Installation Instruction for Shadow SH 2001
Quick Mount Removable Transducer
Content:Content:
Transducer
output socket
cable
mounting adhesive
1. Locate the best position on the instrument for optimum sound quality and output. See suggested locations in fig. 1.
2. Apply an even amount of included adhesive to the bottom of the pickup.
3. Press pickup firmly onto the instrument.
4. Position the included output cable in a convenient location.
5 . Connect to an ppropriate amplifier with included instrument cable.
1
2
3
Fig. 1
Note:
Piezo pickups and transducers have a very high output impedance. In order to get the optimum sound output we
recommend an amplifier with low impedance input.
