Cordless phone

Congratulations on your selection of the 36587 from
American Telecom Services. This expandable 2.4GHz
cordless telephone with Caller ID and Call Waiting has been
designed to give you many years of continuous service and
represents the best value for your money. It requires little
maintenance and is easy to setup and operate. This phone
includes American Telecom’s patent-pending green LDS
button, giving you optional access to some of the lowest long
distance rates available.

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

IMPORTANT SERVICE INFORMATION

Read this manual before attempting to setup or use this instrument. It contains
important information regarding safe installation and use. Keep this manual for
future reference. Also save the carton, packaging and proof of purchase to
simplify and accelerate any needed action.

WARNING

To prevent fire or shock haz ar d, do not e x pose this product to rain or any type of
excess moisture. If it is accidentally dropped into water, the AC adapter should
immediately be unplugged from the wall along with the telephone line cord.

THIS SYMBOL IS INTENDED TO ALERT THE USER OF
THE PRESENCE OF IMPORTANT OPERATING AND
MAINTENANCE (SERVICING) INSTRUCTIONS IN THE
OWNER'S MANUAL.

• 36587 Base and Handset

• Rechargeable Ni-Cd Batt ery P ack

• Telephone Line Cord

• AC Adaptor

• User’s Manual (English and Spanish)

• Warranty Card

• Pay N’ Talk Quick Start and Service Guides

• My Account Card (English and Spanish)

• Privacy Statement

080106B-1 1

36587

CARTON CONTENTS

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

The contents of this p ackage, and the function s of you r particular unit , may
vary slightly from the features explained in this manual.

SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY

INSTRUCTIONS

When using your telephone equipment, basic safety precautions should always
be followed to reduce the risk of fire, electric shock, and injury to persons,
including the following:

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this product near water, for example, near a bathtub, wash
bowl, kitchen sink, or laundry tub, in a wet basement or near a swimming
pool.

5. Do not place this product on an unstable cart, stand, or table. The product
may fall, causing serious damage to the product.

6. Slots and openings in the cabinet and the back or bottom are provided for
ventilati on, to protec t it from overheat ing. These openings should never be
blocked or covered. The openings should never be blocked by placing the
product on the bed, sofa, rug, or other similar surface. This product should
never be placed near or over a radiator or heat register. This product
should not be placed in a built-in installation unless proper ventilation is
provided.

7. This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your dealer or local power company.

8. Do not allow anything to rest on the power cord. Do not locate this
product where the cord will be abused by persons walking on it.

9. Do not overload wall outlets and extension cords as this can result in the

080106B-1 2

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

risk of fire or electric shock.

10. Never push objects of any kind into this product through cabinet slots as
they may touch dangerous voltage points or short out parts that could
result in a risk of fi re or electric sh ock. Never spill liq uid of any kind on
the product.

11. To reduce the risk of electric shock, do not disassemble this product, but
take it to a qualified service contractor when some service or repair work
is required. Opening or removing covers ma y expose you to dan gerous
voltages or other risks. Incorrect reassembly can cause electric shock
when the appliance is subsequently used.

12. Unplug this produ ct from the wall outlet and refer servicin g to qualified
service personnel under the following conditions:

A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the prod uct d oes n ot opera te nor mally b y follo wing t he op erati ng

instructions. Adjust only those controls that are covered by the
operating inst ructions. Improper a djustments of oth er controls may
result in damage and will often require extensive work by a

qualified technician to restore the product to normal operation.
E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinctive change in performance.

13. Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.

14. Do not use the telephone to report a gas leak in the vicinity of the leak.

INSTALLATION

PRECAUTIONS

1. Never install telephone wiring during a lightning storm.

2. Never install telephone jacks in wet locations unless the jack is
specifically designed for wet locations.

3. Never touch uninsulated telephone wires or terminals unless the telephone
line has been disconnected at the network interface.

4. Use caution when installing or modifying telephone lines.

080106B-1 3

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

MAINTENANCE

1. Use a damp cloth to clean the plastic cabinet. A mild soap will help to
remove grease or oil. Never use p olish, solvents, abrasives or s trong
detergents since these can damage the finish.

2. Your phone should be situated away from heat sources such as radiators,
heaters, stoves or any other appliance that produces heat.

CAUTION

There is the risk of explosion if the battery is replaced by an incorrect type.
Dispose of used ba tteries according to the inst ruction. Read and follow these
instructions:

1. Use only the 3.6V, 450mAh, Ni-Cd battery pack .

2. Do not dispose of t he battery i n a fire. Th e cell may expl ode. Ch eck with
local codes for possible special disposal instructions.

3. Do not open or mutilat e the battery. Released elect rolyte is c orrosive and

may cause damage to the eyes or skin. It may be toxic if swallowed.

4. Exercise care in handling the battery in order not to short the battery with
conducting material such as rings, bracelets and keys. The battery or
conductor may overheat and cause burns.

5. Recharge only the battery provided with or identified for use with this
product. The ba ttery may leak c orrosive electrol yte or explode i f it is not
the correct type.

6. Do not attempt to rejuvenate the battery provided with or identified for use
with this product by heating them. Sudden release of the battery
electrolyte may occur causing burns or irritation to eyes or ski n.

7. When inserting the battery into this product, the proper polarity or
direction must be observed. Reverse insertion of batteries can cause
charging that may result in leakage or explosion.

8. Do not store thi s produ ct, or th e ba tter y pr ovid ed wit h or i dent i fied for u se
with this produc t, in high-temp erature areas . Batteries t hat are stored in a
freezer or ref rigerator for the purpose of extendin g shelf life should be
stabilized at room temperature prior to use after cold storage.

080106B-1 4

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

9. Disconnect telephone lines before installing batteries

SAVE THESE INSTRUCTIONS
FCC NOTICE

The FCC requires that you be advised of certain requirements involving the use
of this telephone.

