2PC1815G AC Q751 VS2PC1815G+-1+ R 2PC1815G AC Q752 VS2PC1815G+-1+ R 2PC1815G AC Q801 VS2SB709A//-1Y R 2SB709A (14D1-S/G/W) AA Q801 VS2PB709AR/-1Y R 2PB709AR (14D2-S/G) AB Q802 VS2SB709A//-1Y R 2SB709A (14D1-S/G/W) AA Q802 VS2PB709AR/-1Y R 2PB709AR (14D2-S/G) AB Q804 VS2PD601AR/-1Y R 2PD601AR AB Q1010 VS2SD601A//-1Y R 2SD601A (14D1-S/G/W) AC Q1010 VS2PD601AR/-1Y R 2PD601AR (14D2-S/G) AB

DIODES AND LED’S

D201 RH-EX0676GEZZY R Zener Diode 32.5V AA D203 RH-DX0045GEZZY R Diode AA D301 VHD1SS119//-1Y R 1SS119 AA D302 VHD1SS119//-1Y R 1SS119 AA D331 RH-DX0302CEZZY R Diode (14D1-S/G/W) AC D332 RH-DX0445CEZZ R Diode (14D2-S/G) AL D503 RH-DX0045GEZZY R Diode AA D505 RH-DX0441CEZZY R Diode AC D506 RH-EX0630GEZZY R Zener Diode 9V AA D507 RH-DX0045GEZZY R Diode AA D508 RH-DX0131CEZZY R Diode AC D509 RH-EX0660GEZZY R Zener Diode 22.2V AB D531 RH-EX0627GEZZY R Zener Diode 8.2V AA D532 RH-EX0627GEZZY R Zener Diode 8.2V AA D601 RH-DX0048GEZZY R Diode AA D602 VHD1SS244//-1Y R 1SS244 AB D603 RH-EX0667GEZZY R Zener Diode 26.3V AA D604 VHD1SS119//-1Y R 1SS119 AA D606 RH-DX0131CEZZY R Diode AC D607 RH-DX0045GEZZY R Diode AA D608 RH-DX0468CEZZ R Diode AE D651 RH-EX0627GEZZY R Zener Diode 8.2V AA D652 RH-EX0253TAZZY R Zener Diode AC D653 RH-DX0045GEZZY R Diode AA D701 RH-DX0111PEZZ R Diode AG D705 VHD1SS82///1AY R 1SS82 AC D706 VHD1SS82///1AY R 1SS82 AC D707 VHD1SS82///1AY R 1SS82 AC D751 RH-DX0229CEZZ R Diode AF D752 RH-DX0131CEZZY R Diode AC D754 RH-EX0616GEZZY R Zener Diode 5.9V AA D755 RH-EX0603GEZZY R Zener Diode 4V AA D801 VHD1SS119//-1Y R 1SS119 AA

39

14D1-S/G/W 14D2-S/G

Ref. No. Part No. ★ Description Code

D802 RH-DX0045GEZZY R Diode AA D803 RH-DX0045GEZZY R Diode AA D804 RH-DX0045GEZZY R Diode AA D805 RH-DX0045GEZZY R Diode AA D806 RH-DX0045GEZZY R Diode AA D808 RH-EX0610GEZZY R Zener Diode 4.9V AA D1001 RH-PX0013PEZZ R PhotoDiode AC D1003 VHD1SS119//-1Y R 1SS119 AA D1004 VHD1SS119//-1Y R 1SS119 AA D1007 RH-EX0263TAZZY R Zener Diode AC D1012 RH-EX0611GEZZY R Zener Diode 5V AA D1018 RH-EX0263TAZZY R Zener Diode AC D1019 RH-EX0263TAZZY R Zener Diode AC D1024 VHD1SS119//-1Y R 1SS119 AA

å VA701 RH-VX0073CEZZ R Varistor AD

PR702 RMPTP0028CEZZ R Packaged Circuit AG X1001 RCRSB0300CEZZ R Crystal AF

CF251 RFiLC0318CEZZ R Filter AG CF252 RFiLC0465CEZZ R Filter AD L202 VP-DF270K0000Y R Peaking 27µHAB L203 VP-DF270K0000Y R Peaking 27µHAB L251 VP-XF100K0000Y R Peaking 10µHAB L252 VP-XF6R8K0000Y R Peaking 6.8µHAB

å L701 RCiLF0096PEZZ R Coil AF

L751 RCiLP0225CEZZ R Coil AF L802 VP-DF100K0000Y R Peaking 10µHAB L803 VP-DF100K0000Y R Peaking 10µHAB L1030 VP-DF100K0000Y R Peaking 10µHAB L1050 VP-DF100K0000Y R Peaking 10µHAB L1051 VP-DF100K0000Y R Peaking 10µHAB SF201 RFiLC0442CEZZ R Filter AL

