Page 1
SLPAC8
Portable Air Conditioner
Compact Home AC Cooling Unit with Built-in Dehumidifier
& Fan Modes, Includes Window Mount Kit (8,000 BTU)
Page 2
CONTENT
Important Safety Tips
Precautions...........................................................................................................................3
Product Introduction
Main Parts and Components..........................................................................................4
Control Panel and Remote Controller.........................................................................6
Product Operation
Placement and Installation.............................................................................................7
Operation Method.............................................................................................................8
Clean and Maintenance
Drainage Method...............................................................................................................9
Maintenance......................................................................................................................10
Common Failures and Diagnosis
Intelligent Error Detection............................................................................................11
Fuse Parameters................................................................................................................11
Troubleshooting...............................................................................................................11
Features and Technical Specications .....................................................................12
www.SereneLifeHome.com
2
Page 3
Important Safety Tips
Precautions
Please read the Manual carefully before operating the machine:
This machine is for household use only.
•
This machine is for indoor use only. Please place it in dry environment.
•
Check power cord frequently. If power cord, plug or A/C is damaged,
•
please don’t operate. If the power cord is not long enough, power
extension cable can be used. Cable should not scatter at places where
power cord may be pulled out or people may be stumbled.
The A/C should be away from heat source and avoid direct sunlight.
•
Turn o the A/C before unplugging.
•
Turn o and unplug the A/C before removing or cleaning it, or replacing
•
its parts or when it is not used.
Clean the A/C according to the Manual.
•
Voltage of the A/C should meet requirements. Any damage incurred
•
by incorrect power isn’t included in the warranty.
Children are not allowed to play with the A/C.
•
This appliance is not intended for use by children, unless they have
been given supervision or instruction concerning use of the appliance by
a person responsible for their safety.
Don’t insert your ngers or any hard object to wind guide bar of the air
•
outlet.
Don’t place the A/C at any place with water or other liquid. Prevent water
•
or liquid from entering the A/C.
Don’t repair the A/C by yourself. Any possible hazard incurred by
•
maintenance of laypeople will violate the warranty. If the supply cord is
damaged, it must be replaced by professional maintenance personnel.
Please use the accessories provided by the A/C manufacturer; otherwise,
•
the A/C may be damaged.
Cleaning and user maintenance shall not be made by children without
•
supervision.
www.SereneLifeHome.com
3
Page 4
Special Warning:
•
Place the A/C on even ground and install it vertically, so as to ensure
normal operation of the compressor.
•
The A/C should be at least 50cm away from surrounding objects.
Keep air inlet and outlet smooth.
•
Don’t use the A/C beside gasoline or any other inammable liquid.
•
Don’t use spraying agent and other solvent or ammable substances
near the A/C; otherwise, its plastic may deform and electric parts may be
damaged.
Power
•
The plug should be in good condition and can’t be damaged.
Don’t replace the plug with power plug.
•
In order to run the A/C, plug the power cord rst, and then press the
power key.
•
Place unit in upright position for 2 hours before turning on for rst time.
Product Introduction
MAIN PARTS AND COMPONENTS
1. Handle
2. Control panel
3. Louver
4. Caster
5. Air outlet
6. Air inlet
7. Drainage nozzle
8. Remote controller
9. Exhaust duct assembly
10. Window sealing plate assembly
www.SereneLifeHome.com
4
Page 5
1
2
3
5
6
4
7
Sleep
8
9
10
www.SereneLifeHome.com
5
Page 6
Control Panel and Remote Controller
5
TIMER
MODE
SPEED
Low
Dry
Fan
Cool
High
POWER
Cooling Model
1. Power key
Press the key to turn ON/OFF the A/C.
3
2. Mode key
Press the key to choose cool, fan and dry.
3. Temperature/ time adjusting key
Press the key at cooling mode to increase/
reduce the setting temperature; press it at
4
9
timing mode to adjust time; press Up and
Down keys simultaneously to switch
Fahrenheit and Centigrade degree
5
temperature.
4. Speed key
Press the key to choose high/low speed.
5. Timer key
Press the key at standby mode to set ON time.
Press this key at ON mode to set OFF time.
6. Temperature/ Time Display Window
Displays the adjusted temperature and time
7. Remote controller receiving window
It is used to receive signal of the remote controller.
8. °C/°F switching key
Press the key to switch °C and °F
9. Sleep key
In the cooling mode, the sleep mode can be selected by this key
2
8
1
www.SereneLifeHome.com
6
Page 7
Product Operation
Placement and Installation
Placement
•
Place it at even and dry place, and keep it at least 50cm. away from its
surrounding object.
