The information contained in this report is intended to show verification of the RF Exposure
Assessment of the SenseAnywhere ClimateSensor to the requirements of the applied test
specifications.
Objective To perform RF Exposure Assessment to determine the
Applicant SenseAnywhere B.V.
Manufacturer SenseAnywhere B.V.
Manufacturing Description ClimateSensor
Model Number(s) 20-20-50 / 20-20-51
Test Specification/Issue/Date
Equipment Under Test's (EUT’s) compliance of the applied
rules.
CFR 47 Pt1.1310 (2016)
Document 75937736 Report 09 Issue 1 Page 4 of 12
Page 6
1.2 REGIONAL REQUIREMENTS
The table below shows the regional requirements that are referenced in this test report. A full list
of the requirements is shown in Annex A.
Report Reference Regional Requirement
FCC CFR 47 Pt1.1310 (2016)
Document 75937736 Report 09 Issue 1 Page 5 of 12
Page 7
1.3 PRODUCT INFORMATION
1.3.1 Technical Description
The Equipment under test was a SenseAnywhere B.V. ClimateSensor. A full technical
description can be found in the manufacturer’s documentation.
All reported calculations were carried out on the relevant information supplied for the
SenseAnywhere ClimateSensor to demonstrate compliance with the applied test specification(s).
The sample assessed was found to comply with the requirements of the applied rules.
1.3.2 Supported Features
The following radio access technologies and frequency bands are supported by the equipment
under test.
Radio Access Technology 900 MHz SRD
Frequency Band 902 MHz to 928 MHz*
*The EUT was a single channel device with an operating frequency of 915.3 MHz.
1.3.3 Antennas
The following antennas are supported by the equipment under test.
No. Model Gain(dBi)
1 Not Specified -1
The wireless device described within this report has been shown to be capable of compliance
with the basic restrictions related to human exposure to electromagnetic fields for both General
Public and Occupational. The calculations shown in this report were made in accordance with
the procedures specified in the applied test specification(s).
Required Compliance Boundary (m)
Occupational General Population
0.01 0.01
Table 1 – Compliance Boundary Results
Document 75937736 Report 09 Issue 1 Page 6 of 12
Page 8
Calculated RF exposure level at compliance boundary of 0.01 m
Regional
Requirement
FCC* 0.0100 3.0510 N/A N/A N/A N/A
S Field (W/m2) E Field (V/m) H Field (A/m)
Result Limit Result Limit Result Limit
* Requirement and Result in mW/cm2
Table 2 – Occupational Results
The calculations show that the EUT complies with the occupational exposure levels described in
the and CFR 47 Pt1.1310 (2016) at the point of investigation, 0.01 m.
Calculated RF exposure level at compliance boundary of 0.01 m
Regional
Requirement
FCC* 0.0100 0.6102 N/A N/A N/A N/A
S Field (W/m2) E Field (V/m) H Field (A/m)
Result Limit Result Limit Result Limit
* Requirement and Result in mW/cm2
Table 3 – General Population Results
The calculations show that the EUT complies with the general population exposure levels
described in the and CFR 47 Pt1.1310 (2016) at the point of investigation, 0.01 m.
Document 75937736 Report 09 Issue 1 Page 7 of 12
Page 9
SECTION 2
TEST DETAILS
Document 75937736 Report 09 Issue 1 Page 8 of 12
Page 10
r
r
2.1 RATIONALE FOR ASSESSMENT OF THE RF EXPOSURE
The aim of the assessment report is to evaluate the compliance boundary for a set of given input
power(s) according to the basic restrictions (directly or indirectly via compliance with reference
levels) related to human exposure to radio frequency electromagnetic fields.
The chosen assessment method to establish the compliance boundary in the far-field region is
the reference method as defined in the relevant specifications.
The RF exposure assessment is based upon the following criteria:
The SenseAnywhere ClimateSensor operates with the following transmitters active on the
antenna ports shown in Section 1.3.3. For each transmitter, the Radio Access Technology (RAT),
EIRP inclusive of antenna gain and duty cycle, gain of the antenna and lowest frequency of
operation are shown as they contribute to the calculation of S Field, E field and H field values
according to the following formulas.
The power flux (S Field):
PG
S
),(
2
4
The electric field strength (E Field):
E
PG
),(30
The magnetic field strength (H Field):
E
H
o
Where:
P = Average Power (W)
G = Antenna Gain (dBi)
r = Distance (cm) or (m)
o
= 377
Document 75937736 Report 09 Issue 1 Page 9 of 12
Page 11
2.2 TEST RESULT DETAILS
The frequencies shown in the tables below have been chosen based on the lowest possible
frequency that the EUT can transmit.
