Food Server
FS-4 PLUS
120V USA
COMPLETE UNIT 81000
BASE ONLY 80970
230V CONTINENTAL EUROPE
COMPLETE UNIT 81010
BASE ONLY 80980
230V AUSTRALIA
COMPLETE UNIT 82420
BASE ONLY 80990
230V UNITED KINGDOM
COMPLETE UNIT 84540
BASE ONLY 84500
...for purchasing our 4-Quart Food Warmer
to keep your soup, chili, gravy or sauce at the
perfect temperature from the first serving to the last.
QUICKLY HEAT TO SAFE SERVING TEMPERATURE
Thank You
Page 2
Page 2
UNIT SET-UP
WASH ALL PARTS PROPERLY BEFORE EVERY USE. See page 5.
• Fill 2.5 cups (20 oz) of water up to
water level line inside basin.
• Do not overfill.
FILL WATER VESSEL BASIN
1
SET THERMOSTAT KNOB
PLUG CORD into power source.
5
3
PRESS SWITCH to the “ON” position.
4
to recommended serving temperature.
• Pull knob out to turn and adjust.
• Push knob in to lock.
• Dial indicator uses increments of 5º F.
• Thermostat range is 75º—210º F.
(24º—99º C)
• To heat unit faster, thermostat may
TEMPORARILY be rotated to maximum.
• Product being served must always be
inside inset.
Never place food directly into water
vessel basin of unit.
2.5 Cups Water = 0.59 Liter
PUT INSET INTO WATER
VESSEL BASIN
2
TIP: Check water levels
throughout the holding period
to ensure even heating.
Filtered water is recommended
to deter corrosion.
TIP: Simplify change-outs with
an additional inset and lid.
Order item #81111.
Page 3
Page 3
1 1
2 2
3
PRE-HEAT UNIT
for at least 5 minutes
with:
• Correct amount of water in basin.
• Lid closed.
• Thermostat knob set at maximum setting.
ADD FOOD PRODUCT
• Put food which has already been
preheated to 150°F (66°C) into the inset.
• Maximum capacity of food product is
4 quarts (16 cups). Do not overfill.
PRE-HEAT UNIT
for at least 5 minutes
with:
• Correct amount of water in basin.
• Lid closed.
• Thermostat knob set at maximum setting.
ADD FOOD PRODUCT
• Put food into the inset.
• Maximum capacity of food product is
4 quarts (16 cups). Do not overfill.
MAINTAIN SAFE
HOT FOOD HOLDING
•
After food reaches safe serving temperature
of 165°F (74°C), maintain product
temperature at or above 150°F (66°C).
• Adjust controller if needed to avoid
overheating food.
NSF International and ANSI (American National Standards Institute) list this unit as a
“Rethermalization and Hot Food Holding unit (Standard 4).”
Rethermalization of food products is achieved by
this appliance when it elevates the food product
temperature from a refrigerated 40°F (4°C) to a
safe serving temperature of 165°F (74°C) within a
period of 2 hours.
Hot Food Holding is achieved with this appliance
when it maintains a food product temperature at or
above 150°F (66°C), in all locations throughout the
product, for a minimum of 2 hours, even if any lid,
cover, or pump is removed. The lid, cover, or pump is
recommended to help maintain product temperature.
MONITOR FOOD CLOSELY FOR FOOD SAFETY.
The United States Public Health Service
recommends that hot food be held at a minimum
of 140°F (60°C) to help prevent bacteria growth.
COLD FOOD IS NOT TO BE ADDED TO THE
UNIT FOR RETHERMALIZATION WHILE HOT
FOOD IS BEING HELD.
RETHERMALIZATION HOT FOOD HOLDING
SAFETY
WARNING-
ELECTRICAL SHOCK COULD OCCUR
This unit must be earthed or grounded.
This requires all three prongs (terminals) on cord
plug to be plugged into power source.
According to food and safety regulations, most
foods must be stored and/or served at certain
temperatures or they could become hazardous.
Check with local food and safety regulators for
specific guidelines.
Be aware of the product you are serving and the
temperature the product is required to maintain.
Server Products, Inc. can not be responsible for
the serving of potentially hazardous product.
(208-240V)
Page 4
Page 4
UNIT TAKE-DOWN
PRESS SWITCH to the “OFF” position.
1
EMPTY WATER FROM
WATER VESSEL BASIN
after each use.
4
DRY
thoroughly with a soft dry cloth.
5
REMOVE INSET FROM
WATER VESSEL BASIN
3
UNPLUG CORD
CAUTION- HOT
Allow unit to cool before continuing.
2
TIP: Remember to empty the
water each day rather than add—
This will greatly extend the life
of your warmer.
Proper drying after each use helps
maintain the stainless steel.
Page 5
Page 5
CLEANING
WARNING-
ELECTRICAL SHOCK COULD OCCUR
• Electrical components of unit could be
damaged from water exposure or any liquid.
• Never immerse unit into water or any liquid.
• Never use any water jet or pressure sprayer
on unit.
• Ensure unit is “OFF” and unplugged.
CAUTION- HOT
Allow unit to cool before cleaning.