1. This telephone is hearing aid compatible.

2. This equipment complies with 47 CFR Part 68 requirement. On the
bottom of this equipment is a label that contains, among other information,
the ACTA registrat i on num b er and Rin ger E qu i va lenc e Nu mb er (RE N) for
this equipment. If requested, provide this information to your telephone
company.

3. The REN is useful to determine the quantity of devices you may connect
to your telephone line and still have all of those devices ring when your
number is called . In most, but not all areas , the sum of the RENs of all
devices should not exceed five (5.0). To be certain of the number of
devices you may connect to your line, as determined by the REN, you
should call your local telephone company to determine the maximum
REN for your calling area.

4. If your telephone causes harm to the telephone network, the telephone
company may discontinue your service temporarily. If possible, they will
notify you in advance. But if advance notice is not practical, you will be
notified as soon as pos sible. You will be advised of your right to file a
complaint with the FCC.

5. Your telephone company may make changes to its facilities, equipment,

operations or procedures that could affect the proper operation of your
equipment. If they do, you will be given advance notice so as to give you
an opportunity to maintain uninterrupted service.

6. This equipment may not be used on coin service provided by the
telephone company. Connection to party lines is subject to state tariffs.
(Contact your state public utility commission or corporation commission
for information.).

7. USOC jack type is RJ11C and the compatible jack is part 68 compliance.

NOTICE: If your home has specially wired alarm equipment connected to the

080106B-1 5

N

f

y

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

telephone lin e, ensure the installati on of this [equipment ID] does not disab le
your alarm equipment. If you have questions about what will disable alarm
equipment, consult your telephone company or a qualified installer.

This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and, (2) this device must accept any interference received,
including interference that may cause desired operation. Privacy of
communications may not be ensured when using this phone.

Changes or modifications not expressly approved in writing by

orthwestern Bell P hones may void the user's authority to operate this

equipment.

Some cordless p hones oper ate at frequ encies th at may cau se interfer ence to
nearby TVs and VCRs; to minimize or prevent such interference, the base o
the cordless phone should not be placed near or on top of a TV or VCR; and,
if interference is experienced, moving the cordless telephone farther awa
from the TV or VCR will often reduce or eliminate the interference.

AC ADAPTOR: Use only with Class 2 Transformer,

9VDC output , 200mA, center pin
positive.

080106B-1 6

N

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

36587 CONTROLS DIAGRAM

EW
CALL/MSG
WTG
LED Indicator

TALK Button

UP Button

TONE(*)Button

EDIT/MUTE
Button

FLASH Button

SELECT
/TRANSFER
Button

RE/PA Button

DC 9V Jack LINE Jack

080106B-1 7

LCD Display

IN USE/CHARGE
LED Indicator

PAGE Button

DOWN Button

# Button

MENU/SCAN
Button

LDS Button

Base Unit
(Rear View)

DC 9V
200mA

LINE

2.4

Cordless phone

GHz

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

DESCRIPTIONS

Handset Controls:
LCD Display - Shows call in formation, ph one status, prom pts and Phonebook

items.

IN USE/ MSG WTG/ NEW CALL Indicator – Lights solid whenever the
handset is in TALK mode. Turns off when the handset is not in use and out of
the base unit. Red LED blinks when you have call(s) and new message(s).

TALK Button - Press this button to place a call, answer a call, or end a call.

TONE * Button - In programming mode & tone dialing mode, this key is used

as a normal number key. In pulse dialing mode, it is used to initiate temporary
DTMF dialing.

# Button - During you view the caller list, press to place a long distance call or
to place a local call. Allows you to change the format of displayed number.

FLASH Button - Momentarily hangs up the phone to access custom calling
features such as Call waiting or Three-way calling provided by you local phone
company.

UP/DOWN Button -Allows you to adjust the handset volume (3 steps) in
TALK mode. (DOWN) It also allows you to view the caller list. (UP) It also
allows you to view the directory.

Microphone - Used for speaki ng with callers.

Re(Redial)/Pa(P ause) Button – (Redial) Press to redial the last number you

dialed. (Pause)Press to insert pause while dialing.

EXIT/MUTE –This key is used to exit all models of operation and return the
handset and base unit to the standby mode. In talk mode, this button allows you

080106B-1 8

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

to temporarily disable the handset microphone. The LCD Display will show
“MUTE”.

LDS Button - Press to enter Long Distance Service.

SELECT/TRANSFER Button – Allow you to save the changes for the listed

items. In talk mode, this button allows you to transfer a call to another
registered h andset.
Note: During a call, when the user want to transfer a call to another registered
handset. The user must press the SELECT/TRANSFER button and then press
the telephone keypad (1,2,3,4). The call is quick transferred to the destination
handset, the destination handset starts ringing and shows “FORWARDED
CALL”. If destination handset user does not answer the call with 30 sec, source
handset will be ring back for 30 sec.

MENU/SCAN – While in standby mode, this button allows you to set the
handset in Programming mode. While in Talk mode, it is used to manually
select one of t h e 30 op era t ing ch ann els when you exp eri en ce i nt erfer en c e on th e
handset.

Receiver – Allows you to hear calls .

BASE UNIT CONTROLS:

Base Antenna - A fixed antenna.

Base Unit Charge Terminals - Used for charging handset batteries. We

recommend that you clean these contacts periodically with an
alcohol-moistened cloth or cotton swab.

IN USE/CHARGE LED Indicator - Lights up steadily when the phone is in
talk mode and turns off when the handset is not in use. It will flash when paging
the handset . It ligh ts up steadi ly when t he hand set is being charged on the bas e
and it turns off when the handset is removed from its cradle.

080106B-1 9

N

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

PAGE Bu tton - Allows you to locat e the handset when it is not on th e base, or
to alert the person near to the handset.

