Chapter 1: Introduction

Quick Start Guide

The following instructions will help you quickly install and configure your PT22 for use in your data
center equipment cabinet. For detailed information on each step, go to the page number listed to the
right.

1. Mount the PT22..........................................................................................................................6

2. Connect to the power source ......................................................................................................7

3. Connect the devices....................................................................................................................7

4. Connect the sensors....................................................................................................................7

5. Connect to the PT22...................................................................................................................8

6. Configure the PT22 ....................................................................................................................9

• Login as the predefined Administrator (admn/admn).......................................................10

• Configure the network settings .........................................................................................14

• Create new administrative user account............................................................................15

• Configure location and PT22 names.................................................................................13

• Configure sensor names....................................................................................................13

• Configure new user account(s) .........................................................................................15

• Remove the predefined Administrator..............................................................................17

7. Connect the PT22 to the network.

Technical Support

Server Technology understands that there are often questions when installing and/or using a new
product. Free Technical Support is provided from 8:30 AM to 5:00 PM, Monday-Friday, Pacific Time.

Server Technology, Inc.
1040 Sandhill Drive Tel: [phone] Web: www.servertech.com
Reno, Nevada 89521 USA Fax: [phone] Email: [e-mail]

4 • Introduction Sentry PT22 Installation and Operations Manual

Equipment Overview

1. The power inlet/cord(s) connects the CDU to the electrical power source.

2. Two RJ45 connectors for Serial (RS-232) and Ethernet connection.

3. Two mini RJ11 connectors for Temperature/Humidity sensors.

A number is printed above each PT22 outlet. These numbers may be used in commands that require an
outlet name.

3

2

1

Figure 1.1 PT22 Views

1

1

1

Sentry PT22 Introduction • 5
Installation and Operations Manual

Chapter 2: Installation

Before installing your Sentry PT22, refer to the following lists to ensure that you have all the items
shipped with the unit as well as all other items required for proper installation.

Standard Accessories

• Mounting bracket hardware: two mounting brackets and four screws

• RJ45 to RJ45 crossover cable

• RJ45 to DB9F serial port adapter (for connection to standard DB9M DTE serial port)

• DB9F to DB25M modem cable

• Cable Management Bar with four mounting screws

Optional Accessories

• Temperature/Humidity sensors

Additional Required Items

• Separate power input cord(s)

• Flathead and Phillip screwdrivers

• Screws, washers and nuts to attach the PT22 to your rack

Safety Precautions

This section contains important safety and regulatory information that should be reviewed before
installing and using the Sentry PT22. For input and output current ratings, see Power Ratings in
Appendix C: Technical Specifications.

Only for installation and use in a
Service Access Location in
accordance with the following
installation and use instructions.

This equipment is designed to be
installed on a dedicated circuit.

Dedicated circuit must have circuit
breaker or fuse protection.
PT22s have been designed without a
master circuit breaker or fuse to avoid
becoming a single point of failure. It is
the customer’s responsibility to
provide adequate protection for the
dedicated power circuit. Protection of
capacity equal to the current rating of
the PT22 must be provided and must
meet all applicable codes and
regulations. In North American,
protection must have a 10,000A
interrupt capacity.

The plug on the power supply cord
shall be installed near the equipment
and shall be easily accessible.

Always disconnect the power supply
cord before opening to avoid electrical
shock.

WARNING! High leakage current!
Earth connection is essential before
connecting supply!

Destiné à l'installation et l'utilisation
dans le cadre de Service Access
Location selon les instructions
d'installation et d'utilisation.

Cet équipement est conçu à être
installé sur un circuit spécialisé.

Le circuit spécialisé doit avoir un
disjoncteur ou une protection de
fusible. PT22s ont été conçus sans
disjoncteur général ni fusible pour
éviter que cela devient un seul endroit
de panne. C’est la responsabilité du
client de fournir une protection
adéquate pour le circuit-alimentation
spécialisé. Protection de capacité
équivalant à la puissance de
l'équipement, et respectant tous les
codes et normes applicables. Les
disjoncteurs ou fusibles destinés à
l'installation en Amérique du Nord
doivent avoir une capacité
d'interruption de 10.000 A.

La prise sur le cordon d’alimentation
sera installée près de l’équipement et
sera facilement disponible.

Toujours déconnecter le cordon
d’alimentation avant d’ouvrir pour
éviter un choque électrique.

ATTENTION ! Haut fuite très
possible ! Une connection de masse
est essentielle avant de connecter
l’alimentation !

Nur für Installation und Gebrauch an
Anschlusszugriffspunkten gemäß der
folgenden Installations- und
Gebrauchsanweisungen.

Diese Ausrüstung ist zur Installation in
einem festen Stromkreis vorgesehen.

Der feste Stromkreis muss mit einem
Schutzschalter oder einem
Sicherungsschutz versehen sein.
PT22s verfügt über keinen
Hauptschutzschalter bzw. über keine
Sicherung, damit kein einzelner
Fehlerpunkt entstehen kann. Der
Kunde ist dafür verantwortlich, den
Stromkreis sachgemäß zu schützen.
Der Kapazitätsschutz entspricht der
aktuellen Stromstärke der Geräte und
muss alle relevanten Codes und
Bestimmungen erfüllen. Für
Installation in Nordamerika müssen
Ausschalter bzw. Sicherung über

10.000 A Unterbrechungskapazität
verfügen.

Der Stecker des Netzkabels muss in
der Nähe der Ausrüstung installiert
werden und leicht zugänglich sein.