Installation
Screw the exhaust duct assembly in the air outlet behind the panel
•
(counterclockwise).
Insert the air exhaust hose into the window sealing plate, adjust opening
•
width of window so that the window can match with the sealing plate
properly; length of the sealing plate is adjustable.
www.SereneLifeHome.com
7
Page 8
Incorrect Installation
It’s important to keep the exhaust duct smooth. Incorrect installation will
•
aect work of the A/C.
Prevent the exhaust duct from sharp bending.
•
Ensure air can ow smoothly in the duct.
•
Warning:
The exhaust duct is designed especially
for this model. Don’t replace or lengthen it;
otherwise, it will result in failure.
Notice:
Max. developed length of the exhaust duct is 1,500mm. It’s better to
shorten it while in use and keep it horizontal while installation.
OPERATION METHOD
Cooling Mode
When the A/C enters cooling mode automatically or cooling mode is
•
selected after power ON, the cooling indicator lamp lights up.
Press Up/Down key to adjust setting temperature (16°C~30°C)(60°F~86°F).
•
Press Speed key to choose High/Mid/Low speed.
•
Fan Mode
• When pressing mode key or choosing Fan mode by pressing the remote
controller, the wind indicator lamp lights up.
Press Speed key to choose High/Mid/Low speed.
•
Temperature can’t be set.
•
www.SereneLifeHome.com
8
Page 9
Dehumidication Mode
•
When pressing mode key or choosing
dehumidication mode by pressing the remote
controller, the dehumidication indicator lamp
lights up.
•
Remove the dehumidication water wedge, insert
water manifold, place the other end of the water
manifold into the water vessel or drainage passage,
as shown in the right gure.
•
After entering the dehumidication mode,
if room tempearture≥17°C (62°F), the compressor
is ON. Then control as follows: when room temperature ≤15°C (59°F), the
compressor is OFF; when temperature increases to room temperature
≥17°C (62°F), the compressor will start again (in order to protect the
compressor, it will be restarted 3min. later).
•
In dehumidication mode, the fan is defaulted to run at low speed, and
wind speed can’t be adjusted.
•
Temperature can’t be set.
Note: When use dehumidify function, should remove exit pipe components,
otherwise, it will cause worse dehumidify performance, and appear “FL”
water full alarm
Sleep mode (optional function)
•
Under cool mode, pressing sleep mode key on the remote controller or
pressing time key and down key together on the machine, it will start
sleep mode with low wind speed and can’t be adjusted. Pressing the
sleep mode key again or pressing time key and down k ey together on
the machine to quit the sleep mode.
•
If you press the wind speed key under the sleep mode, the screen will
display ”SL”
Timer Mode
•
In standby state, press the Timer key to set ON time. Press Up and Down
keys to set ON time (0~24H), and the timer indicator lamp lights up.
•
In ON state, pressure the timer key to set OFF time. Press Up and Down
keys to set OFF time (0~24H), and the timer indicator lamp lights up.
Clean and Maintenance
DRAINAGE METHOD
This product is equipped with automatic water vaporization system.
The condenser is cooled with the circulating of condensing water, so as
to improve cooling eciency and save energy.
www.SereneLifeHome.com
9
Page 10
If the internal vessel is full of water, the display
•
screen will display “FL”, and the compressor
stops working automatically. After power o,
unscrew the water cover, pull out the water
plug to drain o water, and it will become
normal after being restarted.
MAINTENANCE
Notice: In order to avoid electric shock, please turn o the A/C and unplug
before maintenance or repair.
CLEANING
• Unplug before cleaning.
Wipe with soft semi-dry cloth. Don’t use chemical reagent, such as
•
benzene, alcohol and gasoline etc; otherwise surface of the A/C and even
the whole A/C will be damaged.
• Prevent water from spattering in the A/C.
FILTER SCREEN
• Wash the lter screen once every two weeks. If it is blocked by dust,
eciency of the A/C will be reduced.
• Take out the air inlet grille and pull out the lter screen at both sides
according to the direction shown in the following gures.
• Put the lter screen into the warm water (about 40°C or 104°F) added
with neutral detergent, dry it at a shady place after cleaning.
www.SereneLifeHome.com
10
Page 11
SEASONAL CLEANING
If the A/C will not be used for a long time:
•
Pull out the water plug to drain.
•
Run the A/C in fan mode for 2H till the inside is dry.
•
Turn o the A/C and unplug.
