OWNER’S GUIDE
NH130
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
For Household Use Only
WHEN USING AN ELECTRICAL
APPLIANCE, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS
BE OBSERVED, INCLUDING THE
FOLLOWING:
READ ALL INSTRUCTIONS
BEFORE USING YOUR SHARK
NAVIGATOR PORTABLE POWER
VAC.
POLARIZED PLUG:
To reduce the risk of electric shock,
this appliance has a polarized plug
(one blade is wider than the other).
As a safety feature, this plug will
fit into a polarized outlet only one
way. If the plug does not fit fully
into the outlet, reverse the plug. If it
still does not fit, contact a qualified
electrician. DO NOT force into
outlet or try to modify to fit.
WARNING: To reduce the risk of
electric shock or injury, do not
use outdoors or on wet surfaces.
2
TOL L FR EE : 1 -8 00 -798 -739 8
®
WARNING:
TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR INJURY:
GENERAL ELECTRICAL SAFETY:
1. Unplug from electrical outlet when not
in use and before ser vicing.
2. DO NOT use vacuum with a damaged
cord or plug. If appliance is not working
as it should, has been dropped,
damaged, left outdoors, or dropped
into water, return it to EURO-PRO
Operating LLC for examination, repair,
or adjustment.
3. DO NOT pull or carry vacuum by the
cord.
4. DO NOT unplug by pulling on cord; to
unplug, grasp the plug, not the cord.
5. DO NOT handle plug or appliance with
wet hands.
6. DO NOT run the vacuum over the
power cord.
7. DO NOT use the cord as a handle.
8. DO NOT close a door on the cord.
9. DO NOT pull cord around sharp
corners. The use of an extension cord is
not recommended.
10. DO NOT leave appliance when
plugged in.
11. Keep cord away from heated surfaces.
12. Turn off all controls before plugging or
unplugging vacuum cleaner.
HOSE ATTACHMENTS:
1. DO NOT use if air flow is restricted;
if the air paths, the hose, or the
accessories become blocked, turn
the vacuum cleaner off. Remove all
obstructions before you turn on the
unit again.
2. Keep the end of the hose and
accessory openings away from face
and body.
3. Keep cleaning tools and hose suction
openings away from hair, face, fingers,
uncovered feet, or loose clothing.
4. Only use manufacturer’s recommended
attachments.
GENERAL USE:
1. Use only as described in this manual.
2. DO NOT put any objects into openings.
DO NOT use with any opening blocked;
keep free of dust, lint, hair, and
anything that may reduce air flow.
3. Keep your work area well lit.
4. DO NOT place vacuum on unstable
surfaces such as chairs or tables.
5. DO NOT allow young children to
operate the vacuum or use as a toy.
Close attention is necessar y when used
by or near children.
6. DO NOT use vacuum cleaner if it
has been dropped, damaged, left
outdoors, or submerged in water.
Return to EURO-PRO Operating LLC
for examination, repair, or adjustment.
7. DO NOT use without dust cup and/or
filters in place.
DUST CUP/FILTERS/ACCESSORIES:
1. Before turning on the vacuum:
• Make sure that all filters are
thoroughly dry after routine
cleaning.
• Make sure that dust cup and all
filters are in place after routine
maintenance.
• Make sure accessories are free
of blockages.
• Only use filters and accessories
provided by EURO-PRO
Operating LLC. [Failure to do so
will void the warranty.]
GENERAL CLEANING:
1. DO NOT pick up large-sized objects.
2. DO NOT pick up hard or sharp objects
such as glass, nails, screws or coins that
could damage the vacuum cleaner.
3. DO NOT pick up smoking or burning
objects such as hot coals, cigarette
butts, or matches.
4. DO NOT pick up flammable or
combustible materials such as lighter
fluid, gasoline, or kerosene or use
vacuum in areas where they may be
present.
5. DO NOT pick up toxic solutions such
as chlorine bleach, ammonia, or drain
cleaner.
6. DO NOT use in an enclosed space
where vapors are present from
paint, paint thinner, moth-proofing
substances, flammable dust or other
explosive or toxic materials.
7. DO NOT vacuum up any liquids.
8. DO NOT immerse vacuum cleaner in
water or other liquids.
9. DO NOT use outdoors or on wet
surfaces; use only on dry surfaces.
10. Use extra care when cleaning
on stairs.
ww w.shar kclean .co m
3
Contents
Thank you for
purchasing
®
the Shark
Navigator
Portable
Power Vac.
