RF & MICROWAVE TRANSISTORS
.55 - 88 MHz
.32 VOLTS
.COMMON EMITTER
.GOLD METALLIZATION
.INTERNAL INPUT MATCHING
.C LASS AB PUSH PULL
. HIGH SATURATED POWER CAPABILITY
.DIFFUSED EMITTER BALLAST
RESISTORS
. D ESI GN ED FOR H IGH POWER LINEAR
OPERATION
.P
OUT
240WMIN.WITH12.0dBGAIN
=
SD1476
TV/LINEAR APPLICATIONS
2x.437x.4502LFL(M165)
epoxy sealed
ORDER CODE
SD1476
PIN CONNECTION
BRANDING
SD1476
DESC RIPT ION
The SD1476 is a gold metallized epitaxial silicon
NPN planar transistor using diffused emitter ballast
resistors for high linearity Class AB operation in
VHF and Band I television transmitters and transposers.
ABSOLUTE MAXIMUM RATINGS (T
Symbol Parameter Value Uni t
V
CBO
V
CEO
V
EBO
I
C
P
DISS
T
J
T
STG
THERMA L DA TA
R
TH(j-c)
Collector-Base Voltage 70 V
Collector-Emitter Voltage 40 V
Emitter-Base Voltage 4.0 V
Device Current 25 A
Power Dissipation 430 W
Junction Temperature +200
Storage Temperature
Junction-Case Thermal Resistance 0.4 °C/W
case
= 25°C)
1. Collector 3. Emitter
2. Base
50 to +150
−
°
C
°
C
November 1992
1/8
SD1476
ELECTRICAL SPECIFICA TIONS (T
case
= 25°C)
STATIC
Symbol Test Conditions
BV
BV
BV
BV
I
I
CBO
CER
CEO
EBO
CEO
CBO
h
FE
IC= 50mA IE= 0mA 70 — — V
IC= 50mA RBE= 51Ω 68 — — V
IC= 100mA IB= 0mA 40 — — V
IE= 20mA IC= 0mA 4.0 — — V
VCE= 30V IE= 0mA — — 10 mA
VCB= 30V IE= 0mA — — 10 mA
VCE= 5V IC= 7A 10 — 50 —
Min. Typ. Max.
Value
DYNAMIC
Symbol Test C ond itions
P
*f=88 MHz VCE= 32 V ICQ= 2 x 400mA 240 — — W
OUT
G
P
η
cf=88 MHz VCE= 32 V ICQ= 2 x 400mA 50 — — %
C
OB
Note: *1 dB Comp ression
f = 88 MHz VCE= 32 V ICQ= 2 x 400mA 12 — — dB
f = 1 MHz VCB= 28 V — — 220 pF
Value
Min. Typ. Max.
Unit
Unit
2/8
TYPICA L PERFO R MA NCE
SD1476
POWER OUTPUT vs POWER INPUT
THERMAL RESISTANCE vs CASE
TEMPERATURE
POWER GAIN vs FREQ U ENCY
COLLECTOR EFFICIENCY vs FREQUENCY
3/8
SD1476
IMPEDA NCE DATA
TYPICAL INPUT
IMPEDANCE
Z
IN
TYPICAL COLLECTOR
LOAD IMPEDANCE
Z
CL
FREQ. ZIN(Ω)ZCL(Ω)
55 MHz 1.7 j 1.0 6.1 + j 1.0
65 MHz 1.5 + j 1.3 7.0 + j 2.1
75 MHz 1.0 + j 1.1 6.2 + j 2.0
90 MHz 0.8 + j 0.4 3.4 + j 4.4
P
= 240 W
OUT
VCC= 32 V
4/8
PRINTED CIRCUIT BOARD LAYOUT
SD1476
5/8
SD1476
TEST CIRCUIT
C1 : 10pF + 33pF, ATC 100B
C2 : 47pF, ATC 100B
C3, C’3 : 1.5nF + 2.2nF, ATC 100B
C4 : 4 - 60pF, Arco 404
C5 : 2 x 100pF + 47pF, ATC 100B
C6 : 2 x 330pF + 3 x 180pF +270pF, ATC 100B
C7 : 150pF + 10pF, ATC 100B
C8, C’8 : 4.7nF, ATC 100B
C9 : 4 - 40pF, Arco 403
C10 : 10pF, ATC 100B
C11 : 43pF, ATC 100B
C12, C’12 : 1µF 63V, LCC CPM13B
C13, C’13 : 82nF 100V, LCC 745
C14, C’14 : 270nF 63V, LCC7950
L1, L7 : 4 Turns Diameter 7mm, Wire Diameter 1.5mm
L2 : 7 Turns Diameter 25mm, Coaxial Cable Zc
L3, L’3 : 2 Turns Diameter 2.5mm, Wire Diameter 0.8mm
L4, L’4 : Length 15mm, Wire Diameter 1.5mm
L5, L’5 : Length 30mm, Wire Diameter 1.5mm
L6 : 6 Turns Diameter 25mm, Coaxial Cable Zc
L8, L’8 : 16 Turns Diameter, Wire Diameter 1.5mm
L9, L’9 : 1 Turn, Wire Diameter 1.5mmin Ferrite
L10, L’10
L11, L’11 : 14 Turns, Wire Diameter 0.6mm Around Resistor 1W
R1, R’1
R2, R’2 : 180Ω,1W
Material : Epoxy 63 mil, Er=2.55
(stackpole 57 33 12)
25Ω
=
25Ω
=
6/8
PACKAGE MECHANICAL DATA
Ref.: Dwg. No.12-0165
SD1476
7/8
SD1476