DC 9V jack - A jack located on the rear side of the base unit used for
connecting the AC adaptor to the base unit.

TEL LINE jack – Accepts the line cord for connection to the telephone outlet.

INSTALLATION

CAUTION: USE ONLY THE NICKEL CADMIUM (Ni-Cd)

BATTERY TYPE INCLUDED WITH THIS UNIT. USE OF OTHER
BATTERY TYPES MAY CAUSE INJURIES O R DAMAGE.

1. Remove the battery com partm ent cover of the ha ndset by p ressin g the top
of the cover and sliding it down.

2. Connect the Ni-Cd battery pack plug along the slot into the handset’s
battery connector as shown below.

i-Cd Battery

Pack

Red
wire

(Figure 1)

3. Insert the Ni-Cd battery into the battery compartment.

4. Replace the battery compartment cover by sliding it up towards the
handset.

NOTE: Use the type and size of Ni-Cd battery pack, 3.6V, 450mAh. It is
recommended that the Ni-Cd battery pack should be fully charged overnight
prior to initial use.

Black
Wire

Battery
Connector

080106B-1 10

U

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

Belt Clip Installation
With the back of the handset facing up, insert one side of the belt clip hook into
the matching slots at the top side of the handset as shown in Figure2. Slide the
other hook until it locks into place from the opposite side of the handset.

Belt clip hook

(Figure 2)

POWER CONNECTION

CAUTION: You must use a Class II, 120 Volt AC/9 Volt DC adaptor

that delivers at least 200mA for base unit. The center t ip must be positive a nd
the plug must correctly fit the base unit’s DC 9V 200mA jack.

1. Plug the AC adaptor into a standard AC outlet.

2. Insert the small plug into the DC 9V 200mA jack on the rear of the base

unit as shown in Figure 3.

Base

nit

DC 9V

DC 9V Jack
AC Adaptor

Plug

200mA

AC Outlet

LINE

AC Adaptor

(Figure 3)

080106B-1 11

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

INITIAL SETUP

Please follow these steps before using the cordless telephone for the first ti m e.

1. Ensure that the handset battery pack is installed and charged fully for at
least 14 hours.

2. Ensure that all connections(line cord and adapter cord) are properly
inserted into the rear of the base unit.

TELEPHONE OPERATION

To Place a Long Distance Call
LDS (Long Distance Service) Button
Access Pay N’ Talk Prepaid long distance service from every handset

To access the LDS service:

1. Pick up the handset and press the green LDS access key.

2. The phone automatica lly goes off-hook and you are connected to th e Pay
N” Talk Long Distance platform.

3. Dial the long distance number that you wish to call as follows:

For U.S. domestic (regional and national), dial 1+(area code)+(phone number)
For international calls, dial 011+(country code)+(city code)+(phone number)

When finished with your call, press the TALK button or place the handset on
the base unit.

PLACE A CALL

1. Pick up the handset and press the TALK button. The LCD Display will
show “PHONE ON”. The base unit IN USE LED indicator will light up.

2. Listen for a dial tone.

3. Dial the telephone number. The phone numbers appear on the LCD
Display as you enter the number.

4. When finished with your call, press the TALK button or place the handset
on the base unit. The base IN USE LED indicator will turn off.

080106B-1 12

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

RECEIVE A CALL
NOTE: If you are expectin g incoming calls, the hand set must be programmed

to the RING 1, 2, 3, 4 mode.

If the handset is on the base

:

1. When the phone rings, simply pick up the handset from the base cradle.

2. Start your conversation.

3. To end your conversation, either press the TALK button or place the
handset on the base unit. The base IN USE LED indicator will turn off.

If the handset is out of the base:

1. When the phone rings, press the TALK button on the handset. The LCD
Display will show “ PHONE ON” , the base unit IN USE LED Indicator
and handset IN USE LED Indicator will light up.

2. Start your conversation.

3. To end your conversation, press the TALK button , the base IN USE LED
Indicator and handset IN USE LED Indicator will turn off.

LAST NUMBER REDIAL

A. AFTER HEARING A BUSY TONE WHEN PLACING A CALL

1. If you get a busy tone, press the handset TALK button to hang up.

2. Press the handset TALK button again and listen for a dial tone.

3. Press the handset RE/PA button. This will automatically redial the last
telephone number you called (up to 32 digits).

4. When finished with your call, press the TALK button or place the handset
on the base unit. The base IN USE LED indicator will turn off.

B. WHEN THE HANDSET IS OFF THE BASE UNIT AND IN STANDBY

MODE

1. Press the TALK button on the handset and listen for a dial tone.

2. Press the RE/PA button. This will automatically redial the last telephone
number that you called (up to 32 digits).

3. When finished with your call, press the TALK button or place the handset
on the base unit. The base IN USE LED indicator will turn off.

080106B-1 13

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

SAVING IN THE PHONEBOOK

1. Press the MENU/SCAN button.

2. Press the SELECT/TRANSFER button.

3. Use the TELEPHONE KEYPAD button (0-9) to enter the name, (see the
“TELEP HONE KE YPAD CHARACT ERS SET TING” s ectio n ) you c an
store up to 15 characters.

4. Press the SELECT/TRANSFER button once.

5. Enter the telephone number using the TELEPHONE KEYPAD button
(0-9). You can store up to 24 digits.

6. Press the SELECT/TRANSFER button to save into memory, and then will
automatically go back to standby mode.

NOTE: If th ere are no memory locat ions left in the ph onebook, the unit will
display “ MEMORY FULL”. To continue with memory programming, you must
delete or edit existing speed dial numbers. If no active buttons are pressed for
20 seconds , the LCD Display will au tomatically return to STANDBY mode.

