Shark KD400WM User Manual

WWW.SHARKSONICDUO.COM

SONIC DUO

™

Wood & Hard Floor Cleaner

KD400WM

OWNER’S GUIDE

KD400WM_26_IB_E_130225_6.indd 1 13-02-25 9:35 AM

TOLL FREE: 1-800-798-7398

IMPORTANT SAFETY INSTRUCTIONS

For Household Use Only

WHEN USING YOUR SHARK® SONIC DUO™, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:

READ ALL INSTRUCTIONS BEFORE USING YOUR SHARK® SONIC DUO

™

Wood & Hard Floor Cleaner.

POLARIZED PLUG:

This appliance has a polarized plug (one blade is wider than the other). As a safety feature, this plug will ﬁt into a polarized outlet only one way. If the plug does not ﬁt fully into the outlet, reverse the plug. If it still does not ﬁt, contact a qualiﬁed electrician. Do not

attempt to defeat this safety feature.

CAUTION:

Keep all Shark® branded cleaners and polishes out of the reach of children. Eye irritant. Should some of the Shark® branded cleaners and polishes be rubbed or splashed into the eyes, wash out thoroughly with water. If irritation continues, contact a physician. In case of ingestion, drink 16 FL. oz. (2 cups) of water.

WARNING:

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:

1. Use the system only for its intended use.

2. DO NOT use outdoors.

3. DO NOT leave the appliance unattended when plugged in. Always turn the appliance off (O) and unplug the power cord from the electrical outlet when not in use and before servicing.

4. Turn off all controls before unplugging.

5. DO NOT allow to be used as a toy. Close attention is necessary when used by or near children, pets or plants.

6. Use only as described in this manual.

7. Use only manufacturer’s recommended accessories.

8. DO NOT use with damaged cord or plug. If the appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return the appliance to EURO-PRO Operating LLC for examination and repair. Incorrect re-assembly or repair can cause a risk of electrical shock or injury to persons when the appliance is used.

9. To protect against a risk of electric shock, DO NOT immerse the appliance into water or any other liquids.

10. DO NOT handle the plug or the appliance with wet hands or operate the appliance without shoes.

11. DO NOT pull or carry by cord, use the power cord as a handle, close a door on the cord, or pull the cord around sharp edges or corners. Do not run the appliance over the power cord. Keep the power cord away from heated surfaces.

KD400WM_26_IB_E_130225_6.indd 2 13-02-25 9:35 AM

www.sharksonicduo.com

12. DO NOT unplug by pulling on the power cord. To unplug, grasp the plug not the power cord. Do not use extension cords or outlets with inadequate current carrying capacity.

13. DO NOT use for space heating purposes.

14. DO NOT put any objects into openings. Do not use with any opening that is blocked.

15. DO NOT put hands or feet under the Sonic Duo™.

16. Keep hair, loose clothing, ﬁngers, and all parts of the body away from openings and moving parts.

17. Use ONLY on ﬂat, horizontal surfaces. Do not use on walls, counters or windows.

18. To reduce the risk of ﬁre and electric shock use ONLY Shark®’s cleaning and polishing solutions intended for use with this appliance.

19. DO NOT add any cleaning solutions in the Shark® Sonic Duo™ other than Shark®’s Wood & Hard Floor Cleaner. The Wood & Hard Floor Polish should never be run through the Sonic Duo™. It will cause clogging. Use of other scented perfumes, oils or any other chemicals added to the solution or to the Reusable Bottle used in this appliance may damage or clog the unit and void the warranty. If you live in a hard water area, we recommend using distilled water to dilute the Wood & Hard Floor Cleaner for better performance.

20. DO NOT mix other cleaners with Shark®’s Wood & Hard Floor Cleaner as this could affect the effectiveness of the appliance.

21. DO NOT use the Sonic Duo™ to clean up or absorb ﬂammable or combustible materials.

22. NEVER LEAVE THE Sonic Duo™ IN

ONE SPOT ON ANY SURFACE FOR ANY PERIOD OF TIME WHEN THE CLEANING OR POLISHING PAD IS ATTACHED OR WITH THE APPLIANCE TURNED ON AS THIS WILL DAMAGE YOUR FLOORS.

