SGS-THOMSON M54HC7240, M54HC7241, M54HC7244, M74HC7240, M74HC7241 Technical data

查询M54HC7240供应商

OCTAL BUS BUFFERWITH3 STATE OUTPUTS

HC7240: INVERTED - HC7241/7244 NON INVERTED

.HIGH SPEED

tPD= 15 ns(TYP.) at VCC=5V

.LOWPOWER DISSIPATION

ICC=4µA (MAX.) at TA=25oC

.HIGH NOISE IMMUNITY

VH= 1.1 V(TYP.) at VCC=5V

.OUTPUTDRIVE CAPABILITY

15 LSTTL LOADS

.SYMMETRICALOUTPUT IMPEDANCE

|IOH|=IOL=6 mA (MIN)

.BALANCEDPROPAGATIONDELAYS

t

PLH=tPHL

.WIDE OPERATINGVOLTAGERANGE

VCC(OPR)= 2V to 6V

.PIN AND FUNCTION COMPATIBLE

WITH 54/74LS240/241/244

DESCRIPTION

TheM54/74HC7240, HC7241andHC7244arehigh
speed CMOSOCTAL BUS BUFFERsfabricated in
silicongate C2MOS technology.

They have the same high speed performance of
LSTTL combined with true CMOS low power
consumption.

The designerhas a choise of select combination of
inverting and non-inverting outputs, symmetricalG
(active low output control) input, and
complementary G andG inputs. Each controlinput

M54HC7240/7241/7244

M74HC7240/7241/7244

B1R

(PlasticPackage)

M1R

(MicroPackage)

ORDER CODE S :

M54HC XXXXF1R M74H CX XXXM1 R
M74HC XXXXB1R M74 HCXXXXC1R

governsfour BUS BUFFERs.
The HC7240,HC7241 and HC7244 have the same

pinconfigurationandfunctionastheHC240,HC241
and HC244 and they have a hysteresis
characteristics with each input so can be used as a
line receiver, etc.

All inputs are equipped with protection circuits
against static discharge and transient excess
voltage.

F1R

(CeramicPackage)

C1R

(Chip Carrier)

PIN CONNECTION (top view)

October 1993

HC7244HC724 1HC7240

1/12

M54/M74HC7240/7241/7244

CHIP CARRIER

HC7244HC724 1HC7240

INPUT AND OUTPUT EQUIVALENT CIRCUIT PIN DESCRIPTION (HC7240)

PIN No SYMBOL NAME AND FUNCTION

1 1G Output Enable Input
2, 4, 6, 8 1A1 to 1A4 Data Inputs
9, 7, 5, 3 2Y1 to 2Y4 Data Outputs

11, 13, 15,172A1 to 2A4 Data Inputs

PIN DESCRIPTION (HC7241)

PIN No SYMBOL NAME AND FUNCTION

1 1G Output Enable Input
2, 4, 6, 8 1A1 to 1A4 Data Inputs
9, 7, 5, 3 2Y1 to 2Y4 Data Outputs

11, 13, 15,172A1 to 2A4 Data Inputs

18, 16, 14,121Y1 to 1Y4 Data Outputs

19 2G Output Enabel Input
10 GND Ground (0V)
20 V

CC

Positive Supply Voltage

18, 16, 14,121Y1 to 1Y4 Data Outputs

19 2G Output Enabel Input
10 GND Ground (0V)
20 V

CC

Positive Supply Voltage

PIN DESCR IPTION (HC7 244)

PIN No SYMBOL NAME AND FUNCTION

1 1G Output Enable Input
2, 4, 6, 8 1A1 to 1A4 Data Inputs
9, 7, 5, 3 2Y1 to 2Y4 Data Outputs

11, 13, 15,172A1 to 2A4 Data Inputs

18, 16, 14,121Y1 to 1Y4 Data Outputs

19 2G Output Enabel Input
10 GND Ground (0V)
20 V

CC

Positive Supply Voltage

2/12

IEC LOGIC SYMBOLS

TRUTH TABLE

M54/M74HC7240/7241/7244

HC7244HC724 1HC7240

INPUT OUTPUT

G G (HC7241) An Yn (HC7240) Yn (HC7241) Yn (HC7244)

LHLHLL
LHHLHH

X: ”H” or ”L”
Z: Highimpedance

HLXZZZ

CIRCUIT SCHEMATIC (1/8 PACKAGE)