TELEPHONE KEYPAD CHARACTERS

The TELEPHONE KEYP AD buttons (0-9) a re used to enter the c haract ers
when entering names. Press the appropriate KEYPAD button to get the
following characters.

KEYPAD BUTTON CHARACTERS

1 1
2 A B C 2
3 D E F 3
4 G H I 4
5 J K L 5
6 M N O 6
7 P Q R S 7
8 T U V 8
9 W X Y Z 9
0 0
* *
# &

,

, - . #

080106B-1 14

A

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

For example, if you want to enter the character “C” , press the “2” KEYPAD
button. The first character displayed will be “A”. Press the “2” button again to
display “B”, and press the “2” button again to display the letter “C”.

VIEWING THE PHONEBOOK

This Phonebook lets you scroll through the list to find the person you need for
one touch dialing. You can store up to 20 names and telephone numbers in the
Memory.

1. Press the UP button.

2. Press the UP or DOWN button to find the one you need.

ALEX BROWIN

6045551212

NOTE: To exit the Phonebook at anytime, Press the E X IT/M U TE button .

EDITING NAME AND NUMBER IN THE PHONEBOOK

1. Press the UP button.

2. Press the UP or DOWN button to find the one you want to edit.

3. Press the SELECT/TRANSFER button, the LCD will show “QUICK
EDIT ERASE” and then press the UP or DOWN to select “ EDIT ”.
Press the SELECT/TRANSFER button to confirm a selection.

4. Press the TELEPHONE KEYPAD button to edit the name.

ALEX BROWIN

6045551212

5. Press the UP or DOWN button to move to the letter or number you want to
change.
To erase, press the DOWN B utton t o remove p revious letter, pres s the U P

LEX BROWIN

6045551212

cursor is blinking

080106B-1 15

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

button a second time will produce a space
To add, use the TELEPHONE KEYPAD buttons(0-9).

6. Press the

7. Press the DOWN button to move the cursor to the number you want to

8. Press the SELECT/TRANSFER button to confirm.

NOTE: When no active buttons are pressed for 20 seconds, the LCD Display
will automati cally return to STANDBY mode.

PLACING CALLS FROM THE PHONEBOOK

1. Press the UP button.

2. Press the UP or DOWN button to find the contact you want to call.

3. Press the TALK button to dial out the telephone number.

4. Start your conversation.

5. To end your conversation, either press the TALK button or place the

NOTE: Be sure to check that the line is not in use by another extension.

DELETING A STORED NUMBER

1. Press the UP button.

2. Press the UP or DOWN button to find the one you want to delete.

3. Press the SELECT/TRANSFER button. The LCD Display will show

4. Press the UP or DOWN button to select “ERASE”, and then press the

SELECT/TRANSFER button to edit the number.

change.
To erase, press the DOWN button to remove previous number.
To add, use the TELEPHONE KEYPAD buttons(0-9).

ALEX BROWIN

6045551212

handset on the base unit.

“QUICK EDIT ERASE”.

SELECT/TRANSFER button. The LCD will show “ ERASE NO
YES”.

cursor is blinking

080106B-1 16

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

5. Press the UP or DOWN button to select “ YES” and then press the
SELECT/TRANSFER button to confirm a deletion.

6. Press the EXIT/MUTE button to return to STANDBY mode.

MIXED MODE DIALING (Temporary Pulse to Tone Dialing)

1. If you only have pulse (rotary dialing) service in your area and want to
access Tone services (Bank by Phone , etc.), ensure that the unit is set to
the Pulse position.

2. Press the TONE (*) button once to switch from Pulse to Tone dialing
temporarily. Pulse dialing mode resumes when the call is ended.

PAUSE FUNCTION

• In some cases, such as PABX or long distance service, a pause may be
needed in th e dialin g sequen ce. Press ing th e handset RE/PA button inserts
the programmed time interval between dialed numbers.

FLASH FUNCTION

• Used to access custom calling features such as Call Waiting or Three-Wa y
Calling provided by your local phone company. Flash can also be used to
restore a dial tone to make a new call.

CHANNEL SELECTION(30 Channels)

• Your cordless telephone lets you select a channel from the 30 frequencies
available to transmit signals between the base unit and handset. If the
existing channel becomes noisy or starts having interference, you can
either move closer t o the base unit or press the ME NU/SCAN button on
the handset until a better reception is found.

LOW BATTERY WARNING

• When the hand set battery voltage l evel is low, the handset LCD Di splay
shows symbol “
LOW” at the top left corner of handset and a beep sounds.

• Return the handset on the base cradle to charge.

” at the lower le ft c orner of ha ndset and “B ATTERY

080106B-1 17

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

PAGING FUNCTION

• If you have misplaced the handset or need to alert person nearly the
handset, press the PAGE button on the base unit. Each press of this button
will activate the handset to beep for 60 seconds and LCD Display shows
“PAGING” and the base IN USE LED Indicator and the handset IN USE
LED Indicator will start to blink. Press again to stop.

NOTE: Even if the handset is in RING OFF mode, the base unit can page the
handset.

CALLER ID OPERATION

GETTING TO KNOW YOUR NEW PHONE
IMPORTANT: Subscription t o Caller ID (CID)/C all Waiting ID services from

your local phone company is required for using the Caller ID/Call Waiting ID
features of the 36587. Your new 36587 telephone gives you the
ultimate in c ordless telephone sound qu ality with the luxury of Ca ller ID and
Call Waiting ID.
If this is your first cordless telephone, you will soon discover that your cordless
is similar to regula r telephones, except wit hout the cord. If you have own ed a
cordless in the past, you will discover that the 36587 telephone is the most
powerful and full-functioned Call Waiting ID cordless telephone on the market,
some key features are:

• 50 name and number Caller ID/Call Waiting ID memory (Call List)

• 20 name and number programmable memory (Phonebook)

• Hearing – aid compatibility

• Automatic or manual selection of the clearest of 30 channels

Unlike regular telephones, your cordless telephone does not work during power
failures. We do not recommend that you use a cordless telephone as the only
phone in your residence.

