Page 1
REFERENCE GUIDE
1/8TH SCALE 4WD COMPETITION CAR
Page 2
- 2 -
- 3 -
PARTS LIST & EXPLODED VIEWS
The parts list and the exploded views for the Serpent
960 are separate from the Instruction Manual. The
exploded views show all the parts for a particular
assembly step, together with the Serpent part number.
In the parts list at the back of this Reference Guide you
will find the part number and the name of the part. In
addition to all the Serpent 960 parts used in this car kit,
you will also find lists of option parts for the Serpent
960, as well as a general items (such as fasteners) and
promotional items.
Serpent will regularly update the Serpent 960 parts
list and will make it available on the Serpent 960
product page at Serpent.com. Be sure to check the
Serpent 960 product page at Serpent.com frequently.
All information about the 960 can be found here: publications, news items, set-ups, FAQ’s, images, downloads, videos, and interesting forums in several languages. Serpent.com provides you with an enormous
amount of interesting and often valuable information
about the Serpent 960; information is provided by
Serpent, its factory and team drivers, and experienced
racers from around the world. Often this information
is even available in several languages! If you’re not a
member of Serpent.com yet, sign up today and experience why Serpent excels not only on the track, but
also on the Internet.
1.0 FRONT ASSEMBLY 3
2.0 REAR ASSEMBLY 4
3.0 RADIO PLATE ASSEMBLY 5
4.0 SHOCK ASSEMBLY 6
5.0 RADIO PLATE MOUNTING 7
6.0 GEARBOX ASSEMBLY 8
7.0 CENTAX ASSEMBLY 8
8.0 FINAL ASSEMBLY 9
INTRODUCTION
CONTENTS
Page 3
- 3 -
FRONT ASSEMBLY
808214
909264
909222
903106
808214
902227
909224
808344
1107
1257
1256
9226
6337
903108
808346
808340
1347
902229
1274
1257
903105
903103
909217
1258
801245
1232
1261
902232
801245
909220
903101
1207
909245
909250
1257
902252
1347
9212
1089
903118
909225
1283
1273
9213
1321
902134
1239
902131
902131
902136
902135
1321
902133
1650
902250
909250
1257
909236
1660
902128
1245
903110
6361
1207
1342
1205
9212
903118
1065
9213
902228
903109
1650
903107
903104
903105
801245
909216
Complete Servo Saver Set - #902130
909220
1239
902229
Page 4
- 4 -
- 5 -
REAR ASSEMBLY
6337
1205
909325
808344
808340
808346
909224
1347
909238
1107
903113
903125
1343
1348
903126
909224
1273
903123
1239
903121
9619
1110
1249
903129
1239
902308
903124
1257
903120
903131
1273
1276
808152
1239
1236
1729
903130
909344
1202
909345
1241
903170
909373
903155
1347
802328
903121
1107
909395
909242
1257
9618
909248
909322
903154
903156
903115
1270
1106
903118
902138
1660
1650
1245
903117
903127
909336
1257
1321
909356
903119
902420
1263
903112
903114
1343
903125
903123
903124
909366
1243
9611
9612
901355
901356
1321
903116
903121
903122
1311
1261
1274
Page 5
- 5 -
RADIO PLATE ASSEMBLY
1240
903135
902119
903102
1242
1660
1650
902138
1242
903136
902115
902116
902116
1602
1070
1241
902121
903134
903136
903137
902116
1602
1493
1242
903135
1241
903135
802151
903157
1608
902170
1247
1296
1241
1256
909403
1247
1240
1240
1241
1272
1242
1240
903138 - 23
903139 - 24
903140 - 25
901158 - 23
901159 - 24
901160 - 25
OPTION: Upright Throttle Servo
OPTION: Laydown Throttle Servo
Page 6
- 6 -
- 7 -
SHOCK ASSEMBLY
903179
903178
909405
6442
1370
909418 - Blue
903168
1202
903175
903171
903169
909407
903166
903167
903168
903168
903177
909414 - Orange*
909415 - White*
909416 - Yellow*
909417 - Red*
909419 - Purple*
909420 - Grey*
909416 - Yellow
909414 - Orange*
909415 - White*
909417 - Red*
909418 - Blue*
909419 - Purple*
909420 - Grey*
* Optional
Set of Front Shock absorbers - #903164
Set of Rear Shock absorbers - #903165
Complete O-ring set - #903170
Page 7
- 7 -
RADIO PLATE MOUNTING
808144
902105
1239
903111
1218
1298
1272
1272
902152
903164
1650
1274
1239
902155
902157
1272
1273
1257
1272
903133
1650
903165
1272
Page 8
- 8 -
- 9 -
902411
902412
902448 - 48T
1241
6626
1342
902445 - 45T
902420
1320
902413
1268
902416
2 Speed gearbox LC (no shaft incl.) - #902410
6599 (optional use)
