Embeddable Digital Video Recorders
4000 Series
Models 4011, 4012, 4013
Hardware Manual
Ver. 2.1.0 | July 2018
Page 2
2
Table of Contents
Limited warranty ......................................................................................................................... 4
Introduction .................................................................................................................................. 5
Connectors .................................................................................................................................... 7
USB Connectors ........................................................................................................................ 7
Model 4011 ................................................................................................................................ 7
Power ..................................................................................................................................... 7
Video ...................................................................................................................................... 7
Audio out .............................................................................................................................. 7
Keypad ................................................................................................................................... 8
RS-232 .................................................................................................................................... 8
Model 4012 ................................................................................................................................ 9
Power ..................................................................................................................................... 9
Video ...................................................................................................................................... 9
Audio out .............................................................................................................................. 9
Keypad ................................................................................................................................... 9
Incremental encoders ........................................................................................................ 10
RS-232 .................................................................................................................................. 10
Model 4013 .............................................................................................................................. 12
Video .................................................................................................................................... 12
Power ................................................................................................................................... 12
Incremental encoders ........................................................................................................ 12
Keypad ................................................................................................................................. 13
Audio in ............................................................................................................................... 13
Audio out ............................................................................................................................ 14
RS-232 .................................................................................................................................. 14
Overlays....................................................................................................................................... 15
Primary overlay ...................................................................................................................... 15
Secondary overlay .................................................................................................................. 15
Page 3
3
Menu system ............................................................................................................................... 17
Firmware updates ...................................................................................................................... 26
Customizations ........................................................................................................................... 28
Keypad functions ................................................................................................................... 28
Splash screen ........................................................................................................................... 28
Maintaining custom settings ................................................................................................ 28
Wireless ....................................................................................................................................... 30
WiFi adapters .......................................................................................................................... 30
Streaming video from a DVR ............................................................................................... 30
Specifications .............................................................................................................................. 32
Revision history .......................................................................................................................... 33
Page 4
4
Limited warranty
Sensoray Company, Incorporated (Sensoray) warrants the hardware to be free from defects
in material and workmanship and perform to applicable published Sensoray specifications
for two years from the date of shipment to purchaser. Sensoray will, at its option, repair or
replace equipment that proves to be defective during the warranty period. This warranty
includes parts and labor.
The warranty provided herein does not cover equipment subjected to abuse, misuse,
accident, alteration, neglect, or unauthorized repair or installation. Sensoray shall have the
right of final determination as to the existence and cause of defect.
As for items repaired or replaced under warranty, the warranty shall continue in effect for
the remainder of the original warranty period, or for ninety days following date of shipment
by Sensoray of the repaired or replaced part, whichever period is longer.
A Return Material Authorization (RMA) number must be obtained from the factory and
clearly marked on the outside of the package before any equipment will be accepted for
warranty work. Sensoray will pay the shipping costs of returning to the owner parts that are
covered by warranty. A restocking charge of 25% of the product purchase price will be
charged for returning a product to stock.
Sensoray believes that the information in this manual is accurate. The document has been
carefully reviewed for technical accuracy. In the event that technical or typographical errors
exist, Sensoray reserves the right to make changes to subsequent editions of this document
without prior notice to holders of this edition. The reader should consult Sensoray if errors
are suspected. In no event shall Sensoray be liable for any damages arising out of or related
to this document or the information contained in it.
E
XCEPT AS SPECIFIED HEREIN, SENSORAY MAKES NO WARRANTIES, EXPRESS OR
IMPLIED, AND SPECIFICALLY DISCLAIMS ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. CUSTOMER’S RIGHT TO RECOVER DAMAGES
CAUSED BY FAULT OR NEGLIGENCE ON THE PART OF SENSORAY SHALL BE LIMITED
TO THE AMOUNT THERETOFORE PAID BY THE CUSTOMER. SENSORAY WILL NOT BE
LIABLE FOR DAMAGES RESULTING FROM LOSS OF DATA, PROFITS, USE OF PRODUCTS,
OR INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE
POSSIBILITY THEREOF.
Third party brands, names and trademarks are the property of their respective owners.
Page 5
5
Introduction
Sensoray's 4000 series of compact digital video recorders (DVRs) is targeted for
embedded OEM applications. The family currently includes models 4011, 4012 and 4013.
