Shark MV2010UKJR, MV2010UKL Owner's Manual

VAC-THEN-STEAM™

MV2010UKJR

OWNER’S GUIDE

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

For Household Use Only

WHEN USING YOUR SHARK® VAC-

THEN-STEAM™, BASIC SAFETY

PRECAUTIONS SHOULD ALWAYS
BE FOLLOWED, INCLUDING THE
FOLLOWING:

WARNING:

TO REDUCE
THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY READ ALL

INSTRUCTIONS BEFORE USING
YOU R VAC-THEN-STEAM™.

DANGER OF SCALDING.

Please use caution when using the
steam function. The steam emitted
from the appliance is very hot.

1. Use the system only for its

intended use.

2. DO NOT use outdoors. Use only

on dry, indoor surfaces.

3. DO NOT leave the appliance

unattended when plugged in. Always
unplug the power cord from the
electrical outlet when not in use and
before servicing.

4. DO NOT allow the appliance to be

used by children. Close attention
is necessary when used by or near
children, pets or plants.

5. DO NOT operate the appliance with

a damaged plug or cord, or if the unit
has been dropped, damaged, left
outdoors or dropped into water. To
avoid the risk of electric shock, do
not disassemble or attempt to repair
the appliance on your own. Incorrect
re-assembly or repair can cause a
risk of electrical shock or injury to
persons when the appliance is used.

6. Use only as described in this manual.

7. Use only manufacturer’s

recommended accessories and
replacement pads.

8. To protect against a risk of electric

shock, DO NOT immerse the
appliance into water or any other
liquids.

www.sharkclean.co.uk

9. DO NOT handle plug or appliance
with wet hands or operate appliance
without shoes.

10. DO NOT pull or carry by power cord,
use power cord as a handle, close a
door on the power cord, or pull the
power cord around sharp edges or
corners. Do not run appliance over
cord. Keep power cord away from
heated surfaces.

11. DO NOT unplug by pulling on
power cord. To unplug, grasp the
plug not the power cord. Do not
use extension cords or outlets
with inadequate current carrying
capacity.

12. DO NOT put any objects into the
unit openings. Do not use the unit if
any opening is blocked; keep free of
dust, lint, hair and anything that may
reduce airflow.

13. DO NOT put hands or feet under the
Vac-Then-Steam™. Unit gets very hot
and may burn.

14. Use O NLY on flat, horizontal
surfaces. Do not use on walls,
counters or windows.

15. DO NOT use on leather, wax polished
furniture and floors, synthetic fabrics,
velvet or other delicate, steam
sensitive materials.

16. DO NOT add cleaning solutions,
scented perfumes, oils or any other
chemicals to the water used in this
appliance as this may damage the
unit or make it unsafe for use and
void the warranty. If you live in a hard
water area, we recommend using
distilled water in your Vac-Then-
Steam™.

17. When in use, NEVER turn the
appliance over or on its side. NEVER

DIRECT STEAM TOWARDS PEOPLE,
ANIMALS OR PLANTS.

18. NEVER LEAVE THE CLEANING

UNIT IN ONE SPOT ON ANY
SURFACE FOR ANY PERIOD OF
TIME WHEN MICROFIBRE PAD IS
ATTAC H E D.

19. Carefully remove the microfibre
pad immediately after you have
unplugged and allowed the
appliance to cool.

20. When cleaning the appliance,
unplug the power cord from the
electrical outlet and clean with a dry
or damp cloth. Do not pour water
or use alcohol, benzene or paint
thinner on the unit.

21. Extreme caution should be
exercised when using this appliance
to clean stairs.

22. Never use Steam function without
microfibre pad attached.

23. Keep your work area well lit.

24. Store appliance indoors in a cool,
dry place.

25. To avoid circuit overload, do not
operate another appliance on the
same socket (circuit) as the cleaning
unit.

26. If an extension cord is absolutely
necessary, an extension cord rated
a minimum of 15 ampere, 14 gage
cord should be used. Cords rated for
less amperage may overheat. Care
should be taken to arrange cord so
that it cannot be pulled or tripped
over.

