Shark S3101 N, S3101W N User Manual

STEAM MOP

TRAPEADOR A VAPOR

VADROUILLE À VAPEUR

OWNER’S MANUAL MANUAL DEL USUARIO GUIDE DU PROPRIÉTAIRE

Models-Modelos-Modèles: S3101 N – S3101W N 120V., 60Hz, 1550 Watts/Vatios

EURO-PRO Operating LLC

Boston, MA, 02465

1 (800) 798-7398 www.sharkcompany.com

IMPORTANT SAFETY INSTRUCTIONS

When using your SHARK Steam Mop, basic safety precautions should always be observed, including the following:

Warning: To reduce the risk of fire,

electrical shock, or injury:

1. Read all instructions before using your steam mop.

2. Use the system only for its intended use.

3. Do not use outdoors.

4. Do not leave the appliance unattended when plugged in. Always unplug the power cord from the electrical outlet when not in use and before servicing.

5. Do not allow the appliance to be used as a toy. Close attention is necessary when used by or near children, pets or plants. Do not leave applianc e unattended while connected.

6. Use only as described in this manual.

7. Use only manufacturer’s recommended accessories.

8. Do not operate the appliance with a damaged plug or cord, or if the unit has been dropped or damaged. To avoid the risk of electric shock, do not disassemble or attempt to repair the appliance on your own. Return the appliance to EURO-PRO Operating LLC (see warranty) for examination and repair. Incorrect re-assembly or repair can cause a risk of electrical shock or injury to persons when the appliance is used.

9. To protect against a risk of electric shock, do not immerse the steam mop into water or any other liquids.

10. Do not pull or carry by power cord, use power cord as handle, close a door on the power cord, or pull the power cord around sharp edges or corners. Keep power cord away from heated surfaces.

11. Do not unplug by pulling on power cord. To unplug, grasp the plug not the power cord. Do not use extension cords or outlets with inadequate current carrying capacity.

12. Do not handle plug or steam mop with wet hands or operate appliance without shoes.

13. Do not put any objects into openings. Do not use with any opening blocked.

14. Do not put hands or feet under the steam mop. Unit gets very hot.

15. Use ONLY on flat, horizontal surfaces. Do not use on walls, counters or windows.

16. Do not use on leather, wax polished furniture or floors, synthetic fabrics, velvet or other delicate, steam sensitive materials.

17. Do not add cleaning solutions , scented perfumes, oils or any other chemicals to the water used in this appliance as this may damage the unit or make it unsafe for use. If you live in a hard water area, we recommend using distilled water in your steam mop.

18. When in use, NEVER turn the appliance over or on its side.

NEVER DIRECT STEAM TOWARDS PEOPLE, ANIMALS OR PLANTS.

19. NEVER LEAVE THE STEAM MOP IN ONE SPOT ON ANY SURFACE FOR ANY PERIOD OF TIME WHEN MICRO-FIBER PAD IS ATTACHED.

20. Carefully remove the micro-fiber pad immediately after you have finished using the steam mop.

21. When cleaning the steam mop, unplug the power cord from the electrical outlet and clean with a dry or damp cloth. Do not pour water or use alcohol, benzene or paint thinner on the unit.

22. Extreme caution should be exercised when using this appliance to clean stairs.

23. Never use steam mop without micro-fiber pad attached.

24. Keep your work area well lit.

25. Store steam mop indoors in a cool, dry place.

ADDITIONAL IMPORTANT SAFEGUARDS

1. To avoid circuit overload, do not operate another appliance on the same socket (circuit) as the steam cleaner.

2. If an extension cord is absolutely necessary, an extension cord rated a minimum of 15 ampere, 14 gage cord should be used. Cords rated for less amperage may overheat. Care should be taken to arrange cord so that it cannot be pulled or tripped over.

3. Do not leave unattended when the system is connected to a power supply/electrical outlet.

WARNING: To reduce the risk of electric shock, this appliance has a polarized

plug (one blade is wider than the other). This plug will fit in a polarized outlet onl y one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do NOT modify the plug in any way.

