Shandong Bittel Intelligent Technology MODA B User Manual

User Manual

MODA Series

Followed description maybe different from the real device. Please keep the real device as the criterion. The telephone is subject to change without notice. In order to fully use this device please read this manual carefully.

We bring good things to Hospitality.

_______________________________________________________________________

BITTEL Page 1 of 14 MODA

Thank you for purchasing a Bittel product.

1. CHARGER MODULE

1. Convenient charging cables for Apple and USB-C devices

2. Two USB Ports (5V, 2.1A)

3. One USB-C Port (5V, 2.1A)

4. Optional wireless charging module added to upper stack.

MAIN FEATURES

MODA is a kind of Multi-Media device, which is specially designed to meet the need of hotel guestroom.

MODA is Portuguese word, which means modern and fashion. Now MODA is the latest new products of Bittel designed by Jacob Jensen, which means Modern, Modular and Stylish.

MODA combines the unique design and useful features in one, which is made of first class electrical materials, awarded several patents.

We will introduce one module by one.

Charger Module is the necessary model, which is the base of the

device.

Main Features:

magnetically attached

_______________________________________________________________________

BITTEL Page 2 of 14 MODA

Location

1. Smart Charging Port

2. Quick Charging Port

3. HDMI IN Port

4. TYPE C Port

5. Magnetic charging

Cable

6. HDMI OUT

Port

7. RS232 Port

8. DC Port

9. TO TEL Port

10 Handset Cord Port

1. Bluetooth 5 compatible

2. MODA specific pairing ID;upon request activate( push button or

3. Non-active timeout after 20 minutes of inactivity

2.FM RADIO/BLUETOOTH MODULE

This module owns the feature of Radio and Bluetooth.

Main Feature:

command *Requires MODA voice recognition module)

_______________________________________________________________________

BITTEL Page 3 of 14 MODA

4. FM Radio quick scan through frequencies

Location and Feature

3 4

1. Bluetooth Button

2. Volume -

3. Turning-

4.Turning+

5.Volume +

6. Radio Button

1. Playing Music

2. FM Radio

Operation

Apple devices/ mobile phones/ MP3 and other devices can be played by Bluetooth.

Please press Bluetooth key, an ID Number will be displayed on the LCD screen of the Clock module. Then open Bluetooth function of the mobile devices to search that ID No and they will be paired connection without password. The Bluetooth button will flash and keep light if the connection is correct.

Press Bluetooth button again, will close the bluetooth feature.

Please press RADIO key to select the FM-RADIO mode, then press TUNING+/- to select the needed frequency.

_______________________________________________________________________

BITTEL Page 4 of 14 MODA

Press TUNING+/-for a while, it will search frequency forward or

3. Turn on/off Hotel Mode

4. Auto dimming with ambient light sensor which needs work with

1. TruTime insures clock time is always correct.

2. Automatic Daylight savings adjustments

3. Rechargeable battery backup keeps time and alarm visible and

4. Auto Dimming with ambient light sensor

5. Easy to use alarm with 10-minute duration

6. Single day alarm

7. Support IR remote for easy adjustment of clock and or calendar.

backward and will stop automatically after searching certain channel.

Press RADIO for a while, you can choose the channel of 87.5-

108.0Mhz or 76-108.0Mhz.

AUDIO OFF mode, press VOLUME- for a while, LCD display of the Clock Module will display ON or OFF (ON or OFF the hotel mode).

ON standards for turning on the hotel mode, the volume can be

adjusted from 0 to 20;

Off standards for turning off the hotel mode, the volume can be

adjusted from 0 to 30.

Clock Module.

The ▼ button of the Clock Module can also be used to adjust the

brightness.

3. CLOCK MODULE

Main Features:

active for 24 hours.

_______________________________________________________________________

BITTEL Page 5 of 14 MODA