All of those record audio and video (A/V) to USB storage media and can capture JPEG
images on-the-fly without interrupting the recording. The units output live or recorded
video, or JPEG snapshots to an external composite monitor. Date and time are
maintained by a real-time clock with battery backup. Implementing a complete DVR
requires connecting power, a custom keypad or a keyboard, and a USB storage
device(s).
The DVRs encode standard NTSC/PAL composite video using efficient H.264
compression. Audio is digitized and compressed using AAC encoding. The compressed
A/V streams are multiplexed and recorded as MP4 or transport stream (.ts) files on a
user-supplied USB storage device, with file names automatically generated by the realtime clock. Videos and snapshots are saved to the /DCIM directory on the storage
device(s). Bit rates can be tailored to match application requirements and storage
capacity.
Models 4012 and 4013 include two incremental encoder interfaces, which allow position
information to be captured in real time and overlaid directly onto the video. The DVR
provides power to the encoders, 5 or 12V, selectable with a switch (model 4013) or a
jumper (model 4012). Each encoder's power line is protected by a 0.2A resettable fuse.
Various text overlays can be applied to appear in the recorded video and preview.
An external USB storage device is required for DVR operation. If desired, a second USB
storage device may also be connected and the DVR will simultaneously record to both
devices. A common application for this is recording to a removable device while
creating an archival copy on a non-removable device. USB connectors are located on
both sides of the board to facilitate connection to both removable and embedded
storage devices.
The DVR user interface supports a user-supplied keypad working in conjunction with
the board's flexible on-screen menu system. Keypad switches functionality is
configured to match the control scheme of your custom keypad. If preferred, a standard
keyboard can be plugged into any of 3 available USB ports and used to control the DVR.
All members of the 4000 series use the same firmware. Some features are available on
particular models only. Connector pinouts are listed for each model in respective
chapters below. Differences between the models are summarized in Table 1.
Page 6
6
Table 1. Summary of differences between the members of 4000 series.
Features 4011 4012 4013
External USB ports
vertical
vertical
right
-
angle
Incremental encoder interfaces
0 2 2
Built-in microphone yes yes no
Line audio input no optional yes
RS-232 (Note 1)
optional
yes yes
Note 1: Firmware implementation of RS-232 communications requires knowledge of
application specific protocols and is provided on a custom basis. Please contact
Sensoray if this feature is required.
Page 7
7
Connectors
USB Connectors
There is a total of three USB 2.0 connectors on all models: two on the top side and a
single connector on the bottom side. All connectors are functionally interchangeable.
The only difference is that a storage device plugged into the connector on the top side
is considered “external”, on the bottom side – “internal”.
Model 4011
Power
J11, Molex 0705530002.
Mating part: Molex 0050579403, crimping contacts Molex 0016020102.
Pin Signal
1 + 12V
2 n/c
3 ground
Video
In (J10), out (J2), Molex 0705530001.
Mating part: Molex 0050579402, crimping contacts Molex 0016020102.
Pin Signal
1 video in/out
2 ground
Audio out
J13, Molex 0705530003.
Mating part: Molex 0050579404, crimping contacts Molex 0016020102.
Page 8
8
Pin Signal
1 left channel
2 ground
3 ground
4 right channel
Keypad
J4, Molex 90500-4007 or TE Connectivity 5-520314-7, 7 pin.
Accepts a ZIF-style flex tail, 0.1” pitch.
Recommended mapping for keypad pins and functions:
Pin Function Signal
1 Record/Pause
DIO33V0
2 Stop/Back DIO33V1
3 Snapshot
DIO33V2
4 Down
DIO33V3
5 Menu/OK DIO33V4
6 Common (ground)
7 Up DIO33V6
Keypad functions could be remapped, as discussed in Customizations chapter, using
signal names from the table above.
Each key is expected to be a normally open tactile switch to a common line. No external
debouncing is required.
RS-232
Optional, J7, Molex 53047-0310.
Mating part: Molex 0510210300, crimping contacts 0500588000.
Pin Signal
1 TX
2 RX
3 ground
Page 9
9
Model 4012
Power
J11, Molex 0705530001. Mating part: Molex 0050579402.
Pin Signal
1 ground
2 +12 V DC
Video
In (J10), out (J2)
Molex 0705530002. Mating part: Molex 0050579403.
Pin Signal
1 video
2 ground
3 not connected
Audio out
J13, Molex 0705530003. Mating part: Molex 0050579404.
