USER'S MANUAL
AUTO-DARKENING WELDING HELMET
ULTRA LIGHTEN SPEEDY
ULTRA LIGHTEN SPEEDY
AUTO DARKENING WELDING HELMET
AUTO DARKENING WELDING HELMET
SERVOGLAS
www.servore.com
www.servore.com
Instructions for use of ServoGlasⓇ6000
Thank you for purchasing a ServoGlasⓇ6000 welding helmet.
For your own protection, safety and to ensure the maximum service life of your new
Note
helmet please read this manual carefully before use. Misuse or abuse may result in
injury or reduced protection and may also void your warranty.
1. Before Use
ServoGlas 6000 features an easy to use digital control set giving you control over Shade,
Sensitivity, Delay and allowing you to switch the helmet to grind mode. In grind mode the
helmet will not auto darken.
The auto darkening welding filter in the 6000 has been designed for arc welding and gas cutting. It is
suitable for all normal arc welding processes such as MIG, MAG, TIG, SMAW, Plasma Arc and Air Carbon
welding.
Before use the shade control should be adjusted to the appropriate level based upon EN169 (European
Standard specifications or equivalent) or other appropriate safety guidelines. When in doubt please consult
your safety representative or your authorized ServoGlas
The ServoGlas
maximum level indicated on the product and as described in the relevant Standards. This protection is failsafe and is not compromised by loss of battery power or other electronic failure.
The ServoGlas
the welding arc and respond accordingly resulting in the appropriate darkened filter state as set by the
user and as indicated on the scaled adjustment. Please note that professional judgement may be required
to achieve the best results. When in doubt consult an authorized safety representative or your ServoGlas
distributor and always maintain a conservative attitude towards operation.
Two replaceable lithium batteries type CR2032 (3V) are used as major power sources. An additional solar
cell panel extends battery life and ensures efficient operation. When operating normally the welding
helmet will switch on automatically and switch off automatically to save power a few minutes after the last
welding arc has been detected.
To provide a general check of system status you may wish to set the shade control to 11 and hold the
helmet towards a bright incandescent light source. Under normal circumstances the filter will change
from light to dark state and back to light state again as you move the helmet away. Please note that if you
have any questions or there is any doubt about the performance of your Servore product you should refer
to your authorized safety representative or ServoGlas
Ⓡ
6000 provides continuous protection from ultraviolet and infrared radiation to the
Ⓡ
6000 welding filter cartridge is fitted with four independently operated sensors that detect
■ Always use genuine ServoGlasⓇ6000 front and inside cover plates. Failure to do
Note
so may result in injury and will void the warranty.
■ The ServoGlas
additional protection.
■ Check your helmet for physical damage and test it regularly. If your helmet is
damaged or is not working normally have it tested and repaired before use.
■ Always select the appropriate shade before use according to the type of welding
and current/amperes used. When in doubt refer to your authorized safety
representative.
Ⓡ
6000 is not designed for overhead welding without the use of
Ⓡ
6000 distributor.
Ⓡ
distributor.
Ⓡ
2
SERVOGLAS 6OOO
2. Parts List
The following parts are available from Servore and your authorized ServoGlasⓇ6000 distributor.
