Shark MV2010 User Manual
www.SharkVacThenSteam .com
VAC-THEN-STEAM™
MV2010
OWNER’S GUIDE
MV2010_11_IB_ENG_110103.indd 1 11-01-03 1:26 PM
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
WHEN USING YOUR SHARK® VAC-
THEN-STEAM™, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS
BE FOLLOWED, INCLUDING THE
FOLLOWING:
WARNING:
THE RISK OF FIRE , ELECTRIC
SHOCK OR INJURY READ ALL
INSTRUCTIONS BEFORE USING
YOUR VAC-THEN-STEAM™.
DANGER OF SCALDING.
Please use caution when using the
steam function. The steam emitted
from the appliance is very hot.
1. Use the system only for its
intended use.
2. DO NOT use outdoors. Use only
on dry, indoor surfaces.
3. DO NOT leave the appliance unattended
when plugged in. Always unplug the
power cord from the electrical outlet
when not in use and before servicing.
4. DO NOT allow the appliance to be used
by children. Close attention is necessary
when used by or near children, pets or
plants.
5. DO NOT operate the appliance with a
damaged plug or cord, or if the unit has
been dropped, damaged, left outdoors
or dropped into water. To avoid the risk
of electric shock, do not disassemble or
attempt to repair the appliance on your
own. Return the appliance to EUROPRO Operating LLC (see warranty)
for examination and repair. Incorrect
re-assembly or repair can cause a risk of
electrical shock or injury to persons when
the appliance is used.
6. Use only as described in this manual.
7. Use only manufacturer’s recommended
accessories and replacement pads.
TOL L FREE : 1 -8 00 -79 8-73 98
TO REDUCE
8. To protect against a risk of electric shock,
DO NOT immerse the appliance into
water or any other liquids.
9. DO NOT handle plug or appliance
with wet hands or operate appliance
without shoes.
10. DO NOT pull or carry by power cord, use
power cord as a handle, close a door on
the power cord, or pull the power cord
around sharp edges or corners. Do not
run appliance over cord. Keep power
cord away from heated surfaces.
11. DO NOT unplug by pulling on power
cord. To unplug, grasp the plug not
the power cord. Do not use extension
cords or outlets with inadequate current
carrying capacity.
12. DO NOT put any objects into the unit
openings. Do not use the unit if any
opening is blocked; keep free of dust,
lint, hair and anything that may reduce
airflow.
13. DO NOT put hands or feet under the Vac-
Then-Steam™. Unit gets very hot and may
burn.
14. Use ONLY on flat, horizontal surfaces. Do
not use on walls, counters or windows.
15. DO NOT use on leather, wax polished
furniture and floors, synthetic fabrics,
velvet or other delicate, steam sensitive
materials.
16. DO NOT add cleaning solutions, scented
perfumes, oils or any other chemicals to
the water used in this appliance as this
may damage the unit or make it unsafe
for use and void the warranty. If you live
in a hard water area, we recommend
using distilled water in your Vac-Then-
Steam™.
17. When in use, NEVER turn the appliance
over or on its side. NEVER DIRECT
STEAM TOWARDS PEOPLE, ANIMALS
OR PLANTS.
18. NEVER LEAVE THE CLEANING UNIT IN
ONE SPOT ON ANY SURFACE FOR ANY
PERIOD OF TIME WHEN MICRO-FIBER
PAD IS ATTACHED.
MV2010_11_IB_ENG_110103.indd 2 11-01-03 1:26 PM
19. Carefully remove the micro-fiber pad
immediately after you have unplugged
and allowed the appliance to cool.
20. When cleaning the appliance, unplug the
power cord from the electrical outlet and
clean with a dry or damp cloth. Do not
pour water or use alcohol, benzene or
paint thinner on the unit.
21. Extreme caution should be exercised
when using this appliance to clean stairs.
22. Never use Steam function without microfiber pad attached.
23. Keep your work area well lit.
24. Store appliance indoors in a cool,
dry place.
25. To avoid circuit overload, do not operate
another appliance on the same socket
(circuit) as the cleaning unit.
26. If an extension cord is absolutely
necessary, an extension cord rated a
minimum of 15 ampere, 14 gage cord
should be used. Cords rated for less
amperage may overheat. Care should be
taken to arrange cord so that it cannot be
pulled or tripped over.
27. DO NOT store unit with damp/wet microfiber cleaning pad attached.
28. DO NOT use the vacuum cleaner without
dust cup and filter in place.
29. DO NOT vacuum up any liquids.
30. DO NOT pick up anything that is burning
or smoking such as cigarettes, matches
or hot ashes.
