LTRS Series
Serene Heated Ladder Towel Rail
Square Profile
Installation and Operating Instructions
PRN5924 Rev. 3.0 Nov. 2008 edition
Contents
1Safety Information........................3
2Installation....................................4
Regulations.............................................................4
Methods .................................................................4
Components............................................................5
Visible Supply Cord.................................................6
Concealed Supply Cord..........................................8
Optional Spacers..................................................10
3 Specifications ..............................11
Dimensions...........................................................11
Electrical...............................................................11
Construction..........................................................11
4Operation....................................12
5Maintenance...............................12
Conrtact Addresses..............................................12
3
LTRS Series
Serene Heated Ladder Towel Rail - Square Profile
1Safety Information
When using any electrical appliance, safety precautions should
always be observed. Read these instructions carefully before
installation and retain for future reference.
•This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
•Children should be supervised to ensure that they do not play
with the appliance.
•This appliance is intended to dry towels and therefore is hot to
the touch. Any rise in ambient temperature is directly reflected
in the appliance, and as a result of this the appliance will feel
hotter to the touch during warmer periods. Also the insulation
effect of towels will cause the operating temperature to
increase slightly.
•Do NOT use this appliance other than for its intended use.
•Do NOT immerse in any liquid.
•Do NOT allow the supply cord to come into contact with heated
surfaces during operation.
•To avoid a hazard this heated towel rail MUST NOT be used to
carry towels or any other articles that have been in contact with
oil, petroleum based products or dry cleaning fluids.
•Use this appliance only on the voltage specified on the rating
label.
•Regulations require that electrical work be carried out only by
authorised persons. For your own safety, and that of others,
please ensure this is done.
Caution:
If this appliance is supplied from a cord extension set or an
electrical portable outlet device, the cord extension set or
electrical portable device must be positioned so that it is not
subject to splashing or ingress of moisture.
4
LTRS Series
Serene Heated Ladder Towel Rail - Square Profile
2Installation
Regulations
This appliance MUST be installed in accordance with the
relevant wiring rules and regulations which cover installation of
appliances and accessories in damp situations such as
bathrooms, showers, laundries and other areas with fixed water
containers (In Australia and New Zealand - AS/NZS 3000: 2000
Wiring Rules).
NOTE: This Class II appliance does NOT require Earthing. The
side frames of the Towel Rail should be mounted vertically, with
the heated rails horizontal, and the supply entry at the bottom.
The Heated Ladder Towel Rail is supplied with a 900mm supply
cord and plug. Where protected by an RCD, the Heated Towel
Rail can be plugged directly into a socket outlet, otherwise
permanent connection to the supply via a permanent connection
unit is required. On directly wired models, a suitable
disconnection device (acting in all supplies) must be
incorporated in the fixed supply wiring.
In order to avoid a hazard for young children, this appliance must
be installed so that the lowest heated rail is at least 600mm
above the floor.
Methods
The Towel Rail can be installed with either the supply cord
VISIBLE or CONCEALED inside the bottom mounting leg and
wired directly into the wall.
•To install the Towel Rail with the supply cord VISIBLE,
go to page 6.
•To install the Towel Rail with the supply cord CONCEALED,
go to page 8.
Optional Spacers (see page 10) are available to space the top
Mounting Brackets when the bottom part of the wall is tiled.
5
LTRS Series
Serene Heated Ladder Towel Rail - Square Profile
Components
The Heated Ladder Towel Rail is supplied with the following
installation components:
Table 1: Installation Components
Item Description Quantity
1 Standard Mounting Bracket 3
2 Cable Mounting Bracket 1
3 Mounting Base Extension 1
4 Leg Fixing Screw (short) 4
5 Wall Fixing Screw (long) 4
6 Flat Washer 1
7 Adhesive Dots 4
Figure 1: Installation Components
1
3
5
6
2
4
7
6
LTRS Series
Serene Heated Ladder Towel Rail - Square Profile
Visible Supply Cord
As standard, the supply cord exits through the bottom of either
the left or right hand mounting leg (see Figure 2 below).