å T601 RTRNZ0144PEZZ R Transformer AE å T602 RTRNF0228PEZZ R H-Volt Transformer AX å T701 RTRNW0015PEZZ R Transformer AL

C201 VCEA0A1CW476M+R 47 16V Electrolytic AB C202 VCEA0A1AW337M+ R 330 10V Electrolytic AC C203 VCKYCY1HF103Z R 0.01 50V Ceramic AA C204 VCEA0A0JW477M+ R 470 6.3V Electrolytic AC C205 VCKYCY1HF103Z R 0.01 50V Ceramic AA C206 VCEA0A1HW106M+R 10 50V Electrolytic AB C231 VCKYCY1HF223Z R 0.022 50V Ceramic AB C232 VCKYCY1HB821K R 820p 50V Ceramic AA C233 VCKYCY1HB472K R 4700p 50V Ceramic AA C234 VCKYCY1EF104Z R 0.1 25V Ceramic AA C251 VCKYCY1HF223Z R 0.022 50V Ceramic AB C252 VCEA0A1CW107M+R 100 16V Electrolytic AC C301 VCEA0A1CW477M+R 470 16V Electrolytic AC C304 VCEA0A1CW106M+R 10 16V Electrolytic AB C306 VCEA0A1CW106M+R 10 16V Electrolytic AB C310 VCEA0A1HW105M+R 1 50V Electrolytic AB C311 VCEA0A1HW105M+R 1 50V Electrolytic AB C312 VCEA0A1HW224M+R 0.22 50V Electrolytic AB C316 VCEA0A1CW107M+R 100 16V Electrolytic AC C331 VCKYPA2HB102K+ R 1000p 500V Ceramic AA C332 RC-QZA103TAYJ+ R 0.01 50V C333 VCEA0A1CW108M R 1000 16V Electrolytic AD C352 VCEA0A1HW105M+R 1 50V Electrolytic AB C354 VCEA0A1HW105M+R 1 50V Electrolytic AB C356 VCKYCY1HB472K R 4700p 50V Ceramic AA C359 VCEA0A1CW106M+R 10 16V Electrolytic AB C360 VCE9GA1HW225M+R 2.2 50V Elect.(N,P) AB C409 VCKYCY1CF474Z R 0.47 16V Ceramic AB C410 VCKYCY1CF474Z R 0.47 16V Ceramic AB C411 VCKYCY1HB102K R 1000p 50V Ceramic AA C412 VCEA0A1CW477M+R 470 16V Electrolytic AC C501 VCKYPA1HB102K+ R 1000p 50V Ceramic AA C504 VCKYCY1HB103K R 0.01 50V Ceramic AA C505 VCEA0A1HW107M+R 100 50V Electrolytic AB C507 VCKYCY1HB103K R 0.01 50V Ceramic AA C508 VCFYSA1JB224J+ R 0.22 63V Mylar AD

PACKAGED CIRCUITS

COILS AND TRANSFORMER

CAPACITORS

M.Polyester Film

AB

Ref. No. Part No. ★ Description Code

C509 VCEA0A1CW477M+R 470 16V Electrolytic AC C510 VCKYPA2HB102K+ R 1000p 500V Ceramic AA C514 VCFYSA1JB563J+ R 0.056 63V Mylar AD C529 VCKYCY1CB823KY R 0.082 16V Ceramic AH C531 VCKYCY1HB102K R 1000p 50V Ceramic AA C532 VCKYCY1HB102K R 1000p 50V Ceramic AA C533 RC-QZA104TAYJ+ R 0.1 50V C601 RC-QZA563TAYJ+ R 0.056 50V C602 VCEA0A1HW475M+R 4.7 50V Electrolytic AB C603 VCEA0A1HW105M+R 1 50V Electrolytic AB C604 VCEA0A2EW106M R 10 250V Electrolytic AD C605 VCKYPA2HB102K+ R 1000p 500V Ceramic AA C606 VCFPFA2EB334J R 0.33 250V M.Polypro AD C607 VCFPFD3ZA532H R 5300p 1.8kVM.Polypro AD C608 VCKYPA2HB102K+ R 1000p 500V Ceramic AA C610 VCEA0A1CW108M R 1000 16V Electrolytic AD C611 VCEA0A1EW476M+ R 47 25V Electrolytic AB C612 VCEA0A1CW477M+R 470 16V Electrolytic AC C620 VCKYPA2HB102K+ R 1000p 500V Ceramic AA C640 VCFYSB2EB823J R 0.082 250V C651 VCQYTA1HM222J+ R 2200p 50V Mylar AA C652 RC-QZA472TAYJ+ R 4700p 50V Mylar AB C653 VCEA0A1HW105M+R 1 50V Electrolytic AB C654 VCKYCY1HF223Z R 0.022 50V Ceramic AB C655 VCEA0A1HW106M+R 10 50V Electrolytic AB C656 VCEA0A1HW474M+R 0.47 50V Electrolytic AB C657 VCKYCY1EF104Z R 0.1 25V Ceramic AA C658 VCKYCY1EF104Z R 0.1 25V Ceramic AA

