Sensr GP2x User Manual

GP2x

User Guide

USB ACCELEROMETER

Copyright © 2009 SENSR LLC. All Rights Reserved. R001-421-V1.0

Version 1.0
February 7, 2010

GP2X USER GUIDE

TABLE OF CONTENTS

1 PREAMBLE 3

1.1 FCC Statement 3

1.2 Software License Agreement 3

1.3 Acceptable Use 5

2 GP2X USB ACCELEROMETER 5

2.1 General 5

2.2 Specications 5

2.3 Acceleration Ranges 6

2.4 Real-Time Data Capture Mode 6

2.5 LED Status Indicator 6

2.6 Start button 6

2.7 Temperature 6

3 SYSTEM SETUP 7

3.1 Installing the Software 7

3.2 Connecting the GP2x and installing the USB drivers 8

4 MISCELLANEOUS 9

4.1 GP2X Maintenance 9

4.2 Technical Support 9

4.3 Product Warranty 10

2

GP2X USER GUIDE

1 PREAMBLE

1.1 FCC Statement

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:

This device may not cause harmful interference.

This device must accept any interference received, including interference that may cause
undesirable operation.

This device must only be used with the supplied interface cables. A Class A digital device is intended
for use in commercial, business and industrial environments.

1.2 Software License Agreement

PLEASE READ THIS SOFTWARE LICENSE AGREEMENT CAREFULLY BEFORE USING THE SOFTWARE.

License Grant: SENSR LLC. (“SENSR”) and its suppliers grant to Customer (“Customer”) a nonexclusive
and nontransferable license to use the Sensview software (“Software”) in object code form only on as
many central processing units as is required to support the functionality of the products used in
conjunction with this software.

EXCEPT AS EXPRESSLY AUTHORIZED ABOVE, CUSTOMER SHALL NOT: COPY, IN WHOLE OR IN PART,
SOFTWARE OR DOCUMENTATION; MODIFY THE SOFTWARE; REVERSE COMPILE OR REVERSE ASSEMBLE
ALL OR ANY PORTION OF THE SOFTWARE; OR RENT, LEASE, DISTRIBUTE, SELL, OR CREATE DERIVATIVE
WORKS OF THE SOFTWARE.

Customer agrees that aspects of the licensed materials, including the specic design and structure of
individual programs, constitute trade secrets and/or copyrighted material of SENSR. Customer agrees
not to disclose, provide, or otherwise make available such trade secrets or copyrighted material in any
form to any third party without the prior written consent of SENSR. Customer agrees to implement
reasonable security measures to protect such trade secrets and copyrighted material. Title to Software
and documentation shall remain solely with SENSR.

SOFTWARE WARRANTY. SENSR warrants that for a period of ninety (90) days from the date of shipment
from SENSR: (i) the media on which the Software is furnished will be free of defects in materials and
workmanship under normal use; and (ii) the Software substantially conforms to its published specications.
Except for the foregoing, the Software is provided AS IS. This limited warranty extends only to Customer
as the original licensee. Customer’s exclusive remedy and the entire liability of SENSR under this limited
warranty will be, at SENSR’s option, repair, replacement, or refund of the Software. In no event does SENSR
warrant that the Software is error free or that Customer will be able to operate the Software without
problems or interruptions. This warranty does not apply if the software (a) has been altered, except by
SENSR, (b) has not been installed, operated, repaired, or maintained in accordance with instructions
supplied by SENSR.

DISCLAIMER. EXCEPT AS SPECIFIED IN THIS WARRANTY, ALL EXPRESS OR IMPLIED CONDITIONS,
REPRESENTATIONS, AND WARRANTIES INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTY
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT OR ARISING FROM
A COURSE OF DEALING, USAGE, OR TRADE PRACTICE, ARE HEREBY EXCLUDED TO THE EXTENT ALLOWED

3

GP2X USER GUIDE

BY APPLICABLE LAW. IN NO EVENT WILL SENSR BE LIABLE FOR ANY LOST REVENUE, PROFIT, OR DATA,
OR FOR SPECIAL, INDIRECT, CONSEQUENTIAL, INCIDENTAL, OR PUNITIVE DAMAGES HOWEVER CAUSED
AND REGARDLESS OF THE THEORY OF LIABILITY ARISING OUT OF THE USE OF OR INABILITY TO USE THE
SOFTWARE EVEN IF SENSR HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. In no event shall
SENSR’s liability to Customer, whether in contract, tort (including negligence), or otherwise, exceed the
price paid by Customer. The foregoing limitations shall apply even if the above-stated warranty fails of
its essential purpose. SOME STATES DO NOT ALLOW LIMITATION OR EXCLUSION OF LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES.