HC724 0 HC7244

3/12

M54/M74HC7240/7241/7244

ABSOLU TE MAXI MU M RAT I NG S

Symbol Parameter Value Unit

V

CC

V

V

O

I

IK

I

OK

I

O

I

or I

CC

P

D

T

stg

T

AbsoluteMaximumRatingsarethose values beyond whichdamage tothedevicemayoccur. Functional operation under these condition isnotimplied.
(*)500 mW:≅ 65oC derate to300 mW by 10mW/oC: 65oCto85oC

RECO MM ENDED OPERAT IN G CO NDITIONS

Symbol Parameter Value Unit

V

CC

V

I

V

O

T

op

Supply Voltage -0.5 to +7 V
DC Input Voltage -0.5 to VCC+ 0.5 V

I

DC Output Voltage -0.5 to VCC+ 0.5 V
DC Input Diode Current ± 20 mA
DC Output Diode Current ± 20 mA
DC Output Source Sink Current Per Output Pin ± 35 mA
DC VCCor Ground Current ± 70 mA

GND

Power Dissipation 500 (*) mW
Storage Temperature -65 to +150
Lead Temperature (10sec) 300

L

Supply Voltage 2 to 6 V
Input Voltage 0 to V
Output Voltage 0 to V
Operating Temperature: M54HC Series

M74HC Series

CC
CC

-55 to +125

-40 to +85

o

C

o

C

V
V

o

C

o

C

4/12

DC SPECIFICATIONS

Symbol Parameter

V

V

V

V

V

I

I

High Level

P

Threshold
Voltage

Low Level

N

Threshold
Voltage

Hysteresis

H

Voltage

High Level

OH

Output Voltage

Low Level Output

OL

Voltage

I

Input Leakage

I

Current
3 State Output

OZ

Off State Current
Quiescent Supply

CC

Current

M54/M74HC7240/7241/7244

Test Conditions Value

T

=25oC

V

(V)

CC

A

54HC and 74HC

Min. Typ. Max. Min. Max. Min. Max.

2.0 1.0 1.25 1.5 1.0 1.5 1.0 1.5

4.5 2.3 2.7 3.15 2.3 3.15 2.3 3.15

6.0 3.0 3.5 4.2 3.0 4.2 3.0 4.2

2.0 0.3 0.65 0.9 0.3 0.9 0.3 0.9

4.5 1.13 1.6 2.0 1.13 2.0 1.13 2.0

6.0 1.5 2.3 2.6 1.5 2.6 1.5 2.6

2.0 0.3 0.6 1.0 0.3 1.0 0.3 1.0

4.5 0.6 1.1 1.4 0.6 1.4 0.6 1.4

6.0 0.8 1.2 1.7 0.8 1.7 0.8 1.7

2.0
V

=

I

4.5 4.4 4.5 4.4 4.4

6.0 5.9 6.0 5.9 5.9

4.5 I

6.0 I

IO=-20 µA

V

IH

or

V

IL

=-6.0 mA 4.18 4.31 4.13 4.10

O

=-7.8 mA 5.68 5.8 5.63 5.60

O

2.0

I

=20µA

4.5 0.0 0.1 0.1 0.1

O

1.9 2.0 1.9 1.9

0.0 0.1 0.1 0.1

6.0 0.0 0.1 0.1 0.1

4.5 I

6.0 I

6.0

VO=VCCor GND

V

6.0

= 6.0 mA 0.17 0.26 0.33 0.40

O

= 7.8 mA 0.18 0.26 0.33 0.40

O

VI=VIHor V

I=VCC

IL

or GND ±0.5 ±5 ±10 µA

6.0 VI=VCCor GND 4 40 80 µA

-40 to 85oC
74HC

-55 to 125oC
54HC

Unit

±0.1 ±1 ±1 µA

V

V

V

V

V

5/12

M54/M74HC7240/7241/7244

AC ELECTRICAL CHARACTERISTICS (CL=50pF,Inputtr=tf=6ns)

Test Conditions Value

T

=25oC

Symbol Parameter

t
t

TLH
THL

Output Transition
Time

V

C

CC

(V)

L

(pF)

2.0
50

4.5 7 12 19

A

54HC and 74HC

Min. Typ. Max. Min. Max. Min. Max.

