Sercomm DBC831 Users Manual

Wireless HD
Doorbell Camera
Setup Guide
Document Version: 1.4 Copyright 2016. All Rights Reserved. All trademarks and trade names are the properties of their respective
owners.
Sercomm Confidential
i
Package Contents
The following items should be included: If any of these items are damaged or missing, please contact your service provider immediately.
1. Doorbell Camera x 1
2. Micro USB to USB Cable x 1
3. Mounting Bracket with Anti-theft Screw x 1
4. Screw/Anchor x 2
5. Gradienter x 1
6. Splice Connectors x 2
Sercomm Confidential
7. Allen Key
Sercomm Confidential
Sercomm Confidential
Chapter 1
1
Introduction
This Chapter provides details of the Wireless HD Doorbell Camera's features, components and capabilities.
Overview
DBC831 is a WiFi enabled video doorbell camera that lets you answer the door from your iOS or Android mobile device no matter where you are in the world. This device features a video camera, built-in microphone and a speaker that allows you to see, hear and speak to your visitors from a smart phone, tablet or PC. (The customers are required to make their own APP or server which can communicate with doorbell camera. Sercomm can support the customized API for development based on customers definition.)
It is also an all-in-one camera that has automatic and manual day/night switching, PIR sensor and IR illumination, which can provide illumination around 3 meters long under low light conditions in a simple, economical manner.
This device, which attaches to your current doorbell wires, is easy to install and connects to your home internet through WiFi. When a visitor rings the doorbell, the device will send an alert to one or several people and each person can accept or ignore the call.
Figure 1: Network Diagram - Wireless HD Doorbell Camera
Sercomm Confidential
1
Product Features
Features
Doorbell Camera. Takes a snapshot/live video when a visitor rings the doorbell, so you can see who is outside. It also allows you to stream video, audio or both simultaneously.
NoteThe intercom is up to 2 minutes.
Multiple Users Support. Allows for up to 5 users on an account so an entire family can receive alerts when a visitor rings the doorbell.
Dual Video Support. The Wireless HD Doorbell Camera can support H.264 and MJEPG video for different image compression.
Suitable for Home, Business or Public Facilities. Whether for Home, Business or Public Facility surveillance, the Wireless HD Doorbell Camera has the features you need.
Day/Night Switch. With the day/night switching feature, you are able to view and record better images even in the dark of night.
IR LED Support. Each Wireless HD Doorbell Camera has a high power infrared LED. The LED can provide illumination around 3 meters, which can help to output a better video quality while under low-light conditions in the morning or evening.
PIR (Passive Infrared Sensor) Support. This device is embedded with a PIR Sensor, which senses infrared light radiating from human bodies in its field of 3 meters view. This feature is very helpful in enhancing home security systems.
WiFi Connectivity. Makes it easy to link with your home wireless network.
Easy Installation. This device connects to your existing doorbell wiring. It comes with the supplies you need to install on a variety of surfaces.
Wireless Features
Supports 11n Wireless Stations. The 802.11n standard provides for backward compatibility with the 802.11b standard, so 802.11n,
802.11b and 802.11g Wireless stations can be used simultaneously.
Wireless Network Support. The Wireless HD Doorbell Camera supports wireless transmission.
WPS Support. WPS (WiFi Protected Setup) can simplify the process of connecting any device to the wireless network by using the push button configuration (PBC) on the Wireless HD Doorbell Camera, or entering a PIN code if there's no button.
Sercomm Confidential
2