Ziehen Sie vor dem Öffnen immer das
Netzkabel heraus, um die Gefahr
eines elektrischen Schlags zu
vermeiden.

ACHTUNG! Hoher Ableitstrom! Ein
Erdungsanschluss ist vor dem
Einschalten der Stromzufuhr
erforderlich!

6 • Installation Sentry PT22 Installation and Operations Manual

Mounting

1. Select the appropriate bracket mounting points for

proper mounting depth within the rack.

2. Attach the brackets to these mounting points with two

screws for each bracket.

3. Install the enclosure into your rack, using the slots in

each bracket. The slots allow about ¼ inch of
horizontal adaptability to align with the mounting
holes of your rack.

NOTE: A mounting bracket kit for 23” wide racks or cabinets is
available. Contact your Server Technology Sales Representative for
more information.

Figure 2.1 Mounting

Connecting to the Power Source

The input power cord must first be attached to the unit before connecting the unit to the power source.
Each outlet powers up sequentially, eliminating a potential blown primary fuse or circuit breaker from
excessive in-rush current.

To attach the power cord to the unit:

1. Plug the female end of the power cord firmly into its connector at the base.

2. Use a screwdriver to tighten the two screws on the retention bracket.

To connect to the power source:

Plug the male end of the power cord into the AC power source.

Connecting Devices

To avoid the possibility of noise due to arcing:

1. Keep the device’s on/off switch in the off position until after it is plugged into the outlet.

2. Connect devices to the PT22 outlets.

NOTE: Server Technology recommends even distribution of attached devices across all available outlets to avoid
exceeding the outlet, branch or phase limitations. See Power Ratings on page 69 for more information.

Always disconnect both power supply cords before opening to avoid electrical shock.
Afin d’éviter les chocs électriques, débranchez les cables électrique avant d’ouvrir.
Immer beiden Netzleitungen auskuppeln vor den Aufmachen um elektrischen Schlag zu vermeiden.

Connecting the Sensors

The Switched CDU is equipped with two mini RJ11 T/H ports for attachment of the
Temperature/Humidity sensors. Attach the mini RJ11 plug of the sensor(s) to the appropriate T/H port.

Sentry PT22 Installation • 7
Installation and Operations Manual

Connecting to the Unit

Serial (RS232) port

The PT22 is equipped with an RJ45 Serial RS-232 port for attachment to a PC or networked terminal
server using the supplied RJ45 to RJ45 crossover cable and RJ45 to DB9F serial port adapter as
required. See Power Ratings in Appendix C: Technical Specifications for more information on the
Serial RS-232 port.

Ethernet port

The PT22 is equipped with an RJ45 10/100Base-T Ethernet port for attachment to an existing network.
This connection allows access to the Switched PT22 via Telnet or HTML.

The PT22 is configured with the following network defaults to allow unit configuration out-of-the-box
through either Telnet or HTML:

• IP address: 192.168.1.254

• Subnet Mask: 255.255.255.0

• Gateway: 192.168.1.1

The local PC network connection must be configured as noted below:

NOTE: Contact your system administrator for instructions in reconfiguring the network connection. Reconfiguration of
your network connection may require a restart to take effect.

• IP address: 192.168.1.x (where x is 2-253)

• Subnet Mask: 255.255.255.0

Modem port

The PT22 is equipped with a DB9 male Modem serial port for connection to an external modem using
the supplied DB9 female to DB25 male serial cable. See Power Ratings in Appendix C: Technical
Specifications more information on the Modem port.

8 • Installation Sentry PT22
Installation and Operations Manual

Chapter 3: Operations

INTERFACES 10

Outlet Naming and Grouping 10
Usernames and Passwords 10

HTML INTERFACE 11

Logging In 11
Outlet Control 12

Individual..............................................................................................................................12

Group....................................................................................................................................12

Environmental Monitoring 13

Input Load ............................................................................................................................13

Sensors..................................................................................................................................13

Configuration 13

System...................................................................................................................................13

Network ................................................................................................................................14

Telnet/SSH ............................................................................................................................14

HTTP/SSL.............................................................................................................................14

Serial Ports...........................................................................................................................15

Outlets ..................................................................................................................................16

Groups ..................................................................................................................................16

Users.....................................................................................................................................17

FTP.......................................................................................................................................18

SNTP.....................................................................................................................................18

SNMP....................................................................................................................................18

LDAP ....................................................................................................................................19

TACACS+.............................................................................................................................19

Tools 21

Restart ..................................................................................................................................21

Ping ......................................................................................................................................21

COMMAND LINE INTERFACE 22

Logging In 22
Operations Commands 24
Administration Commands 28

User Administration .............................................................................................................28

Outlet Administration ...........................................................................................................31

Group Administration...........................................................................................................33

Environmental Monitor Administration................................................................................34

Serial Port Administration....................................................................................................34

System Administration ..........................................................................................................37

TCP/IP Administration.........................................................................................................39

HTTP Administration ...........................................................................................................40

Telnet Administration ...........................................................................................................41

FTP Administration ..............................................................................................................41

SNTP Administration............................................................................................................42

Interfaces

The PT22 has two interfaces: the HTML interface accessed via the HTTP enabled Ethernet connections
and the command line for serial and Telnet connections.