Pin Signal
1 left
2 ground
3 ground
4 right
Keypad
J1/J4, Standard part: Amphenol/FCI 76382-407LF, 7 pin.
Options:
76382-408LF – 8 pin;
76382-409LF – 9 pin;
76382-410LF – 10 pin.
Page 10
10
Mating connectors: Amphenol/FCI 65801-007LF, 65801-008LF, 65801-009LF, 65801010LF.
Standard pinout:
Pin Function Signal
1 Record/Pause
DIO33V0
2 Stop/Back DIO33V1
3 Snapshot
DIO33V2
4 Down
DIO33V3
5 Menu/OK DIO33V4
6 common (ground)
7 Up DIO33V6
Keypad functions could be remapped, as discussed in Customizations chapter, using
signal names from the table above.
Each key is expected to be a normally open tactile switch to a common line. No external
debouncing is required.
Incremental encoders
JP1, JP2, Molex 0532610671. Mating part: Molex 0510210600.
Pin Signal
1 Power. Selected with JP3 (+5V or +12V). Pro-
tected with a 0.2A resettable fuse
2 A+
3 A4 B+
5 B6 Ground
Note: If using single ended encoder signals, leave the negative line (A-, B-) unconnected.
RS-232
J18, Molex 0705530002. Mating part: 0050579403.
Optional, J7, Molex 53047-0310. Mating part: Molex 0510210300, crimping contacts
0500588000.
Page 11
11
Pin Signal
1 TX
2 RX
3 ground
Page 12
12
Model 4013
Video
J2, Samtec IPL1-106-02-L-SH-K.
Mating part: Samtec IPD1-06-S-K, crimp terminals CC79L-2630-01-L.
Pin Signal
1 n/c
2 ground
3 video in
4 n/c
5 ground
6 video out
Power
J11, Samtec IPL1-102-02-L-SH-K.
Mating part: Samtec IPD-02-S-K, crimp terminals CC79L-2630-01-L.
Pin Signal
1 ground
2 +12 V DC
Incremental encoders
JP1, JP2, Samtec T1M-06-GF-SH-L-K.
Mating part: Samtec ISS1-06-L, crimp terminals CC09M-01-GF.
Pin Signal
1 encoder power (+)
2 A+
3 A-
4 B+
5 B-
6 ground
Note: If using single ended encoder signals, leave the negative line (A-, B-) unconnected.
Page 13
13
Keypad
J1, Samtec IPL1-110-02-L-SH-K.
Mating part: Samtec IPD1-10-S-K, crimp terminals CC79L-2630-01-L.
Recommended mapping for keypad pins and functions:
Pin Function Signal
1 unused
2 Encoder #2 reset
DIO33V8
3 Encoder #1 reset
DIO33V7
4 Up DIO33V6
5 Common (ground)
6 Menu/OK
DIO33V4
7 Down DIO33V3
8 Snapshot DIO33V2
9 Stop/Back
DIO33V1
10 Record/Pause DIO33V0
Keypad functions could be remapped, as discussed in Customizations chapter, using
signal names from the table above.
Each key is expected to be a normally open tactile switch to a common line. No external
debouncing is required.
Audio in
J17, Samtec T1M-03-F-SV-L-P.
Mating part: Samtec ISS1-03-L, crimp terminals CC09M-01-GF.
Pin Signal
1 ground
2 Right
3 Left
Page 14
14
Audio out
J13, Samtec IPL1-104-02-L-SH-K.
Mating part: Samtec IPD1-04-S-K, crimp terminals CC79L-2630-01-L.
Pin Signal
1 Right
2 ground
3 ground
4 Left
RS-232
J18, Samtec IPL1-103-02-L-SH-K.
Mating part: Samtec IPD1-03-S-K, crimp terminals CC79L-2630-01-L.
Pin Signal
1 TX
2 RX
3 ground
Page 15
15
Overlays
DVRs support a wide choice of text overlay information displayed on the preview,
recorded video, and screen shots. Overlay's position on the screen, font size and
background transparency can be adjusted.
The overlays are divided into primary and secondary overlay groups. One selection
from each group can be displayed on the screen at any time. Overlay transparency and
screen position can be set separately for each group.
Primary overlay
Primary overlay allows display of one selection of the following data:
1. Date/time
2. Encoder reading
3. Arbitrary text
Date and time display supports various formats. Encoder readings are converted into
length units (feet or meters). Up to five arbitrary text messages (up to 40 characters long)
can be stored and later selected for display, one at a time.
