The RGB LIT 200 is an ATX midi tower that not only offers effective lighting, but also directs RGB into expressive
paths: In and around the elegant viewing window, an addressable RGB fan mounted on the rear and an
addressable RGB strip provide atmospheric hardware illumination, which is supplemented by an LED strip in
the front. These light sources meet a reflective pattern, which is reminiscent of the conducting paths of a
circuit board, printed on the tempered glass front panel. This creates an expressive eye-catcher - that goes
beyond mere RGB. With a total of six mounting options for fans as well as enough space for radiators, powerful
hardware and up to six SSDs, the case offers both style and substance.
STYLE AND SUBSTANCE
COMBINED
In addition to breathtaking looks, the RGB LIT offers a sophisticated functionality with various cable pass-throughs,
a practical power supply tunnel and dust filters behind each air intake. There is also plenty of space for the
hardware: Graphics cards with a length of up to 35 cm have room, as do CPU coolers with a height of up to 15.7 cm
and power supplies with a maximum length of 21.5 cm.
REFLECTIVE TEMPERED
GLASS FRONT PANEL
The front panel of the RGB LIT 200 is equipped with a large tempered
glass window, printed with a reflective circuitry-like pattern. Together
with the LED strip inside the front panel, the chosen illumination is
distributed over the pattern and the entire front panel, creating a
vibrant, effective look that is not just RGB, but, above all, expressive.
EFFECTIVE HARDWARE
ILLUMINATION
Even though the RGB LIT is visually eccentric, the inner worth is what
really counts. And precisely this can be presented particularly well
through the tempered glass side panel. For even more elegance, we
have designed the side panel so that it is attached to the back of the
case with hardly visible and easy-to-remove thumbscrews. To ensure
that the illumination of the hardware components can keep pace with
the lighting of the front panel, an addressable LED strip is attached
below the tempered glass side window. This provides additional
effects and a complete illumination of the case.
4-PORT ADDRESSABLE
DI G
5
V
DI G
5
V
DI G
V
RESET SW
DI G
5
V
RGB CONTROLLER
Addressable RGB LED
Fans/ Strips
5
V
DI G
DI G
V
5
Addressable RGB LED
Fans/ Strips
Mainboard
Addressable
RGB
Pin Header
DI G
DI G
V
5
+5V D
ADD_HEADER
The RGB LIT 200 comes with a pre-installed addressable
RGB controller. With compatible mainboards, this will function as a hub for controlling and synchronizing up to four
addressable LED components, which will illuminate in up
to 16.8 million colors. The controller is connected to the
5
V
power supply via a SATA connector and to a mainboard via
a 4-pin or 3-pin header for addressable LEDs with the
pinout: 5V-D-coded-G or V-D-G.
SATA
or
V D G
VDG
MANUAL COLOR CONTROL
The RGB LIT 200 also has a manual color control
function for mainboards which do not have
headers for addressable LED components. With
this, the RGB controller is not connected to the
mainboard, but rather connected to the power
supply and the reset switch of the PC case. The
switch’s reset function is then replaced with a
new function which allows up to fourteen lighting
modes to be cycled through and selected, or, if
desired, the lighting can be turned off.
Red Green Blue White Yellow Cyan
RGB
Mode 7
Pink
Addressable RGB LED
Fans/ Strips
5
V
DI G
DI G
5
V
5
V
DI G
DI G
5
V
RESET SW
RGB
Mode 6
RGB
Mode 5
RGB
Mode 4
RGB
Mode 3
RGB
Mode 2
RGB
Mode 1
Addressable RGB LED
Fans/ Strips
SATA
EASY TO INTEGRATE
The RGB LIT 200 case, along with all
other Sharkoon products marked with
the Addressable RGB logo, are certified for Asus Aura Sync, MSI Mystic
Light Sync, Gigabyte Fusion and
ASRock Polychrome SYNC.