6503
1340
909514
1315
909512
909559 - 19T
909556 - 16T
909519
909516
1238
1377
6583
909519
909518
6584
6587N
6585
909515
6582
6579
Centax-II clutch set (excl. flywheel) - #909510
2 Speed shaft 960 - #903116
1249
1268
902447 - 47T*
902449 - 49T*
902444 - 44T*
902446 - 46T*
909555 - 15T*
909557 - 17T*
909558 - 18T*
909560 - 20T*
* - Optional
* - Optional
GEARBOX ASSEMBLYCENTAX ASSEMBLY
#1205 - E-clip 5.0 R5
#1253 - Grubscrew M3x8 H11
#1111 - Pin NRA 3x13.8 P13
Mounting fasteners
Page 9
- 9 -
FINAL ASSEMBLY
1311
6364
902340
1237
6571
1312
1243
903132
1272
Not Included
903141
1270
1599
Not Included
1272
901255
1595
1258
1523
1615
1638
1636
909356
1240
1638
1619
1523
1250
903128
1204
1639
1639
1638
1243
902172
1611/12/13
1619
1654
1619
1639
1638
1239
1638
1250
1638
903152 - Rim
903153 - Rim
Not Included
1636
1615
Page 10
- 10 -
- 11 -
ART No. DESCRIPTION
903000 SERPENT 960 1/8 4WD KIT
MANUAL, DECALS
903147 Manual S960
903148 Ref guide S960
903149 Setup book S960
903150 Decal S960 A4 + A5
903151 Decal S960 A5
RADIO INSTALLATION / BATTERY
1070 Grommet rubber soft (4)
1296 Washer nylon M3x7x0.5 (4)
1604 Antenna rods pink (2)
1611 Servo lever 23T, double arm (2)
1612 Servo lever 25T, double arm (2)
1613 Servo lever 24T, double arm (2)
1615 Ball-joints 4mm (4)
1619 Wire-guide nylon
1636 Throttle linkage set
1638 Brake-linkage set
1639 Collar alu 2.1 + setscrew (4)
1650 Balls 6mm/setscrews hex (4)
1654 Spring small (4)
1660 Ball-joints 6mm (20)
802151 Receiver cover
901158 Servo lever 23T, single arm
901159 Servo lever 24T, single arm
901160 Servo lever 25T, single arm
902119 Receiver bracket 960
902121 Mounting bracket steering servo
902138 Rod threaded L + R (2)
902170 Shaft, throttle lever
902172 Throttle slide part
903128 Throttle lever
903134 Bracket throttle-brake servo
903135 Mount-supports servo
903138 Servo lever 23T, single arm
903139 Servo lever 24T, single arm
903140 Servo lever 25T, single arm
903141 Battery-support plate S960
903157 Receiver bracket 710 / 960
SERVO SAVER AND STEERING
902128 Track-rod set (2)
902130 Servo-saver set 950
902131 Servo-saver nylon parts
902133 Servo-saver shaft inner
902134 Servo-saver shaft outer
902135 Servo-saver pre-tension nut
902136 Servo-saver spring
FUEL TANK AND PARTS
1431 Rubber tank seals (4)
1493 Pressure nipple
1494 Silicone tubing 50cm white
1602 Tank-clips small (10)
902115 Mounting-pin tank + rubber cap (2)
902116 Cap rubber for mounting pin tank (2)
903136 Shim 3.1x8x5 nylon
903137 Fueltank 125cc
BALL-BEARINGS
1311 Ball-bearing 5x8
1312 Ball-bearing 5x8 flanged
1315 Ball-bearing 5x10
1320 Ball-bearing 6x10 flanged
1321 Ball-bearing 6x10x3 (2)
1340 Ball-bearing 5x13 HS (2)
1342 Ball-bearing 6x13 HS (2)
1343 Ball-bearing 6x15 HS (2)
1346 Ball-bearing 12x18 HS (2)
1347 Ball-bearing 12x21 HS (2)
1348 Ball-bearing 15x24 HS (2)
1377 Thrustbearing 5x10
SHOCK ABSORBERS
903164 Shock-set front (2)
903165 Shock-set rear (2)
903166 Piston rod FR (2)
903167 Piston rod RR (2)
903168 Nylon parts frame shocks