27. DO NOT store unit with damp/wet
microfibre cleaning pad attached.

28. DO NOT use the vacuum cleaner
without dust cup and filter in place.

29. DO NOT vacuum up any liquids.

30. DO NOT pick up anything that
is burning or smoking such as
cigarettes, matches or hot ashes.

31. To reduce the risk of fire DO
NOT use to pick up flammable or
combustible liquids such as gasoline
or use vacuum in areas where
flammable or combustible fumes
may be present.

32. DO NOT pick up toxic solutions
such as chlorine bleach, ammonia or
drain cleaner with the cleaning unit.

33. DO NOT use in an enclosed space
where vapors are present from
paint, paint thinner, mothproofing
substances, flammable dust or other
explosive or toxic materials.

34. DO NOT run the cleaning unit over
large-sized objects.

35. DO NOT pick up hard or sharp
objects such as glass, nails, screws
or coins that could damage the
cleaning unit.

36. DO NOT place appliance on
unstable surfaces such as chairs or
tables.

37. DO NOT allow the cleaning unit to
be used as a toy.

38. Close attention is necessary when
used near children.

39. Keep hair, loose clothing, fingers
and all parts of the body away from
openings and moving parts.

40. Turn off all controls before plugging
or unplugging your Vac-Then-

Steam™.

WAR NIN G : Your appliance is

designed to clean non-carpeted,
sealed hard floor surfaces that will
withstand high heat. Do not use on
unsealed wood or unglazed ceramic
floors, on surfaces that have been
treated with wax or on some no wax
floors. The sheen may be removed
by the heat and steam action. It is
always recommended to test an
isolated area of the surface to be
cleaned before proceeding. We also
recommend that you check the use
and care instructions provided by the
floor manufacturer.

IMPORTANT: This appliance is
not intended for use by persons
(including children) with reduced
physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning the use of the appliance
by a person responsible for their
safety.

www.sharkclean.co.uk

Steam Technology

Thank you for purchasing the

®

Shark

the complete hard floor
cleaning system.

The unique steam technology
turns simple tap water into
super-heated steam that infuses
the microfibre pads for chemical
free cleaning. Only this method
creates and delivers 100°C
steam that is effective enough
to clean and sanitise all your
hard floor surfaces. The Shark®
Vac-Then-Steam™ can help you
achieve a truly clean and healthy
environment for you and
your family.

Vac-Then-Steam™,

TECHNICAL SPECIFICATIONS

Voltage: 220-240V., 50Hz.

Power:

Vacuum: 400 Watts

Steam: 1550 Watts

Water
Capacity: 300 ml (10 oz.)

www.sharkclean.co.uk

Not to be disposed

of with other

household waste.

IP44

Contents

Getting Started: Assembly ................................................2

Getting Started: Mode Controls ......................................4

Vacuum Mode .........................................................................5

Steam Mode ............................................................................8

Maintaining Your Vac-Then-Steam™ ..............................12

Troubleshooting Guide .......................................................14

www.sharkclean.co.uk

1

Getting Started: Assembly

i

When assembling your Vac-Then-Steam™
there may be a little water in or around
the water tank. This is because we
quality test all our Shark products before
distributing them, so you get a quality

Shark® Vac-Then-Steam™.

a

c

d

e

f

b

g

a Telescopic Handle

b Cleaning Unit with Dust Cup

c 1 All-Purpose Cleaning Pad and

1 Heavy Duty Cleaning Pad

d Steam Frame

e Storage Tray

f Filling Flask

g 1 Replacement Post-Motor Filter

h 1 Replacement Dust Cup Filter Set

h

j

k

l

m

n

o

q

p

r

i Mop Handle

j Quick Release Swivel Cord Wrap

k Cord Clip

l Telescopic Handle Latch

m Carry Grip

n Vacuum and Steam Mode Panel

o Water Tank Cap

p Water Tank Viewing Window

q Post-Motor Filter Access

r Dust Cup

2

www.sharkclean.co.uk

1

2

3

ASS E M B LY

1 Slide the Telescopic Handle into the

cleaning unit until it locks into place.
Once in position, you never have to
remove the handle.

2 For your comfort, you can adjust the

height of the handle. To do so pull
the latch down on the handle tube
90 degrees to the open position.
Holding the handle, extend the tube
to the height that is right for you and
then close latch to lock into position.