Secondary overlay
Secondary overlay allows display of one selection of the following data:
1. Title overlay
2. Coded overlay
3. Extra overlay
4. Additional overlay
Title overlay is an arbitrary text (32x14 characters) that could be entered and saved
to/loaded from a file on the internal or external storage device (parameters.txt).
Coded overlay allows assigning a 2-letter code to text messages and retrieving those for
display by typing in the code (a USB keyboard is required). Coded overlays are stored
in a file on the internal or external storage device (codes.txt). Codes and
corresponding messages could be entered using a standard USB keyboard connected to
the unit, or codes.txt file could be created on a computer and transferred to the USB
storage device. Codes are separated from messages with one or more spaces.
Page 16
16
Extra overlay is similar to Title overlay. It is an arbitrary text (32x14 characters) that
could be entered and saved to/loaded from a file on the internal or external storage
device (extra.txt). Additional overlay is similar to Extra overlay and is loaded from
addl.txt.
Page 17
17
Menu system
The DVRs are controlled using a keypad or a standard keyboard and the on-screen
menu system.
Context-dependent keyboard functions mapping:
Key
Functions
Outside of the menu Inside the
menu
Enter, Space Menu OK
F2 Menu
Up arrow Rewind by set amount Move up
Down arrow
Fast forward by set amount
Move down
Escape Stop Back
R Record/Pause
S Snapshot (screen shot)
P Pause toggle during recording or
playback; Play video otherwise
M Mute toggle
F Fast forward by set amount
D Rewind by set amount
K Keypad mapping menu
O Overlays menu
T Title overlay toggle
C Coded
overlay toggle
E Extra overlay toggle
F4 Toggles the mode that allows adjusting
the current secondary overlay position
with arrow keys
Page 18
18
Context-dependent keyboard functions mapping (continued):
Key
Functions
Outside of the menu Inside the
menu
F6 Resets the first incremental encoder
footage to 0 without affecting the
calibration factor
F10 Enters the free text mode. Escape exits the
free text mode
Top menu
Play video
View snapshots
Overlays
File management
Setup
Help with Keys
Play video
Plays video recordings stored on the media. Selecting “Play video” brings the next
menu level:
===Play video source===
Internal
External
Selections are displayed if both internal and external storage devices are present. If
only one is present, the files list is displayed. File selection is made using arrow keys.
Pressing OK/Enter starts playback. Escape or Stop terminates the playback.
View snapshots
Displays snapshots (.jpg) stored on the media. Behavior is similar to “Play video”.
Overlays
Brings up Overlay menu:
Page 19
19
==Overlays==
Primary Overlay:
Toggles the overlay text on or off. Allows selecting one of 2 font sizes.
Setup Primary Overlay
Allows setup of Primary overlay. The available options are:
Text
Brings up Select Overlay Text menu.
== Select Overlay Text==
This menu allows selection of text to be displayed on top of live
and recorded video.
The following conventions are used:
^d – current date;
^t – current time;
Products with incremental encoder additionally allow display of
encoder data:
^e – encoder #1 data;
^f – encoder #2 data.
Selected length unit (m or ft) is displayed for each encoder. Units
are selected in Rotary Encoders menu (see below).
Custom text strings set up in Custom Text menu (see below) are
also listed.
Custom text
Allows entry of up to 5 custom strings for an overlay. Only one of five is
displayed at any given time. Entry of each string is terminated by pressing
Enter key.
Date Format
Allows selection of various date formats for date overlay.
Time Format
Allows selection of various time formats for time overlay.
Background
Selects background transparency for overlays.
Move...
Page 20
20
Moves the overlay box across the screen in selected direction.
Secondary overlay
Allows selecting a secondary overlay which is displayed concurrently with
primary from the following options:
Off
Turns secondary overlay off
Title
Selects Title overlay as secondary
Coded
Selects Coded overlay as secondary
Extra
Selects Extra overlay as secondary
Addtl
Selects Additional overlay as secondary
Setup Title (Coded, Extra, Addtl) Overlay (T, C, E, A)
== Title Overlay ==
Edit Text
Allows manual text entry
Load
Loads from parameters.txt
Save
Saves parameters.txt
Text size
Selects text size
Background
Selects background transparency
Move…
Selects overlay's position on the screen
File management
Selecting “File management” brings up the following selections (selections depend on
the presence of internal and/or external drives):
Copy video from internal
Copy video from external
Copy snapshots from internal
Copy snapshots from external
Delete files from internal
Delete files from external
Rename files on internal
Page 21
21
Rename files on external
Select files:
The last item allows switching between individual and group files selection. The
latter allows selecting files for a group operation (copy or delete).