903169 Insert shock (2)
903170 O-ring + clip set
903171 O-ring 10x1 (4)
903172 O-ring 3.8x1.5 (4)
903173 O-ring 12x1.6 (4)
903174 E-clip 2.3mm (4)
903175 Foam insert (4)
903176 Nut adj alu + o-ring (4)
903177 Nut shock alu (4)
903178 Body alu shock FR (2)
903179 Body alu shock RR (2)
909414 Spring-set D=1.4 L=27-22.7 orange (4)
909415 Spring-set D=1.5 L=27-22.7 white (4)
909416 Spring-set D=1.6 L=27-22.7 yellow (4)
909417 Spring-set D=1.7 L=27-22.7 red (4)
909418 Spring-set D=1.8 L=27-22.7 blue (4)
909419 Spring-set D=1.9 L=27-22.7 purple (4)
909420 Spring-set D=2.0 L=27-22.7 grey (4)
SERPENT SPECIAL SHOCK ABSORBER OIL
1670 Silicone shock-oil 20W 100cst
1674 Silicone shock-oil 25W 180cst
1671 Silicone shock-oil 30W 350cst
1675 Silicone shock-oil 35W 600cst
1672 Silicone shock-oil 40W 1000cst
1676 Silicone shock-oil 45W 1400cst
1673 Silicone shock-oil 50W 2000cst
CHASSIS / RADIO PLATE
902152 Spacer Radio plate (3)
902155 Radio plate bracket
902157 Roll-bar chrome
903101 Chassis S960
903102 Radio plate S960
903132 Side plate L carbon
903133 Side plate R carbon
BODYMOUNTS FR and RR
1601 Body clips (10)
808144 Body mount universal
808152 Centering bushing threaded
903111 Body plate FR
903130 Bodymount RR
909342 Nylon arms short (2)
909344 Pivot pins body mount upper (2)
909345 Pivot bushings rear body mount (4)
909366 T-bracket rear body support
FRONT SECTION
1065 O-ring for alu front axle (10)
1089 Shim nylon adaptor FR 6.1x11x1 (4)
1107 Pin NRA 2.5x21.8 (4)
6337 Spring quick change system
6361 Belt short 6mm
801245 Anti-roll bar levers + eccentric
808214 Caster spacer set (2)
808340 Nylon cup 8.5mm
808344 Adj. nut alu M10 (4)
808346 Pivot balls steel 8.5mm (2)
902105 Bumper
902227 Wishbone front lower left
902228 Wishbone front lower right
902229 Downstop lever L + R
902232 Pivot pins front lower (2)
903103 Bearingblock FR L
903104 Bearingblock FR R
903105 Suspension bracket FR upper (2)
903106 Wishbone FR upper L
903107 Wishbone FR upper R
903108 Steering block L
903109 Steering block R
903110 Shocktower carbon FR
903118 Eccentric nylon (2)
903145 Suspension-set FR S960
909216 Anti-roll bar blade male
909217 Anti-roll bar blade female
909220 Driveshafts front (2)
909222 Wheel-axles steel front (2)
909224 Shim 12x18x0.3mm (2)
909225 Front axle alu. with OWBs
909264 Pivot pins front upper (2)
9213 Pulley / flange 24T
9212 Inner driveshaft adaptors (2)
9226 Lever alu quick-change (2)
MIDDLE SECTION
6364 Drive-belt long 6mm
901255 Belt-tensioner shaft and nut
902250 Middle shaft bracket
902252 Middle shaft steel
909236 Pulley / flange 16T
909238 Pulley / flange 18T
909242 Pulley / flange 22T
909245 Pulley / flange 25T
909248 Brake-pulley adaptor alu.
909250 Pulley adaptor alu. (2)
REAR SECTION
1107 Pin NRA 2.5x21.8 (4)
802328 Pivot pin rear upper (2)
808340 Ball-cups set nylon (12)
808344 Alu. adjusting nuts M10 (4)
808346 Pivot-balls 8.5mm (2)
902308 Pivot pin rear lower 3.5mm (2)
903117 Stiffener RR upper carbon
903119 Susp bracket RR L