3 Wrap cord around cord holders and

secure plug to cord.

NOTE: The Vac-Then-Steam™, is
a complete bare-floor cleaning
and sanitising system. It comes
“vacuum-ready” out of the box.

QUICK TIP: For easier pushing and

pulling, extend the height of the
handle by using the telescopic latch
on the pole.

www.sharkclean.co.uk

3

Getting Started: Vacuum and Steam Panel

STEAM MODE:

The Vac-Then-Steam™ has two
operating modes:

1

VACUUM MODE:

1

2

DO NOT USE STEAM PAD AND

FRAME IN VACUUM MODE

2

3

3

OPER ATING IN VACUUM MODE:

1 Remove steam pad and frame,

if attached. See page 8 for
instructions. Vacuum will not activate
if steam frame is attached.

2 SLIDE THE TOGGLE SWITCH UP to

expose the vacuum power button.

3 Press the VACUUM POWER BUTTON

to the ON “I” position to activate
the vacuum.

4

www.sharkclean.co.uk

OPER ATING IN STEAM MODE:

1 Attach steam pad and frame.

Steam mode will not work if the pad
and frame are NOT attached. See
page 8 for assembly instructions.

2 Fill the water tank.

SLIDE THE TOGGLE SWITCH DOWN

to expose the Steam Power button

3 Press the STEAM POWER BUTTON

to the ON “I” position. The button
will be illuminated red when steam
mode is activated.

4 Wait 30 seconds to heat water, then

TILT HANDLE BACK TO ACTIVATE
STEAM PUMP.

Vacuum Mode

After inserting the telescopic handle,
your cleaning system is vacuum-ready.
Begin vacuuming your hard-surface
floors by tilting the cleaning unit back
and pressing the vacuum power button.

1

2

3

USING VACUUM MODE

1 Pull and twist the quick release cord

holder to unwrap the power cord
completely. Plug in the unit.

2 To vacuum, slide the toggle switch

until the vacuum power button is
exposed. Press the vacuum power
mode button to the ON “I” position.

IMPORTANT: You cannot use the

vacuum function if the frame and
pad are attached to the base of the
cleaning unit.

NOTE: Only vacuum sealed and

non-carpeted bare floor surfaces.
Refer to floor manufacturer
guidelines and warnings.

3 Place your foot lightly on the top

of the cleaning unit base. Tilt the
cleaning unit back. Vacuum your
floors.

IMPORTANT: Vacuum all surfaces

first before steam-cleaning to avoid
condensation build-up. Avoid
vacuuming after steam mopping.

NOTE: If you vacuum and then

steam-clean one room, before
moving on to the next, wait 10
minutes for the condensation to
clear before vacuuming again.

www.sharkclean.co.uk

5

Vacuum Mode

2

1

3

STORAGE

1 Place your foot lightly on the top of

the base. Tilt cleaning unit into the
upright position.

2 Turn OFF “O” the vacuum power

button and unplug the unit.

3 Wrap cord around cord holders and

secure plug. Store cleaning unit in an
upright position.

6

www.sharkclean.co.uk

IMPORTANT:

Always carry
the Vac-Then-
Steam™ by the
cleaning unit
collar; rather
than by the
handle.

EMPT YING THE DUST CUP

1

EMPT YING THE CONE FILTER

2

3

3

1

2

EMPTYING THE DUST CUP

1 Press the dust cup latch at the

bottom of the canister upward. Pull
the dust cup assembly out and down.

2 Twist dust cup cover counter-

clockwise to open.

3 Tap canister gently over trash

receptacle to empty.

EMPTYING THE CONE FILTER

Over time the debris may gather in

the cone filter of your Vac-Then-
Steam™. Clean the filter often for
optimal suction performance.

1 Lift the filter frame out from the top

of the dust cup and remove the two
filter layers from the filter frame.

4

2 Tap filter canister gently over trash

receptacle to empty debris from the
conical filter.

Reattach the filter frame.

3 To reattach the dust cup cover, align

the indicators that are printed on the
rear of the dust cup and cover. Turn
the cover clockwise and make sure
the solid arrows are aligned before
reinserting the dust cup into the
vacuum.