The above warranty DOES NOT apply to any beta software, any software made available for testing or
demonstration purposes, any temporary software modules or any software for which SENSR does not
receive a license fee. All such software products are provided AS IS without any warranty whatsoever.
This License is eective until terminated. Customer may terminate this License at any time by destroying
all copies of Software including any documentation. This License will terminate immediately without
notice from SENSR if Customer fails to comply with any provision of this License. Upon termination,
Customer must destroy all copies of Software.

Software, including technical data, is subject to U.S. export control laws, including the U.S. Export
Administration Act and its associated regulations, and may be subject to export or import regulations
in other countries. Customer agrees to comply strictly with all such regulations and acknowledges
that it has the responsibility to obtain licenses to export, re-export, or import Software.

This License shall be governed by and construed in accordance with the laws of the State of Iowa,
United States of America, as if performed wholly within the state and without giving eect to the
principles of conict of law. If any portion hereof is found to be void or unenforceable, the remaining
provisions of this License shall remain in full force and eect. This License constitutes the entire
License between the parties with respect to the use of the Software.

4

GP2X USER GUIDE

1.3 Acceptable Use

The SENSR GP2x is a general-purpose instrument only, it is not recommended for any use that requires
critical measurement or precision triggering. The GP2x is not to be used for:

• Critical testing

• Monitoring life support or patient diagnoses

• Any type of input or controller for any process or system including but not limited to:

• Automated production or manufacturing

• Life support or patient diagnosis

• Vehicle or machine control

• Emergency, redundant or back up systems

The GP2x is designed to be used in a protected environment and should not be exposed to liquids.

It is the responsibility of the user to conrm that any use of the product conforms with all country, federal,
state, county, municipal laws, ordinances and regulations, if any, applicable to the transport and use of
the GP2x.

2 CX1 NETWORK ACCELEROMETER AND INCLINOMETER

2.1 General

The GP2x USB Accelerometer is a 3 - axis motion sensing instrument that allows the user to monitor,
record and evaluate; motions, impacts, shocks, drops, orientations and temperature.

2.2 Specications

Size: 3.935” x 2.560” x 1.140”
Weight: 5.5 oz
Housing Material: 6061 - T6 Aluminum
Power: 25mA max.
Connectivity: USB
Accelerometer Type: Programmable 3 Axis MEMS
Accelerometer Range: User programmable ±2.5, ±3.3, ±6.7, and ±10G
Frequency Response: DC - 45Hz
Sampling Rate: 400samples/sec per axis
Device Temperature Range: -20°C to +70°C (-4°F to 158°F)

Note: GP2xL features a high sensitivity accelerometer that has 4 programmable ranges: 1.5g, 2g, 4g and 6g.

5

GP2X USER GUIDE

2.3 Acceleration Ranges

The GP2x incorporates a programmable 3-axis MEMS accelerometer. The user can select which range is
appropriate for their application. It is recommended the user select the lowest range reasonable for their
application, as this will optimize data. Choosing an acceleration range does not limit the survivability of
the accelerometer, which is shock rated for more than 1000Gs.

2.4 Real-Time Data Capture Mode

The GP2x is a real-time data capture instrument—the user sees the real-time acceleration values as they
are occurring. The user can control when the system records/displays data. Recording control can be
done on the PC or at the instrument. USB extenders can be used with the GP2X to increase the cable
length if required.

2.5 LED Status Indicator

The GP2X has an LED indicator that is used to quickly determine the status of the unit. Depending
upon the unit’s status the LED will ash green, yellow or red. Each ash color and ash frequency has
a specic meaning:

Red, Green, Yellow ash Instrument is initializing

Green Flash Instrument is ready to sample data

2.6 Start Button

The GP2x features a top mounted “start” button—this button can be used to control when data is
being recorded.

