Page 1
Single Dip
Server
MODEL: DI-1
120V USA
92000
92118 (CUSTOM)
230V CONTINENTAL
EUROPE
92010
230V AUSTRALIA
92070
230V UNITED KINGDOM
92230
Double Dip
Server
MODEL: DI-2
120V USA
92020
230V CONTINENTAL
EUROPE
92030
230V AUSTRALIA
92080
230V UNITED KINGDOM
92240
Triple Dip
Server
MODEL: DI-3
120V USA
92040
230V CONTINENTAL
EUROPE
92050
230V AUSTRALIA
92090
230V UNITED KINGDOM
92250
Thank You
...for purchasing our specialty dip warmer.
Menu additions are easy with dipped treats like soft
serve ice cream, fresh fruit, cookies and waffle cones.
SERVE BETTER WITH CONE DIP
Page 2
SAFETY
WARNING-
ELECTRICAL SHOCK COULD OCCUR
This unit must be earthed or grounded.
This requires all three prongs (terminals) on cord
plug to be plugged into power source.
(208-240V)
USE
NOTICE
DO NOT DRIP FOOD INTO KNOB AREA
OR PLUG SIDE OF UNIT.
This may damage the thermostat,
resulting in intermittent heating.
According to food and safety regulations, most
foods must be stored and/or served at certain
temperatures or they could become hazardous.
Check with local food and safety regulators for
specific guidelines.
Be aware of the product you are serving and the
temperature the product is required to maintain.
Server Products, Inc. can not be responsible for
the serving of potentially hazardous product.
DIP TEMPERATURE
Refer to food manufacturer for recommended
temperatures.
Monitor food temperature.
Unit is intended for use with cone dip and
dessert products heated in temperature ranges
from ambient to approximately 150˚ F.
Different serving models are available for
toppings which require higher temperatures.
Please see page 8 for help ordering.
Page 2
Page 3
PARTS
LID
TOP
STAINLESS STEEL JAR
94009
(Included with 230V units)
SHROUD
THERMOSTAT KNOB
86242
KNOB GUARD
04973
LIDS
DI-1: 92008
DI-2: 92026
DI-3: 92046
TOPS
DI-1: 92115
DI-2: 92116
DI-3: 92117
REMOVABLE
BOTTOM
FEET
92098
PARTS MAY VARY
DEPENDING ON UNIT
WANT ASSISTANCE?
Contact our customer service team at
800.558.8722 or spsales@server-products.com
REMOVABLE
BOTTOMS
DI-1: 92004
DI-2: 92024
DI-3: 92044
CORDS
120V USA
230V CONTINENTAL EUROPE
230V AUSTRALIA
230V UNITED KINGDOM
Page 3
Page 4
UNIT SET-UP
INSERT REMOVABLE BOTTOM
1
into slot in base of shroud.
INSERT DIP CONTAINER
2
into shroud.
Position #10 can(s) or stainless steel jar(s)
between bumps at bottom.
TIP: Stainless steel jars are
available. Order item #94009.
(Stainless steel jars are
included with 230V units.)
WASH ALL PARTS PROPERLY
BEFORE EVERY USE. See page 6.
3
4
5
6
Page 4
INSTALL TOP ONTO SHROUD
INSTALL LID ONTO SHROUD
Align lid hinge holes onto pivot pins
on shroud.
Press lid hinges inward towards each other
until pivot pins fit into hinge holes.
PLUG CORD into power source.
SET THERMOSTAT KNOB
to recommended serving temperature.
To heat unit faster, thermostat may
TEMPORARILY be rotated to maximum.
Page 5
UNIT TAKE-DOWN
ROTATE THERMOSTAT
1
to lowest setting.
UNPLUG CORD
2
CAUTION- HOT
Allow unit to cool before continuing.
REMOVE TOP
3
from shroud.
TIP: Lid may remain attached.
To detach lid for cleaning,
press hinges inward towards
each other until pivot pins are
released from hinge holes.
REMOVE DIP CONTAINER
4
PULL REMOVABLE BOTTOM
5
out from slot at base of shroud.