CLEAN VESSEL,
INSET & LID
• Before first use and after use daily,
disassemble and clean unit.
• Ensure unit is “OFF” and unplugged.
• Wash with dishwashing soap and hot water.
1
RINSE fully with clear water.
2
SANITIZE all parts according to local
sanitization requirements. All parts in contact
with food must be sanitized.
3
DRY all parts fully with a clean soft cloth.
4
CLEAN EXTERNAL SURFACES
• Wipe daily with a clean damp cloth.
• Dry with a clean soft cloth.
• Glass and surface cleaners approved for use
in food contact areas may be used.
5
• A mildly abrasive nylon or brass brush may
be used to remove any stubborn food or
mineral deposits on interior surfaces of unit.
• Fully rinsing and drying all parts can help
prevent corrosion. Elements and minerals in
tap water can accumulate on stainless steel
parts and create corrosion.
• Do not use abrasive, caustic or ammonia
based cleansers.
• Do not use products containing acids,
alkalines, chlorine, or salt. These agents can
corrode stainless steel.
• Do not use metal scrapers or cleaning pads
that could scratch surfaces.
This warmer, water vessel
and food inset with lid are
constructed of stainless steel—
one of the best materials for food
serving and storage.
If you notice corrosion beginning on
any stainless steel surface, you may need to
change the cleansing agent, sanitizing agent, or
the cleaning procedures you are using.
CARE OF STAINLESS STEEL
Page 6
Page 6
WIRING
Cord Assembly
Bushing/Strain Relief
Rocker Switch
Thermal Cutout
Thermostat
500W Heating Element
Wire Nut
3
4
5
6
7
1
2
Cord Assembly
Bushing/Strain Relief
Rocker Switch
9" Wire Assembly
Thermostat
500W Heating Element
3
4
5
6
1
2
UNIT 81000 | 120V | USA
UNIT 81010 | 230V | CONT. EUROPE, AU, UK
BLACK
WHITE
GREEN
FLAG
1 2 3
5
4
6
7
BROWN
BLUE
GREEN/YELLOW
1 2
3
5
4
6
1A2A1
FLAG FLAG
2
Page 7
Page 7
ACCESSORY ITEMS
DID YOU KNOW?
This warmer can be retrofit to another
dispensing method, so you can also heat
(3) squeeze bottles, pump precise portions
or ladle from a 3-quart jar or #10 can.
WANT ASSISTANCE?
Contact our customer service team at
800.558.8722 or spsales@server-products.com
SQUEEZE BOTTLE
SIGNATURE TOUCH PART
Bottle Inset & (3) 16 oz Bottles 86819
High-Density Squeeze Bottles, 16 oz 86809
PORTION CONTROLLED
DISPENSING PART
Stainless Steel Pump, 1 oz max 81320
Stainless Steel Jar, 3 qt 94009
Storage Lid 94008
Jar or #10 Can Spacer (required) 82063
LIGHT LADLING PART
Stainless Steel 10" Ladle, 1 oz 82561
Adapter Ring 82507
Lift-Off Lid 82509
Stainless Steel Jar, 3 qt 94009
Storage Lid 94008
Jar or #10 Can Spacer (required) 82063
Page 8
Page 8
Manual #01822-RevE 091515
SERVER PRODUCTS
LIMITED WARRANTY
GENERAL SERVICE,
REPAIR OR RETURNS
Server Products equipment is backed by a
two-year limited warranty against defects in
materials and workmanship.
For complete warranty information go to:
www.Server-Products.com
HELP or ORDERING REPLACEMENT PARTS
Please be prepared with your Model, Part and
Series Numbers. This information and other
important data is located on the lid and/or base
of the unit.
262.628.5600 | 800.558.8722
SPSALES@SERVER-PRODUCTS.COM
Server Products Inc.
3601 Pleasant Hill Road
Richfield, WI 53076 USA
UNIT DOES NOT HEAT?
• Ensure cord is securely plugged in.
• Ensure power is available from source.
• Ensure unit is on.
• Ensure thermostat knob is set correctly.
• Ensure
that the correct amount of water is in basin.
PREVENT PITTING ON INSIDE
SURFACE OF VESSEL
• Empty water from water vessel basin each day.
• Thoroughly dry basin each day.
• If possible, use filtered water to fill vessel basin.
Before sending any item to Server Products for service,
repair, or return, contact Server Products customer
service to request a Return Authorization Number.
Merchandise must be sent to Server Products with this
number. Service is extremely prompt. Typically, units
are repaired and ship out within 48 hours.
Merchandise being returned for credit must be in new
and unused condition and not more than 90 days
old and will be subject to a 20% restocking charge.
Electrical parts (thermostats, heating elements, etc.)
are not returnable.
Servicing Cord: Specific tools are required for safe
and proper power supply cord removal and installation.
If cord must be replaced, only a representative of the
OEM (original equipment manufacturer) or a qualified
technician may replace cord. Cord must meet code
designation H05 RN-F requirements.
TROUBLESHOOTING
Please Visit
www.YouTube.com/user/ServerProducts
to see videos of more information.