å C701 RC-FZ031SCEZZ R 0.1 275V

C702 RC-KZ0029CEZZ+ R 0.01 250V Ceramic AC C703 RC-KZ0029CEZZ+ R 0.01 250V Ceramic AC C704 RC-KZ0029CEZZ+ R 0.01 250V Ceramic AC C705 RC-EZ1286CEZZ R 150 400V Electrolytic AT C709 RC-KZ0039CEZZ R 680p 2kV Ceramic AB C710 VCEA0A1HW476M+R 47 50V Electrolytic AB C711 VCKYPA1HB102K+ R 1000p 50V Ceramic AA C712 VCKYPA1HB471K+ R 470p 50V Ceramic AA

å C751 RC-KZ0102GEZZ R 680

C752 VCKYPH3DB561K R 560p 2kV Ceramic AC C753 RC-EZ0776CEZZ R 100 160V Electrolytic AF C754 RC-EZA069WJZZ R 33 160V Electrolytic AE C755 VCEA0A1CW108M R 1000 16V Electrolytic AD C756 RC-QZA103TAYJ+ R 0.01 50V C759 VCEA0A0JW477M+ R 470 6.3V Electrolytic AC C760 VCEA0A0JW228M R 2200 6.3V Electrolytic AD C801 VCEA0A1HW105M+R 1 50V Electrolytic AB C803 VCEA0A1CW107M+R 100 16V Electrolytic AC C804 VCKYCY1HB222K R 2200p 50V Ceramic AA C805 VCKYD41HB102KY R 1000p 50V Ceramic AA C806 VCKYD41HB102KY R 1000p 50V Ceramic AA C807 VCKYD41HB102KY R 1000p 50V Ceramic AA C808 VCEA0A1CW107M+R 100 16V Electrolytic AC C809 VCKYCY1CF474Z R 0.47 16V Ceramic AB C810 VCKYCY1CF474Z R 0.47 16V Ceramic AB C811 VCEA0A1CW107M+R 100 16V Electrolytic AC C812 VCFYFA1HA224J+ R 0.22 50V C813 VCFYFA1HA224J+ R 0.22 50V C814 VCKYCY1HB471K R 470p 50V Ceramic AA C816 VCKYCY1HB471K R 470p 50V Ceramic AA C1001 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB C1002 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB C1003 VCEA0A1CW106M+R 10 16V Electrolytic AB C1004 VCKYCY1CF474Z R 0.47 16V Ceramic AB C1005 VCKYCY1CF474Z R 0.47 16V Ceramic AB C1006 VCEA0A1CW106M+R 10 16V Electrolytic AB C1008 VCCCCY1HH330J R 33p 50V Ceramic AA C1009 VCCCCY1HH330J R 33p 50V Ceramic AA C1010 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB C1011 VCKYCY1CF474Z R 0.47 16V Ceramic AB C1012 VCKYCY1CF474Z R 0.47 16V Ceramic AB C1013 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB C1014 VCEA0A1CW106M+R 10 16V Electrolytic AB C1016 RC-QZA104TAYJ+ R 0.1 50V Mylar AB C1018 VCKYCY1HB221K R 220p 50V Ceramic AA C1019 VCEA0A1HW225M+R 2.2 50V Electrolytic AB C1024 RC-QZA104TAYJ+ R 0.1 50V Mylar AB

M.Polyester Film M.Polyester Film

M.Polyester Film

AC250V

Ceramic AE

M.Polyester Film

M.Polyester Film M.Polyester Film

AB AB

AD

AB

AB AB

40

Ref. No. Part No. ★ Description Code

14D1-S/G/W 14D2-S/G

Ref. No. Part No. ★ Description Code

RJ2 VRN-MD2AL000J R 0 1/10W Metal Film AA

RESISTORS

RJ9 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ13 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ14 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ15 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ16 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ17 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ18 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ19 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ24 VRN-MD2AL000J R 0 1/10W Metal Film AA

(14D2-S/G) RJ26 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ28 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ32 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ33 VRN-MD2AL000J R 0 1/10W Metal Film AA