2.7 Temperature

The unit has an internal temperature sensor that is used for accelerometer temperature compensation.
The sensor is placed adjacent to the accelerometer and measures the internal temperature of the GP2x.
The temperature sensor is factory calibrated to be within ±1.5 ° C. Since the GP2x is an extremely
low-power device and does not generate any appreciable heat, it does not aect the reported
temperature. The GP2x samples temperature every 10 seconds.

The GP2x’s temperature response rating is:

Moving Air

• Time to reach 50% of temperature dierence

• 5 minutes 10 seconds

• Time to reach 90% of temperature dierence

• 19 minutes

Still Air

• Time to reach 50% of temperature dierence

• 11 minutes 15 seconds

• Time to reach 90% of temperature dierence

• 1 hour 8 minutes

6

GP2X USER GUIDE

3 SYSTEM SET-UP

3.1 Installing the Software

This device Please verify that your PC meets the following minimum system requirements:
Operating System: Windows XP SP2, Vista, Windows 7

Note: USB driver support for 32-bit OS only.

CPU: Pentium 4, 1.4 GHz
System Memory (RAM): 1GB
Hard Disk: 2 GB free space (for data les)
Display: 1024 x 768, 32-bit “True Color”
Microsoft .NET Frameworks: 2.0 Service Pack 2 or newer and 3.5 SP1 or newer

The software for the GP2x USB Accelerometer is based upon Microsoft’s .NET Framework. The user can
download this environment from Microsoft using the Windows update utility. Depending on the update
settings the “Custom” update option may need to be selected. The .NET Framework 3.5 is considered an
optional component and is listed in the Software category.

SensView – A graphics-based data viewer and analyzing program that lets users review real-time and
collected data. The program can be used for short-duration monitoring and recording of data from
one GP2X.

You must install the .NET Framework 3.5 before you install the Sensview application.

SensView is contained in a compressed folder located in the Applications folder on the SENSR CD.
Double-click the icon for the compressed folder, a window should open to show the contents of the
compressed folder. Drag the folder inside the window to a location on your desktop. SensView is now
located inside this folder on your desktop and is ready to be launched.

To execute the program, double-click the SensView.exe le.

3.2 Connecting the GP2x and Installing the USB Drivers

The SENSR GP2x USB Accelerometer communicates with the computer via USB. Device driver software is
required for communication between your PC and each SENSR instrument. Start the driver installation by
ensuring that the SENSR CD is in your PC and then connect the GP2X to the host computer.

You should see an indication near the system tray that the computer has detected new hardware.

7

GP2X USER GUIDE

A moment later, a dialog will appear for the Found New Hardware Wizard. Do not allow the wizard
to connect to Windows Update to search for software. Click the Next button.

Allow the wizard to install the software automatically. Windows should search the SENSR CD for the
appropriate drivers. If the wizard cannot nd the correct software, you can install from a specic location.
The drivers are located on the SENSR CD in the Drivers\Sensr GP Series Device Drivers Vx.x.x

A warning will appear to advise you that the software has not passed Windows Logo testing.
This is not a problem. Click the Continue Anyway button.

GP2X USER GUIDE

When the wizard is nished, this dialog appears. Click the Finish button.

You should see an indication near the system tray that the computer has nished installing the hardware.

4 MISCELLANEOUS

4.1 GP2X Maintenancee

Cleaning The GP2X can be cleaned by dampening a cloth with Windex™ and wiping

down the exterior surfaces. Do not spray cleaning uid directly on the GP2X.

Calibration The GP2X uses a DC response accelerometer and is calibrated using the Earth’s
gravity. The unit is factory-calibrated using precision surface plates and
temperature chambers; users who want to check the calibration of their unit
can connect a unit to the PC. If it is suspected the unit requires calibration the
user can contact the factory to arrange a review.

Storage Store the unit in a dry, indoor environment.

4.2 Technical Support

For questions about the GP2x or an application, e-mail support at [e-mail] or call 563.245.3750.
Standard hours of operation are 8 am - 5 pm CST, M—F.