Outlet Naming and Grouping

For commands requiring an outlet name, you may specify it in one of two ways: a predefined absolute
name or a descriptive name assigned by an administrator.

For units with multiple infeed connectors, absolute names are specified by a period (.) followed by the
tower letter, the infeed letter and outlet number.

Example: The absolute name for outlet 8 on the B infeed of tower A is .AB8.

Outlets may also be included in one or more named groups of outlets, enabling you to issue a command
that affects all outlets in a named group.

Usernames and Passwords

The PT22 has one predefined administrative user account (username/password: admn/admn) and supports
a maximum of 128 defined user accounts

NOTE: For security, Server Technology recommends removal of the predefined administrative user account after a new
account with administrative rights has been created.

Only an administrative-level user may perform operations such as creating/removing user accounts and
command privileges, changing passwords and displaying user information. An administrator may also
view the status of all sensors and power inputs.

Usernames may contain from 1-16 characters and are not case sensitive; spaces are not allowed.
Passwords may contain up to 16 characters, and are case sensitive.

10 • Operations Sentry PT22
Installation and Operations Manual

HTML Interface

The HTML interface is constructed of three major components: the System Location bar, the
User/Navigation bar and the Control Screen. The System Location bar displays the Sentry’s location
and IP address as well as the current Control Screen title. The User/Navigation bar displays the current
user and privilege level and provides access to all HTML pages. And the Control Screen is used to
display current data and allow changes to outlet states or system configuration.

The following sections describe each interface section/page and their use.

User/Navigation System Location Control Screen

Figure 3.1 Example HTML page

Log

ging In

Logging in through HTML requires directing the HTML client to the configured IP address of the unit.

T

o log in by HTML:

In the login window, en

If you enter an invalid username or password, you will be prompted again.

You are given three attempts to enter a valid username and password combi

ter a valid username and password and press OK.

nation. If all three fail, the

session ends and a protected page will be displayed.

NOTE: The default Sentry username/password is admn/admn.

Sentry PT22 Operations • 11
Installation and Operations Manual

Outlet Control

The Outlet Control section offers access to the Individual and Group outlet control pages. From the
Individual and Group pages, the user can review and manipulate power control functions for all outlets
and groups assigned to the current user. Both pages include the outlets absolute and descriptive names,
the Outlet Status reported to the Sentry by the outlet, the current Control State being applied by the
Sentry and the outlet load in amperes.

Available outlet and group power states may be set to on, off or reboot.

Individual

The Individual outlet control page displays all outlets assigned to the current user. The user may apply
on, off or reboot actions to individual, multiple or all accessible outlets.

To apply actions to individual or multiple outlets:

In the Individual Outlet Control section, select the desired action from the Control Action drop-down
menu for each individual outlet to be changed and press Apply.

To apply an action to all outlets:

In the Global Control section, select the desired action from the Control Action drop-down menu and
press Apply.

Group

The Group outlet control page displays all groups assigned to the current user as well as the outlets for
each group.

To select a group:

Select the group name from the drop-down menu and press Select. The page will refresh to display all
outlets associated to the selected group name.

To apply an action to a group:

Select the desired action from the drop-down menu and press Apply.

Outlet State/Control State Field Values

Outlet State Control State Description

On On Outlet is on

Off Off Outlet is off

Off Pend On Outlet is off and about to turn on in response to a sequence timer

Off Reboot Outlet is off and a Reboot action has been initiated

On Idle On A restart has occurred – Last Control State has been maintained

Off Idle Off A restart has occurred – Last Control State has been maintained

On Wake On A power-loss has occurred – Wakeup State has been applied

Off Wake Off A power-loss has occurred – Wakeup State has been applied

On/Wait Off Outlet state in transition – Requery of outlet status required

Off/Wait On Outlet state in transition – Requery of outlet status required

On/Error varies Error State – Outlet should be off but current is sensed at the outlet

Off/Error varies Error State – Outlet should be on but no current is sensed at the outlet

No Comm varies Communication to the outlet has been lost*

* Control State will be applied when communication is re-established

12 • Operations Sentry PT22
Installation and Operations Manual

Environmental Monitoring

Input Load

The Input Load page displays the tower(s) absolute and descriptive name and the cumulative input load
in amperes of all devices attached to the Sentry at the time the page was loaded. This page will refresh
automatically every 10 seconds.

Sensors

The Sensors page displays:

• Temperature/humidity sensor’s absolute and descriptive names

• Temperature/humidity sensor readings in degrees Celsius and percent relative humidity

Configuration

The Configuration section offers access to all unit configuration options including Network,
Telnet/SSH, HTTP/SSL, Serial Ports, Users, FTP, Proxy/SNTP and SNMP. This section is available to
administrative level users only.

System

The System configuration page is used for reference of system information such as Ethernet NIC Serial
Number, Ethernet MAC address and system firmware and hardware revisions as well as assignment and
maintenance of the system location and tower descriptive names.