(14D2-S/G) RJ35 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ37 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ38 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ41 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ42 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ43 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ46 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ47 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ49 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ50 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ51 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ52 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ53 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ56 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ71 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ73 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ75 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ76 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ77 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ78 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ83 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ88 VRN-MD2AL000J R 0 1/10W Metal Film AA R217 VRN-MD2AL000J R 0 1/10W Metal Film AA R230 VRN-MD2AL000J R 0 1/10W Metal Film AA R364 VRN-MD2AL000J R 0 1/10W Metal Film AA R366 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ10 VRS-CY1JF000JY R 0 1/16W Metal Oxide AA RJ21 VRS-CY1JF000JY R 0 1/16W Metal Oxide AA R201 VRN-MD2AL101J R 100 1/10W Metal Film AA R202 VRN-MD2AL101J R 100 1/10W Metal Film AA R216 VRS-VV3LB223J R 22k 3W Metal Oxide AB R219 VRD-RA2BE392JY R 3.9k 1/8W Carbon AA R231 VRD-RA2BE681JY R 680 1/8W Carbon AA R232 VRN-MD2AL272J R 2.7k 1/10W Metal Film AA R233 VRN-MD2AL102J R 1k 1/10W Metal Film AA R234 VRN-MD2AL391J R 390 1/10W Metal Film AA R251 VRN-MD2AL181J R 180 1/10W Metal Film AA R252 VRN-MD2AL181J R 180 1/10W Metal Film AA R253 VRD-RA2BE680JY R 68 1/8W Carbon AA R254 VRN-MD2AL560J R 56 1/10W Metal Film AB R255 VRN-MD2AL223J R 22k 1/10W Metal Film AA R256 VRN-MD2AL223J R 22k 1/10W Metal Film AA R262 VRN-MD2AL560J R 56 1/10W Metal Film AB R263 VRN-MD2AL560J R 56 1/10W Metal Film AB R301 VRN-MD2AL101J R 100 1/10W Metal Film AA R302 VRN-MD2AL101J R 100 1/10W Metal Film AA R303 VRN-MD2AL561J R 560 1/10W Metal Film AA R304 VRN-MD2AL100J R 10 1/10W Metal Film AA R305 VRN-MD2AL274J R 270k 1/10W Metal Film AA R310 VRN-MD2AL473J R 47k 1/10W Metal Film AA R311 VRN-MD2AL473J R 47k 1/10W Metal Film AA R313 VRN-MD2AL102J R 1k 1/10W Metal Film AA R314 VRN-MD2AL472J R 4.7k 1/10W Metal Film AA R315 VRN-MD2AL272J R 2.7k 1/10W Metal Film AA R316 VRN-MD2AL272J R 2.7k 1/10W Metal Film AA R318 VRD-RA2BE680JY R 68 1/8W Carbon AA R334 VRN-MD2AL332J R 3.3k 1/10W Metal Film AA R335 VRS-CY1JF564JY R 560k 1/16W Metal Oxide AA R352 VRN-MD2AL681J R 680 1/10W Metal Film AA