•
Wash the lter screen and reassemble it.
•
Dismantle the exhaust duct and keep it properly.
•
Cover the A/C with a plastic bag and place it at a dry place.
Common Failures and Diagnosis
Intelligent Error Detection
Error-detecting code Multi-functional defection
E1 Error of the coil’s temperature sensor
E2 Error of indoor temperature sensor
Anti-freezing protection: temperature of the coil is too low
E4
FUSE PARAMETERS
•
Voltage: 250VAC • Current: 3.15A
and the whole A/C is o. When temperature excesses 8°C
or 46.4°F, the protection is released and previous working
state is recovered.
Troubleshooting
In case of any of the following trouble, please contact professional
maintenance personnel in time.
TROUBLE CAUSE SOLUTION
The A/C doesn’t
work
The A/C st
frequently
art
s
No display
The
display panel displays
“FL”
Time
OFF
function is st
Direct sunlight
Doors and windows
there
are
lots of people
heat source in
or
Filter screen is very dirty
Air inlet
or
air outlet is blocked
keep
room
arted
open;
Reset circuit breaker on
Restart the
draining, then it will become
The A/C can be
after being turning off.
Draw the curtain
Close
source
Clean
Remove the stem
A/C
doors and
or
replace it
www.SereneLifeHome.com
AC cord
after
power
restarted 3 minutes
windows,
normal
remove
off
and
heat
11
Page 12
Big noise of the
A/C
The compressor
doesn’t
work
The A/C
Its delay protection is st
is placed unevenly
arted
Place it at
avoid shaking
Wait for 3min., turn
temperature
even and
decreases
firm
on aft
ground,
er
Notice: When there is any abnormal to the A/C, turn it o and unplug, and
then contact professional maintenance personnel.
The above technical parameters are subject to change without notice.
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact you local government for information regarding
the collection systems available.
If electrical appliances are disposed of in landlls or dumps,
hazardous substances can leak into the groundwater and
get into the food chain, damaging your health and well
-being. When replacing old appliances with new ones, the
retailer is legally obligated to take back your old appliance
for disposals at least free of charge.
SLPAC8
Portable Air Conditioner
Compact Home AC Cooling Unit with Built-in Dehumidier & Fan
Modes, Includes Window Mount Kit (8,000 BTU)
Features:
•
Lightweight & Portable A/C Unit
•
Compact Freestanding Room Air Conditioner
•
(3) Operation Modes: AC Cooling / Dehumidier / Fan
•
Hassle-Free, Quick Setup Cooling
•
Simple Electric Plug-in Operation
•
Convenient Wide-Area Climate Control Room AC Coverage
•
Digital Touch Button Control Panel with LED Display
•
Time, Temperature & Fan Speed Adjustment Settings
•
Includes Universal Window Mount AC Exhaust Kit
•
Removable & Washable Air Filter Screen
www.SereneLifeHome.com
12
Page 13
• Modern Style, Sleek Body Housing
•
Energy Ecient: Low Power Consumption
•
Low Noise Level Motor
•
Rolling Wheels for Easy Portability
•
Used for Home, Oce, School & Business Rooms
What’s in the Box:
• AC Unit
Exhaust Hose
•
Window Installation Plate
•
Remote Control
•
Technical Specs:
• Cooling Power: 8,000 BTU
Rated Power: 900 Watt
•
Coverage Area: Cools Rooms up to 215'+ Square Feet
•
Air Flow: 290 Cubic Meters / Hour
•
Operating Modes: Cool / Fan / Dry (Dehumidier)
•
Moisture Removal / Dehumidier: 1.2 Liters / Hour
•
Operating Noise Level: 57+/-3dBA
•
Fan Speed Settings: Low / High
•
Temperature Unit Selectable: °F / °C (Fahrenheit / Celsius)
•
Adjustable Timer Settings: Up to 24 Hours
•
Construction Material: Engineered ABS Housing
•
Battery Operated Remote Control, Requires (2) x ‘AAA’ Batteries, Included
•
Power Cable Length: 4.3'ft.
•
Power Supply: 120V
•
Dimensions (L x W x H): 14.6’’ x 13.8’’ x 27.2’’ -inches
•
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Email: [email protected]
This product can expose you to a chemical or group of checmicals, which may
include ”Acrylonitrile” which is known in the state of California to cause cancer,
birth defects, or other reproductive harm. For more info, go to
https://www.p65warnings.ca.gov/.
www.SereneLifeHome.com
13
Page 14
Loading...