Setup
Selecting “Setup” brings up the next menu level:
== Setup ==
Set Date/Time
Allows setting the battery backed-up real-time clock. The real-time clock is used to
automatically generate file names for saved video files and snapshots. There is also
an option of having the date/time text overlay present in recorded video and
snapshots.
Video
Brings up Video setup menu:
==Setup Video==
Video Standard
Allows selecting between NTSC and PAL.
Interpolate
Turning interpolation ON gets rid of motion artifacts at an expense of some
vertical resolution loss.
Video Bit Rate
Determines the compression level of recorded video. The higher the bit rate,
the higher is the quality, the more space is required on the storage device.
Playback Seek
Adjusts the amount (in seconds) of time skipped when using Rewind and
Fast Forward functions.
Snapshot quality
Adjusts the compression level of JPEG snapshots. The higher the setting, the
higher the quality and the larger the file size.
Snapshot overlay
Determines whether the overlay is present on snapshots.
Recording at power-on
Page 22
22
When set to ON recording starts automatically once the board is powered on
with approximately 20-30 second boot delay.
Recording format
Presents a choice of MP4 or TS (transport stream). Default is MP4 (for
compatibility reasons). TS format, which is now supported by most hardware
and software players, may be preferable because of better robustness in case
of an accidental recording interruption, for example, due to a power loss.
Audio
Brings up Audio setup menu:
==Setup Audio==
Audio Volume
Adjusts input volume. The higher the value the louder recorded audio is.
Audio AGC
Turns audio automatic gain control on or off.
Mute Recording at Start
Selecting “Mute” disables audio recording each time recoding is started.
Selecting "Unmute" enables audio recording each time recording is started.
Selecting "Disabled" keeps the current setting at the start of the recoding (set
previously with a keyboard or a keypad). Audio recording can be enabled
and disabled while recording is in progress by pressing “M” key on the
keyboard, or a corresponding (Mute/Unmute) key on the keypad.
Audio Input
Selects between microphone and line. Note that available type of input
depends on the model and assembly option of the board.
Playback Volume
Adjusts audio playback volume.
Audio passthru
Enables or disable audio pass-through.
Record Storage Device
Page 23
23
Allows selecting device(s) that video and snapshots are recorded to: internal,
external or both. If "Prompt" option is selected the user is prompted each time a
recording is started.
Rotary Encoders (models 4012, 4013 only)
Brings up Select Encoder menu.
==Select Encoder==
Encoder 1
Encoder 2
Allows selecting one of the two available encoder interfaces. Selecting one of
those brings up Setup Encoder 1(2) menu:
==Setup Encoder 1(2)==
Units
Selects length units, meters or feet.
Set Zero Point
Sets zero length point.
Set calibration point
In order to calibrate encoder readings in length units the known length
of cable needs to be dispensed (after zero has been set). Select one of
suggested calibration points (after having dispensed the corresponding
length).
Set offset
Allows manually adjusting the offset point after the calibration.
System Information
Displays various system information, including the unit's serial number, firmware
version, detected storage devices with free space available. Additionally allows
managing system parameters.
Reset system parameters
Resets system parameters to default values. The defaults can be either factory, or
custom. Please see "Maintaining custom settings" section for the details.
Save system parameters
Saves current system parameters to config.txt file.
Page 24
24
Load system parameters
Loads system parameters from config.txt file.
Update firmware
This selection is available only if a firmware file is detected in the root directory of
one of the connected storage devices. Please obtain the firmware file s4011.fw
from Sensoray and copy it to a root directory of a USB drive. Update process usually
takes about 30 s, after which the board restarts. Please refer to "Firmware updates"
chapter for the details.
Update custom.zip
This selection is available if custom.zip file is detected in the root directory on one
of the connected storage devices. This file contains custom settings, such as a splash
screen and default system parameters.