31. To reduce the risk of fire DO NOT use to
pick up flammable or combustible liquids
such as gasoline or use vacuum in areas
where flammable or combustible fumes
may be present.
32. DO NOT pick up toxic solutions such as
chlorine bleach, ammonia or drain cleaner
with the cleaning unit.
33. DO NOT use in an enclosed space
where vapors are present from paint,
paint thinner, mothproofing substances,
flammable dust or other explosive or
toxic materials.
34. DO NOT run the cleaning unit over largesized objects.
35. DO NOT pick up hard or sharp objects
such as glass, nails, screws or coins that
could damage the cleaning unit.
36. DO NOT place appliance on unstable
surfaces such as chairs or tables.
37. DO NOT allow the cleaning unit to be
used as a toy.
38. Close attention is necessary when used
near children.
39. Keep hair, loose clothing, fingers and all
parts of the body away from openings
and moving parts.
40. Turn off all controls before plugging or
unplugging your Vac-Then-Steam™.
WARNING: Your appliance is designed
to clean non-carpeted, sealed hard floor
surfaces that will withstand high heat. Do
not use on unsealed wood or unglazed
ceramic floors, on surfaces that have
been treated with wax or on some no
wax floors. The sheen may be removed
by the heat and steam action. It is always
recommended to test an isolated area
of the surface to be cleaned before
proceeding. We also recommend that
you check the use and care instructions
provided by the floor manufacturer.
POLARIZED PLUG
TO REDUCE THE RISK OF ELECTRIC
SHOCK, this appliance has a polarized
plug (one blade is wider than the other).
As a safety feature, this plug will fit into a
polarized outlet only one way. If the plug
does not fit fully into the outlet, reverse
the plug. If it still does not fit, contact a
qualified electrician. DO NOT ATTEMPT
TO DEFEAT THIS SAFETY FEATURE.
SAVE THESE
INSTRUCTIONS
ww w.S harkVa cThe nSteam .com
MV2010_11_IB_ENG_110103.indd 3 11-01-03 1:26 PM
Steam Technology
Thank you for purchasing the
®
Shark
the complete bare floor
cleaning system.
The unique steam technology,
turns simple tap water into
super-heated steam that infuse
the micro-fiber pads for chemical
free cleaning. Only this method
creates and delivers 212°F
steam that is effective enough
to clean and sanitize all your
hard floor surfaces. The Shark®
Vac-Then-Steam™ can help you
achieve a truly clean and healthy
environment for you and
your family.
Vac-Then-Steam™,
THIS BOOK COVERS MODEL NUMBER:
MV2010 11
TECHNICAL SPECIFICATIONS
Voltage: 120V., 60Hz.
Power: 1550 Watts
Water
Capacity: 300 ml (10 oz.)
TOL L FREE : 1 -8 00 -79 8-73 98
MV2010_11_IB_ENG_110103.indd 4 11-01-03 1:26 PM
Contents
Getting Started: Assembly ................................................2
Getting Started: Mode Controls ......................................4
Vacuum Mode .........................................................................5
Steam Mode ............................................................................8
Maintaining Your Vac-Then-Steam™ ..............................12
Troubleshooting Guide ....................................................... 14
Warranty and Registration ................................................15
Eng lis h
Visit SharkVacThenSteam.com for more
helpful hints and support.
ww w.S harkVa cThe nSteam .com
MV2010_11_IB_ENG_110103.indd 1 11-01-03 1:26 PM
1
Getting Started: Assembly
h
When assembling your Vac-Then-Steam™
there may be a little water in or around
the water tank. This is because we
quality test all our Shark products before
distributing them, so you get a quality
Shark® Vac-Then-Steam™.
a
c
d
e
f
b
g
i
j
k
l
m
n
p
o
q
a Telescopic Handle
b Cleaning Unit with Dust Cup
c 2 All-Purpose Cleaning Pads and
1 Heavy Duty Cleaning Pads
d Steam Frame
e Filling Flask
f 1 Replacement Post-Motor Filter
g 1 Replacement Dust Cup Filters Set
2
MV2010_11_IB_ENG_110103.indd 2 11-01-03 1:26 PM
TOL L FREE : 1 -8 00 -79 8-73 98
h Mop Handle
i Quick Release Swivel Cord Wrap
j Cord Clip
k Telescopic Handle Latch
l Carry Grip
m Vacuum and Steam Mode Panel
n Water Tank Cap
o Water Tank Viewing Window
p Post-Motor Filter Access
q Dust Cup