903120 Susp bracket RR R
903121 Pivot insert nylon (4+4+4)
903113 Bearing block RR L
903114 Bearing block RR R
903118 Eccentric Nylon (2)
903122 Rear plate
903123 Wishbone RR lower
903124 Wishbone RR upper
903125 Upright RR
903126 Spacer upright alu (2)
903127 Anti-roll bar rear adjustable
903129 Spacer anti-roll bar RR
903131 Shock tower RR carbon
903146 Suspension-set RR S960
903154 Nylon inserts wheel-axles (2)
903156 Driveshaft rear 62mm (2)
909224 Shim 12x18x0.3mm (2)
909322 Wheel-axles steel rear (2)
909325 Quick-change levers alu rear (2)
909336 Rear anti-roll bar ball-rod
9619 Pulley adapter alu 19T
9620
BRAKE SYSTEM
1106 Pin NRA 2.5x19.8 (4)
901355 Brake pads black (4)
901356 Brake-plates steel (3)
903112 Brake cam alu
903115 Brake support plate carbon
909356 Brake-cam / spring-set
9612 Ventilated brake-disk
9611 Steel brake disks (2)
9618 Alu. collar brake pulley
TRANSMISSION
903155 Axle solid rear
909373 Kevlar drive-belt 8mm
909395 Pulley solid axle 51T
PARTS LIST SERPENT 960
Page 11
- 11 -
2-SPEED GEARBOX
1111 Pin NRA 3x13.8 (4)
1115 Pin NRA 5x5 (4)
6626 Springs / screws 2-speed
902410 2-speed gearbox LC (no shaft incl)
902411 Drive-flange alu with OWB LC
902412 Adaptor 2-speed LC
902413 Clutch bell alu LC
902416 2-speed clutch shoes set LC
902444 2-speed gear 44T (2nd) LC
902445 2-speed gear 45T (2nd) LC
902446 2-speed gear 46T (2nd) LC
902447 2-speed gear 47T (1st) LC
902448 2-speed gear 48T (1st) LC
902449 2-speed gear 49T (1st) LC
903116 Shaft 2-speed
CLUTCH SYSTEM
1377 Centax II thrust-bearing 5x10
6503 Flywheel cone (3)
6579 Centax flywheel 38mm
6582 Centax clutch-nut
6583 Centax pre-load adjusting nut
6584 Centax spring cup
6585 Centax thrust washer
6587N Centax clutch shoe
6599 Centax shim-set 7x13 (10)
909510 Centax II clutch-set (excl. Flywheel)
909514 Centax II bearing spacer 5x7
909515 Centax II centrifugal shoes (3)
909516 Centax II spacer thrustbearing
909518 Centax II coilspring 1.8
909519 Centax 5x10 shim-set 0.1 (2) 0.3 (1)
909512 Centax II clutch-housing universal
909555 Centax gear-pinion alu. 15T
909556 Centax gear-pinion alu. 16T
909557 Centax gear-pinion alu. 17T
909558 Centax gear-pinion alu. 18T
909559 Centax gear-pinion alu. 19T
909560 Centax gear-pinion alu. 20T
ENGINE MOUNTS
1595 Mount alu exhaust wire
1599 Exhaust mounting wire
6571 Engine mounting screws/washers
902340 Engine mounts M21
WHEELS
903152 Rim front 1/8 yellow (2)
903153 Rim rear 1/8 yellow (2)
909851 Tire savers 1/8 (10)
OPTION PARTS
1015 Engine mount screws Torx / washers (4)
1017 Engine mount screws hex-flanged (4)
1018 Screw-flanged M4x14 hex (4)
1265 Screw CSH M4x10 aluminum (10)
1360 Ball-bearing 6x13 PHQ (2)
1362 Ball-bearing 12x21 PHW (2)
1388 Thrust-bearing 5x10 ceramic
1391 Bearing-set ceramic S960 (19)
1461 Tool front anti-roll bar
1462 Tool pressure nipple / Centax nut
6123A Body post alu short (2)
6587 Centax clutch shoe black
6587XP Centax clutch shoe black XP
808251 Middle shaft bracket alu
9606 Brake disk steel ventilated (2)