WARNING: Your steam mop is desi gned to clean hard floor surfaces that will

withstand high heat. Do not use on unsealed wood or unglazed ceramic floors. On surfaces that have been treated with wax or some no wax floors, the sheen may be removed by the heat and steam action. It is always recommended to test an isolated area of the surface to be cleaned before proceeding. We also recommend that you check the use and care instructions from the floor manufacturer.

IMPORTANT: Do not store unit with damp/wet micro-fiber cleaning pad

attached. Never leave the steam mop in one spot on any surface for any period of time with a damp or wet micro-fiber cleaning pad attached as this will damage your floors.

IMPORTANT: Do NOT add cleaning solutions, scented perfumes, oils or

any other chemicals to the water used in this appliance. If you live in a hard

water area, we recommend using distilled water in your steam mop.

WARNING: Danger of Scalding. Please use caution when using

the steam mop. The steam emitted from the openings is very hot.

SAVE THESE INSTRUCTIONS

FOR HOUSEHOLD USE ONLY

SAVE THESE INSTRUCTIONS

For Household Use Only

Rev. 11/08

GETTING TO KNOW YOUR STEAM MOP

1. Ergonomic Hand Grip

2. Quick Release Cord Wrap

3. Upper Extension Tube

4. Locking Latch

5. Telescopic Tube

6. Lower Cord Wrap

7. Pump Actuator

8. Water Tank Cap

9. Water Tank

10. Power “On” Light (Green)

11. Mop Head

12. Micro-Fiber Cleaning Pad (x2)

13. Filling Flask

14. Funnel

15. Power Cord (not shown)

FEATURES

Your Shark St eam Mop utilizes steam to remove tough grease,dirt and g r ime. Steam is nature’s purest and most powerful cleaner for safely cleaning all hard floor surfaces in your home without harsh chemicals, thus being perfectly ecological. Cleans your tile, hardwood, linoleum and vinyl floors.

1. Quick & Easy

Eliminates rinsing, wringing, carrying buckets of water and redistributing the dirt on the floor.

2. Powerful

Powerful steam dries quickly unlike traditional mopping. Uses powerful steam for superior cleaning and sanitizing.

3. No Harsh Chemicals

Use plain tap water or distilled water. Leaves no chemical residue behind.

4. Lightweight

No heavy buckets to carry. The Shark Steam Mop weighs only 3 lbs. Only one third the weight of carrying a bucket of water and a mop.

5. Ergonomic Soft Grip Handle

Comfortable design makes it easy to maneuver without physical strain.

6. Quick Start-Up

Steam is ready in just 30 seconds.

7. Power “On” Light

The power “On” light will turn green when the unit is plugged in.

Technical Specifications

Voltage: 120V., 60Hz. Power: 1550 Watts Water Capacity: 8 U.S. Fl. Oz. (250ml)

*Note: Illustrations may differ from actu al unit.

8. Reusable Cleaning Pad

Durable triple layer micro-fiber cleaning pad loosens, lifts and locks in dirt. Just toss in the washing machine when done.

OPERATING INSTRUCTIONS

How To Assemble Your Steam Mop

1. Remove all the parts from the packaging.

2. Insert the upper extension tube into the lower telescopic tube. (Fig. 1) Push it in until you hear it click into place.

3. Insert the extension tube assembly into the pump actuator. Make sure that the locking tab snaps into place. (Fig. 1)

4. Place the micro-fiber cleaning pad underneath the mop head. Make

Pump

actuator

sure that the hook and latch strips are facing up. (Fig. 2) Press to secure.

TIP: The micro-fiber

cleaning pads have

Fig. 1

a colored tab so that a different pad can be assigned to different tasks or

Mop

head

rooms in the house.