Helmet Knob Parts
Part No. Parts
1 Helmet shell
2 Magnifyng Lens(108X51mm)
3 Inner Cover Plate
4 Battery Case
5
6 Front Cover Plate
7 Front Cover
Auto-darkening Welding Filter
3
www.servore.com
HH
HK
HK
HK-1 HK-2 HK-3 HK-4 HK-5 HK-6
HK-3R
Part No. Parts
HH Head Harness
HK Helmet Knob Set
HK-1 P-Bolt
HK-2 Band Holder
HK-3L Angular Stopper L
HK-3R Angular Stopper R
HK-4 Angular Washer
HK-5 Washer
HK-6 Knob
2-1. Technical Specifications
Shade Level
Eye Protection
Switching Time(light to dark)
Switching Delay(dark to Light)
Sensors
Sensitivity Adjustment
Power Supply
Battery Life
Supplementary Power
Replaceable Battery
Cartridge Size
Filter Window
Total Weight
Operating Temperature
Storage Temperature
Inactivated-Light shade #3 Activated-Dark shade #8~#14
Full time UV and IR protection to Shade 15
1/25,000sec(0.04msec)
5 Step adjustment fast(0.05)-slow(0.8)
4
5 Step adjustment Lo-Hi
3V lithium (CR2032) 2EA (user replaceable)
2000hours(Approximately)
Solar cell(Auto On/Off)
Low battery indicator
133 x 116 x 10mm
X: 100 x 67mm, V: 96 x 46mm
X: 530g V: 510g
-5
to +55
-20 to +70
Helmet Adjustment
Move P-bolt back and forth to adjust the
helmet distance between eyes and filter
window.
4
3. Control Function
3-1. Shade Control
The shade control has two ranges 8 to 12 and 13/14. To move between the two
ranges hold the shade button down for two seconds. Single presses of the
shade button will allow you to adjust the shade. The LED’s will indicate the
shade number.
Note that when in the grind mode the shade control will not function.
SERVOGLAS 6OOO
<
Recommended shade numbers according to BS 679, DIN 4647-1 and EN169
According to the conditions of use, the next greater or the next smaller scale number can be used.
3-2. Delay Control
Use the delay control to change how quickly the screen clears after you stop
welding. Please note that this control does not change the speed at which the
helmet darkens. Using this control will help reduce eye strain when working
on welding with high residual heat and tack welding.
>
5
www.servore.com
3-3. Light Sensitivity Control
Use the sensitivity control when working near other welders or on reflective
surfaces.
Adjust the sensitivity by repeated pressing the button. The LED’s will cycle
through indicating the setting from high to low.
3-4. Grind mode button
Pressing the grind mode button switches the helmet into grinding mode. In this
mode the helmet will not darken and the shade, sensitivity and delay controls
will not function. Pressing the grind button again returns the helmet to its
normal auto darkening function. In the grind mode the green LED under the L
will pulse very faintly. If the helmet is not used for approximately 30 mins the
helmet will automatically return to the welding mode.
4. Maintenance
Always ensure that all maintenance procedures are conducted in a clean dry place.
Use clean dry hands and avoid direct contact with any glass surfaces.
Note
Handle cover plates and welding filters by the edges and carefully clean off any dirt or
debris before re-use.
4-1. Changing the front cover plates
To change the front cover lens push the two lugs at the base of the auto darkening filter (accessible
from the inside of the helmet) downwards and push gently out.
The old cover lens can now be removed and the new cover lens put into the mounting frame. Be sure to
remove the protective film from both sides of the cover lens!
Replace the frame by first locating the lugs at the top of the frame in the corresponding slots in the
helmet shell.
Snap the two lugs back into place at the bottom of the frame and check that a tight seal has been
achieved all around.
To remove the auto darkening filter first completely remove the front cover lens frame and then locate
the small locking tag at the top of the auto darkening (see picture 4 above). Gently lift this tab and the
filter will drop out.
WARNING: Be sure to be ready to catch the filter as you lift the tab!
6
SERVOGLAS 6OOO
Note
Always use genuine Servore parts. Never use a welding helmet without both front
and inner cover lenses installed.
7
www.servore.com
4-2. Changing the battery
Batteries usually last about two years. A low battery light will pulse when they need to be replaced.
Remove the auto darkening filter (see overleaf) and change both batteries at the same time observing
polarity and using high quality batteries.
Always note the polarity of the batteries and install them as shown in the diagram and as marked.
Batteries rely on good electrical contact to function properly and so always use clean dry hands and
Note
8
avoid getting dirt inside the cartridge when exchanging batteries.