Custom splash screen
The splash screen has to be created as a JPEG file with the name splash.jpg with
one of the following resolutions: 720x480 for NTSC systems, or 720x576 for PAL
systems. This file has to be placed into the directory called images, and zipped to
custom.zip. To remove a custom splash screen place a zero byte custom.zip file
into the root directory of a storage device and then select “Update custom.zip”. To
create a zero length file in Windows open a command prompt window and type
copy NUL /b custom.zip.
Custom default parameters
Custom default parameters (activated by selecting "Reset system parameters" from
"System information" menu) must be first saved to config.txt (using "Save
system parameters" from "System information" menu). The resulting config.txt
must be zipped into the root directory of custom.zip, and loaded using "Update
custom.zip" from "Setup" menu.
Turn WiFi On/Off
This selection is available only if the unit is programmed with WiFi-enabled
firmware and a WiFi adapter is detected in one of the USB ports. Please note that in
order to be detected by the DVR a WiFi adapter needs to be present at the power up.
Page 25
25
Turn WiFi ping on (available only when WiFi is turned on)
Enabling WiFi pings may help with some wireless clients (receiving devices) that
keep dropping the connection. Should be turned off normally.
Page 26
26
Firmware updates
Except for a few special cases updating the firmware is a straightforward procedure.
First, the firmware file is copied to the root directory of a storage device, the storage
device is then connected to the DVR. After that "Update firmware" selection appears in
the Setup menu. Selecting this option starts the process which takes about 30 seconds.
After that the unit automatically reboots.
The process maybe a bit more complicated when updating from a relatively old
firmware version to the new, WiFi-enabled firmware. Adding WiFi support to the
Sensoray’s family of DVRs resulted in a significantly different layout of the firmware.
Therefore the process of firmware update may be different when updating from an
older version without WiFi support to the version with WiFi support.
Update procedure:
1. Find out the current version of the firmware installed on your unit by going to Set-
up/System Information in the Menu.
2. Obtain the WiFi-enabled firmware file from Sensoray (s4011.fw, approximately 11 MB
in size). Please contact support at [email protected].
3. If the version of the firmware installed on your unit is 1660 or newer (version number is
greater or equal), skip to step 6.
4. Obtain a non-WiFi firmware file version 1660 or newer from Sensoray (s4011.fw,
approximately 6.5 MB in size) .
5. Copy non-WiFi firmware v.1660 or newer to the root directory of a USB drive, plug it
into your unit, and perform the firmware update procedure (Setup/Update firmware).
If the unit does not reboot for longer than 1 minute, cycle the power. If the pass-through
video is black, reset system parameters (Setup/System Information/Reset System Parameters). Make sure the firmware version now matches that of the firmware obtained
from Sensoray.
6. Copy WiFi-enabled firmware to the root directory of a USB drive replacing the previous
file, plug it into your unit, and perform the firmware update procedure (Setup/Update
firmware). If the unit does not reboot for longer than 1 minute, cycle the power. If the
pass-through video is black, reset system parameters (Setup/System Information/Reset
Page 27
27
System Parameters). Make sure the firmware version now matches that of the firmware
obtained from Sensoray.
7. The option “Turn WiFi on” should be now available in Setup menu section (if the WiFi
adapter is present).
Page 28
28
Customizations
Keypad functions
The 4000 series DVRs allow creating custom keypad functions and layout. The process
is simple and takes 2 steps: assigning custom keypad functions and saving the custom
layout to the flash drive. After that the units are customized by loading the custom
mapping file. Once loaded the file does not have to be present on the flash drive.
Assigning custom keypad functions requires a USB keyboard to be connected to the
DVR. Press "K" key to start the process. For each pin of the keypad connector select the
corresponding signal name (DIO33V0, etc.), press Enter, and pick a desired function or
combination of functions from the list. Once the process is complete, save the custom
configuration to the file by going to Menu/Setup/System information/Save system
parameters. The configuration is save to custom.txt file in the root directory of the
flash drive. Note that all other settings are saved as well.
To load custom settings on another system connect the flash drive with custom.txt
file present on it, and select Menu/Setup/System information/Load system parameters.
Once the parameters are loaded the system no longer needs custom.txt file to be
present on the flash drive.
Splash screen
A custom splash screen can be created as described in "Update custom.zip" section of
"Menu system" chapter.