R359 VRN-MD2AL102J R 1k 1/10W Metal Film AA R360 VRN-MD2AL103J R 10k 1/10W Metal Film AA R361 VRN-MD2AL104J R 100k 1/10W Metal Film AA R431 VRN-MD2AL101J R 100 1/10W Metal Film AA R432 VRN-MD2AL820J R 82 1/10W Metal Film AA R458 VRN-MD2AL103J R 10k 1/10W Metal Film AA R459 VRD-RA2BE680JY R 68 1/8W Carbon AA R501 VRD-RA2BE272JY R 2.7k 1/8W Carbon AA R502 VRD-RM2HD102JY R 1k 1/2W Carbon AA R503 VRN-VV3AB2R7J R 2.7 1W Metal Film AA R504 VRN-MD2AL181J R 180 1/10W Metal Film AA R505 VRN-MD2AL102J R 1k 1/10W Metal Film AA R506 VRS-VV3AB331J R 330 1W Metal Oxide AA R507 VRN-VV3AB1R0J R 1 1W Metal Film AA R508 VRD-RA2BE153JY R 15k 1/8W Carbon AA R509 VRD-RA2BE153JY R 15k 1/8W Carbon AA R511 VRN-MD2AL181J R 180 1/10W Metal Film AA R512 VRD-RM2HD5R6JY R 5.6 1/2W Carbon AA R521 VRD-RA2BE333JY R 33k 1/8W Carbon AA R529 VRD-RA2BE223JY R 22k 1/8W Carbon AA R530 VRS-CY1JF334JY R 330k 1/16W Metal Oxide AA R531 VRN-MD2AL101J R 100 1/10W Metal Film AA R532 VRN-MD2AL101J R 100 1/10W Metal Film AA R533 VRD-RA2BE393JY R 39k 1/8W Carbon AA R601 VRS-SV2HC102J R 1k 1/2W Metal Oxide AA R602 VRD-RA2BE393JY R 39k 1/8W Carbon AA R603 VRD-RA2BE273JY R 27k 1/8W Carbon AA R604 VRD-RA2BE563JY R 56k 1/8W Carbon AA R605 VRD-RM2HD124JY R 120k 1/2W Carbon AA R606 VRN-VV3AB1R5J R 1.5 1W Metal Film AA R607 VRD-RM2HD270JY R 27 1/2W Carbon AA R609 VRD-RA2BE154JY R 150k 1/8W Carbon AA R610 VRD-RA2BE102GY R 1k 1/8W Carbon AB R611 VRN-MD2AL102J R 1k 1/10W Metal Film AA R612 VRN-MD2AL123J R 12k 1/10W Metal Film AA R613 VRN-MD2AL103J R 10k 1/10W Metal Film AA R614 VRS-SV2HC150J R 15 1/2W Metal Oxide AA R615 VRS-VV3DB682J R 6.8k 2W Metal Oxide AA R616 VRN-VV3ABR47J R 0.47 1W Metal Film AA R618 VRS-VV3DB391J R 390 2W Metal Oxide AA R619 VRS-VV3LB103J R 10k 3W Metal Oxide AB R620 VRS-VV3AB472J R 4.7k 1W Metal Oxide AA R622 VRD-RA2BE102JY R 1k 1/8W Carbon AA R623 VRD-RM2HD184JY R 180k 1/2W Carbon AA R624 VRN-MD2AL472J R 4.7k 1/10W Metal Film AA R625 VRN-VV3DB8R2J R 8.2 2W Metal Film AB R626 VRD-RM2HD470JY R 47 1/2W Carbon AA R633 VRD-RA2BE333JY R 33k 1/8W Carbon AA R634 VRD-RA2BE103JY R 10k 1/8W Carbon AA R641 VRN-SV2HCR47J R 0.47 1/2W Metal Film AA R651 VRN-MD2AL223J R 22k 1/10W Metal Film AA R652 VRN-MD2AL102J R 1k 1/10W Metal Film AA R653 VRN-MD2AL822J R 8.2k 1/10W Metal Film AA R654 VRN-MD2AL273J R 27k 1/10W Metal Film AA R655 VRN-MD2AL391J R 390 1/10W Metal Film AA R656 VRN-MD2AL100J R 10 1/10W Metal Film AA R658 VRD-RA2BE101JY R 100 1/8W Carbon AA R663 VRD-RA2BE101JY R 100 1/8W Carbon AA R701 VRW-KQ3NC3R9K R 3.9 7W Cement AE R707 VRS-VV3DB104J R 100k 2W Metal Oxide AB R708 VRD-RA2BE681JY R 680 1/8W Carbon AA R709 VRN-VV3DBR47J R 0.47 2W Metal Film AB R710 VRN-VV3DBR56J R 0.56 2W Metal Film AA

(14D1-S/G/W)

R710 VRN-VV3DBR47J R 0.47 2W Metal Film AB

(14D2-S/G) R711 VRD-RA2BE682JY R 6.8k 1/8W Carbon AA R712 VRD-RA2BE152JY R 1.5k 1/8W Carbon AA R716 VRD-RA2BE562JY R 5.6k 1/8W Carbon AA

å R751 VRC-UA2HG825KY R 8.2M 1/2W Solid AA å R752 VRC-UA2HG825KY R 8.2M 1/2W Solid AA

R753 VRD-RM2HD124JY R 120k 1/2W Carbon AA R754 VRD-RM2HD150JY R 15 1/2W Carbon AA R755 VRD-RA2BE221JY R 220 1/8W Carbon AA R756 VRD-RM2HD270JY R 27 1/2W Carbon AA R757 VRN-MD2AL151J R 150 1/10W Metal Film AA R801 VRN-MD2AL221J R 220 1/10W Metal Film AA