4 To replace the dust cup in to the unit,

gently push the dust cup assembly
up and in. The dust cup will click
into place.

www.sharkclean.co.uk

7

Steam Mode

1

3

ASS E M B LY

1 Attach a steam pad onto the bottom

of the steam frame, matching the
hook and loop fasteners.

2 Place the steam frame/pad assembly

on the floor with the magnetic
connections facing up.

8

www.sharkclean.co.uk

MAGNETIC

CONNECTIONS

3 Place the cleaning unit onto the

Steam Frame. THE UNIT MUST BE
UPRIGHT.

IMPORTANT: steam frame and pad

must be attached to the cleaning unit
in order to use the steam function.

2

Do not use chemicals or
detergents in your
Vac-Then-Steam™. You only
need water to achieve
super-heated, sanitising
steam.

1

2

FILLING THE WATER TANK

1 Keep the cleaning unit in the upright

position to add water. Turn the water
tank cap counter-clockwise and
remove from the tank.

2 Use the filling flask and pour water

into the tank. Do not overfill.
Replace the cap on the water
tank by turning cap clockwise and
tightening.

NOTE: If you live in a hard water

area, we recommend using distilled
water in your Vac-Then-Steam™.

www.sharkclean.co.uk

9

Steam Mode

1

2

3

STEAM CLEANING

1 Plug in the cleaning unit. Slide the

toggle switch to expose the steam
power button.

2 Press the steam power button to the

ON “I” position. The illuminated red

light indicates that the “boiler” is on.
Wait 30 seconds for the water to
heat up and for steam to be ready.

10

www.sharkclean.co.uk

3 Place your foot lightly on the top of

the base. TILT HANDLE BACK TO
ACTIVATE STEAM PUMP.

4 Push handle upright to stop steam.

NOTE: Check water level and fill

anytime throughout the cleaning
process to maintain optimal steam.

3

1

2

40°

1

2

STORAGE

1 Unplug and turn the unit OFF “O”.

Press your foot on the steam frame.
Separate steam pad from steam
frame.

2 Remove the water tank cap and

empty water tank.

3 Wrap cord securely around cord

management hooks.

Store your Vac-Then-Steam™ in the

storage tray.

CAUTION: Use caution when

handling the steam frame. Magnetic
connections on the frame retain heat.

CARE OF YOUR MICROFIBRE

CLEANING PAD

1 Wash pads in warm water. Wash

separately from other laundry. Only
use liquid detergent (no powder
detergent). Do not use fabric
softeners. Line dry. Do not tumble
dry.

2 If there are loose threads on the

pad carefully cut the threads with
scissors. Do not pull on them or cut
at the base.

www.sharkclean.co.uk

11

Maintaining Your Vac-Then-Steam™

Replacement filter sets
have been provided with
your product. Use one of
the replacement filter sets

1

Thin Filter
Thick Filter

2

24

when another set is drying.

3

CARE OF YOUR DUST CUP FILTERS

1 Unplug and turn OFF “O” the

vacuum. Pull out the dust cup. See
page 7 for instructions.

Lift the filter frame out from the top

of the dust cup. Remove the two
filter layers from the filter frame.

2 Thoroughly rinse the two filters in

lukewarm water. Squeeze out any
excess water. Air dry for 24 hours
before reusing.

3 Insert a dry filter set into the filter

frame. T he order of the filters
impacts your dust cup performance.
Make sure the thick filter is on the
bottom and the thin filter is on top.

Put the frame with the filter set back

into the top of the dust cup.

12

www.sharkclean.co.uk

RECOMMENDED MAINTENANCE

SCHEDULE: Using only water,

thoroughly rinse filters every 3
months and dry for 24 hours.
Replace filter set in the Vac-Then-
Steam™ once a year. More regular
filter care or replacement may be
required with excessive use.

1

2

A replacement post-motor
filter has been provided
with your product. Use the
replacement filter while the
other is drying.

3

POST-MOTOR FILTER

1 Remove the Shark® logo sticker from

the Shark® logo knob on the post
motor cover.

2 Using a Philips screwdriver, remove

the wo screws from the logo knob.

3 Twist the Shark

post-motor cover counter-clockwise
to release cover.