Getting Started ............................................................................. 6
How to Use ..................................................................................... 8
Maintenance ...................................................................................10
Emptying the Dust Cup ........................................................ 10
Cleaning the Pre-Motor Filters ...........................................11
Cleaning the Post-Motor Filter...........................................12
Checking for Blockages ............................................................. 13
Troubleshooting Guide ..............................................................16
Warranty .......................................................................................... 17
Registration .................................................................................... 19
TECHNICAL SPECIFICATIONS
Voltage: 120V., 60Hz.
Power: 800 Watts
6.67 Amps
4
TOL L FR EE : 1 -8 00 -798 -739 8
ww w.shar kclean .co m
5
Getting Started
A
B
Use the Portable Power Vac
as a stand alone vacuum for
spot-cleaning small areas and
large piles of debris, or with the
Flexible Hose and cleaning tools
for above-floor cleaning.
C
D
F
FIRST THING’S FIRST, YOU NEED TO
KNOW WHAT’S IN THE BOX YOU JUST
OPENED:
A Portable Power Vac
B Flexible Hose
C Hose Connector
D Pet Hair Power Brush
E 2-in-1 Crevice/Dusting Tool
F Long Reach Crevice Tool
G Storage Bag (not shown)
E
NOTE: Always turn power off before
attaching or detaching accessories.
a
b
c
d
FLEXIBLE HOSE
With the right cleaning tool in place
and the Flexible Hose, you can extend
your reach into hard-to-clean areas.
(fig. a)
NOTE: Use the Hose without any
accessories attached for large debris
cleaning.
2-IN-1 CREVICE/DUSTING TOOL
Allows you to reach into narrow
cleaning spaces, between cushions,
under radiators and baseboards,
or hard-to-reach corners; it also
allows you to dust a variety of
surfaces from furniture and window
blinds to lamp shades and book
shelves. In addition, the nylon bristles
make the tool safe to use on most
fabric surfaces. (fig. b)
PET HAIR POWER BRUSH
This unique tool was engineered for
fast and easy removal of pet hair and
ground-in dirt from carpeted stairs
and upholstery. (fig. c)
LONG REACH CREVICE TOOL
Use this tool for extra reach and for
cleaning behind radiators, up in the
corners of the ceiling and all kinds of
narrow spaces. (fig. d)
6
TOL L FR EE : 1 -8 00 -798 -739 8
ww w.shar kclean .co m
7
How to Use
a
b
USING THE PORTABLE POWER VAC
1 While holding the Vacuum, press
the Power Button to begin cleaning.
(fig. a)
NOTE: Always hold vacuum by the
Handle while pressing the Power
Button to turn on or off and during
use.
2 Make sure all the three wheels are
resting on a flat surface. This guides
the debris into the Inlet Opening.
(fig. b)
NOTE: Because of the powerful
suction of the Vacuum, take care
when cleaning scatter-type rugs and
carpets with more delicate edges.
3 Empty Dust Cup after cleaning and
periodically during cleaning when
it appears full. (See “Maintenance”
section for instructions.)
c
d
Inlet
Opening
USING THE PORTABLE POWER
VAC WITH FLEXIBLE HOSE AND
ACCESSORIES
For cleaning and dusting above-theground and for hard-to-reach places.
4 Turn the Vacuum over and attach the
Hose Connector to the Inlet Opening
by aligning the arrows, pressing the
Connector down through the slots
(fig. c) and then sliding it towards
the back of the unit (fig. d) until you
hear it click into place.
e
f
g
5 Attach a cleaning tool to the other
end of the Hose:
• 2-in-1 Crevice/Dusting Tool (fig. e)
NOTE: To convert the Crevice Tool
into a Dusting Tool, press the button
on the side and slide the nylon bristle
collar up.
• Pet Hair Power Brush (fig. f)
• Long Reach Crevice Tool (fig. g)
6 While holding the Vacuum by the
Handle, press Power Button to begin
cleaning.
7 Hold the vacuum by the Handle and
press the Power Button to turn off.
j
h
i
8 Remove the Flexible Hose and Hose
Connector from the Vacuum by
pressing and holding the release
button on the side of the Hose
Connector (fig. h) while you slide
it toward the front of the Vacuum
(fig. i) and lift out. (fig. j)
NOTE: Always remove the Hose
Connector before emptying Dust
Cup.
9 Empty Dust Cup after cleaning and
periodically during cleaning when
it appears full. (See “Maintenance”
section for instructions.)