For description names, up to 24 alphanumeric and other typeable characters (ASCII 33 to 126 decimal –
spaces are not allowed) are allowed.

NOTE: Spaces may be used for the location description only.

Creating a descriptive system location name:

Enter a descriptive name and press Apply.

Creating a descriptive unit name:

Click on the Tower Names link.

On the subsequent Tower Names page, enter a descriptive name and press Apply.

Creating a descriptive input feed name:

Click on the Input Feed Names link.

On the subsequent Input Feed Names page, enter a descriptive name and press Apply.

Creating a descriptive outlet name:

Click on the Outlet Names link which will open the Outlets configuration page. See Outlets on page
16 for additional information on creating descriptive outlet names.

Creating a descriptive serial port/Pass-Thru name:

Click on the Serial Port Names link which will open the Serial Ports configuration page. See Serial
Ports on page 15 for additional information on creating descriptive serial port names.

Creating a descriptive Environmental Monitor name:

Click on the Environmental Monitor Names link.

On the subsequent Environmental Monitor Names page, enter a descriptive name and press Apply.

Creating descriptive sensor names:

Click on the Sensor Names link.

On the subsequent Sensor Names page, enter a descriptive name and press Apply.

Sentry PT22 Operations • 13
Installation and Operations Manual

Network

The Network configuration page is used for maintenance of the network interface. From this page an
administrator may configure the IP address, subnet mask, gateway address, DNS addresses as well as
view the link status, speed and duplex value.

The Sentry is configured with the following network defaults to allow unit configuration out-of-the-box
through either Telnet or HTML:

• IP address: 192.168.1.254

• Subnet Mask: 255.255.255.0

• Gateway: 192.168.1.1

The initial local PC network connection must be configured as noted below:

NOTE: Contact your system administrator for instructions in reconfiguring the network connection. Reconfiguration of
your network connection may require a restart to take effect.

• IP address: 192.168.1.x (where x is 2-253)

• Subnet Mask: 255.255.255.0

NOTE: The unit must be restarted after network configuration changes. See Performing a warm boot: on page 21.

Setting the IP address, subnet mask, gateway or DNS address:

In the appropriate field, enter the IP address, subnet mask, gateway address or DNS address and press Apply.

Telnet/SSH

The Telnet/SSH configuration page used to enable or disable Telnet and SSH support and configure the
port number that the Telnet or SSH server watches. For more information on SSH see page 47 in
Chapter 4: Advanced Operations.

Enabling or disabling Telnet or SSH support:

Select Enabled or Disabled from the appropriate Server drop-down menu and press Apply.

Changing the Telnet or SSH server port number:

In the appropriate Port field, enter the port number and press Apply.

HTTP/SSL

The HTTP/SSL configuration page used to enable or disable HTTP and SSL support, configure the port
number that the HTTP server watches and responds to, selection of the method of authentication used
and SSL access level. For more information on SSL see page 45 in Chapter 4: Advanced Operations.

Enabling or disabling HTTP or SSL support:

Select Enabled or Disabled from the appropriate Server drop-down menu and press Apply.

Changing the HTTP server port number:

In the HTTP Port field, enter the port number and press Apply.

Setting the HTTP authentication method:

The Sentry HTTP server supports two authentication methods for security and validation of the
username-password – Basic and MD5 digest.

The Basic method utilizes Base64 encoding to encode and deliver the username-password over the
network to the HTTP server for decoding and authentication. This basic method is supported by all
web browsers and offers a minimum level of security.

NOTE: The Base64 algorithm is widely-known and susceptible to packet-sniffer attack for acquisition of the encoded
username-password string.

The MD5 digest method provides stronger protection utilizing one-way encoded hash numbers, never
placing the username-password on the network. Instead, the sending browser creates a challenge code
based on the hash algorithm, provided username-password and unique items such as the device IP
address and timestamp, which is compared against the HTTP server internal user database of valid
challenge codes. The MD5 digest method offers a higher level of security than the Basic method but at
present is not supported by all browsers.

NOTE: MD5 is known to be fully supported by Internet Explorer 5.0+

Select Basic or MD5 from the Authentication drop-down menu and press Apply.

14 • Operations Sentry PT22
Installation and Operations Manual

Setting SSL access level

Sentry SSL supports configuration of SSL connections as being either optional or required. The default
access level is set to optional.

• Optional –Both non-secure (HTTP) and SSL encrypted connections (HTTPS) are allowed access.

• Required – ONLY SSL encrypted connections (HTTPS) are allowed access.

Select Optional or Required from the Secure Access drop-down menu and press Apply.

Serial Ports

The Serial Ports configuration page is used for maintenance of all serial ports.

NOTE: Pass-Thru connections may only be initiated from the command line interface via a direct serial or Telnet session.

Setting the data-rate for all serial ports:

Select the serial port data-rate from the drop-down menu and press Apply.

Setting the serial port timeout value:

Enter the timeout value (in minutes) in the Connection Timeout field and press Apply.

Creating a descriptive serial port name:

Click on the Edit link in the Action column next to the port to be configured.

On the subsequent Serial Port Edit page, enter the descriptive name. Up to 24 alphanumeric and other typeable
characters (ASCII 33 to 126 decimal, spaces and colon characters are not allowed) are allowed. Press Apply.

