Sercomm YN400 Users Manual

Home Monitoring
Gateway
User Guide
Table of Contents
CHAPTER 1 INTRODUCTION .............................................................................................1
Package Contents ..............................................................................................................1
Features..............................................................................................................................1
LEDs...................................................................................................................................2
Requirements.....................................................................................................................4
Procedure...........................................................................................................................4
CHAPTER 3 BOARD DESCRIPTION..................................................................................6
Overview ............................................................................................................................6
Components and connectors ............................................................................................6
Router/AP configuration ................................................................................................10
Copyright © 2008. All Rights Reserved. Document Version: 1.0 All trademarks and trade names are the properties of their respective owners.
i
Chapter 1
Introduction
1
This Chapter provides an overview of the Home Monitoring Gateway's fea­tures and capabilities.
Congratulations on the purchase of your new Home Monitoring Gateway. The Home Monitor­ing Gateway is a consumer electronic device, which is used for home monitoring and security.

Package Contents

The following items should be included:
The Home Monitoring Gateway Unit
Power Adapter
A Stand
If any of the above items are damaged or missing, please contact your dealer immediately.

Features

BCM5354 processor with16MB Flash and 32MB SDRAM
Two Ethernet ports with RJ45 connectors.
Front Panel LEDs
Z-Wave Transceiver
Two USB 2.0 ports
WPS button
Reset button
Power In connector
Internal antenna for WiFi and Z-Wave
1
Wireless Adapter User Guide

LEDs

Front-mounted LEDs
The Home Monitoring Gateway has 8 LEDs.
POWER
ETH (1~2) (Green)
WiFi
ZWave
USB (1~2)
On (Green)- Power On
Off - Power Off
On (Amber) - POST (power on self test) failure or device malfunc-
tion
On (Green)- LAN connection established.
Off - No active connection on the corresponding LAN port.
Flashing - Data is being transmitted or received via the corre-
sponding LAN (hub) port.
On - Wireless connection available
Off - No Wireless connection available.
Flashing - Data is being transmitted or received via the Wireless
connection.
On - ZWave function enabled.
Off - ZWave function disabled.
Flashing - Data is being transmitted or received via the Wireless
connection.
On (Green)- USB connection established.
Off - No active connection on the corresponding USB port.
Service
Flashing - Data is being transmitted or received via the corre-
sponding USB port.
On (Green)- Control Point has made a successful activation to the
Portal Server.
Off - No active connection to the Portal Server.
Flashing - Attempting to establish a connection to the Portal
Server.
2