10 When you are finished cleaning,
unplug the vacuum and remove
accessories. Store all accessories in
the storage bag and place in a cool
dry place for storage along with the
vacuum.
8
TOL L FR EE : 1 -8 00 -798 -739 8
ww w.shar kclean .co m
9
F
ilt
e
r
a
c
c
e
s
s
E
m
p
t
y
d
u
s
t
c
u
p
Maintenance
To reduce the risk of electric shock, unplug the unit before performing any
cleaning, maintenance, or troubleshooting checks.
Reassemble all parts securely before operating vacuum.
Dust Cup
1
Empty each time you clean.
a
c
Pre- Motor
Filters
Pre-Motor Foam Filters (2)
2
Pre-Motor Large Felt Filter (1)
3
Post-Motor Foam Filters (1)
4
Post-Motor Felt Filters (1)
5
Rinse and dry every month under normal use.
Rinse and dry every month under normal use.
Rinse and dry every 6 months under normal use.
DO NOT rinse Post-Motor Felt Filter
c
a
b
EMPTYING THE DUST CUP
The Dust Cup needs to be emptied
each time you vacuum and
periodically during cleaning, when
the Dust Cup appears full.
1 Remove the Flexible Hose and Hose
Connector from the Vacuum by
pressing and holding the release
button on the side of the Hose
Connector (fig. a) while you slide it
toward the front of the Vacuum
(fig. b) and lift out. (fig. c)
10
TOL L FR EE : 1 -8 00 -798 -739 8
d
2 Hold Vacuum over a trash receptacle
and press the Dust Cup Release
Button to release the door. Tap
gently to empty contents. (fig. d)
3 Press the door shut again until it
clicks.
4 Check to make sure door is secure
before turning the Vacuum on.
Filter Access
b
CLEANING THE PRE-MOTOR FILTERS
1 Stand the Vacuum up with the Dust
Cup on the top and the Handle facing
you.
2 Slide the Filter Access Button
upward to unlatch the Dust Cup from
the Vacuum. (fig. a)
3 While holding the Filter Access
button, twist the Dust Cup to the
right (fig. b) so that the Black
Triangle on the Dust Cup aligns with
the ‘Unlock’ Symbol on the Vacuum.
4 Remove the Dust Cup and pull out
the gray Filter Holder with Small
Foam Filter. Pull out Large Foam and
Felt Filters. (fig. c)
5 Rinse all filters thoroughly in
lukewarm water until the water runs
clear.
6 Squeeze out excess water and let air-
dry for 24 hours before replacing; do
not use hair dryer or other heating
methods to dry.
d
7 Make sure all filters are completely
dry before inserting back into
Vacuum.
8 To re-insert Filters:
• Place the Large Felt Filter into
Vacuum first.
• Next, place the Large Foam Filter.
• And finally, place the Filter Holder
with Small Foam Filter tucked
inside.
9 Align locking grooves of the Dust
Cup with tab on the Vacuum body.
First push the Dust Cup down and
then to the left (fig. d) until you
hear the Filter Access Button lock
securely in place and the Black
Triangle on the Dust Cup is aligned
with the ‘Locked’ Symbol on the
Vacuum
DO NOT operate the vacuum without
ALL the filters in place.
DO NOT operate the vacuum with
WET filters.
ww w.shar kclean .co m
11
Checking for Blockages
a
Exhaust Foam Filter Felt Filter
CLEANING THE POST MOTOR FOAM
FILTER
1 Lay the Vacuum down with the
Handle facing up.
2 Twist the Exhaust Filter
Compartment so that the Black
Triangle on the Handle aligns with
the ‘Unlock’ Symbol on the Exhaust
Filter Compartment and remove.
(fig. a)
3 Pull out Foam Filter.
4 Rinse only the Foam Filter
thoroughly in lukewarm water until
the water runs clear.
5 Squeeze out excess water and let air-
dry for 24 hours before replacing; do
not use hair dryer or other heating
methods to dry.
6 Make sure the filter is completely dry
and insert it back into Exhaust Filter
Compartment.
12
TOL L FR EE : 1 -8 00 -798 -739 8
DO
NOT
RINSE
b
7 Grip Exhaust Filter Compartment
and align ‘Unlock’ Symbol with Black
Triangle on Handle of the Vacuum.
8 Push Exhaust Filter Compartment
into Vacuum and twist so that the
Black Triangle on the Handle aligns
with the ‘Locked’ Symbol on the
Exhaust Filter Compartment to lock
it into place. (fig. b)
DO NOT operate the vacuum without
ALL the filters in place.