9

GP2X USER GUIDE

4.3 Product Warranty

SENSR LLC. (“SENSR”) warrants to the original Customer (“Customer”) that SENSR brand instruments
(“Product”) are free from defects in material and workmanship under normal use and service for a period
of 1 year commencing upon the date of purchase.

This Limited Warranty is conditioned upon proper use of Product by Customer. This Limited Warranty
does not cover: (a) defects or damage resulting from accident, misuse, abuse, neglect, unusual physical,
electrical or electromechanical stress, or modication of any part of Product, including cables, or cosmetic
damage; (b) equipment that has the serial number removed or made illegible; (c) any surfaces or other
externally exposed parts that are scratched or damaged due to normal use; (d) malfunctions resulting
from the use of Product in conjunction with accessories, products, or ancillary/peripheral equipment not
furnished or approved by SENSR; (e) defects or damage from improper testing, operation, maintenance,
installation, or adjustment; (f ) installation, maintenance, and service of Product, or (g) Product used or
purchased outside the United States or Canada. During the warranty period, SENSR will repair or replace,
at SENSR’s sole option, without charge to Customer, any defective component part of Product. To obtain
service under this Limited Warranty, Customer must contact SENSR Customer care at 1.563.245.3750.
Upon receipt, SENSR will promptly repair or replace the defective Product. SENSR may, at SENSR’s sole
option, use rebuilt, reconditioned, or new parts or components when repairing any Product or replace
Product with a rebuilt, reconditioned or new Product. Repaired or replaced product will be warranted
for a period equal to the remainder of the original Limited Warranty on the original Product or for 90 days,
whichever is longer. All replaced parts, components, boards and equipment shall become the property
of SENSR. If SENSR determines that any Product is not covered by this Limited Warranty, Customer must
pay all parts, shipping, and labor charges for the repair or return of such Product.

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED HEREIN, CUSTOMER TAKES THE PRODUCT
“AS IS,” AND SENSR MAKES NO WARRANTY OR REPRESENTATION AND THERE ARE NO CONDITIONS, EXPRESS
OR IMPLIED, STATUTORY OR OTHERWISE, OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT,
INCLUDING BUT NOT LIMITED TO: THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY
PARTICULAR PURPOSE OR USE; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY
LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION
MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS WARRANTY OF ANY KIND WHATSOEVER WITH
RESPECT TO THE PRODUCT. ALL IMPLIED WARRANTIES AND CONDITIONS THAT MAY ARISE BY OPERATION
OF LAW, INCLUDING IF APPLICABLE THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE HEREBY LIMITED TO THE SAME DURATION OF TIME AS THE EXPRESS WRITTEN
WARRANTY STATED HEREIN. SOME STATES/PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. IN ADDITION, SENSR
SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE, USE, OR
MISUSE OF, OR INABILITY TO USE THE PRODUCT OR ARISING DIRECTLY OR INDIRECTLY FROM THE USE
OR LOSS OF USE OF THE PRODUCT OR FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING
INCIDENTAL, SPECIAL, CONSEQUENTIAL OR SIMILAR DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR
BENEFITS, OR FOR DAMAGES ARISING FROM ANY TORT (INCLUDING NEGLIGENCE OR GROSS NEGLIGENCE)
OR FAULT COMMITTED BY SENSR, ITS AGENTS OR EMPLOYEES, OR FOR ANY BREACH OF CONTRACT OR
FOR ANY CLAIM BROUGHT AGAINST CUSTOMER BY ANY OTHER PARTY. SOME STATES/PROVINCES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE/PROVINCE TO PROVINCE.
THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL CUSTOMER OF
THIS PRODUCT AND STATES CUSTOMER’S EXCLUSIVE REMEDY. IF ANY PORTION OF THIS LIMITED WARRANTY
IS HELD ILLEGAL OR UNENFORCEABLE BY REASON OF ANY LAW, SUCH PARTIAL ILLEGALITY OR
UNENFORCEABILITY SHALL NOT AFFECT THE ENFORCEABILITY FOR THE REMAINDER OF THIS LIMITED
WARRANTY WHICH CUSTOMER ACKNOWLEDGES IS AND WILL ALWAYS BE CONSTRUED TO BE LIMITED
BY ITS TERMS OR AS LIMITED AS THE LAW PERMITS.