INTRODUCTION TO CALLER ID AND CALL WAITING ID

The 36587 Caller ID/Calling Waiting ID devices allow you to take
advantage of the Caller identification delivery service offered by your local
telephone company. For more information, you can refer to the following

080106B-1 18

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

Question and Answer ta ble:

QUESTIONS ANSWERS

What is Caller ID? Caller ID is a device that identifies the calling

party before you answer a call. This device can be
used to screen unwanted calls and eliminate
harassment from annoying calls.

What is Caller
Waiting ID?
How does Caller ID
and Call Waiting ID
work?

Who provides Caller
ID service?

How can I activa te my
Caller ID?

RECEIVING NEW CALL

• When you receive a new call, the call information is stored under
CALLER ID List. The “NEW NUMBER” segment of LCD Display if
there is new c all(s).

• When you receive a call, the system displays the caller information sent by
the telephone company, called a Call Record. The Call Record consists of
the following information:

Call Waiting ID is a device that can also identifies
the call waiting party before you answer a call.
When used with Caller ID/Call Waiting service,
the Caller ID/Call Waiting ID device displays the
name(if available), and the telephone number (if
available) of the person calling before you answer
your telephone.
Your local telephone company. However, not all
local telephone companies provide Caller ID
service. Please call you local phone company to
confirm that the service is available before you
install the device.
For you Caller ID unit to function, you must first
arrange with your local telephone company to
have Caller ID/Call Waiting ID service installed on
you line. There is an extra charge added to your
monthly telephone bill for this service. Before
using this unit, please read this instruction manual
carefully.

080106B-1 19

A

N

d

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

a. The caller’s name(if available)
b. The caller’s telephone number
c. The date and time of the call

JOHN SMITH

555-

555-1212

AM

• If there is no call records, the LCD display shows “CID EMPTY” by
pressed the DOWN button..

VIEWING THE CALLER ID LIST

1. In standby mode, press the DOWN button to enter Caller ID list. If there is
new call(s), the new call(s) will be displayed at first.

Month/Date

ALEX BROWIN

12/15 10:00 01

604­555-1212

AM

NEW

LEX BROWIN

604-

555-1212

12/15 10:00 01

AM

NEW

Time

umber of calls recorded

2. Press the UP or DOWN button to scroll to the next call. The DOWN
button will go throu gh the calls from th e last ca ll receiv ed t o the fi rst. Th e
UP button will allow you to view th e calls from the fi rst call received to
the last.

3. Press the EXIT/MUTE button to finish.

NOTE: If no active buttons are pressed for 20 seconds, the LCD Display will
automatically return to STANDBY mode.

CALLER ID DISPLAY

JOHN SMITH

12/25 10:00

555-

555-1212

AM

OLD

This display shows the name, number, time an
date of the call.

38

080106B-1 20

b

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

MESSAGE WAITING

NEW 00 OLD 00

12/25 10:00

AM

AM

NOTE: If a call is rec eived from the sam e number more than once since the
records were las t view ed, n o n ew en t ry is ma d e, b u t th e rep ea t call i c on “*” a nd
the number of repeat calls is displayed.

CALL WAITING

When you subscribe to Call Waiting service from your local telephone
Company, this telepho ne will d isp lay t he n ame and number of th e s econd ca ller
while you are having a conversation.

1. When a second call comes in whi le you are having a conversati on, you
will hear a notificati on tone from the handset and volu me is momentarily
muted. The LCD Display will au tomatically shows t he name and number
of the second caller.

2. Press the FLASH button to answer the second caller.

3. When you are finished, press the FLASH button to continue your
conversation with the first caller.

MESSAGE WAITING

If you have subscribed to the Voice Mail message service and you have
requested Visual Message Indication from your local telephone company, the IN
USE/M SG WTG/NE W CALL LED ind icator wi ll blink a nd the LCD D isplay
will show “MES S A GE WAITING” when there are voice message(s) for you. To
remove the MESSAGE WAITING indicator, see the “ Message Waiting
Setting” section.

Display shows when a voice mail message has

een received and is stored by message waiting

service provided by the phone company.

This is disp la yed wh en t h ere i s no Call er ID d a t e
stored.

MESSAGE WAIGING

12/25 9:07AM

080106B-1 21

play

play

play

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

PLACING A CALL FROM THE CALLER LIST

1. Press the DOWN button.

2. Press the UP or DOWN button to select the call record you wish to call
back.

3. If the number displayed is not correct (needing 7, 10, 11 digits), press the
# button to select call number.

11 digit number
dis

ed as below:

JOHN SMITH
1-555-

555-1212

12/25 9:07AM

Press # button

JOHN SMITH
555-

555-1212

12/25 9:07AM

Press # button

JOHN SMITH

555-1212

12/25 9:07AM

Press # button

JOHN SMITH
1-

555-1212

12/25 9:07AM

OLD

OLD

OLD

8

8

OLD

8

8

10 digit number
dis

ed as below:

JOHN SMITH
555

555-1212

12/25 9:07AM

Press # button

OLD

JOHN SMITH
1-555-

555-1212

12/25 9:07AM

Press # button

OLD

JOHN SMITH

555-1212

12/25 9:07AM

Press # button

OLD

JOHN SMITH
1-

555-1212

12/25 9:07AM

OLD

8

8

8

JOHN SMITH

12/25 9:07AM

JOHN SMITH
1-

12/25 9:07AM

8

7 digit number
dis

ed as below:

555-1212

OLD

Press # button

555-1212

OLD

8

8

080106B-1 22

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

4. Press the TALK button to dial out.

5. To end your conversation, either press the TALK button or place the
handset on the base unit.

SAVING THE NAME AND NUMBER FROM THE CALLER LIST INTO
PHONE BOOK

1. Press the DOWN button

2. Press the UP or DOWN button to scroll to the call record you wish to
delete.

3. Press the SELECT/TRANSFER button. The LCD Display will show
“DIAL ERASE STORE”. Press the UP or DOWN button to select
“STORE”, and then press the SELECT/TRANSFER button to confirm a
selection.

