Server Express
Pumps
MODEL 07737
Used with pouches up to
1½ gallons with 16mm fitments.
™
Thank You
...for purchasing our Server Express™ Pump.
Express™ pouched condiment systems are sealed
and sanitary, achieve excellent evacuation and have
only a few parts for easy clean-up.
SIMPLIFY CONDIMENT MANAGEMENT— GO POUCHED
ASSEMBLY
INSERT PINCH VALVE
1
into pump housing.
TIP: Squeeze the pinch valve
open before installation to
ensure it isn’t stuck shut.
INSTALL DOME
2
Slide loop of dome up the housing tube.
WASH ALL PARTS
PROPERLY BEFORE USE. See page 3.
3
Page 2
Press dome into housing fully.
Ensure valve flap covers bottom opening.
INSERT DISCHARGE FITTING
into pump housing discharge tube.
Place loop of fitting around peg on end of
discharge tube to secure.
SAFETY
IMPORTANT
Clean, rinse, sanitize, and dry parts daily or regularly
to comply with local sanitization requirements.
NSF International (National Sanitation
Foundation) lists this pump as: “Not acceptable
for dispensing potentially hazardous foods.”
According to food and safety regulations, most foods
must be stored and/or served at certain temperatures
or they could become hazardous. Check with local food
and safety regulators for specific guidelines. Server
Products, Inc. cannot be responsible for the serving
of potentially hazardous product.
CLEANING
DISASSEMBLY
FLUSH & RINSE
1
all pump surfaces with hot water.
Place lower end of pump into container
of hot water and operate pump until all
remaining product is expelled and only hot
water is discharged.
DISASSEMBLE & CLEAN
2
all washable parts with soap and hot water.
Use brush to clean any confined areas.
RINSE
3
fully with clear water.
SANITIZE
4
all parts according to local sanitization
requirements. All parts in contact with food
must be sanitized.
AIR DRY
5
all parts fully.
YES!
Use dishwashing
soap, hot water
and nylon brush
• Dishwasher safe
• Do not use abrasive, caustic or ammonia
based cleansers.
• Do not use cleansing agents with high
concentrations of acid, alkaline or chlorine.
• Do not use metal scrapers or cleaning
pads that could scratch surfaces.
Page 3
MODEL 07737
PART QTY DESCRIPTION
07383 1 PUMP DOME, BLACK
07798 1 LARGE PINCH VALVE
07389 1 PUMP HOUSING ASSEMBLY
07796 1
DISCHARGE FITTING, .256, MED.
TROUBLESHOOTING
TIP: Squeeze the pinch valve
open before installation to
ensure it isn’t stuck shut.
DOME 07383
PINCH VALVE 07798
PUMP HOUSING
ASSEMBLY
07389
DISCHARGE
FITTING
07796
DIFFICULT TO ATTACH PARTS?
• Wet parts with clean water to help fit.
PRODUCT DOESN’T PUMP?
• Ensure pinch valve is inserted in housing.
• Ensure connector is snapped fully in place to
fitment in pouch.
• Ensure pump is properly installed in unit.
• Clean pump thoroughly.
DOME POPS OFF?
• Clean thoroughly. Food residue could prevent
a tight seal between dome and housing.
• Ensure dome edges are flush with housing.
SERVER PRODUCTS
LIMITED WARRANTY
Server Products equipment is backed by a
two-year limited warranty against defects in
materials and workmanship.
For complete warranty information go to:
www.Server-Products.com
GENERAL SERVICE,
REPAIR OR RETURNS
Before sending any item to Server Products for service,
repair, or return, contact Server Products customer
service to request a Return Authorization Number.
Merchandise must be sent to Server Products with this
number. Service is extremely prompt. Typically, units
are repaired and ship out within 48 hours of receipt.
Merchandise being returned for credit must be in new
and unused condition and not more than 90 days old
and will be subject to a 20% restocking charge.
HELP or ORDERING REPLACEMENT PARTS
Server Products Inc.
3601 Pleasant Hill Road
Richfield, WI 53076 USA
262.628.5600 | 800.558.8722
SPSALES@SERVER-PRODUCTS.COM
Page 4
Please be prepared with the Part Numbers for your
items. Individual part numbers are listed above.
Manual #01750-RevB 061815
