SereneLife SLAPF30 User guide

SLAPF30

Smart Automatic Pet Feeder

Digital Pet Food Dispenser with Voice Recorder

Key Features

Large capacity Hopper
7L ( around 7Lbs dry food)

Humanized design, simply
setting

Voice record/play at the
programmed meal time

Accurate portion control

Two Power supply:
Battery and Power adaptor

How to assemble and use it:

1. Assemble the bowl. Apply power，plug in the power adaptor.

If you do NOT want to use power adaptor, you can charge to use battery.

Bowl

USB cable

2

www.SereneLifeHome.com

Adaptor

2. Install batteries to the base (3 new “D” Cell, alkaline batteries. Batteries NOT

included) make sure the power switch is at “On” location.

Make sure the power
switch at “I” location.

Be sure to match positive
and negative markings)

3. Setting the feeder per the following instruction

INTERFACE

Quick Start Guide

1. Manual feeding Option and function check:press and hold “Manual” button

for 3 second, the rotor will rotate 1 portion. Repeat it 2 more times, if each time,

it will feed 1 portion. It means the machine with no problem.

Manual
Button

3

www.SereneLifeHome.com

2. To set current time: Press and hold “Time” and “Hour” button simultaneously,
then click “Hour” button setting current hour (Note: when you click，always hold

“Time” button). Press and hold “Time” and “minute” button，then click “minute”

button setting minute.

For example: Current time is 21:51

3. To set breakfast meal:Press and hold “Breakfast” and “ON/OFF” button to set
feeding breakfast or not.Press and hold “Breakfast” and “Meal Size” button
setting meal size.Press and hold “Breakfast” and “Hour” button to set breakfast
hour，Press and hold “Breakfast” button and “Minute” button to set breakfast

minute.

“ Meal Size”

• Model S: small meal size For Small & Medium pets
Programmable: 1 to 39 portions (5g -195g)

• Model L: Large meal size For Medium & large pets

Programmable: 1 to 39 portions (10g -390g)

On = Feeding breakfast

O = No Breakfast

www.SereneLifeHome.com

Meal time

4

4. To set lunch and dinner meal and 4th meal: As above，press and hold “Lunch”
and related button to se lunch meal.Press and hold “Dinner” and related button
to set dinner. Same goes with 4th meal.

Lunch:

Off = No feeding

Dinner:
On= Feeding

4thmeal:
On= Feeding

5. To set voice recording and play:Press and hold “MIC” button for 3 second till
LCD ashing to record your voice. To check your voice, press and hold “Play”
button for 3second.

Voice Recording

Interface

Voice Play button

MIC location

5

www.SereneLifeHome.com

CLEANING

1. Disassembly the Hopper and Bowl

2. Hand clean with soft cloth and hand dry

Warning: Base unit should not be submerged in water at any time, that will
damage electronic components and void the warranty.

Can be

washable

Warning: Base unit

should not be

submerged in water

Can be

washable

Troubleshooting:

1. The “Low battery” light is ashing?
Change 3 new “D” Cell, alkaline batteries.
Normally 3 new “D” Cell, alkaline batteries can last around 1year.

WARNING:

• Requires 3 “D” size batteries. Batteries NOT included.

• Use only alkaline batteries.

• Estimated life of one set of batteries is one year.

• Keep ngers and hands clear of food wheel.

• Always turn unit OFF before cleaning.

• Check the low battery light frequently to be sure the feeder has power.

• Check the level of food frequently, to be sure the feeder is dispensing properly.

Note: SLAPF30 has 2 models （exchangeable food dispenser）

1. Model S: For Small and medium size pet.
Programmable: 1 to 39 portions (5g -195g)

2. Model L: For medium and large size pet
Programmable: 1 to 39 portions (10g -390g)

www.SereneLifeHome.com

6

SLAPF30

Smart Automatic Pet Feeder

Digital Pet Food Dispenser with Voice Recorder

Features:

• Simple Electronic Plug-in Design

• Programmable Automatic Feeder Dispenser

• Ensures an Optimal Feeding Schedule & Weight Control

• Built-in Microphone & Speaker for Voice Recording

• Playback a Personalized Message to Announce Feeding Time

• Adjustable Pet Food Dispense Amount & Daily Dispense Frequency

• Digital LCD Display Screen

• Front Panel Button Control Center

• Sleek & Rounded, Modern-Style Housing

• Close-Fitting Lid Keeps Pet Food Fresh Longer

• Selectable Dispensing Modes: Manual / Automatic

• Large Capacity Pet Food Hopper Bin for Multiple Feedings

• Stain-Resistant & Easy-to-Clean

• Certied Pet-Safe: Made of BPA-Free Plastic

• Perfect for Cats, Dogs & Other Furry Friends

• *For Use with Dry Pet Food / Kibble / Treats Only

What’s in the Box:

• Digital Pet Food Dispenser

• Integrated Feeding Bowl

• Power Cable

• 1 x USB cable

Technical Specications:

• *Optional Battery Powered, Requires (3) x ‘D’ Batteries, Not Included

• Pet Food Storage Capacity: 7 Liters (7 lbs.)

• Dispense Sizes / Serving Portions: Small: 5g - 195g, Large: 10g - 390g

• Construction Material: Polypropylene, Engineered ABS

• Power Cord Length: 9.8’ ft.

• Power Adapter Voltage: 5V/1A

• Power Supply: 120V-240V

• Dimensions (L x W x H): 9.8’’ x 13.7’’ x 15.3’’ –inches

7

www.SereneLifeHome.com