NOTE: Port names ‘1’ thru ‘64’, ‘CONSOLE’ and ‘MODEM’ are reserved system names and may not be used.

Enabling or disabling serial port active signal checking:

Click on the Edit link in the Action column next to the port to be configured.

On the subsequent Serial Port Edit page, select On or Off from the DSR Check drop-down menu and press Apply.

Enabling or disabling modem initialization strings:

By default, the Sentry assumes an external modem is attached to the Modem port and sends
initialization strings to that modem as necessary. The Sentry sends the initialization strings under the
following conditions:

• System start –DSR is high and DCD is low

• Normal operations – If DSR transitions from low to high and DCD is low

• Normal operations – After a session initiated from the Modem port ends

• Normal operations – After a Pass-Thru connection to the Modem port is disconnected

Click on the Edit link in the Modem port Action column.

On the subsequent Serial Port Edit page, select On or Off from the Modem Initializations drop-down
menu and press Apply.

Sentry PT22 Operations • 15
Installation and Operations Manual

Editing modem initialization strings:

Click on the Edit link in the Modem port Action column.

On the subsequent Serial Port Edit page, enter the initialization string in the appropriate field and press
Apply.

The Init1 and Init2 strings may be up to 48 characters. The Attention and Hang-up strings may be up to
16 characters.

Predefined Modem Initialization Strings

String Type String Description

Init 1 AT Gets modem attention

Init 2 AT E0 Q1 S0=1 S2=64 S12=50 &C1 &D2 Initializes default settings required

Attention @@@ Switches the modem to command mode

Hang-up ATH Forces a hang-up of an active connection

NOTE: Sentry Remote Power Managers do NOT support variable data-rate mode modems. The modem operating mode
must be set to fixed data-rate mode to avoid the data-rate being changed after initialization.

The modem manual must be referred to as the command(s) required to set the configuration to fixed data-rate mode vary
significantly from manufacturer to manufacturer. The modem should be configured directly from a PC using a terminal
program and the command &W be used to save the new configuration to memory and set it to default.

Outlets

The Outlets configuration page is used for assignment and/or editing of outlet sequence and reboot
timers, descriptive names and wakeup states.

Setting the outlet sequencing interval:

Enter the sequencing interval (in seconds) in the Sequence Interval field and press Apply.

Setting the outlet reboot delay:

Enter the reboot interval (in seconds) in the Reboot Delay field and press Apply.

Editing the outlet descriptive name:

Click on the Edit link in the Action column next to the outlet to be configured.

On the subsequent Outlet Edit page, enter the descriptive name. Up to 24 alphanumeric and other
typeable characters (ASCII 33 to 126 decimal, spaces are not allowed) are allowed. Press Apply.

Changing the outlet wakeup state:

Click on the Edit link in the Action column next to the outlet to be configured.

On the subsequent Outlet Edit page, select On, Off or Last from the Wakeup State drop-down menu
and press Apply.

Setting the outlet Post-On delay:

Click on the Edit link in the Action column next to the outlet to be configured.

On the subsequent Outlet Edit page, enter the outlet Post-On delay (in seconds) in the Post-On Delay
field and press Apply.

Groups

The Groups configuration page is used for creation and deletion of group and assignment of outlets to
groups.

Creating a group:

Enter a descriptive group name in the Group Name field. Up to 24 alphanumeric and other typeable
characters (ASCII 33 to 126 decimal, spaces are not allowed) are allowed. Press Apply.

Removing a group:

Click on the Remove link in the Action column for the group to be removed and press Yes on the
subsequent confirmation window.

16 • Operations Sentry PT22
Installation and Operations Manual

Adding and Deleting outlets from a group:

Press the Edit link in the Action column for the associated group.

On the subsequent Group Edit page, select or deselect outlets to be included in that group. Press
Apply.

Users

The Users configuration page is used for creation and removal of usernames, assignment of accessible
outlets and group, assignment of privilege levels and the changing of user passwords.

Creating a new user:

Enter a user name in the Username field. Up to 16 alphanumeric and other typeable characters (ASCII
33 to 126 decimal, spaces are not allowed) are allowed.

Enter a password for the new user and verify in the Password and Verify Password fields. For security,
password characters are not displayed. Press Apply.

Removing a user:

Click on the Remove link in the Action column for the user to be removed and press Yes on the
subsequent confirmation window.

Changing a user password:

Click on the Edit link in the Action column for the associated user.

On the subsequent User Edit page, enter a password and verify the new password for the new user in the
Password and Verify Password fields. For security, password characters are not displayed. Press Apply.

Changing a user’s access privilege level:

The Sentry has four defined access privilege levels; Admin, User, On-Only and View-Only:

• Admin: Full-access for all configuration, control (On, Off, Reboot), status and Pass-Thru.

• User: Partial-access for control (On, Off, Reboot), status and Pass-Thru of assigned

outlets, groups and serial ports.

• On-Only: Partial-access for control (On), status and Pass-Thru of assigned outlets, groups

and serial ports.

• View-Only: Partial-access for status and Pass-Thru of assigned outlets, groups and serial

ports.

The administrator may also grant administrative privileges to other user accounts allowing the Sentry to
have more than one administrative-level user.