25 60 75

6.0 6 10 13

t
t

PLH
PHL

Propagation
Delay Time

2.0
50

4.5 15 25 31

50 125 155

6.0 13 21 26

t

t

PZL
PZH

Output Enable
Time

2.0
50 RL=1KΩ

4.5 21 30 38

68 150 190

6.0 16 26 32

t

t

PLZ
PHZ

Output Disable
Time

2.0
50 RL=1KΩ

4.5 21 30 38

48 150 190

6.0 19 26 32

C

C

Input Capacitance 5 10 10 10 pF

IN

OUT

Output

10

Capacitance

C

(*) Power Dissipation

PD

Capacitance

(*) CPDisdefined as the value ofthe IC’s internal equivalent capacitance which is calculated fromthe operating currentconsumption withoutload.
(RefertoTestCircuit).Average operting currentcan be obtained bythe followingequation. ICC(opr) = CPD•VCC•fIN+ICC/8(per channel)

HC7240

HC7241/7244

33
34

-40 to 85oC
74HC

-55 to 125oC
54HC

Unit

ns

ns

ns

ns

pF

pF

TEST CIRCUIT ICC(Opr.)

6/12

SWITCHING CHARACTERISTICS TEST CIRCUIT

HC72 40

M54/M74HC7240/7241/7244

HC7241 / HC7244

7/12

M54/M74HC7240/7241/7244

Plastic DIP20 (0.25) MECHANICAL DATA

DIM.

MIN. TYP. MAX. MIN. TYP. MAX.

a1 0.254 0.010

B 1.39 1.65 0.055 0.065

b 0.45 0.018

b1 0.25 0.010

D 25.4 1.000
E 8.5 0.335

e 2.54 0.100

e3 22.86 0.900

F 7.1 0.280

I 3.93 0.155

L 3.3 0.130

Z 1.34 0.053

mm inch

8/12

P001J

M54/M74HC7240/7241/7244

Ceramic DIP20 MECHANICAL DATA

DIM.

MIN. TYP. MAX. MIN. TYP. MAX.

A 25 0.984
B 7.8 0.307
D 3.3 0.130
E 0.5 1.78 0.020 0.070

e3 22.86 0.900

F 2.29 2.79 0.090 0.110

G 0.4 0.55 0.016 0.022

I 1.27 1.52 0.050 0.060

L 0.22 0.31 0.009 0.012

M 0.51 1.27 0.020 0.050

N1 4° (min.), 15° (max.)

P 7.9 8.13 0.311 0.320

Q 5.71 0.225

mm inch

P057H

9/12

M54/M74HC7240/7241/7244

SO20 MECHANICAL DATA

DIM.

MIN. TYP. MAX. MIN. TYP. MAX.

A 2.65 0.104
a1 0.10 0.20 0.004 0.007
a2 2.45 0.096

b 0.35 0.49 0.013 0.019

b1 0.23 0.32 0.009 0.012

C 0.50 0.020

c1 45° (typ.)

D 12.60 13.00 0.496 0.512

E 10.00 10.65 0.393 0.419

e 1.27 0.050

e3 11.43 0.450

F 7.40 7.60 0.291 0.299

L 0.50 1.27 0.19 0.050

M 0.75 0.029

S8°(max.)

mm inch

10/12

P013L

M54/M74HC7240/7241/7244

PLCC20 MECHANICAL DATA

DIM.

MIN. TYP. MAX. MIN. TYP. MAX.

A 9.78 10.03 0.385 0.395

B 8.89 9.04 0.350 0.356

D 4.2 4.57 0.165 0.180
d1 2.54 0.100
d2 0.56 0.022

E 7.37 8.38 0.290 0.330

e 1.27 0.050

e3 5.08 0.200

F 0.38 0.015
G 0.101 0.004
M 1.27 0.050

M1 1.14 0.045

mm inch

P027A

11/12

M54/M74HC7240/7241/7244

Information furnished is believed to be accurate and reliable.However, SGS-THOMSON Microelectronics assumes no responsability for the
consequences of use of such information nor for any infringement of patents or other rights of third parties which may results from its use. No
license isgranted by implication or otherwiseunder any patent or patent rights ofSGS-THOMSON Microelectronics. Specificationsmentioned
in this publication are subject to changewithout notice. This publication supersedes and replaces all information previously supplied.
SGS-THOMSON Microelectronicsproductsare notauthorized foruse ascriticalcomponentsin life support devices orsystems withoutexpress
written approval of SGS-THOMSON Microelectonics.

 1994 SGS-THOMSON Microelectronics - All RightsReserved