When installing the Towel Rail with the Supply Cord visible, the
Cable Mounting Bracket (item 2) must be fitted to the wall with
the Flat Washer (item 6) fitted inside the Bracket and with the slot
in the Bracket facing downwards to clear the supply cord (see
Figure 3 below).
Follow the instructions on the following page to install the Towel
Rail with visible Supply Cord.
Figure 2: Visible Supply Cord
Cable
Mounting Bracket
Supply Cord
Supply Cord Grommet
Mounting Leg
Towel Rail Frame
Figure 3: Cable Mounting Bracket Fixing (for visible supply cord)
Cable Mounting
Bracket
Slot facing downwards
Flat Washer
Wall Fixing
Screw (long)
7
LTRS Series
Serene Heated Ladder Towel Rail - Square Profile
To install the Towel Rail with visible supply cord:
1.Firstly, establish a suitable position on the wall for attaching
the Towel Rail, with at least two leg Mounting Brackets
aligned with wall studs or dwangs.
2.Remove the Cable Mounting Bracket from the Towel Rail by
undoing the side Leg Fixing Screw.
3.Attach the Cable Mounting Bracket to the wall, ensuring the
slot is facing downwards. Fit the Flat Washer (supplied)
inside the Bracket (see Figure 3 on page 6) and attach to
the wall with either a Wall Fixing Screw (supplied) or a
suitable wall fixing plug.
4.Attach one of the Adhesive Dots (supplied) to the back of
each of the remaining three Mounting Brackets and remove
the protective paper backing.
5.Insert the remaining three Mounting Brackets into the frame
mounting legs. Ensure the rectangular fixing slot, in each
Mounting Bracket, faces downwards.
6.Fit the Towel Rail frame leg onto the Cable Mounting
Bracket, already screwed to the wall, ensuring the Supply
Cable Grommet engages firmly into the Mounting Bracket. If
necessary use a level to align the Towel Rail in the desired
position, before pressing firmly against the frame to adhere
the remaining three Mounting Brackets to the wall.
7.Pull the Towel Rail frame away, leaving the Mounting
Brackets attached to the wall.
8.Attach the remaining three Mounting Brackets to the wall
using the three Wall Fixing Screws (supplied).
9.Refit the Towel Rail frame over the Mounting Brackets and
lock in place with the four Leg Fixing Screws (supplied).
10.Either connect the supply cord to a socket outlet or, if
installed in a bathroom, have an authorised person connect
the supply cord to a switched permanent connection unit.
8
LTRS Series
Serene Heated Ladder Towel Rail - Square Profile
Concealed Supply Cord
The supply cord can be concealed inside the bottom mounting
leg of the Towel Rail and wired directly into the wall.
Before installing the Towel Rail with the concealed Supply Cord:
1.Remove the Cable Mounting Bracket from the Towel Rail by
undoing the side Leg Fixing Screw.
2.Cut the plug off the end of the Supply Cord.
3.Slide the Supply Cord Grommet out of the slot in the bottom
mounting leg and remove the grommet from Supply Cord.
4.Feed the Supply Cord through the centre of the Cable
Mounting Bracket (see Figure 4 above).
5.Rotate the Cable Mounting Bracket so the slot underneath
the mounting leg is blanked off.
6.Screw the Cable Mounting Bracket to the mounting leg with
the side Leg Fixing Screw.
To install the Towel Rail on the wall, follow the instructions on the
following page.
Figure 4: Concealed Supply Cord Installation
Cable Mounting Bracket
Supply Cord
Mounting Leg
Towel Rail
Frame
Leg Fixing Screw
Mounting Base Extension
9
LTRS Series
Serene Heated Ladder Towel Rail - Square Profile
To install the Towel Rail with concealed supply cord:
7.Establish a suitable position on the wall for attaching the
Towel Rail, with at least two leg Mounting Brackets aligned
with wall studs or dwangs. Mark the wall with the location of
the Concealed Cable Mounting Bracket.
8.The recess in the back of the Cable Mounting Bracket fits
over the flange of the Mounting Base Extension so you will
need to drill a Ø16mm hole in the wall to accommodate the
Extension. If the hole coincides with a wall stud it will be
necessary to drill a hole out of the side of the stud to allow
the Supply Cord to exit.