41

14D1-S/G/W 14D2-S/G

Ref. No. Part No. ★ Description Code

R802 VRN-MD2AL221J R 220 1/10W Metal Film AA R803 VRN-MD2AL221J R 220 1/10W Metal Film AA R804 VRN-MD2AL221J R 220 1/10W Metal Film AA R805 VRN-MD2AL822J R 8.2k 1/10W Metal Film AA R806 VRN-MD2AL123J R 12k 1/10W Metal Film AA R807 VRN-MD2AL103J R 10k 1/10W Metal Film AA R808 VRN-MD2AL221J R 220 1/10W Metal Film AA R809 VRD-RA2BE224JY R 220k 1/8W Carbon AA R812 VRN-MD2AL101J R 100 1/10W Metal Film AA R813 VRN-MD2AL221J R 220 1/10W Metal Film AA R1001 VRN-MD2AL221J R 220 1/10W Metal Film AA R1002 VRN-MD2AL331J R 330 1/10W Metal Film AA R1003 VRN-MD2AL471J R 470 1/10W Metal Film AA R1004 VRN-MD2AL821J R 820 1/10W Metal Film AA R1005 VRN-MD2AL181J R 180 1/10W Metal Film AA R1011 VRN-MD2AL101J R 100 1/10W Metal Film AA R1012 VRD-RA2BE271JY R 270 1/8W Carbon AA R1013 VRD-RA2BE101JY R 100 1/8W Carbon AA R1014 VRN-MD2AL101J R 100 1/10W Metal Film AA R1015 VRN-MD2AL332J R 3.3k 1/10W Metal Film AA R1016 VRN-MD2AL101J R 100 1/10W Metal Film AA R1017 VRN-MD2AL332J R 3.3k 1/10W Metal Film AA R1019 VRN-MD2AL392J R 3.9k 1/10W Metal Film AA R1020 VRN-MD2AL101J R 100 1/10W Metal Film AA R1021 VRN-MD2AL153J R 15k 1/10W Metal Film AA R1022 VRN-MD2AL101J R 100 1/10W Metal Film AA R1023 VRN-MD2AL101J R 100 1/10W Metal Film AA R1024 VRN-MD2AL122J R 1.2k 1/10W Metal Film AA R1025 VRN-MD2AL101J R 100 1/10W Metal Film AA R1026 VRN-MD2AL224J R 220k 1/10W Metal Film AA R1028 VRN-MD2AL101J R 100 1/10W Metal Film AA R1030 VRN-MD2AL102J R 1k 1/10W Metal Film AA R1031 VRD-RA2BE562JY R 5.6k 1/8W Carbon AA R1032 VRN-MD2AL332J R 3.3k 1/10W Metal Film AA R1034 VRN-MD2AL101J R 100 1/10W Metal Film AA R1035 VRN-MD2AL332J R 3.3k 1/10W Metal Film AA R1036 VRN-MD2AL332J R 3.3k 1/10W Metal Film AA R1037 VRN-MD2AL101J R 100 1/10W Metal Film AA R1038 VRN-MD2AL101J R 100 1/10W Metal Film AA R1039 VRN-MD2AL223J R 22k 1/10W Metal Film AA R1040 VRN-MD2AL101J R 100 1/10W Metal Film AA R1041 VRN-MD2AL101J R 100 1/10W Metal Film AA R1042 VRD-RA2BE101JY R 100 1/8W Carbon AA R1046 VRN-MD2AL101J R 100 1/10W Metal Film AA R1048 VRS-CY1JF102JY R 1k 1/16W Metal Oxide AA R1050 VRN-MD2AL392J R 3.9k 1/10W Metal Film AA R1051 VRN-MD2AL683J R 68k 1/10W Metal Film AA R1072 VRN-MD2AL101J R 100 1/10W Metal Film AA R1073 VRN-MD2AL101J R 100 1/10W Metal Film AA

SWITCHES

å S702 QSW-P0591CEZZ R Switch AQ

S1001 QSW-K0003AJZZ+ R Switch, CH UP AB S1002 QSW-K0003AJZZ+ R Switch, CH DOWN AB S1003 QSW-K0003AJZZ+ R Switch, VOL UP AB S1004 QSW-K0003AJZZ+ R Switch, VOL DOWN AB S1005 QSW-K0003AJZZ+ R Switch, PICTURE/PRESET AB

MISCELLANEOUS PARTS

å ACC701 QACCB5003PEZZ R AC Cord (14D1-W) AY å ACC701 QACCZ2008PEZZ R AC Cord (except 14D1-W) AM å F701 QFS-C3229CEZZ R Fuse, T3.15A/250V AD

FB601 RBLN-0091GEZZY R Ferrite Bead AB

å FH701 QFSHD1013CEZZ+ R Fuse Holder AC å FH702 QFSHD1014CEZZ+ R Fuse Holder AC

J402 QJAKE0210CE04 R Jack, Video AC J403 QJAKE0210CE09 R Jack, Audio AC J409 QJAKHA004WJZZ R Jack, AV-1 IN AE P301 QPLGN0241CEZZ R Plug, 2pin(S) AA

(14D1-S/G/W)

P302 QPLGN0461CEZZ R Plug, 4pin(S) AB

(14D2-S/G)

P303 QPLGN0461CEZZ R Plug, 4pin(HP) AB

(14D1-S/G/W)

P303 QPLGN0561CEZZ R Plug, 5pin(HP) AB

(14D2-S/G)

Ref. No. Part No. ★ Description Code

å P601 QPLGN0660CEZZ R Plug, 6pin(F) AC

P602 LHLDW1104PEZZ R Holder(H) AB P603 QPLGN0341CEZZ R Plug, TP651-3 AA P701 QPLGN0260CEZZ R Plug, 2pin(M) AC