NOTE: You cannot remove administrative privileges from the Admn user unless another user has already been given
administrative access level privileges created.

Click on the Edit link in the Action column for the associated user.

On the subsequent User Edit page, select Admin, User, On-only or View-only from the Access Level
drop-down menu and press Apply.

Granting or removing Environmental Monitoring viewing privileges:

Click on the Edit link in the Action column for the associated user.

On the subsequent User Edit page, select Yes or No from the Environmental Monitoring drop-down
menu and press Apply.

NOTE: This also grants or removes viewing privileges for the optional Equipment Cabinet Environmental Manager. See
the Equipment Cabinet Environmental Manager Installation and Operations manual for more information.

Adding and Deleting outlet access:

Click on the Outlets link in the Access column for the associated user.

On the subsequent User Outlets page, select or deselect outlets to be accessed by the user and press Apply.

Adding and Deleting group access:

Click on the Groups link in the Access column for the associated user.

On the subsequent User Groups page, select or deselect group to be accessed by the user and press Apply.

Sentry PT22 Operations • 17
Installation and Operations Manual

Adding and Deleting serial port access:

Click on the Ports link in the Access column for the associated user.

On the subsequent User Ports page, select or deselect ports to be accessed by the user and press Apply.

FTP

The FTP configuration page is used for setup and maintenance of all settings required to perform an
FTP firmware upload. See Appendix B: Uploading Firmware for more information on uploading
firmware.

Setting the FTP Host IP Address:

Enter the IP address in the Host IP Address field and press Apply.

Setting the FTP username:

Enter the FTP server username in the Username field, and press Apply.

Setting the FTP password:

Enter the FTP server password in the Password field, and press Apply.

Setting the filepath:

Enter the path of the file to be uploaded in the Directory field, and press Apply.

Setting the filename for upload:

Enter the filename of the file to be uploaded in the Filename field, and press Apply.

Testing the FTP upload configuration:

This test validates that the unit is able to contact and log onto the specified FTP server, download the
firmware file and verify that the firmware file is valid for this unit.

Press Test.

SNTP

The SNTP configuration page is used for setup and maintenance of SNTP support.

Setting the SNTP Server Address:

Enter the IP address in the primary and/or secondary address field and press Apply.

SNMP

The SNMP configuration page is used for setup and maintenance of all settings required to enable
SNMP support as well as access to the trap configuration pages. For additional information on SNMP
support and detailed descriptions of available traps, see SNMP on page 48.

NOTE: Traps are generated according to a hierarchical architecture; i.e. if a Tower Status enters a trap condition, only the
Tower Status trap is generated. Infeed and Outlet Status traps are suppressed until the Tower Status returns to Normal.

Enabling or disabling SNMP support:

Select Enabled or Disabled from the drop-down menu and press Apply.

Setting the community strings:

Enter the community string in the appropriate field and press Apply.
Community strings may be 1 to 24 characters

Setting the trap timer:

Enter a trap timer value in the Error Trap Repeat Time field and press Apply.
The Error Trap Repeat Time value may be 1 to 65535 (in seconds).

Setting trap destinations:

Enter an IP address in the appropriate Trap Destination field and press Apply.

Enabling or disabling tower traps:

Click on the Tower Traps link.

On the subsequent Tower Traps page, select or deselect the desired traps and press Apply.

18 • Operations Sentry PT22
Installation and Operations Manual

Configuring input feed traps:

Click on the Input Feed Traps link.

On the subsequent Input Feed Traps page, select or deselect the desired traps and press Apply.

For Load traps, enter a maximum load value for the infeed in the High Load Threshold field and press Apply.
The High Load Threshold value may be 0 to 255 (in amperes).

Configuring outlet traps:

Click on the Outlet Traps link.

On the subsequent Outlet Traps page, select or deselect the desired traps and press Apply.

LDAP

The LDAP configuration page is used for setup and maintenance of all settings required to enable
LDAP support. For additional information and configuration requirements, see LDAP on page54.

Enabling or disabling LDAP support:

Select Enabled or Disabled from the LDAP drop-down menu and press Apply.

Setting the LDAP server IP address:

Enter the IP address in the Host IP1 and/or Host IP2 address field and press Apply.

Changing the LDAP server port:

Enter the port number in the LDAP Port field and press Apply.

Setting the LDAP bind password type:

Select Simple or MD5 from the drop-down menu and press Apply.

For more information on LDAP bind password types, see Setting the LDAP bind password type
on page 55.

Setting the search bind Distinguished Name (DN):

Enter the fully-qualified distinguished name (FQDN) in the Search Bind field and press Apply.

Setting the search bind password for Distinguished Name (DN):

Enter the Search Bind Password in the Search Bind Password field and press Apply.

Setting the group membership attribute:

Enter the group membership attribute in the Group Membership Attribute Field and press Apply.

Setting the group membership value type:

Select the appropriate value from the drop-down menu and press Apply.

Setting the user search base Distinguished Name (DN):

Enter the User Search Base DN in the User Search Base DN field and press Apply.

Setting the user search filter:

Enter the User Search Filter in the User Search Filter field and press Apply.

Setting the DNS IP address:

See Creating a descriptive Environmental Monitor name:

Click on the Environmental Monitor Names link.