23. When cleaning the Sonic Duo™, unplug the power cord from the electrical outlet, and clean with a dry or damp cloth. Do not pour water or use alcohol, benzene or paint thinner on the unit.

24. Unplug the appliance before attaching or removing the pads.

25. Extreme caution should be exercised when using this appliance to clean stairs.

26. Never use the Sonic Duo™ without the Hard Floor Cleaning Pad or Hard Floor Polishing Pad attached.

27. Keep your work area well lit.

28. Store the Sonic Duo™ indoors in a cool, dry place.

29. To avoid circuit overload, do not operate another appliance on the same socket (circuit) as the Sonic Duo™.

30. If an extension cord is absolutely necessary, an extension cord rated a minimum of 15 ampere, 14 gauge cord should be used. Cords rated for less amperage may overheat. Care should be taken to arrange cord so that it cannot be pulled or tripped over.

31. This appliance is provided with double insulation. Use only identical replacement parts. See instructions for servicing of double-insulated appliances.

WARNING: Your SONIC DUO

designed to clean hard ﬂoor surfaces. Do not use on wood or tile ﬂoors that are highly worn, unﬁnished or have a wax or oil ﬁnish. Surfaces that have been treated with wax or some no wax ﬂoors may be damaged by the cleaning and polishing solutions therefore it is always recommended to test an isolated area of the surface to be cleaned before proceeding. You should always check the use and care instructions from the ﬂoor manufacturer.

™

SAVE THESE INSTRUCTIONS

KD400WM_26_IB_E_130225_6.indd 3 13-02-25 9:35 AM

TOLL FREE: 1-800-798-7398

Servicing of double-insulated appliances:

A double-insulated appliance is marked with one or more of the following: The words “doubleinsulation” or “double-insulated” or the double insulation symbol (square within a square).

In a double-insulated appliance, two systems of insulation are provided instead of grounding. No grounding means is provided on a double-insulated appliance, nor should a means for grounding be added to the appliance. Servicing a double-insulated appliance requires extreme care and knowledge of the system, and should be done only by qualiﬁed service personnel. Replacement parts for a double-insulated appliance must be identical to the parts they replace.

This manual covers model numbers: KD400WM 26

TECHNICAL SPECIFICATIONS

Voltage: 120V~, 60Hz. Power: 96 Watts Reusable Bottle Capacity: 32 oz.

Euro-Pro, Shark, Sonic Duo, and Rotator are trademarks of Euro-Pro Operating LLC. All other brand names may be trademarks of their respective owners.

KD400WM_26_IB_E_130225_6.indd 4 13-02-25 9:35 AM

www.sharksonicduo.com

Contents

Thank you for purchasing the

Shark® Sonic Duo™ Wood &

Hard Floor Cleaner.

Getting Started ................................................................................................... 2

Using Your Sonic Duo™ Wood & Hard Floor Cleaner........................................4

Cleaning Your Hard Floors ................................................................................ 4

Polishing Your Hard Floors ............................................................................... 6

Care and Maintenance ........................................................................................ 9

Ordering Replacement Parts ................................................................................10

Troubleshooting Guide ........................................................................................ 11

Warranty ............................................................................................................. 13

KD400WM_26_IB_E_130225_6.indd 1 13-02-25 9:35 AM

TOLL FREE: 1-800-798-7398

Getting Started

When assembling your Sonic Duo™ there may be a little water in the Reusable Bottle. This is because we test all of our products 100% before you buy them, so you get a quality Shark® Sonic Duo™ Wood & Hard Floor Cleaner.

g Reusable Bottle for Hard Floor Cleaning Solution

h Wood & Hard Floor Cleaner

a Handle

b Spray Button

c On/Off Button

d Sonic Duo™ Scrub Head

e Spray Nozzle

f Storage Tray

KD400WM_26_IB_E_130225_6.indd 2 13-02-25 9:35 AM

i Hard Floor Cleaning Pad (x2)

NOTE: Additional accessories such as cleaning pads and

cleaning solutions are available for purchase at www.sharksonicduo.com or by calling 1-800-798-7398. A special tool that aids in the removal of scuff marks and polish touch ups is also available.