å P702 QPLGN0269GEZZ R Plug, 2pin(M) AB

P1001 LHLDW1105PEZZ R Holder(K) AB P1002 QPLGN0561CEZZ R Plug, 5pin(BC) AB RDA302 PRDAR0341PEFW R Heat Sink for IC302 AD

RDA302 PRDAR0340PEFW R Heat Sink for IC302 AE RDA501 PRDAR0118GJFW R Heat Sink for IC501 AD

RDA701 PRDARA028WJFW R Heat Sink for IC701 AE RMC1001 TP201 QLUGP0102PEZZ R Lug, Test Point AA

RRMCU0222CEZZ R Remote Receiver AL LHLDP1066PE00 R Holder AC

(14D1-S/G/W) (14D2-S/G)

DUNTKB509WEA4(14D1-S/G) DUNTKB509WEA5(14D2-S/G) DUNTKB509WEA8(14D1-W)

PWB-B:CRT UNIT

Q870 RH-TX0110BMZZ+ R TX0110BM AC Q871 RH-TX0110BMZZ+ R TX0110BM AC Q872 RH-TX0110BMZZ+ R TX0110BM AC Q883 RH-TX0124BMZZ+ R TX0124BM AC Q885 RH-TX0124BMZZ+ R TX0124BM AC Q887 RH-TX0124BMZZ+ R TX0124BM AC

D881 VHD1SS244//-1Y R 1SS244 AB D882 VHD1SS244//-1Y R 1SS244 AB D883 VHD1SS244//-1Y R 1SS244 AB D884 VHD1SS119//-1Y R 1SS119 AA D885 VHD1SS119//-1Y R 1SS119 AA D886 VHD1SS82///1AY R 1SS82 AC D887 VHD1SS82///1AY R 1SS82 AC D888 VHD1SS82///1AY R 1SS82 AC

C871 VCCCCY1HH471J R 470p 50V Ceramic AA C872 VCCCCY1HH391J R 390p 50V Ceramic AA C873 VCCCCY1HH471J R 470p 50V Ceramic AA C875 VCKYPA2HB102K+ R 1000p 500V Ceramic AA C876 RC-KZ0150CEZZ R 1000p C878 VCEA0A2EW106M+ R 10 250V Electrolytic AD C880 VCCCCY1HH471J R 470p 50V Ceramic AA C881 VCKYPA1HB471K+ R 470p 50V Ceramic AA C882 VCKYPA1HB471K+ R 470p 50V Ceramic AA C886 VCKYPA2HB102K+ R 1000p 500V Ceramic AA

R879 VRN-MD2AL471J R 470 1/10W Metal Film AA R880 VRN-MD2AL471J R 470 1/10W Metal Film AA R881 VRN-MD2AL471J R 470 1/10W Metal Film AA R882 VRS-VV3DB153J R 15k 2W Metal Oxide AA R883 VRD-RM2HD272JY R 2.7k 1/2W Carbon AA R884 VRS-VV3DB153J R 15k 2W Metal Oxide AA R885 VRD-RM2HD272JY R 2.7k 1/2W Carbon AA R886 VRS-VV3DB153J R 15k 2W Metal Oxide AA R887 VRD-RM2HD272JY R 2.7k 1/2W Carbon AA R888 VRN-MD2AL471J R 470 1/10W Metal Film AA R892 VRN-MD2AL102J R 1k 1/10W Metal Film AA R893 VRN-MD2AL102J R 1k 1/10W Metal Film AA R894 VRN-MD2AL102J R 1k 1/10W Metal Film AA R898 VRN-MD2AL471J R 470 1/10W Metal Film AA R899 VRN-MD2AL471J R 470 1/10W Metal Film AA

å SC881 QSOCV0017PEZZ R Socket AF

P882 LHLDW1105PEZZ R Holder(K) AB P884 LHLDW1104PEZZ R Holder(H) AB

TRANSISTORS

DIODES

CAPACITORS

3.15kV

Ceramic AB

RESISTORS

MISCELLANEOUS PARTS

42

Ref. No. Part No. ★ Description Code

14D1-S/G/W 14D2-S/G

Ref. No. Part No. ★ Description Code

DUNTKB510WEA3

PWB-C HEADPHONE UNIT

RESISTORS

RJ60 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ61 VRN-MD2AL000J R 0 1/10W Metal Film AA RJ62 VRN-MD2AL000J R 0 1/10W Metal Film AA R370 VRN-MD2AL471J R 470 1/10W Metal Film AA R371 VRN-MD2AL471J R 470 1/10W Metal Film AA