Maintaining custom settings
There are several ways of saving and restoring custom settings. Whenever any changes
have been made to the system settings, those could be saved by using "Save system
parameters" selection from "System information" submenu. The settings are saved to
config.txt file in the root directory of either internal or external drive (selected by
the user in case both drives are present). Those saved settings can be restored later by
using "Load system parameters" selection from "System information" submenu. It is
also possible to reset parameters to factory defaults by using "Reset system parameters"
selection from "System information" submenu.
Sometimes it may be preferable for "Reset system parameters" command to reset
parameters to custom defaults instead of factory defaults. That can be done using the
Page 29
29
following procedure.
1. System parameters need to be changed, as desired.
2. Parameters need to be saved to config.txt using "Save system parameters".
3. config.txt needs to be placed into custom.zip file.
4. custom.zip must be loaded using "Update custom.zip" from "Setup" menu.
After that custom.zip no longer needs to be present on the flash drive, all the
settings are stored in the onboard non-volatile memory.
Page 30
30
Wireless
All members of the 4000 DVR series support streaming video over the wireless network. This feature requires special WiFi enabled firmware to be programmed. Please
refer to "Firmware updates" chapter for the details.
To implement a network, plug in an approved USB WiFi adapter into one of the USB
ports and power up the unit. Once the DVR boots a WiFi network named “s4011” becomes available. Please note that the WiFi adapter has to be already plugged in when
the unit is powered up.
As with any wireless network, connection is handled by the operating system of the
connecting device. The “s4011” network is unsecured. Any device can connect to it
without a password and can connect either to the video stream directly, via RTSP, or
access the browser based interface.
WiFi adapters
Only devices qualified by Sensoray are guaranteed to work. Currently the following
products are recommended:
1. Anewish Mini WiFi adapter, available from https://www.amazon.com/ANEWISH-
Mini-Wifi-150Mbps-Raspberry/dp/B017N6KI8W, or similar
2. Similar adapters based on Ralink RT5730 chipset.
3. The Edimax EW-7811Un adapter. Available from
https://www.amazon.com/Edimax-EW-7811Un-150Mbps-RaspberrySupports/dp/B003MTTJOY.
4. The Lib-Link adapter with a large antenna for extended range up to 100 feet. Avail-
able from https://www.adafruit.com/product/1030.
Please note that availability may change.
Streaming video from a DVR
By using an RTSP client a video stream can be viewed on a mobile device or a computer. There are various free programs available from Google Play or iTunes to directly
view RTSP streams. Sensoray tested two of those: VLC
Page 31
31
(http://www.videolan.org/vlc/index.html) and RTSP Player (http://rtsp-
player.soft112.com).
Boot the 40xx with an approved WiFi adapter plugged in. Select "Turn WiFi on" in the
Settings menu. Wait for the adapter to turn on ("Turn WiFi off" menu selection will replace "Turn WiFi on").
Connect your mobile device or computer to the 40xx server wireless network ("s4011").
Select "Open network stream" option in your RTSP viewing application. Type the URI
rtsp://192.168.0.100:554/streamA.h264 into the location field of the applica-
tion. Please note that the URI is case sensitive.
The default stream is video only with no sound. Other streams are available: a list
streams can be found by connecting to the 40xx device with a browser using address
http://192.168.0.100/rtsp_streams.htm. A link you want can be copied and
pasted into your RTSP stream player.
Page 32
32
Specifications
Input video Composite, NTSC or PAL, 75 Ohm
Output video
Composite, NTSC or PAL, 75 Ohm
Video compression
H.264
, High Profile at Level 3
Snapshots compression
JPEG
Recorded file format
MP4
, transport stream (.ts)
Audio
Built-in microphone (4011, 4012 - option)
Line input
(4012
– option, 4013)
USB ports
3, USB 2.0, high speed
Incremental encoder
channels
2, quadrature (4012, 4013)
Incremental encoder power
5 or 12 V (selectable), 0.1A max per channel.
Each channel protected by a 0.2A resettable fuse.
Incremental encoder input
signal range
Differential RS-422 / single-ended TTL
Power
12 V DC (± 4 V), 2.5 W (incremental encoder
power not included)
Mechanical
3.3 x 2.5 inch; height varies between models (0.8
to 1.2 inch). Please contact Sensoray for drawings
and STEP models.
Operational temperature 0 to +50 °C
Page 33
33
Revision history
Version Notes
2.1.0, July 2018 Features and menu items updated.
2.0.0, March 2017 Initial release of combined 4011, 4012, 4013 manual.
Loading...
