SENSING LABS SL SLS-LAB-6NN1 Datasheet

SL-SETTING

COMMISSIONING KIT

SL SETTING IS THE ESSENTIAL TOOL TO CONFIGURE

PARAMETERS OF SENLAB™ SENSORS.

Besides the possibility of changing Senlab™ sensors factory
settings over-the-air once the product is installed, SL Setting
commissioning kit allows to change them contactless :

• In the workshop before shipping or installation

• Directly on the eld once installed

PC VERSION

SL Setting commissioning kit is a tool that makes use of the
local UHF connectivity embedded within the Senlab™ sensors.
It is available in two versions : a windows PC version and a lighter

Android version dedicated to eld operation. (Note that a Linux

version is also available on request).

ANDROID
VERSION

www.sensing-labs.com

SL SETTING IS MADE UP WITH A USB UHF READER

AND A SOFTWARE PROGRAM

REFERENCES SLS-LAB-6NN1 KIT-LAB-7NND

PREREQUISITES & CONTENT PC VERSION ANDROID VERSION

Operating system (OS)

Connectivity

Content

Windows 10, Windows 8.x, Windows 7 Android 5.0 Lollipop or greater

USB2 typeA male 0.8m cable provided USB2.0 OTG micro-B male 1m cable provided

- Support with integrated magnet and

RFID reader, to facilitate product
positioning and conguration.

- 0.8m USB 2.0 cable for connecting the
hardware to the PC

- SL Setting software for PC on USB key
with licence

CHANGE YOUR DEVICE PARAMETERS IN ONLY 20 SECONDS

AVAILABLE FEATURES

Activation type cfg. (ABP, OTAA with AppEUI)

AppEUI

Application parameters (datalogging period, alarms settings,…)

Magnet switch off activation/desactivation

PC VERSION

- RFID reader with xing element

- 1m USB 2.0 OTG cable for connecting
the player to the android device.

- SL Setting app available on Google
Play store
Licence must be requested to
[e-mail]

ANDROID VERSION

Status reading (version, battery level)

Reading of the current value of the sensor

Battery level reset (Indoor only)

Product stopping

www.sensing-labs.com

KEY FEATURES

SENLABTM NETWORK CONFIGURATION

SENLABTM MAINTENANCE

SENLABTM APPLICATION CONFIGURATION

COMMISSIONING DATA EXPORT

T : [phone]

[e-mail]

Sensing Labs - 187 rue Hélène Boucher
34170 Castelnau-le-Lez