MSI ASUS ASROCK ASUSGIGABYTE
Sharkoon products marked with the "ADDRESSABLE RGB" logo are compatible with mainboards which have headers for addressable RGB LED fans
and strips. The headers should have the pin configuration 5V-D-coded-G or
5V-D-G. Examples of these RGB connections from the most important mainboard manufacturers are shown below. The RGB pin configuration is independent of manufacturer. However, the naming and marking of these
connections may vary between manufacturers. For further information
concerning compatibility, refer to the manual of your mainboard, or visit the
manufacturer's website.
SYSTEMATIC
ARRANGEMENT
43.6 cm
15.7 cm
Max. Length
Graphics Card: 35 cm
In addition to breathtaking looks, the RGB LIT
offers a sophisticated functionality with
various cable pass-throughs, a practical
power supply tunnel and dust filters behind
each air intake.
48.1 cm
SSD
SSD
SSD
Removable Dust Filters
4-Port Addressable RGB Controller
Removable HDD/SSD Cage
SSD
HDD/SSD
HDD/SSD
SSD
Max. Length
Power Supply: 21.5 cm
SSD
Extra-Long Thumbscrew Slots for the
Flexible Positioning of the HDD/SSD Cage
Stable Case Feet
OPTIMAL AIRFLOW
1x 120 mm
Addressable
RGB Fan
(Pre-Installed)
Optional Installation
Possibilities:
2x 120 mm Fans
Detachable Front Panel
1 x 120 mm Fan
(Pre-Installed)
A 120 mm fan is installed behind the eye-catching front panel, providing
airflow through the vertical air intakes on each side of the panel. A further 120
mm fan in the rear completes the airflow. Because the rear fan is always
clearly visible, it has been equipped with addressable RGB lighting, which
atmospherically complements both the side and the front lighting. Even more
can be made of the RGB LIT by installing up to four more fans: two of them in
the front and two in the top of the housing. Alternatively, water cooling is also
possible. For this, 6.4 cm in the front and 5.5 cm in the top of the case are
already provided for a radiator including fans.
ADAPTABLE HDD/SSD CAGE
Removable HDD/SSD Cage
If you have a lot of data, the RGB LIT makes no compromises. The case can
house up to six SSDs, which can be mounted on the power supply tunnel or
behind the mainboard tray. In the tunnel, the HDD/SSD cage offers space for
either two more SSDs or two 3.5" hard drives. If a particularly large amount of
power supply cables has to be accommodated, the cage can be easily removed.
Decoupled Mounting for
Noise Reduction from Vibration
SPECIFICATIONS
General:
Form Factor: ATX
Expansion Slots: 7
Interior Painting:
Tool-Free Devices Installation:
Cable Management System:
Side Panel: Tempered Glass
Weight: 6.7 kg
Dimensions (L x W x H): 43.6 x 20.6 x 48.1 cm
RGB Compatibility:
Type: Addressable
Ports: 4
Manual Control: 14 Modes
Mainboard Compatibility: MSI Mystic Light Sync,
ASUS Aura Sync, Gigabyte
RGB Fusion Ready,
ASRock Polychrome SYNC
RGB Pinout: 5V-D-G & 5V-D-coded-G
I/O:
USB 3.0 (Top): 2
USB 2.0 (Top): 1
Audio (Top):
Fan Configuration:
Front Panel: 1x 120 mm Fan
(Pre-Installed)
2x 120 mm Fan
(Optional)
Rear Panel: 1x 120 mm Addressable
RGB Fan (Pre-Installed)
Top Panel: 2x 120 mm or
2x 140 mm Fans (Optional)
Compatibility:
Mainboard: Mini-ITX, Micro-ATX, ATX
Max. Length Graphics
Cards: 35 cm
Max. Height CPU
Cooler: 15.7 cm
Max. Length Power
Supply: 21.5 cm
Max. Height Radiator
incl. Fan (Front): 6.4 cm
Max. Height Radiator
incl. Fan (Top): 5.5 cm
Radiators (Optional): Up to 360 mm (Front Panel)
Up to 280 mm (Top Panel)
Maximum Drive Bays:
3.5": 2
2.5": 6
Package Contents:
RGB LIT 200
Accessory Set
Manual
www.sharkoon.com