4. Press the SELECT/TRANSFER button twice to confirm.

5. Press the EXIT/MUTE button to return to STANDBY mode.

SELECTIVE DELETING IN THE CALLER LIST

1. Press the DOWN button

2. Press the UP or DOWN button to scroll to the call record you wish to
delete.

3. Press SELECT/TRANSFER button. The LCD Display will show “DIAL
ERASE STORE”

4. Press the UP or DOWN button to select “ERASE”, and then press the
SELECT/TRANSFER button to confirm a select ion. The LCD will s how
“ERASE NO YES ALL”.

5. Press the UP or DOWN button to select “YES”, and then press the
SELECT/TRANSFER button to confirm a deletion the call record.

6. Press the EXIT/MUTE button to return to STANDBY mode.

DELETING ALL RECORDS IN THE CALLER LIST

1. Press the DOWN button

2. Press the UP or DOWN button to scroll to the call record you wish to
delete.

3. Press the SELECT/TRANSFER button. The LCD Display will show

080106B-1 23

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

“DIAL ERASE STORE”

4. Press the UP or DOWN button to select “ERASE”, and then press the
SELECT/TRANSFER button to confirm a select ion. The LCD will s how
“ERASE NO YES ALL”.

5. Press the UP or DOWN button to select “ALL”, and then press the
SELECT /TRANSFER button to confirm a deletion the call record. The
LCD Display will show “ ERASE ALL NO YES”, And th en press th e UP
or DOWN button to select “YES”.

6. Press the SELECT/TRANSFER button to confirm, and then will
automatically go back to standby mode.

PROGRAMS OPERATION

This unit contains the following special Programs:

A. PHONE BOOK
B. LANGUAGE
C. MESSAGE WAITING
D. DIAL MODE
E. DATE/TIME
F. RINGER

G. QUICK DIAL

A. PHONE BOOK

You can edit 20 directory memories.

1. Press the MENU/SCAN button.

2. Press the SELECT/TRANSFER button.

3. Use the TE LEPHONE KEYPAD button (0-9) to en ter the name, (s ee
the “TE LEPHONE KEYPAD CHA RACTERS SETTING” s ection )
you can store up to 15 characters.

4. Press the SELECT/TRANSFER button once.

5. Enter the telephone number using the TELEPHONE KEYPAD button
(0-9). You can store up to 24 digits.

6. Press the SELECT/TRANSFER button to save into memory, and it

PHONE BOOK

080106B-1 24

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

will automatically go back to standby mode.

B. LANGUAGE
This telephone offers English, Spanish and

French languages for your convenience.

1. Press the MENU/SCAN button.

2. Press the UP or DOWN button to select LANGUAGE.

3. Press the SELECT/TRANSFER button to confirm.

4. Press the UP or DOWN button to select English, Spanish and French.

5. Press the SELECT/TRANSFER button to save the setting, and it will
automatically go back to standby mode.

C. MESSAGE WAITING
To turn off the Message Waiting LCD

indicator.

1. Press the MENU/SCAN button.

2. Press the UP or DOWN button to select MESSAGES WAITING

3. Press the SELECT/TRANSFER button to confirm.

4. Press the UP or DOWN button to select YES or ON.

5. Press the SELECT/TRANSFER button to confirm, and it will
automatically go back to standby mode.

D. DIAL MODE
Allows you to set the dialing mode to

either Tone dialing or Pulse dialing.

1. Press the MENU/SCAN button.

2. Press the UP or DOWN button to select DIAL MODE.

3. Press the SELECT/TRANSFER button to confirm.

4. Press the UP or DOWN button to select TONE or PULSE.

5. Press the SELECT/TRANSFER button to save the setting, and it will
automatically go back to standby mode.

E. DATE/TIME

Set the date and time.

1. Press the MENU/SCAN button.

LANGUAGE

MESSAGES WAITING

DIAL MODE: TONE

DATE/TIME

080106B-1 25

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

2. Press the UP or DOWN button to select DATE/TIME.

3. Press the SELECT/TRANSFER button to confirm.

4. Use the UP or DOWN button to enter the m onth, and then press the

SELECT/TRANSFER button to confirm.

5. Repeat step 4 above to set the date, hour and minute.

6. Press the UP or DOWN for AM or PM setting., and then press the
SELECT/TRANSFER button to save the setting, and then will
automatically go back to STANDBY mode.

NOTE: The date and time will automatically set, if you have subscribed to

the Caller ID service from your local telephone company.

F. RINGER

RINGER: 1

1. Press the MENU/SCAN button.

2. Press the UP or DOWN button to select RINGER.

3. Press the SELECT/TRANSFER button to confirm.

4. Press the UP or DOWN button to select the RING (1,2,3,4, OFF). The

1 ringer is the preset mode.

5. Press the SELECT/TRANSFER button to confirm, and it will

automatically go back to standby mode.

G. QUICK DIAL

Allows you to save 9 programmed telephone

QUICK DIAL

numbers into the memory.

1. Press the MENU/SCAN button.

2. Press the UP or DOWN button to select QUICK DIAL.

3. Press the SELECT/TRANSFER button to confirm.

4. Press a number (0-9) on the keypad, where you want the number
stored.

5. Use the TELEPHONE KEYPAD button(1-9) to ent er the name, (see
the “TE LEPHONE KEYPAD CHA RACTERS SETTING” s ection )
you can store up to 15 characters.

