HIGH PERFORMANCE, STABLE 57KHz FILTER
HIGHSELECTIVITY
FLAT GROUP DELAY
HIGHPERFORMANCE LIMITER
VERYFEW EXTERNALCOMPONENTS
4.332MHzCLOCKOSCILLATOR
(8.664MHzOPTIONAL)
TDA7332
RDS FILTER
DESCRIPTION
The TDA7332 is an RDS filter, realized in
switchedcapacitortechnique.
The 4 biquad stage architecture is working with
4.332MHzclock.
Optionallya 8.664MHzxtalcan be used.
The filter has a center frequency of 57KHz and a
bandwidth of 3KHz. Input 2
ter and output smoothing filter are provided.
TEST CIRCUIT
nd
order antialiasing fil-
DIP14 SO14
ORDERING NUMBERS:
TDA7332 TDA7332D
TDA7332DIE1 (Chip on wafer)
November 1999
1/6
TDA7332
ABSOLUTE MAXIMUM RATINGS
Symbol Parameter Value Unit
V
T
op
T
stg
THERMAL DATA
Symbol Description DIP14 SO14 Unit
R
th j-case
PIN CONNECTION (Top view)
Supply Voltage 7 V
S
Operating Temperature Range -40 to 85
Storage Temperature -40 to 150 °C
Thermal Resistance Junction-case Typ. 100 200 °C/W
C
°
BONDINGPAD LOCATIONS
2/6
(Topview)
TDA7332
ELECTRICALCHARACTERISTICS (VCC= 5V, Tamb = 25°C; fosc = 4.332MHz; VIN= 20mVrms unless
otherwise specified)
Symbol Parameter Test Condition Min. Typ. Max. Unit
SUPPLYSECTION
V
CC
I
Supply Voltage 4.5 5 5.5 V
Supply Current 6 9 14 mA
S
FILTER
F
BW 3dB Bandwidth 2.5 3 3.5 KHz
G Gain f = 57KHz 18 20 22 dB
A Attenuation
Ph Phase non linearity A (see note1)
∆
R
S/N Signal to Noise Ratio V
V
R
Center Frequency 56.5 57 57.5 KHz
C
f = +4KHz
∆
f = 38KHz; V
f = 67KHz; V
= 500mVrms
i
= 250mVrms
i
18
50
35
22
80
50
0.5
B (see note1)
C (see note1)
Input Impedance 100 160 200 KΩ
i
= 3mVrms 30 40 dB
i
Input Signal f=19KHz;T3<–40dB(seenote2)
i
1
2
f = 57KHz (RDS + ARI)
Load Impedance Pin 12 100 K
L
5
7.5
10
1
50
LIMITER
RA Resistance pin 8-12 15 21 28 K
V
OL
V
OH
Comp. Output LOW IO= +0.5mA 1 V
Comp. Output HIGH IO = –0.5mA 4 V
Duty Cycle V
= 1mVrms 50 %
i
OSCILLATOR
dB
dB
dB
DEG
DEG
DEG
Vrms
mVrms
Ω
Ω
F
OSC
Oscillator Frequency F
= Open
SEL
F
= Closed to Ground
SEL
4.332
8.664
Output Amplitude 5 V
V
CLL
V
OLH
Clock Input Level LOW 1 V
Clock Input Level HIGH 4 V
CRYSTALTYPE = EURO QUARTZ
Note (1):
The phase non linearity isdefined as: ∆Ph = | -2 φf2 + φf1 + φf3 |
where φfx is the input-output phase difference at the frequency fx (x = 1,2,3)
Measure f1 (KHz) f2 (KHz) f3 (KHz) ∆Ph max
A 56.5 57 57.5 <5°
B 56 57 58 <7.5
C 55.5 57 58.5 <10°
Note (2): The 3th harmonic(57KHz) at the output (pin12) must be less than -40dB in respect to the input signal plus gain.
°
MHz
MHz
PP
3/6
TDA7332
DIM.
MIN.. TYP. MAX.. MIN.. TYP.. MAX..
A 1.75 0.069
a1 0.1 0.25 0.004 0.009
a2 1.6 0.063
b 0.35 0.46 0.014 0.018
b1 0.19 0.25 0.007 0.010
C 0.5 0.020
c1 45°(typ.)
D (1) 8.55 8.75 0.336 0.344
E 5.8 6.2 0.228 0.244
e 1.27 0.050
e3 7.62 0.300
F (1) 3.8 4 0.150 0.157
G 4.6 5.3 0.181 0.209
L 0.4 1.27 0.016 0.050
M 0.68 0.027
S8°
(1) D and F donot includemold flashor protrusions. Mold flash or
potrusions shallnot exceed 0.15mm(.006inch).
mm inch
(ma x.)
OUTLINE AND
MECHANICAL DATA
SO14
4/6
TDA7332
DIM.
MIN. TYP. MAX. MIN. TYP. MAX.
a1 0.51 0.020
B 1.39 1.65 0.055 0.065
b 0.5 0.020
b1 0.25 0.010
D 20 0.787
E 8.5 0.335
e 2.54 0.100
e3 15.24 0.600
F 7.1 0.280
I 5.1 0.201
L 3.3 0.130
Z 1.27 2.54 0.050 0.100
mm inch
OUTLINE AND
MECHANICAL DATA
DIP14
5/6
TDA7332