On the subsequent Environmental Monitor Names page, enter a descriptive name and press Apply.

Creating descriptive sensor names:

Click on the Sensor Names link.

On the subsequent Sensor Names page, enter a descriptive name and press Apply.

Network on page 13 for information on how to set the DNS IP address.

Sentry PT22 Operations • 19
Installation and Operations Manual

Configuring the authentication order:

Select Remote -> Local or Remote Only from the drop-down menu and press Apply.

For more information on remote authentication order, see Setting the authentication order on page 57.

NOTE: Server Technology recommends NOT setting the authentication order to Remote Only until the LDAP has been
fully configured and tested.

Configuring LDAP groups:

Click on the LDAP Groups link at the bottom of the page.

Creating an LDAP group:

Enter a descriptive group name in the LDAP Group Name field. Up to 24 alphanumeric and other
typeable character (ASCII 33 to 126 decimal, spaces are not allowed) are allowed. Press Apply.

Removing an LDAP group:

Click on the Remove link in the Action column for the group to be removed and press OK on the
subsequent confirmation window.

Changing an LDAP group’s access privilege level:

Click on the Edit link in the Action column for the associated LDAP Group.

On the subsequent LDAP Group - Edit page, select Admin, User, On-only or View-only from the
Access Level drop-down menu and press Apply.

For more information on access privilege levels, see Changing a user’s access privilege level:
on page 17.

Granting or removing Environmental Monitoring viewing privileges:

Click on the Edit link in the Action column for the associated LDAP Group.

On the subsequent LDAP Group - Edit page, select Yes or No from the Environmental Monitoring
drop-down menu and press Apply.

Adding and Deleting outlet access:

Click on the Outlets link in the Access column for the associated LDAP Group.

On the subsequent LDAP Group - Outlets page, select or deselect outlets to be accessed by the LDAP
Group and press Apply.

Adding and Deleting outlet group access:

Click on the Groups link in the Access column for the associated LDAP Group.

On the subsequent LDAP Group - Groups page, select or deselect outlet groups to be accessed by the
LDAP Group and press Apply.

Adding and Deleting serial port access:

Click on the Ports link in the Access column for the associated LDAP Group.

On the subsequent LDAP Group - Ports page, select or deselect ports to be accessed by the LDAP Group
and press Apply.

TACACS+

The TACACS+ configuration page is used for setup and maintenance of all settings required to enable
TACACS+ support. For additional information and configuration requirements, see TACACS+ on page 63.

Enabling or disabling TACACS+ support:

Select Enabled or Disabled from the TACACS+ drop-down menu and press Apply.

Setting the TACACS+ server IP address:

Enter the IP address in the Host IP1 and/or Host IP2 address field and press Apply.

Setting the TACACS+ encryption key:

Enter a key and verify the new key the Encryption Key and Verify Encryption Key fields. Press Apply.

For security, key characters are not displayed.

20 • Operations Sentry PT22
Installation and Operations Manual

Configuring the authentication order:

Select Remote -> Local or Remote Only from the drop-down menu and press Apply.

For more information on remote authentication order, see Setting the authentication order on page 64.

NOTE: Server Technology recommends NOT setting the authentication order to Remote Only until the LDAP has been
fully configured and tested.

Configuring TACACS+ privilege levels:

Click on the TACACS+ Privilege Levels link at the bottom of the page.

Changing an TACACS+ Privilege Level’s access privilege level:

Click on the Edit link in the Action column for the associated TACACS+ Privilege Level.

On the subsequent TACACS+ Privilege Level - Edit page, select Admin, User, On-only or View-only
from the Access Level drop-down menu and press Apply.

For more information on access levels, see Changing a user’s access privilege level: on page 17.

Granting or removing Environmental Monitoring viewing privileges:

Click on the Edit link in the Action column for the associated TACACS+ privilege level.

On the subsequent TACACS+ Privilege Level - Edit page, select Yes or No from the Environmental
Monitoring drop-down menu and press Apply.

Adding and Deleting outlet access:

Click on the Outlets link in the Access column for the associated TACACS+ Privilege Level.

On the subsequent LDAP Group - Outlets page, select or deselect outlets to be accessed by the TACACS+
Privilege Level and press Apply.

Adding and Deleting outlet group access:

Click on the Groups link in the Access column for the associated TACACS+ Privilege Level.

On the subsequent LDAP Group - Groups page, select or deselect outlet groups to be accessed by the
TACACS+ Privilege Level and press Apply.

Adding and Deleting serial port access:

Click on the Ports link in the Access column for the associated TACACS+ Privilege Level.

On the subsequent LDAP Group - Ports page, select or deselect ports to be accessed by the TACACS+
Privilege Level and press Apply.

Tools

The Tools section contains access to rebooting the unit, uploading new firmware as well as resetting the unit to
factory defaults. This section is available to administrative level users only.

Restart

Performing a warm boot:

Select the Restart from the Action drop-down menu and press Apply.

Note: System user/outlet/group configuration or outlet states are NOT changed or reset with this command.

Resetting to factory defaults:

See Chapter 5: for more information on resetting a Sentry to factory defaults from the HTML interface.

Uploading new firmware:

See Appendix B: for more information on uploading new firmware from the HTML interface.