6. Press the SELECT/TRANSFER button to confirm.

7. Enter the telephone number using the TELEPHONE KEYPAD button

080106B-1 26

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

(0-9). You can store up to 24 digits.

8. Press the SELECT/TRANSFER button to save the setting, and it will
automatically go back to standby mode.

STORE the name and number into QUICK DIAL from the phone

book

a) Press the UP button.
b) Press the UP or DOWN button to select the one you desire.
c) Press the SELECT/TRANSFER button .
d) Press the UP or DOWN button to select “ QUICK”.
e) Press the SELECT/TRANSFER button.
f) Press a number (1-9) on the key pad you want to store.
g) Press the EXIT/MUTE button to go back to STANDBY mode.

Dial 9 Frequently Called Numbers

a) In STANDBY mode, press and hold a number on the keypad

where the desired phone number is stored.

b) Press TALK button to dial. Or , if you don’t want to dial. You can

press the EXIT/MUTE button to return the standby mode.

EXTENSION HNADSET REGISTERING (Expandable up to 4 handsets)

1. Press and hold PAGE button until you plug the AC adaptor plug into DC
jack (located on the rea r of th e ba se unit s ), and th en th e ba se IN USE LED
will flash.

2. Release the PAGE button.

3. Press the MENU/SCAN button, and then press the telephone keypad
“1,2,3,1” button. You will listen a beep sounds. The LCD will display
REGISTRATION.

4. Place the handset on the base unit to register.

5. Pick up the handset to go back to STANDBY mode.

NOTE: The unit required you to register 4 handsets location completely. If
registered extension handset less than four. The base IN USE LED will flash. At
that time, just simply disconn ect the AC adaptor p lug then reconnect the AC
adaptor plug to return to STANDBY mode.

080106B-1 27

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

1,048,576 Combination Security Coding

The cordless telephone have a digital coding security system to prevent
unauthorized use of your telephone line by other cordless phones nearly. The
cordless telephone have 1,048,576 possible security code combinations. Each
combination of the code is randomly generated by factory equipment.

RESETTING SECURITY CODE AND CHANNEL

Communication between the handset and the base unit may not be possible in
any of the following situations:

1. After a power failure.

2. After relocating the base unit by disconnecting the AC adapter.

3. After replacing the handset battery.

4. The handset goes out of range from the base unit.

To reset, place the handset on the cradle of the base unit for five seconds.

IMPROVING CORDLESS RECEPTION

Follow these guidelines to improve cordless sound quality:

• Select an ar ea to install the un it where it is closest to the center of your
home or office. This will improve the operating range of the unit.

• Keep the base unit away from electrical equipment. Radio Frequency
Interference (RFI) is sometimes generated by these appliances, which can
cause a degradation in cordless reception.

• Keep the handset batteries charged as much as possible. Weak handset
batteri es can limi t the range of cordless opera tion.

MAXIMIZING BATTERY LIFE

Repeated use, or recharge of Ni-Cd batteries without periodic full discharge
results in reduced useable charge time. When you notice the usable charge
duration decreasing, fully discharge the Ni-Cd battery and recharge as
described:

DISCHARGING

1. Unplug the telephone line cord from the 36587.

2. Make sure that the adapter is connected.

3. Lift the handset out of the base cradle.

4. Press the TALK button on the handset and start discharging..

080106B-1 28

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

Once the Symbol LOW Battery appears on LCD display, it means that the
battery level is low. Let it fully discharge for 12 hours. Once the Ni-Cd battery
is fully discharged, you may now charge the battery to its full capacity.
CHARGING

1. Make sure the adapter and telephone line cord are connected to the

36587.

2. Place the handset on the base cradle. The CHARGE LED indicator of the
base unit will light steadily.

3. Leave the handset charging on the base for 14 hours continuously to get a
maximum charge.

4. The 36587 is now ready for regular use. Discharge and charge the
Ni-Cd battery again once you notice a decrease in the useable charge time.

MAINTENANCE

1. Your phone should be situated away from heat sources such as radiators,
heaters, stoves or any other appliance that produces heat.

2. Use a slightly damp cloth to clean the plastic cabinet. A mild soap will
help to remove grease or oil. Never use polish, solvents, abrasives or
strong detergents since these can damage the finish.

TECHNICAL INFORMATION

This cordless phone uses radio frequencies to allow mobility. There are certain
difficulties in using radio frequencies with a cordless telephone. While these are
normal, the following could affect the operation of your system.
NOISE: Electric pulse noise is present in most homes at one time or another.
This noise is most intense during electrical storms. Certain kinds of electric
equipment such as light dimmers, fluorescent bulbs, motors, and fans also
generate noise pulses. Because radio frequencies are susceptible to these noise
pulses, you may occasionally hear them in your handset. Generally, they are
minor annoyances and should not be interpreted as defects in your system.
RANGE: Because radio frequencies are used, location of the base unit can
affect operating range. Try several locations in your home or business and pick
the one that gives you th e clearest sign al.
INTERFERENCE: Some electronic devices operat e in and/or generate

080106B-1 29

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

interference near the operating frequencies of your cordless telephone. While
several protection circuits are used to prevent unwanted signals, there may be
periods when these unwanted signals cause interferenc e. If interferenc e occurs
frequently, it can be minimized or eliminated by lowering the height of your
base antenna or by relocating the base unit. You can check for interference
before selecting the final base unit location by plugging in the phone.

TROUBLESHOOTING

A. TELEPHONE UNIT TROUBLESHOOTING TABLE

SYMPTOM SOLUTION

No dial tone • Check the telephone line cord connectors at both ends

to see if they are pushed in firmly until they click.

• If you had a power failure or had unplugged the
base unit, replace the handset on the base unit for
two to five seconds to reset the system.