9607 Racing brake-pad set L + R
9623 Collar brake-pulley alu light
902129 Turnbuckle 65mm titanium (2)
902137 Servo saver spring 2.0 gold
902139 Servo saver spring 2.2 black
902156 Radio plate bracket alu
902240 Belt-set pro S950 (3) (2 rear, 1 side)
902242 Drive-belt 432x6mm side pro
902243 Drive-belt 210x8mm rear pro
902253 Middle shaft alu coated
902270 Wheel-axles front QC-fixed set
902271 Springs quick-change short (4)
902272 Wheel-nut alu + O-ring (4)
902280 Wheel-axles front CV set
902281 Driveshaft-set front CV
902282 Insert alu CV (2)
902284 Spacer alu steering block (2)
902341 Engine mount mono-block S950R
902370 Wheel-axles rear QC-fixed set
903121 Pivot insert nylon pos 2
903143 Roll center spacer 1mm
903158 Lever FR quick-change alu light (2)
903159 Lever RR quick-change alu light (2)
903160 Eccentric bearing alu (2)
903161 Susp bracket alu FR upper L + R
903162 Rear plate S960 alu grey
903163 Rear plate S960 alu orange
903180 Shock piston set 1H machined (4)
903181 Shock piston set 2H machined (4)
903182 Shock piston set 3H machined (4)
903183 Shock piston set 4H machined (4)
903185 Shim 4x9x1 black RCS (12)
909218 Anti-roll bar levers alu front (2)
909223 Wheel axle front WOS + alu spacer (2)
909224 Shim 12x18x0.3mm (2)
909228 Wheel-axle washers conical (4)
909244 Pulley / flange 24T
909251 Pulley-adaptor alu light (2)
909253 Pulley 16T alu hard-anodised
909254 Pulley 18T alu hard-anodised
909255 Pulley 24T alu hard-anodised
909256 Pulley 25T alu hard-anodised
909257 Pulley 22T brake alu hard-anodised
909323 Wheel-axle set rear light / WOS (2)
909351 Brake bracket alu
909372 Pulley 50T
909513 Centax II clutch-housing universal light
909575 Centax gear-pinion steel 15T
909576 Centax gear-pinion steel 16T
909577 Centax gear-pinion steel 17T
909578 Centax gear-pinion steel 18T
909579 Centax gear-pinion steel 19T
909580 Centax gear-pinion steel 20T
BODIES AND WINGS
1601 Body clips (10)
1722 Trim-strip + nylon mounts
1723 Body washers silicone (5)
1724 Body-stiffener Lexan (2)
1725 Side-wing support foam (2)
1727 Body inserts Lexan - set
1729 Screw-nut M6 black nylon (2)
1751 Body McLaren GT1 MS
1753 Body Porsche GT1 MS
1754 Body Porsche 962 MS EV2
1757 Body Lola VDS MS EV3
TOOLS
1016 Torx wrench
1460 Camber gauge
1461 Tool front anti-roll bar
1462 Tool pressure nipple / Centax nut
909590 Gear pinion wrench
909593 Clutch housing gripper
909597 Centax gap-tool alu
ACCESSORIES
1395 Glow-plug starter 1300 mAh /w. Cable
1400G Powerstart compact starter box grey
1494 Silicone tubing 50cm white
1521 Silicone tubing 50cm purple
1522 Silicone tubing 50cm smoke
1523 Silicone tubing 50cm orange
1605 Antenna rods green (2)
1606 Antenna rods black (2)
1607 Antenna rods blue (2)
1608 Antenna rods orange (2)
1609 Antenna rods purple (2)
1680 One-way lube 25ml
1682 Bearing oil 25ml
1690 Cleaning putty 200g
903142 Powerstart pos supp. S960
MERCHANDISING
1980 Bag Serpent black large
1981 Bag Serpent black small
FASTENING MATERIALS