DO NOT operate the vacuum with
WET filters.
c
Rotating
Bristle
Brush
Blockages may cause your vacuum to
overheat and shut down. To prevent
this from happening, check potential
blockage areas after heavy use or if you
detect a loss of suction or poor cleaning
performance.
1 DUST CUP
Dust Cup may be full. Empty Dust
Cup. For instructions on how to
empty the Dust Cup, see p. 10.
2 FILTERS (FOAM AND FELT)
Ensure that both the Pre and Post
Motor Filters are clean. For cleaning
instructions see p.11 & 12.
3 ACCESSORIES
Check intake openings:
•
• 2-in-1 Crevice/Dusting Tool
• Pet Hair Power Brush
• Long Reach Crevice Tool
Locking
Latch
Turbine
Wheel
ed
CLEANING THE PET HAIR POWER
BRUSH
Turn the Pet Hair Power Brush
•
over, slide the locking latch forward
and tilt the cover upward to
remove. (fig. c)
Inspect the rotating bristle brush,
•
turbine wheel and air passage.
(fig. d)
Remove any blockage or debris
•
and carefully, without damaging
the bristles or belt, cut any build-up
of hair or string wrapped around the
rotating bristle brush with scissors.
To reassemble, first insert the tabs
•
on the front edge of the cover
into the matching holes in the top
half of the Pet Hair Power Brush and
tilt the cover back down pressing
until it clicks into place. (fig. e)
ww w.shar kclean .co m
13
Troubleshooting Guide
PROBLEM POSSIBLE REASONS & SOLUTIONS
Check Filters to see if they need cleaning. Follow
instructions for rinsing and drying the Filters before reinserting back into the Vacuum. (See “Maintenance”
sections for instructions.)
Vacuum is not
picking up dirt.
Dust Cup may be full; empty Dust Cup.
Check Hose and Hose connections for blockages; clear
blockages if required.
If Dust Cup is empty, and attachment inlets are clear, check
for other blockages. (See “Checking for Blockages” for
instructions.)
e f
5 FLEXIBLE HOSE AND HOSE
CONNECTOR
Remove Hose Connector from the
•
Vacuum.
Detach the Flexible Hose from the
•
Hose Connector by squeezing the
tabs and gently pulling out. (fig. e)
Check inside the Hose.
•
Check inside the Hose Connector.
•
Check the Vacuum Inlet Opening.
•
Snap the Flexible Hose back onto
•
the Hose Connector by aligning the
tabs on the Hose with the holes on
the Hose Connector and pushing the
two pieces together until they click
back into place. (fig. f)
14
TOL L FR EE : 1 -8 00 -798 -739 8
To reduce the risk of electric shock,
unplug the unit before performing
any cleaning, maintenance, or
troubleshooting checks.
WARNING: Never insert sharp
objects into any opening to clear an
obstruction.
IMPORTANT: Damages caused
while clearing or attempting to clear
blockages are not covered under
your product’s limited warranty.
Reassemble all parts securely before
operating vacuum.
Vacuum lifts scatter
rugs (lightweight,
movable rugs).
Airflow is restricted.
No suction or light
suction.
Vacuum turns off
on its own.
Because the suction is powerful, take care when vacuuming
scatter-type rugs or rugs with delicately sewn edges.
Check Filters to see if they need cleaning. Follow
instructions for rinsing and drying the Filters before reinserting back into the Vacuum. (See “Maintenance”
sections for instructions.)
Dust Cup may be full; empty Dust Cup.
Check Hose and Hose connections for suction strength;
clear blockages if required.
If Dust Cup is empty, and attachment inlets are clear, check
for other blockages. (See “Checking for Blockages” for
instructions.)
This vacuum cleaner is equipped with a motor protective
thermostat. If for some reason your vacuum overheats, the
thermostat will automatically turn the unit off. Should this
occur, perform the following steps to restart the motor
thermostat:
1. Move the Power Button to the “O” (Off) position.
2. Unplug the vacuum.
3. Empty the Dust Cup and clean Filters. (See
“Maintenance” sections for instructions.)
4. Check for blockages in hose, accessories and inlet
opening. (See “Checking for Blockages” for instructions.)
5. Allow the unit to cool for a minimum of 45 minutes.
6. Plug in the vacuum.
7. Turn the Power Switch to the “I” (On) position to restart
the vacuum.