Ping

The Ping feature may be used to test the Sentry’s ability to contact another Ethernet enabled device’s IP
address. For LDAP support, it may also be used to test the configuration of the Domain Name server
IP address by testing for proper name resolution.

Sentry PT22 Operations • 21
Installation and Operations Manual

Command Line Interface

Logging In

Logging in through Telnet requires directing the Telnet client to the configured IP address of the unit.

Logging in through the Console (RS232) port requires the use of a terminal or terminal emulation
software configured to support ANSI or VT100 and a supported data rate (300, 1200, 2400, 4800, 9600,
19200, 38400, 57600, or 115200 BPS) - 8 data bits-no parity-one stop bit and Device Ready output
signal (DTR or DSR).

To log in by RS-232 or Telnet:

1. Press Enter. The following appears, where x.xx is the firmware version:

Sentry Version x.xx
Username:

NOTE: Logging in by Telnet will automatically open a session. It is not necessary to press Enter.

2. At the Username: and Password: prompts, enter a valid username and password. And press Enter.

You are given three attempts to enter a valid username and password combination. If all three fail,
the session ends.

NOTE: The default Sentry username/password is admn/admn.

When you enter a valid username and password, the command prompt (Sentry:) appears. If a location
identifier was defined, it will be displayed before the Sentry: prompt. See Creating a location

description on page 37 for more information.

Commands may be entered in any combination of uppercase and lowercase. All command characters must
be entered correctly; there are no command abbreviations. A user must have administrative privileges to
use the administration commands. The following tables list and briefly describe each command.

Operations Command Summary

Command Description

On Turns one or more outlets on

Off Turns one or more outlets off

Reboot Reboots one or more outlets

Status Displays the on/off status of one or more outlets

ILoad Displays the total cumulative input load

Istat Displays the status of the infeeds

Connect Connects to a serial port

Envmon Displays the status of the integrated Environmental Monitor

Login Ends the current session and brings up the Username: prompt

Logout Ends a session

Quit Ends a session

List Outlets Lists all accessible outlets for the current user

List Ports Lists all accessible serial ports for the current user

List Group Lists all assigned outlets for a group name

List Groups Lists all accessible groups for the current user

Administrative Command Summary

Add Grouptouser Grants a user access to one or more groups

Add Outlettogroup Adds an outlet to a group name

Add Outlettouser Grants a user access to one or all outlets

Add Porttouser Grants a user access to one or all serial ports

Create Group Adds a group name

Create User Adds a user account

Delete Groupfromuser Removes access to one or more groups for a user

Delete Outletfromgroup Deletes an outlet from a group name

Delete Outletfromuser Removes access to one or all outlets for a user

22 • Operations Sentry PT22
Installation and Operations Manual

Administrative Command Summary (continued)

Delete Portfromuser Removes access to one or all serial ports

List User Displays all accessible outlets/groups/ports for a user

List Users Displays privilege levels for all users

Remove Group Deletes a group name

Remove User Deletes a user account

Restart Performs a warm boot

Set DNS Sets the IP address of the Domain Name server

Set FTP Filename Specifies the file to be uploaded via FTP

Set FTP Filepath Specifies the filepath for the file to be uploaded

Set FTP Host Sets the FTP Host IP address

Set FTP Password Sets the password for the FTP Host

Set FTP Username Sets the username for the FTP Host

Set Gateway Sets the Gateway

Set HTTP Enables or disables HTTP access

Set HTTP Port Specifies the target port for HTTP access

Set HTTP Security Specifies the HTTP server authentication method

Set Infeed Name Specifies a descriptive field for the infeed

Set Ipaddress Sets the IP address

Set Location Specifies a descriptive field for the HTML control screen and login banner

Set Modem Inits Enables or disables Modem port initialization strings

Set Modem Specifies Modem port initialization strings

Set Outlet Name Specifies a descriptive field for a device attached to an outlet

Set Outlet PostOnDelay Sets the Post-On delay for an outlet

Set Outlet RebootDelay Sets the reboot delay for all outlets

Set Outlet SeqInterval Sets the sequencing interval for all outlets

Set Outlet Wakeup Sets the wakeup state for an outlet

Set Subnet Mask Sets the Subnet Mask

Set Telnet Port Sets the Telnet server port number

Set Telnet Enables or disables Telnet access

Set Tower Name Specifies a descriptive field for the Sentry

Set User Access Sets the access level for a user

Set User Envmon Grants or removes privileges to view input and environmental monitoring status

Set User Password Changes the password for a user

Set Port Name Specifies a descriptive field for a serial port

Set Port Dsrchk Sets the DSR active signal checking for a serial port

Set Port Speed Set the connection speed for all serial ports

Set Port Timeout Sets the inactivity timer for Pass-Thru sessions

Show FTP Displays FTP configuration information

Show Infeeds Displays infeed configuration information

Show Network Display network configuration information

Show Outlets Displays configuration information for all outlets

Show Ports Displays serial port configuration information

Show System Displays system configuration information

Show Towers Displays tower configuration information

Version Displays the Sentry firmware version

To display the names of commands that you may execute:

At the command prompt, press Enter. A list of valid commands for the current user appears.

Sentry PT22 Operations • 23
Installation and Operations Manual