SERVOGLAS 6OOO
5. Storage and Temperature Range
Your Servore welding helmet is strong and durable. It is designed to work in temperatures between -5C
and +55C. Do not use your helmet in very hot conditions where temperatures exceed +65C. Always store
your helmet in a clean dry place out of the direct sun and protect it from exposure to moisture or extreme
heat (min/max storage temperature is -20C ~ +70C).
Avoid unnecessary impact or compression of your helmet and never use a helmet that is damaged. Your
Servore welding helmet is a quality professional tool and careful storage will extend the life of your
investment.
6. Inspection
Check your helmet shell and filter on a regular basis when in normal use and after extended periods of
storage. Never use a cracked or damaged helmet as this may result in personal injury and will void your
warranty.
Please replace any worn or damaged parts as necessary.
Genuine ServoGlas
Ⓡ
replacement parts are available from your authorized ServoGlasⓇdistributor.
7. Cleaning
Note
After removing the welding filter from the shell the shell can be cleaned using a mild detergent and water
solution. Sweat bands can be washed. A silicone based lubricant may be used on moving parts if necessary
but is not normally required. The filter may be carefully wiped with a cloth dampened with household
window cleaning solution. Please be careful not to scratch or otherwise damage the filter cartridge with
fragments of welding spatter or other abrasive dirt. Refer to the relevant parts diagram for illustrations
regarding assembly and disassembly.
Never expose the filter cartridge to direct contact with water or solvents.
9
www.servore.com
8. Cautions
■ The ServoGlasⓇ6000 is designed for personal eye and face protection from
harmful radiation, sparks and welding spatter produced under normal welding
conditions. Please follow good industry and safety practices and use additional
protection where necessary.
10
Cautions
■ Cover plates are strong and of industry standard quality but they are breakable.
Ⓡ
The ServoGlas
6000 is a quality welding helmet but is not designed to provide
protection from severe impact such as broken grinding wheels or debris from
other broken tools, corrosive liquids, explosions, or other extreme incidents.
We recommend you always adopt a conservative attitude towards safety and
take additional precautions as required and recommended in the relevant
safety standards relating to the operation you are undertaking.
■ The welding filter is not designed to be waterproof. Please do not use your
helmet in the rain or other inclement weather. To do so may reduce the life of
your helmet and result in damage or injury.
■ In the event that your helmet or welding filter is exposed to direct contact with,
or is submerged in water or other liquid immediately stop using the helmet,
remove the filter cartridge from the shell, remove the batteries from the filter,
inspect carefully for damage and if necessary mop-up excess moisture with a
paper towel and then leave to dry in a warm (not hot) place out of direct
sunlight. Never place your helmet in an oven or microwave to dry. Before use
perform all normal system checks and if in any doubt contact your ServoGlas
Ⓡ
distributor. Your Servore helmet is a precision engineered professional
protection product and must be maintained in good condition to ensure your
personal protection.
Cautions
SERVOGLAS 6OOO
■ When working in the vicinity of other welders it is necessary to adopt good
industry standard practice and ensure a minimum distance of 1M between
workers. Failure to do so may result in injury or malfunction of the auto
darkening mechanism.
■ Please do not wear the helmet when you are not welding. In some
circumstances the auto darkening mechanism may be unexpectedly triggered
resulting in reduced vision and subsequent injury to yourself or others.
Ⓡ
■ Servore does not support the use of ServoGlas
combination with any other manufacturers' products. To use parts that are not
approved by Servore may void your warranty and result in personal injury.
Ⓡ
Please use only genuine ServoGlas
Ⓡ
authorized ServoGlas
distributor.
6000 parts and spares as provided by your
■ Servore reserves the right to make improvements, change or otherwise modify
the specifications, materials and design of any and all Servore products at their
sole discretion with a view to ensuring continuous improvement. Never attempt
any unauthorized modifications or alterations to your Servore product. To do so
may result in personal injury and void your warranty.
6000 range of products in
Thank you for purchasing a Servore product. If you have any questions regarding this
or any other Servore product please contact your authorized ServoGlas
Ⓡ
distributor.
11
Loading...
