Page 1

SLPUMP10

Electric Air Pump Compressor

Inflator for SUP

(Stand Up Paddle-Boards & Water Sport Pool Inflatables)

Page 2

CATALOGUE

I. Product Introduction.......................................1

II. List of Accessories........................................1

III. Details of Accessories..................................1

I. PRODUCT INTRODUCTION

SLPUMP10 is an intelligent DC electric pump with the preset pressure LCD screen, which can be used for inatable tent, SUP, etc. Thanks to the intelligent pressure system, for example, if a pressure value is preset, when the pressure reaches the preset pressure value, the pump will automatically stop inating.

II. LIST OF ACCESSORIES

Please make sure that the following accessories are in the box before using it, if any missing, please contact with the local supplier.

IV. Safety Instructions........................................ 2

Air pump Hose Instruction Book

V. Inflation Operation...................................... 3-4

VI. Precautions.................................................. 4

VII. Fault Handling............................................. 5

III. DETAILS OF ACCESSORIES

VIII. Maintenance and Storage.......................... 5

IX. Suggestions................................................. 5

Please read instruction to ensure that you understand your

product operation and are able to safely and eectively use this product.

16.00

www.SereneLifeHome.com www.SereneLifeHome.com

Inflation inlet

Pressure value LCD screen

Pressure unit toggle button

+ Button increases PSI output

- Button lowers PSI output

On/off button

DC plug

Air tap

Hose

Flexible conduit adaptor

Air inlet

Page 3

IV. SAFETY INSTRUCTIONS

• Warning: In order to reduce the risk of injury, keep out of reach of children. Always supervise children and incapacitated

person contacting or using this air pump.

• Warning: Keep the packaging materials away from children

• Warning: This product is not applicable for persons with

declining physical strength, sensory ability or mental capacity, and person lack of skill unless they are under the protection of their guardians, supervised and directed at the same time.

• Warning: Before moving, maintaining, repairing or adjusting

this product, pull out the DC plug from the socket.

• Warning: Please do not bury the wire in soil, and place in a safe environment where it won't be damaged by mower or other equipment.

• Warning: If power wire is damaged, the power wire must be

changed by the manufacturer or its service agent or similar authorized personnel, in case of any risk.

• Warning: DON'T PLUG OR PULL THE DC PLUG if you are standing in a place with water or your hands are wet.

• Warning: Before inating, please pay attention to check the

maximum bearable pressure of the inatable product because the air bag may be damaged upon exceeding the maximum bearable pressure.

• Warning: The purpose of using this product is limited to the description in the instruction book.

• Warning: Before using, please check the cigarette lighter

socket to make sure that there is no rust or residue inside. The cigarette lighter socket with poor electric conduction may cause overheating of the product or power source, which will damage the product.

V. INFLATION OPERATION

• Connect the end with Flexible conduit adaptor of the hose

with the air pump ination inlet (1), and twist clockwise to

tighten, as Figure 1.

• Install the other end of the hose into the supporting air tap of

the air bag (step 2 in Figure 2), and twist clockwise to tighten it, and then insert the ination valve of the air bag and twist

clockwise to x it (step 2 in Figure 2).

• Plug the DC plug into 12V DC socket.

• Press the pressure unit toggle button to select the unit

you need.

• Press or to set the pressure value you need, with the pressure range value from 0 to 16PSI, (1PSI=0.0689BAR)

• After nishing the above steps, press the power switch button

to start to inate.

• During the inating process, you can press the PSI pressure

output button or button to increase or reduce the pressure value, press the pressure unit toggle button to switch the unit, and press the On/O button to stop.

（Figure 1）

（Figure 2）

www.SereneLifeHome.com www.SereneLifeHome.com

Page 4

• When the pressure reaches the set value, the air pump will

stop working automatically.

• After completing the ination, pull out the DC plug from the 12V DC socket.

• After pulling out the DC plug, please take down the hose from

the air pump and air bag then store it in a safe place.

• Notice: The factory set pressure value of the air pump is 10PSI (10PSI=0.689BAR), and at the time of the secondary use, the

set pressure value for the last time use will be displayed by default.

• Notice: After powered on, if there is no operation within 2

minutes, the air pump will enter standby mode, and the machine can be initiated by pressing the power switch button

VI. PRECAUTIONS

• The applied power source must be the 12V DC power source (as Figure 3).

• Don't block the air inlet (10) at the bottom of the air pump,

and guarantee air inlet (10) to be always unblocked.

• Observe the local waste treatment provisions, and avoid

throwing the air pump away randomly.

• Don't use this product when hose is damaged and change the

hose immediately.

• Don't pull out the hose when inating because high pressure

may hurt the physical body.

• Don't make the air pump work for more than 15 minutes,

because motor overheating may cause internal damage. The

air pump shall be fully cooled for 30 minutes after continuously working up to 15 minutes.

• Please don't use this air pump if any part is damaged. Please

contact professional personnel for repairs.

• This product shall not be exposed to rain or immersed in water.

• In order to prevent risk, place the ination inlet opposite to

face or body.

• Avoid leaving SLPUMP10 while inating.

VII. FAULT HANDLING

Fault Inspection Solution

1. The power source

The air pump cannot be started normally.

Slow or abnormal inflation.

is not plugged properly.

2. The fuse in DC plug (7) is burnt out.

3. Overheating or overload causes motor stop.

1. Check whether the hose is blocked or cracked.

2. The joint between the hose and air pump or air bag is not installed properly.

VIII. MAINTENANCE AND STORAGE

• After using, or if you want to move, maintain or adjust the

product, please rst pull out the DC plug from the socket.

• When it is idle, it shall be properly stored after fully cooled.

• It shall not be exposed to the rain or immersed in water.

• Please store in a dry and ventilated place.

IX. SUGGESTIONS

The warranty period of this product is one year, and it is

suggested to use the original accessories. For any fault not

caused by using the original accessories, it shall be out of the warranty scope.

1. Make sure that the power wire is plugged in the 12V DC socket.

2. Change the fuse.

3. Cool the motor and restart it.

4. If the problem cannot be solved, please contact with the manufacturer or its service agent or the similar authorized personnel.

1. Change the hose or make it unblocked, and check whether the hose is cracked.

2. Reinstall the hose.

3. If the problem cannot be solved, please contact with the manufacturer or its service agent or the similar authorized personnel.

www.SereneLifeHome.com www.SereneLifeHome.com

www.PyleUSA.com

(Figure 3)

www.PyleUSA.com
