FS-2 82 700
ALSO AVAILABLE FOR EXPORT
FOOD WARMERS: FOOD SERVERS
SINGLE WELL
Model FS-2
Bid description
All stainless steel construction with a polished finish. The FS-2
comes complete with an exclusive 1½ quart (1.4 L) bowl (82707),
1 ounce (30 mL) ladle (82717) and lift-off lid.
The adjustable, precalibrated thermostat controls a 250 watt
heating element. Temperature settings are marked on the
thermostat knob. Power is controlled with an ON/OFF rocker
switch.
standard Features
• All stainless steel construction for durability
• Lift-off lid is shaped to cover ladle (opening) and protect
product
• Water fill line eliminates overflow accidents
• 250 watt heating element for reliable heating and holding
• NSF-certified as a rethermalization unit
• Adjustable precalibrated thermostat for accurate heat control
• Temperature marks on knob with protective knob guard
• Exclusive 1½ qt (1.4 L) stainless steel bowl
• 1 oz (30 mL) ladle to serve product
accessory items
1½ qt (1.4 L) Stainless Steel Bowl 82707
1 oz (30 mL) 4" (10.2 cm) Ladle 82717
two year warranty
Server Products equipment is backed by a two-year limited
warranty against defects in materials and workmanship. For a
copy of our complete warranty statement, please refer to
server-products.com.
SpecificationS on re verSe Side
FOOD WARMERS: FOOD SERVERS
SINGLE WELL
Model FS-2
FOOD SERVER/COOKER
FS-2 82700
7 3/8"
18.7 cm
7¾"
19.7 cm
speciFications
Construction All stainless steel with a polished finish. Com-
plete with 1½ qt (1.4 L) bowl, 1 oz (30 mL) 4"
(10.2 cm) ladle and lift-off lid.
Certifications NSF, NSF Rethermalization, C UL US
NSF listing for rethermalization ensures food
is quickly heated to a safe temperature before
bacteria has an opportunity to grow.
Capacity 1½ quart (1.4 L) capacity
Dimensions
Electrical 120V, 60Hz, 250W, 2.1A, 72 in (183 cm)
Weight
FOB RICHFIELD, WISCONSIN 53076
Height Width Depth
7 ¾"
19.7 cm
7 3/8"
18.7 cm
8 ½"
21.6 cm
cord set NEMA 5-15P, 15A, 125V PLUG
6 lb (2.7 kg)
8 ½"
21.6 cm
cad LiBrary
Individual CAD images can be downloaded from our
website. We are also a member of The KCL CADalog
with more than 100 other manufacturers. Our complete
collection of CAD files can be purchased through
Kochman Consultants, Ltd. at kclcad.com.
