IS-IP4K-DN
User Manual
Ver 1.0
©Sentry360 2014
Table of Contents
1. Overview ............................................................................................................................ 3
1.1 Features ...................................................................................................................... 3
1.2 Package Contents........................................................................................................ 3
1.3 Dimensions .................................................................................................................. 4
1.4 Connectors .................................................................................................................. 5
2. System Requirements ...................................................................................................... 6
3. Access Camera ................................................................................................................. 7
3.1 Web Browser Configuration ......................................................................................... 9
1. Overview
The IS-IP4K-DN camera is an MJPEG or H.264 encoding, 4K resolution, IP-addressable, fixed
camera. It is designed to deliver full motion high definition progressive scan digital video across
local area networks. The IS-IP4K-DN features a design with no moving parts, c reating a highresolution fixed image. The IS-IP4K-DN comes equipped with a CS mount that accommodates
a wide variety of fixed lenses for different applications; C mount lenses can also be used with a
C/CS adapter. This dual codec camera enables users to simultaneously output multiple video
streams at resolutions up to 12.6 megapixels which provide clear digital zoom capability for
proactive forensic detail. The IS-IP4K-DN is equipped with a mechanical IR cut filter that filters
infrared light to display high quality video images in low light environments.
1.1 Features
• 12.6 Megapixel CMOS sensor
• Maximum Resolution: 4096 x 3072
• Maximum Framerate: 10 fps
• IR Cut Filter
• Full Onvif Compatibility
• Motion Detection
• PoE 802.3af
• 0.1 lux (color) at F/1.2
• 100/10 LAN Connection
• Protocols: UDP, TCP, HTTP, TFTP, RTSP
• Automatic Exposure
• Automatic White Balance
• Brightness, Contrast, Saturation Controls
1.2 Package Contents
Please check the package contains the following items listed below.
• Camera
• Quick Start Guide
1.3 Dimensions
The IS-IP4K-DN camera and lens dim ensions are shown below.
1.4 Connectors
Designation
Description
1
DC Power
12V DC Power Connector
2
LAN Port
PoE and Ethernet Port
The diagram below shows the IS-IP4K-DN connections.
2. System Requirements
Items
System Requirement
Web Browser
Microsoft Internet Explorer
To connect to the IS-IP4K-DN via web browser, pleas e ensur e your PC has a good network
connection, and meets system requirements as des cr ibed below.
Mozilla Firefox
Google Chrome
Apple Safari
3. Access Camera
Step 1. Power your camera using the correct power source (PoE switch, PoE injector, or
12V adapter).
Step 2. Download, install, and run sentryView™, Sentry360’s camera configuration tool,
here: http://sentry360.com/product/sentryview/
Step 3. Click the Scan button in sentryView™ to scan your network for connected cameras.
Step 4. To automatically configure your camera network settings, check the boxes of the
cameras you want to configure. Then click Auto Configure.
Step 5. Confirm your network settings and click Configure.
Step 6. To manually configure your cameras, click Edit Camera Values at the bottom right,
enter your IP Address, Subnet Mask, Gateway, and DHCP settings. Click Apply to
save these values.
Step 7. Your cameras are now configured. If you are using sentryCore™ as your Video
Management System, please download the latest version here:
http://sentry360.com/product/sentrycore/
Step 8. Right click on a camera and select Browse. The prompt for entering the default
username and password will appear for logging in to the FS-IP5000-M.
3.1 Web Browser Configuration
Camera configuration is accessed through the web browser interface by clicking the Show
Settings button.
When configuration is complete, click the System Tab -> Save to commit settings to permanent
memory.