9.Push the Mounting Base Extension into the Ø16mm hole
firmly until the back of the flange is flush with the wall.
10.Feed the Supply Cord into the wall through the Mounting
Base Extension.
11.Continue with installation as per 'Visible Supply Cord', steps
3 to 9, on page 7.
12.It may be necessary to adjust the Cable Mounting Bracket
so that it fits flush against the wall. This can be done by
loosening the side Leg Fixing Screw and moving the
Bracket forwards or backwards (see Figure 5 below).
13.The wiring must then be connected to a suitable connection
unit. A suitable disconnection device (acting in all supplies)
MUST be incorporated in the fixed supply wiring.
Figure 5: Cable Mounting Bracket Adjustment
Cable Mounting
Bracket
Mounting Leg
Leg Fixing Screw
10
LTRS Series
Serene Heated Ladder Towel Rail - Square Profile
Optional Spacers
Optional 8mm Spacers (Part No. TUR9346-2) are available to
space the top Mounting Brackets when the bottom half of the wall
is tiled (see Figure 6 below).
To fit the optional Spacers:
Top Mounting Bracket
Towel Rail Frame
Figure 6: Optional Spacer Installation
Optional Spacer
Wall Tiles
Wall
Visible Supply Cord
Concealed Supply
Cord
Figure 7:
Attaching Optional Spacer
Optional Spacer
Top Mounting Bracket
Adhesive Dot
1.Before attaching the two top
Mounting Brackets to the wall,
remove the paper backing from the
adhesive dot on each of the optional
Spacers. Then press the Spacer
firmly and centrally on to the top
Mounting Bracket (see Figure 7).
2.Continue with installation as per
'Visible Supply Cord', steps 3 to 9,
on page 7.
11
LTRS Series
Serene Heated Ladder Towel Rail - Square Profile
3Specifications
Table 2: Specifications
Copyright © 2006 SKOPE Industries Limited.
SKOPE Industries Limited reserve the right to alter specifications without notice
Dimensions
Model Height Width Depth Weight Wattage
LTRS7946
795mm 525mm 107mm 4.0 kg 60-65 W
LTRS7960
795mm 665mm 107mm 4.8 kg 75-80 W
LTRSE4352
435mm 525mm 107mm 2.6 kg 35-40 W
Electrical
Supply: 230-240 V 50 Hz, single phase
Insulation Class: Class II - Double Insulated
Wiring: 900mm 2-core supply cord and plug. The plug may
be removed for connection to permanent wiring.
When ordering, the supply cord entry must be
specified either on the left or right hand side.
Controls: No controls provided. Designed for continuous
operation.
Construction
Ingress Protection Rating: IP34 - Splash-proof
Finish: Polished stainless steel frame with chrome plated
fittings and white supply cord and plug.
12
LTRS Series
Serene Heated Ladder Towel Rail - Square Profile
4Operation
Your Serene Heated Ladder Towel Rail costs approximately the
same to run as a 100 Watt light bulb. It will take approximately 45
minutes to reach normal operating temperature and, if need be,
can be left running continuously.
5Maintenance
The Heated Ladder Towel Rail is best wiped down, from time to
time, with a damp cloth. Do NOT use any abrasive or corrosive
cleaners.
The supply cord on this product cannot be replaced without
damaging the appliance. If the supply cord becomes damaged,
in any way, the appliance should be scrapped. If the appliance is
under warranty, contact your nearest Authorised Service Agent.
Contact Addresses
New Zealand
SKOPE INDUSTRIES LIMITED
PO Box 1091, Christchurch
New Zealand
Freephone: 0800 947 5673
Fax: (03) 983 3896
Email: enquiry@skope.co.nz
Website: www.skope.co.nz
Australia
SKOPE AUSTRALIA PTY LTD
A.C.N. 000 384 270
PO Box 7543, Baulkham Hills B.C.
NSW 2153, Australia
Freephone: 1800 121 535
Freefax: 1800 121 533
Email: enquiry@skope.com.au
Website: www.skope.com.au
Loading...