4 Use both hands to grip the cover on

both sides and pull the cover toward
you.

5 Gently peel the filter off the inside of

the cover. Thoroughly rinse the filter
in lukewarm water. Squeeze out any
excess water. Air dry for 24 hours
before reusing.

6 Insert a dry filter into the inside of

the cover. Snap the cover onto the
Vac-Then-Steam™.

®

4 5

logo knob on the

7 Twist the Shark

and replace the two screws to secure
the cover.

NOTE: Replacement logo stickers are

provided should you wish to
re-attach them.

NOTE: Using only water, thoroughly

rinse filter every 3 months and dry
for 24 hours. Replace filter in the
Vac-Then-Steam™ once a year. More
regular filter care or replacement
may be required with excessive use.

DO NOT use a hair dryer or any other

forced hot air to dry any of the filters.

NOTE: Any other servicing should be

performed by an authorized service
representative.

ORDERING REPL ACEMENT PARTS
To order additional replacement parts

and accessories, feel free to contact
us at: Freephone 0800 781 7831.

®

logo knob clockwise

www.sharkclean.co.uk

13

Troubleshooting Guide

PROBLEM POSSIBLE REASONS & SOLUTIONS

Your Vac-Then-Steam™ should be securely plugged into a

The Vac-Then-
Steam™ will not turn
on.

The Vac-Then-Steam™
will not make steam.

The Vac-Then-Steam™
leaves water on the
floo r.

220-240V AC electrical outlet only.
Check your fuse or breaker.

Switch Steam or Vacuum Power button to the ON “I”
position.

Make sure the water tank is filled to the indicated fill line.
Attach Steam Pad and Frame to base of the unit.

Switch Steam Power button to the ON “I” position.

TILT MOP HANDLE BACK TO GENERATE STEAM.

Check to see if your microfibre cleaning pad has absorbed
too much moisture. We recommend you unplug the Vac-
Then-Steam™ and replace the microfibre cleaning pad.

Make sure the steam pad is attached correctly.

Wait 30 seconds after switching Steam Power button ON
“I” before mopping, allowing water to heat to a 100°C
sanitising steam. If the unit is not allowed to heat properly,
some water may be emitted.

The Vac-Then-Steam™
is hard to push.

The Vac-Then-Steam
is not picking up
dirt.

14

www.sharkclean.co.uk

Make sure the steam pad is attached correctly.
Check to see if the cleaning pad is excessively dirty.

Replace if the pad is too dirty or wet.
Try increasing the height of the pole for better leverage by

rasing the height of the telescopic pole.

Check filters to see if they need cleaning. Follow
instructions for rinsing and drying the filters before
re-inserting back into the unit. (See “Maintenance”

™

sections for instructions.)

Dust cup may be full. Empty the dust cup.

Check nozzle at the cleaning base for blockages. Clear
blockages if required.

This appliance complies with the WEEE-Directive 2002/96/EC on the disposal of
electrical and electronic equipment (WEEE).

This appliance complies with the European directives for electromagnetic
compatibility (EMC) 2004/108/EC and its revisions, as well as Low Voltage
Directive (LVD) 2006/95/EC and its revisions.

This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material sources. To return your used device, please use the return and

purchased. They can take this product for environmental safe
recycling.

collection systems or contact the retailer where this product was

Guarantee: This product is unconditionally guaranteed for one year
against all defects of workmanship and materials. This guarantee
does not affect your statutory rights. If this product proves
unsatisfactory please contact our customer service department on
freephone 0800 781 7831.

www.sharkclean.co.uk

15

Distributed by JML
JML, Unit 1 Eastside
Port of Tyne
South Shields
NE33 5SP
[e-mail]
Freephone 0800 781 78 31
www.sharkclean.co.uk

Registered address: JML House, NW5 3EG

Technical Details
Model number: MV2010UKJR 11
Input:
Vacuum: 400 Watts

Steam: 1550 Watts

Main unit voltage: 220-240V., 50 Hz.

COPYRI GHT© EURO-P RO OPERATING LLC 2010

PRINTE D IN CHINA

MV2010UKJR.E.101021

Illustr ations may diffe r from actual product.

Not to be disposed

of with other

household waste.

IP44