MISCELLANEOUS PARTS

J351 QJAKJ0101SEZZ R Headphone Jack AE P351 QPLGN0461CEZZ R Plug, 4pin AB

MISCELLANEOUS PARTS

SP301 VSP9050PB35WA R Speaker AK SP302 VSP9050PB35WA R Speaker(14D-2S/G) AK

QCNW-2206PEZZ R Connecting Cord AD QCNW-2379PEZZ R Connecting Cord AE QCNW-2380PEZZ R Connecting Cord AG

(14D2-S/G)

QCNW-2452PEZZ R Connecting Cord AE

(14D2-S/G)

QPLGJ0113CEZZ R Plug (except 14D1-W) AG

SUPPLIED ACCESSORIES

RRMCG1342PESA R Infrared RC AU TINS-A340WJZZ R Operation Manual AK

TINS-A365WJZZ R Operation Manual AK TINS-A425WJZZ R Operation Manual AF QANTR0018PEZZ R Rod Antenna AQ TMAPCA013WJZZ R Map (14D2-S/G) AC

TMAPCA014WJZZ R Map (14D1-S/G) AC

ACCESSORIE

TCAUA0002PEZZ - Caution Card —

ACCESSORIES

(14D1-S/G)

(14D2-S/G)

(14D1-W)

(except 14D1-W)

(NOT REPLACEMENT ITEM)

PACKING PARTS

(NOT REPLACEMENT ITEM)

SPAKCA285WJZZ - Packing Case — SPAKCA316WJZZ - Packing Case — SPAKCA317WJZZ - Packing Case — SPAKCA363WJZZ - Packing Case — SPAKCA364WJZZ - Packing Case — SPAKP0056PEZZ - Wrapping Paper — SPAKXA138WJZZ - Packing Foam — SPAKXA163WJZZ - Packing Foam — SSAKA0031PEZZ - Polyethylene Bag —

SSAKH0009PEZZ - Polyethylene Bag — SSAKH0015PEZZ - Polyethylene Bag —

(14D1-S)

(14D2-S)

(14D2-G)

(14D1-G)

(14D1-W)

(14D1-S/G/W)

(14D2-S/G)

(14D1-S/G/W)

(14D2-S/G)

43

14D1-S/G/W 14D2-S/G

Ref. No. Part No. ★ Description Code

CABINET PARTS

1 CCABAA145WEV0 R Top Cabinet Ass'y BC 1 CCABAA178WEV0 R Top Cabinet Ass'y BC 1 CCABAA179WEV0 R Top Cabinet Ass'y BC 1-1

1-2 HBDGB0018PESB R SHARP Badge AD 1-3 JBTN-A067WJSA R CTL Buton AC 1-4 GCOVAA193WJSA R RC/LED Cover AD 1-5 JBTN-A066WJSA R Power Button AC 1-6 MSPRC0005PEFW R Power Button Spring AB 2 CCABBA087WEV0 R Rear Cabinet Ass'y AV 2-1

1 CCABAA149WEV0 R Top Cabinet Ass'y BB 1 CCABAA151WEV0 R Top Cabinet Ass'y BB 1-1

1-2 HBDGB0019PESB R SHARP Badge AD 1-3 JBTN-A028WJSA R CTL Buton (14D2-S) AF 1-3 JBTN-A028WJSB R CTL Buton (14D2-G) AF 1-4 GCOVAA106WJSA R LED/RC Cover AC 1-5 JBTN-A069WJSA R Power Button (14D2-S) AD 1-5 JBTN-A069WJSB R Power Button (14D2-G) AD 1-6 MSPRC0068CEFW R Power Button Spring AA 2 CCABBA096WEV0 R Rear Cabinet Ass'y AX 2-1

Not Available

14D1-S/G/W

(14D1-S) (14D1-G) (14D1-W)

- Top Cabinet —

- Rear Cabinet —

14D2-S/G

(14D2-S) (14D2-G)

- Top Cabinet —

- Rear Cabinet —

CABINET PARTS LOCATION

14D1-S/G/W

14D2-S/G

44

P ACKING OF THE SET

★ Buffer Material

★ Wrapping Paper

14D1-S/G/W 14D2-S/G

★ Polystyrene Bag

Operation Manual ★ Batteries

Infrared Remote Control Unit

★ Serial Number Card

★ Number Card

★ Buffer Material

★ Packing Case

Fix the packing case with 22 staples

Mark ★ : Not Replacement Item

45

14D1-S/G/W 14D2-S/G

Ref. No. Part No. ★ Description Code

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

TQ1431-S

Nov. 2002 Printed in Japan

In Japan gedruckt

Design and Production Information

Design : SEM Production : SREC

MY. DS

SHARP CORPORATION AV Systems Group Quality & Reliability Control Center Yaita, Tochigi 329-2193, Japan

46

Sharp 14D1-S, 14D1-G, 14D1-W, 14D2-S, 14D2-G Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