Does not ring • Check the RINGER mode on the handset. For

normal use, set to RING 1,2,3,4. The handset will
not ring in OFF mode.

• Check the telephone line cord connectors at both
ends to see that they are pushed in firmly until they
click.

• You may have exceeded the R inger Equ ivalence
Number(REN) limit of how many phones can be
connected to the same line. The REN total of all
devices(printed on the bottom label of each
unit)should not exceed five(5). Disconnect the
appropriate units to lower the REN total.

No power on
the handset unit

• Check the Ni-Cd battery pack for proper connection
inside the battery compartm ent on the handset.

•

The handset rechargeable Ni-Cd pack may need

080106B-1 30

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

charging.

Does not charge • Check the Ni-Cd battery pack for proper connection

inside the battery compartm ent on the handset.

• Made sure the charging contacts on both the base
unit and the handset are in contact during charging.

• The charging contacts and terminals may need
cleaning with an alcohol-dampened swab.

Range is
limited

Calls received
flutters or fades

Interference on
reception
Excessive static • Refer to the section “Improving Cordless

• Move the base unit so that it is centrally located in
your residence or office and make sure that the base
unit is not located near appliances.

• The handset Ni-Cd battery may be weak. Recharge
the Ni-Cd battery.

• Refer to the section “ Improving Cordless
Reception”.

• The handset rechargeable Ni-Cd battery pack may
need charging.

• Choose an alternate channel using the
MENU/SCAN button on the handset.

• Refer to the section “Improving Cordless
Reception”.

Reception”.

080106B-1 31

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

B. CALLER ID SYSTEM TROUBLESHOOTING TABLE

SYMPTOM SOLUTION

The Caller ID
panel is blank

The Caller ID does
not show the
caller’s name
and/or phone
number

Random
characters and/or
“NO DATA”
appear on the LCD
display
Cannot get call
Waiting
identification on
the LCD panel

• Check the power connection.

• Check the telephone line cord connections.

• Check the batteries for proper i nstallation.

• The Caller ID unit will not function until you

have Caller ID service provided by your local
phone company. Call your local phone company
to have Caller ID installed onto your telephone
line

• If you pick up the phone before the second ring,
the caller information will not be correctly
received. If you have a telephone answering
device(TAD) connected with the unit, set the
TAD to answer after two rings or more.

• If it is a blocked call or an out-of-area call, the
caller’s name and/or phone number will not
appear on the display.

• If only the caller’s phone number appears on the
display, it may be a Single Data Message Format
(SDMF) call, as opposed to a Multiple Data
Message Format (MDMF) call. Please call your
local phone company to see which service you
have.

• On rare occasions, the Caller ID information sent
by the telephone company may have an error in
the transmission. This is not the fault of your
Caller ID unit. It can only capture and store the
data that was received.

• Subscription to Caller ID Call Waiting (CIDCW)
is required from your local phone company for
the CIDCW function to operate properly. Call
you local phone company for details.

080106B-1 32

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

AC ADAPTOR: USE ONLY WITH CLASS 2 POWER SOURCE,

THIS SYMBOL IS INTENDED TO ALERT THE USER

OUTPUT 9VDC, 200mA .

OF THE PRESENCE OF IMPORTANT OPERATING
AND MAINTENANCE (SERVICING) INSTRUCTIONS
IN THE OWNER’S MANUAL.

080106B-1 33

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

If you believe your phone is defective or missing components,
please contact ATS Customer Service at 1-888-928-7746,
Monday – Friday, 9 am to 5 pm PT.

Limited W arranty

WHAT DOES OUR WARRANTY COVER?

• Any defect in material and workmanship.

FOR HOW LONG AFTER THE ORIGINAL PURCHASE?

• To the original purchaser only – ONE YEAR.

WHA T WILL YOUR SERVICE PROVIDER DO?

• At our option, repair or replace your unit.

HOW DO I ARRANGE FOR SERVICE, WHETHER IN
OR OUT OF WARRANTY?

• Call ATS Customer Support for Return Authorization at
1-888-928-7746.

• Carefully pack your unit. Include all accessories provided
with the product. We recommend using the original carton
and packing materials.

• Include a copy of the sales receipt or other evidence of date
of original purchase (if purchase was
within the last 12 months).

• Print your name, address and phone number, along with a
description of the defect, and include this in the package.

080106B-1 34

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

• Include payment for any service or repair not covered by
warranty, as determined by your Service Provider.

WHAT DOES OUR WARRANTY NOT COVER?

• Batteries

• Damage from misuse, neglect or acts of natur e (lightning,

floods, power surges, etc.)

• Products which may be have been modified or incorporated
into other products

• Products purchased and/or operated outside of the U.S., its
territories, or Canada

• Products services by the owner or a service facility not
expressly authorized by American Telecom

• Products purchased more than 12 months from the current
date

• Units purchased in “AS IS” condition or units purchased as
“Distressed Merchandise”

HOW DOES STATE OR PROVINCIAL LAW RELATE TO
THIS WARRANTY?

• This warranty gives you specific rights. You may also have
other rights which vary from state to state or province to
province.

If you believe your phone is defective or missing components,
please contact ATS Customer Service at 1-888-928-7746,
Monday – Friday, 9 am to 5 pm PT.

080106B-1 35

SENTON Enterprises Limited 信 通 企 業 有 限 公 司

Flat 10, 17/F, Fo Tan Industrial Centre, 香港沙田火炭坳背灣街 26-28 號

26-28 Au Pui Wan Street, Fo Tan, Shatin, N.T., Hong Kong 富騰工業中心 17 樓 10 室

T

el: (852) 2687-1712 Fax: [phone] 電話: (八五二) 二六八七 一七一二 (四線)

E-mail address: [email protected] 傳真: (八五二) 二六八七 四一二五

36587/080106B-1

080106B-1 36
