ProPhonic 2X-S & 2MAX Earphones
Thank you for your purchase of Sensaphonics custom
earphones, the most comfortable isolating earphones
available. This User Guide covers both the ProPhonic
2X-S and the 2MAX models, as they utilize the same
construction, from their soft silicone earpieces to their
strong yet supple cables. Both models are designed
for high-resolution audio monitoring while providing up
to 37 dB of isolation from ambient noise. The 2MAX is
optimized for use with wireless personal monitor systems,
incorporating a “louder, faster” response characteristic that
is useful in situations where the earphones must share their
power supply with IEM receiver circuitry. Please take a few
minutes to familiarize yourself with the proper usage and
care of your new earphones. Carefully read and follow all
cautions and instructions.
IMPORTANT SAFETY PRECAUTIONS
Do not use this product while operating motorized vehicles
or heavy machinery, while bicycling or jogging near trafc,
or in any potentially hazardous situation where there is a
need to hear ambient noise.
• Consult your authorized Sensaphonics audiologist
before use.
• DO NOT use at excessive volume levels.
• Avoid dropping or strong impact.
• DO NOT pull on cord to remove it from the jack, or to
remove earphones from your ears. Always grasp the
earpiece or jack for removal.
• DO NOT leave the cord where it can be tripped over.
• DO NOT expose in-ear monitors to temperature
extremes (such as a closed auto in the sun).
• Keep your earphones away from water and dust.
SOUND LEVELS AND HEARING PROTECTION
We strongly recommend that you learn to monitor at lower
levels. The ProPhonic 2X-S and 2MAX make this possible
by virtually eliminating ambient noise. You’ll be surprised at
the full, rich sound you can get when properly isolated from
unwanted noise!
Noise induced hearing loss (NIHL) is a function of exposure
time, average noise level and peak level of very loud
sounds. The table below shows recommended daily
exposure limits based on NIOSH and OSHA guidelines.
These numbers predict average risk across the population,
not individual risk. It’s important to realize that some
people are more susceptible to hearing loss than others.
The excess risk of developing NIHL is 8% using the
NIOSH guideline and 25% using OSHA. (Source: NIOSH
Publication #980126)
SAFE EXPOSURE TIME
Sensaphonics strongly recommends that you use the
NIOSH scale as your guide. Keep in mind that these
guidelines are for exposure during the entire day, from
all sources. Also, it’s important to realize that hearing
damage often occurs without common warning signals
like tinnitus. The only sure way to know if you are
experiencing hearing loss is through annual testing.
We strongly recommend that you see your audiologist
regularly!
For more information, please visit www.sensaphonics.com.
MAINTENANCE AND CLEANING
Keeping your earphones clean is essential! Earwax can block the
sound ports, resulting in reduced output or distortion. To clean the
sound ports, utilize the supplied cleaning tool before each use.
Use the tool’s wire loop to dislodge larger pieces, then clear them
away with the brush.
CABLE REPLACEMENT
The earphone cable is eld replaceable. It is secured by a small
nylon screw at each earpiece. Replacement cables are available.
TECHNICAL SPECIFICATIONS
The ProPhonic 2X-S and 2MAX are custom molded, full-shell soft
silicone earphones, with each earpiece containing two balanced
armature drivers. The earphones are terminated in a standard
1/8-inch stereo mini-plug.
ProPhonic 2X-S 2MAX
Freq. response 20-16,000 Hz 20-16,000 Hz
Impedance 27 Ohms minimum 23 Ohms minimum
Sensitivity 100 dB-SPL at 0.1 V. 105 dB-SPL at 0.1 V.
Isolation up to 37 dB up to 37 dB
Weight 1 ounce (approx) 1 ounce (approx)
Cable: Field replaceable, 52- or 60-inch, matte silver or black
Supplied Accessories: Hard-shell road case, shirt clip, 1/8"–1/4"
adapter, pocket storage pouch, cleaning tool
For spare/replacement parts or repairs, contact Sensaphonics.
Toll-free (US): 877-848-1714
International: 312-432-1714
Fax: 312-432-1738
Email: [email protected]
Sensaphonics Hearing Conservation, Inc.
660 N. Milwaukee Avenue
Chicago, IL 60642
© 2009 Sensaphonics Hearing Conservation, Inc.
Page 2
Custom Earphone
Insertion Instructions
STEP 1
Hold earpiece with
red or blue dot on top.
Blue = left, red = right.
The cables should run
over and behind your ears.
STEP 2
Place canal portion of
the earpiece into your
ear canal.
STEP 3
Rotate the earpiece
toward the back of your
head as you push the
earpiece in.
STEP 4
Make sure top portion
of earpiece is tucked in.
If the earpiece is not all
the way in, you will not
have a good seal and may
lose bass response. See
Step 5 photo for correct
placement.
STEP 5
Once in the ear, don’t be
afraid to push on the canal
portion of the earpiece to
make sure it is all the way
in. You may need to pull
back on your ear while
pushing it in.
STEP 6
Cables can be adjusted to
t close to your head by
moving the split adjuster
(zipper) up or down.
To conrm that you have
a good, full seal, go to
www.sensaphonics.com/test
and download our audio
seal test.
REMOVAL
Never pull on the cable to remove earpieces! Instead,
reach behind the earpiece at the bowl of the ear and
twist the earpiece toward your nose as you remove it.
Simple!
With a little practice, inserting your
Sensaphonics earpieces will become quick
and easy. Just follow these simple steps.