Hook & latch

strips

Fig. 2

To Extend the Telescopic Tube

1. Lift the locking latch up 90°. (Fig. 3)

2. Holding the handle, extend the telescopic tube to the desired length. (Fig. 3)

3. When you have the telescopic tube to the length that you want, close the locking latch.

HELPFUL HINT: If you find the Steam Mop difficult to push/pull during use, then simply increase the height of the pole.

Fig. 3

Filling the Water Tank IMPORTANT: Always insure that the

unit is “UNPLUGGED” from the wall receptacle prior to filling and before attaching the micro-fiber cleaning pad to the bottom of the mop head. Never use the steam mop without the micro-fiber cleaning pad attached to the mop head. NOTE: When using your new steam mop for the first time you may notice water residue inside of the unit. Water drops can also be found in the packaging. This is normal and you should not be alarmed. Each steam mop is 100% tested in the factory to ensure product performance and safety. Sometimes water is left in the unit from these test procedures.

1. Turn the cap counter clockwise and then lift up to remove from the water tank. (Fig. 4)

2. Using the filling flask and funnel, pour one flask of water into the water tank. Do not overfill the unit past the “MAX” fill line on the water tank. (Fig. 4)

3. Replace the cap onto the water tank.

Using the Steam Mop

IMPORTANT: Never use the steam mop

without the micro-fiber cleaning pad attached to the mop head or without water in the water tank. Please note that when using for the first time, the appliance may take longer than the normal 30 second startup time to steam. You may need to pump the handle a few times before the steam is released. This is due to the water making its way from the water tank through the pump and into the heater. This will only occur during the first use.

1. Sweep or vacuum floors before using the steam mop.

2. Twist the quick release cord holder to unwrap the power cord completely.

3. Plug into a 120-volt electrical outlet.

4. The power “On” light will turn green.

5. It takes approximately 30 seconds for the unit to heat up and the steam to be ready.

6. Pump the handle a few times to dampen the micro-fiber cleaning pad. Begin mopping with a forward and backward motion, this pumping action will release steam as you mop.

MAX

Fig. 4

7. When the water tank is empty, the steam mop will stop emitting steam. Unplug the power cord from the electrical outlet and refill the water tank following the instructions above.

8. When you have finished using the steam mop, unplug the unit from the electrical outlet and carefully remove the micro-fiber cleaning pad from the mop head. Please note that the microfiber cleaning pad gets very hot with the steam. Always use caution when removing.

9. Never leave the micro-fiber cleaning pad on the steam mop head when you have finished using the steam mop. Always remove the micro-fiber cleaning pad and wash in warm water with a mild detergent. Never use bleach or fabric softener when washing the reusable micro-fiber cleaning pad. The micro-fiber cleaning pad may be washed in a washing machine and dried in a clothes drier on low heat. We recommend that you air dry.

IMPORTANT: Be careful when machine

washing or drying with mixed fabrics as micro-fiber pads will pick up lint from other fabrics and the hook and latch strips will stick to other garments. We recommend washing the micro-fiber cleaning pads separately or placing them in a garment bag first.

CAUTION: Never store the steam mop

with a wet or damp micro-fiber cleaning pad still attached as this will damage your floors.

Care & Maintenance of the MicroFiber Cleaning Pad

Due to the unique cleaning ability of this pad, proper care of your micro-fiber cleaning pad is required to ensure long life and continued cleaning ability.

• The first thing you should do when you

get a new micro-fiber cleaning pad is to wash and dry it. During the manufacturing process the fabric has a tendency to become flat as it picks up contaminants from the air and machinery. There will also be a number of loose threads that, while they cause no harm, can be annoying the first time you use the pad.

• To wash the micro-fiber cleaning pad, simply put it in your washing machine using the warm water setting or hand wash.

• We recommend washing your microfiber cleaning pads separately from other fabrics or placing them in a garment bag first if washing by machine. They have a tendency to pick up lint and other particles from other fabrics and the next time you use your micro-fiber cleaning pad, this lint will transfer to the surface being cleaned.

• ONLY USE LIQUID DETERGENTS, never use dry detergents as many times the granules do not fully dissolve and become trapped in the cleaning pad. This can scratch the surface that you are cleaning.