1101 Pin NRA 2.5x11.8 (4)
1102 Pin NRB 2.5x11.8 (4)
1103 Pin NRA 2.5x13.8 (4)
1104 Pin NRB 2.5x15.8 (4)
1105 Pin NRA 2.5x17.8 (4)
1106 Pin NRA 2.5x19.8 (4)
1107 Pin NRA 2.5x21.8 (4)
1108 Pin NRA 2x13.8 (4)
1109 Pin NRA 2x9.8 (4)
1110 Pin NRA 3x11.8 (4)
1111 Pin NRA 3x13.8 (4)
1112 Pin NRA 3x19.8 (4)
1113 Pin NRA 3x9.8 (4)
1114 Pin NRA 3x15.8 (4)
1115 Pin NRA 5x5 (4)
1201 E-clip 1.9 (10) R1
1202 E-clip 2.3 (10) R2
1203 E-clip 3.2 (10) R3
1204 E-clip 4.0 (10) R4
1205 E-clip 5.0 (10) R5
1207 E-clip 7.0 (10) R7
1208 C-clip 10x1 (10) T10
1209 G-clip 14x1 (10) S14
1212 Screw rh ph 2.9x9.5 (10) A5
1213 Screw rh ph 2.9x13 (10) A6
1214 Screw rh ph 2.9x16 (10) A7
1215 Screw rh ph 2.9x19 (10) A8
1216 Screw rh ph 2.9x25 (10) A10
1217 Screw rh ph 3.5x9.5 (10) A12
1218 Screw rh ph 3.5x13 (10) A13
1219 Screw rh ph 3.5x16 (10) A14
1220 Screw rh ph 3.5x19 (10) A15
1225 Screw rh M2x6 (10) C2
1226 Screw rh M2x6 (10) C5
1227 Screw rh ph M3x8 (10) D11
1228 Screw rh ph M3x12 (10) D13
1232 Screw rh Allen M3x18 (10)
1235 Screw ch Allen M3x6 (10) F10
1236 Screw ch Allen M3x10 (10) F12
1237 Screw ch Allen M3x12 (10) F13
1238 Screw ch Allen M3x16 (10) F14
1239 Screw rh Allen M3x6 (10) E10
1240 Screw rh Allen M3x8 (10) E11
1247 Screw rh Allen M3x10 (10) E12
1241 Screw rh Allen M3x12 (10) E13
1243 Screw rh Allen M3x16 (10) E14
1234 Screw rh Allen M3x20 (10) E15
1244 Screw rh Allen M4x6 (10) E17
1245 Screw rh Allen M4x8 (10) E18
1246 Screw rh Allen M4x16 (10) E21
1249 Grubscrew M3x3 (10) J8
1250 Grubscrew M3x4 (10) J9
1251 Grubscrew M3x6 (10) J10
1252 Grubscrew M4x10 (10) J19
1253 Grubscrew M3x8 (10) H11
1255 Grubscrew M3x10 (10) H12
1256 Grubscrew M3x12 (10) H13
1257 Grubscrew M4x4 (10) H16
1258 Grubscrew M4x6 (10) H17
1259 Grubscrew M5x5 (10) H24
1260 Grubscrew M5x6 (10) H25
1262 Grubscrew M3x20 (10) H15
1261 Grubscrew M4x10 (10) H17
1263 Grubscrew M5x4 (10) H22
1268 Screw csh ph M3x6 (10) G10
1269 Screw csh ph M3x16 (10) G14
1270 Screw csh ph M3x8 (10) G11
1271 Screw csh ph M4x8 (10) G18
1272 Screw csh ph M4x10 (10) G19
1273 Screw csh ph M4x12 (10) G20
1274 Screw csh ph M4x16 (10) G21
1275 Screw csh ph M5x12 (10) G27
1278 Screw csh Allen M4x20 (10)
1279 Screw csh Allen M4x25 (10)
1280 Screw csh ph 2.2x6.5 (10) B2
1281 Screw csh ph 2.9x9.5 (10) B5
1282 Screw csh ph 3.5x9.5 (10) B12
1283 Screw csh ph 3.5x13 (10) B13
1284 Screw csh ph 3.5x16 (10) B14
1285 Screw csh ph 4.2x13 (10) B20
1290 Washer 3.2x7 (10) N3
1291 Washer 2.5x6 (10) N4
1292 Spring washer 6.2x14x0.9
1293 Spring washer 7.2x14x0.8
1295 Lock washer 3.2x8 (10) O3
1297 Nut nylock M3 (10) L3
1298 Nut nylock M4 (10) L4
1646 Steel balls 6mm M3 (4)
1647 Steel balls 6mm (4)
1650 Balls 6mm/setscrews hex (4)
1660 Ball-joints 6mm (20)
901185 Screw set alu M4x10 (25)
This list is subject to changes without prior notice.
For up-to-date information on Serpent, go to our
Internet site:
www.serpent.com
Page 12
#903148 - Version 1
Serpent Model Racing Cars BV
PO Box 180, 2100 AD, Heemstede
The Netherlands, Europe
Loading...