Note: If vacuum still does not start, contact Customer
Service at: 1-800-798-7398.
ww w.shar kclean .co m
15
Notes
Warranty
Your Shark®
Navigator
Portable Power
Vac comes
with a Five
Year Limited
Warranty.
16
TOL L FR EE : 1 -8 00 -798 -739 8
EURO-PRO FIVE-YEAR (5) LI MITED WARRANTY
EURO-PRO Operating LLC warrants this product to be free from
material defects and workmanship for a period of five (5) years
from the date of purchase when utilized for normal household use,
subject to the following conditions, exclusions and exceptions.
The liability of EURO-PRO Operating LLC is limited solely to the cost
of the repair or replacement of the unit at our option. This warranty
does not cover normal wear of parts and does not apply to any
unit that has been tampered with or used for commercial purposes.
This limited warranty does not cover damage caused by misuse,
abuse, negligent handling or damage due to faulty packaging or
mishandling in transit. This warranty does not cover damage or
defects caused by or resulting from damages from shipping or
repairs, service or alteration to the product or any of its parts, which
have been performed by a repair person not authorized by EURO-
PRO Operating LLC.
If your appliance fails to operate properly while in use under normal
household conditions within the warranty period, you may return
the complete appliance and accessories with proof of purchase
and date, freight prepaid. For customer service support, call
1-800-798-7398 or visit our website at www.sharkclean.com.
If the appliance is found by EURO-PRO Operating LLC to be
defective, in EURO-PRO Operating LLC’s sole discretion, we will
repair or replace it free of charge. Proof of purchase date and
cheque made payable to EURO-PRO Operating LLC in the amount
of $12.95 to cover the cost of return shipping and handling must be
included.
*Non-durable parts including, without limitation, filters, brushes and
electrical parts which normally require replacement are specifically
excluded from warranty.
This warranty is extended to the original purchaser of the unit and
excludes all other legal, implied and/or conventional warranties. The
responsibility of EURO-PRO Operating LLC if any, is limited to the
specific obligations expressly assumed by it under the terms of this
Limited Warranty. In no event is EURO-PRO Operating LLC liable
for incidental or consequential damages to anyone of any nature
whatsoever. Some states do not permit the exclusion or limitation
of incidental or consequential damages, so the above may not apply
to you.
This Limited Warranty gives you specific legal rights, and you may
also have other rights which vary from state to state or province to
province.
*IMPORTANT: Carefully pack item to avoid damage in shipping.
Be sure to include proof of purchase date and to attach a tag to
item before packing including your name, complete address and
phone number with a note giving purchase information, model
number and what you believe is the problem with the item. We
recommend you insure the package (as damage in shipping is
not covered by your warranty). Mark the outside of your package
“ATTENTION CUSTOMER SERVICE”. We are constantly striving
to improve our products, therefore the specifications contained
herein are subject to change without notice.
17
ww w.shar kclean .co m
ww w.shar kclean .co m
17
Look for these other great Shark® products
at your favorite Shark
®
retailer
or on the web at www.sharkclean.com
18 V Pet Perfect ™ II Cordless Hand Vac
OWNERSHIP REGISTRATION CARD
FOR CANADIAN CONSUMERS ONLY
Please fill out and mail the product registration card within
ten (10) days of purchase. The registration will enable us to
contact you in the unlikely event of a product safety notification.
By returning this card you acknowledge to have read and
understood the instructions for use, and warnings set forth in the
accompanying instructions.
Mail to the following address:
• EURO-PRO Operating LLC
4400 Bois Franc, St.Laurent, Québec, Canada H4S 1A7
Owner’s Name:
Address:
City: Province: Postal Code:
| |
Steam Pocket
Full range of Professional Irons
18
TOL L FR EE : 1 -8 00 -798 -739 8
®
Mop
Date Purchased:
Name of Store:
Appliance Model:
NH130
ww w.shar kclean .co m
ww w.shar kclean .co m
19
19
U. S.: E URO -PRO O perati ng L LC
New ton , MA 02459
Ca nad a: EU RO- PR O Op era ting LLC
44 00 B ois Franc
Vil le S t. L aur ent , Qu ébe c H4 S 1A 7
1- 800 -798 -739 8
ww w.shar kclean .co m
COPY RIGHT© EURO- PRO OP ERATING LLC 200 9
PRI NTED IN CHINA
REV. 091224
Illu strati ons may d iffer with act ual pro duct.
Loading...