• NEVER USE BLEACH OR FABRIC SOFTENERS! Bleach will damage the micro-fiber fabric and fabric softeners deposit a coating on the micro-fiber fabric what will not allow the pad to clean efficiently.

• We recommend that you air dry the micro-fiber cleaning pad. If using a clothes dryer, do not put on a high heat setting as high heat will cause the micro-fiber pad to shrink and the micro-fibers to break down.

• Wash the micro-fiber cleaning pads regularly and don’t allow them get too dirty so that they will last much longer. As with any fabric, dirt particles, grease and other contaminants can cause the fibers to break down, therefore regular cleaning will help preserve your micro-fiber cleaning pads.

• As you use the micro-fiber cleaning pad, you will notice that sometimes a thread will loosen or pull out. This is normal and you should NEVER PULL AT THE LOOSE THREAD! Pulling the thread can cause the weave to come undone. Instead, simply trim the thread with a pair of sharp scissors.

OPERATING INSTRUCTIONS

TROUBLE SHOOTING

Helpful Hints

1. Always vacuum or s weep before using the steam mop.

2. The easiest way to use the steam mop is to tilt the ergonomic handle to a 45° angle and clean slowly.

3. Hand wash or machine wash the micro-fiber cleaning pad in a delicate cycle with a mild liquid detergent.

4. We recommend air drying the microfiber cleaning pads for 24 hours, but they could be dried in a dryer on a low heat setting.

5. A good amount of steam passes through the micro-fiber cleaning pad. We recommend that the cleaning pad be changed when it gets too wet. These need to be replaced as necessary.

6. To remove stubborn stains from vinyl or linoleum floors, pre-treat with a mild detergent and some water before using the steam mop.

IMPORTANT: Never leave the steam

mop in one spot on any surface for any period of time with a damp or wet micro-fiber cleaning pad attached as this will damage your floors.

Care and Maintenance

If you consistently use distilled water, cleaning the water tank is unnecessary.

CAUTION: This appliance must be

unplugged from the electrical outlet before performing any cleaning or maintenance tasks on the unit.

Rinsing Out the Steam Mop

1. Let the appliance cool down completely before cleaning or storing.

2. Empty all water from the water tank after each use.

Water

• Use tap water for all your cleaning needs.

• However, if you live in an area with hard water, it is recommended that you use distilled water

IMPORTANT: Do NOT add cleaning

solutions, scented perfumes, oils or any other chemicals to the water used in this appliance, as this may damage it or make it unsafe for use. Use distilled

water if the tap water in your area is very hard.

PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION

STEAM MOP WILL NOT OPERATE

STEAM MOP WILL NOT MAKE STEAM

STEAM MOP LEAVES WATER ON THE FLOOR

STEAM MOP LEFT WHITE SPOT ON FLOOR

1. Power cord not firmly plugged into outlet.

2. No power in wall outlet.

3. Needs servicing.

1. No water in water tank.

1. Micro-fiber cleaning pad is too wet.

1. Steam mop left in one spot too long.

2. Hard water.

1. Plug unit in firmly.

2. Check fuse or breaker. Replace fuse/reset breaker.

3. Call 1 (800) 798-7398.

1. Add water to the water tank following instructions.

1. Unplug unit from power outlet and change the micro-fiber cleaning pad.

1. Never leave the steam mop on the fl oor with a damp or wet cleaning pad still attached when not in use.

2. Use distilled water.

To Order Replacement Micro-Fiber Pads

for Models S3101 N - S3101W N

Item # XT3101

Call: 1 (800)798-7398

Monday to Friday 8:30 A.M. - 5:00 P.M. Eastern Standard Time

Or visit our website: www.sharkcompany.com

FOR TECHNICAL SUPPORT for Models S3101 N - S3101W N

Call: 1 (800) 798-7398

Monday to Friday 8:30 A.M. - 5:00 P.M. Eastern Standard Time