Page 5
Page 6
CLEANING
WARNING-
ELECTRICAL SHOCK COULD OCCUR
• Electrical components of unit could be
damaged from water exposure or any liquid.
• Never immerse unit into water or any liquid.
• Never use any water jet or pressure sprayer
on unit.
• Ensure unit is unplugged.
CAUTION- HOT
Allow unit to cool before cleaning.
WASH REMOVABLE PARTS
1
• Before first use and after use daily,
disassemble and clean unit.
• Ensure unit is unplugged.
• Wash with dishwashing soap and hot water.
RINSE fully with clear water.
2
SANITIZE all parts according to local
3
sanitization requirements. All parts in contact
with food must be sanitized.
DRY all parts fully with a clean soft cloth.
4
CLEAN EXTERNAL SURFACES
5
• Wipe daily with a clean damp cloth.
• Dry with a clean soft cloth.
• Glass and surface cleaners approved for use
in food contact areas may be used.
CARE OF STAINLESS STEEL
This warmer and accessories are
constructed of stainless steel—
one of the best materials for food
serving and storage.
If you notice corrosion beginning on any stainless
steel surface, you may need to change the
cleansing agent, sanitizing agent, or the cleaning
procedures you are using.
Page 6
• A mildly abrasive nylon or brass brush may
be used to remove any stubborn food or
mineral deposits on interior surfaces of unit.
• Fully rinsing and drying all parts can help
prevent corrosion. Elements and minerals in
tap water can accumulate on stainless steel
parts and create corrosion.
• Do not use abrasive, caustic or ammonia
based cleansers.
• Do not use products containing acids,
alkalines, chlorine, or salt. These agents can
corrode stainless steel.
• Do not use metal scrapers or cleaning pads
that could scratch surfaces.
Page 7
WIRING
120V UNITS | USA
BLACK
WHITE
GREEN
Cord Assembly
1
Bushing/Strain Relief
2
Thermostat
3
100W Heating Element
4
Ground Clamp
5
Wire Nut
6
Wire Assembly
7
Insulation
8
230V UNITS
BROWN
GREEN/YELLOW
BLUE
1 2
1 2
3
6
4 85
7
3
6
Cord Assembly
1
Bushing/Strain Relief
2
Thermostat
3
100W Heating Element
4
Ground Clamp
5
Terminal
6
Wire Assembly
7
Insulation
8
7
4 85
Page 7
Page 8
TROUBLESHOOTING
UNIT DOES NOT HEAT?
• Ensure cord is securely plugged in.
• Ensure power is available from source.
• Ensure unit is on.
• Ensure thermostat knob is set correctly.
SERVER PRODUCTS
LIMITED WARRANTY
Server Products equipment is backed by a
two-year limited warranty against defects in
materials and workmanship.
For complete warranty information go to:
www.Server-Products.com
GENERAL SERVICE,
REPAIR OR RETURNS
Before sending any item to Server Products for service,
repair, or return, contact Server Products customer
service to request a Return Authorization Number.
Merchandise must be sent to Server Products with this
number. Service is extremely prompt. Typically, units
are repaired and ship out within 48 hours of receipt.
Merchandise being returned for credit must be in new
and unused condition and not more than 90 days
old and will be subject to a 20% restocking charge.
Electrical parts (thermostats, heating elements, etc.)
are not returnable.
Servicing Cord: Specific tools are required for safe
and proper power supply cord removal and installation.
If cord must be replaced, only a representative of the
OEM (original equipment manufacturer) or a qualified
technician may replace cord. Cord must meet code
designation H05 RN-F requirements.
HELP or ORDERING REPLACEMENT PARTS
Server Products Inc.
3601 Pleasant Hill Road
Richfield, WI 53076 USA
262.628.5600 | 800.558.8722
SPSALES@SERVER-PRODUCTS.COM
Please be prepared with your Model, Part and
Series Numbers. This information and other
important data is located on back of the unit.
Page 8
Manual #01851-RevF 090215
