Please read this manual carefully
before using this TV set and keep it
for future reference.
LCD TV & LCD TV/DVD Combo
USER MANUAL
S1500U/S1900U/S1900UDVD
WARNING AND CAUTION
RISK ELECTRIC SHOCK
DO NOT OPEN
CAUTION
!!
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of
uninsulated dangerous voltage within the product s
enclosure that may be of sufficient magnitude to constitute a
risk of electric shock.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
!!
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS
POLARIZED PLUG WITH AN EXTENSION CORD,
RECEPTACLE OR OTHER OUTLET UNLESS THE
BLADES CAN BE FULLY INSERTED TO PREVENT
BLADE EXPOSURE.
CAUTION: These servicing instructions are for use by qualified service
personnel only. To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating instructions unless
you are qualified to do so.
CAUTION: USE OF ANY CONTROLS, ADJUSTMENTS, OR PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE. (This item is only for TV with DVD models.)
IMPORTANT SAFETY INSTRUCTIONS
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long
periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
15)The apparatus shall not be exposed to dripping or splashing and that no
objects filled with liquids, such as vases, shall be placed on the apparatus.
16)The mains plug or appliance inlet is used as the disconnect device, remain it
readily operable during the apparatus normal use.
Safety Instructions(for TV with DVD)
PRECAUTIONS
FCC WARNING-This equipment may
generate or use radio frequency
energy.Changes or modifications to this
equipment may cause harmful
interference unless the modifications are
expressly approved in the instruction
manual.The user could lose the authority
to operate this equipment if an
unauthorized change or modification is
made.
CAUTION:USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE.
LASER SAFETY
This unit employs a laser.Only a qualified
service person should remove the cover
or attempt to service this device,due to
possible eye injury.
CAUTION:VISIBLE AND INVISIBLE
LASER RADIATION WHEN OPEN AND
INTERLOCK DEFEATED.DO NOT
STARE INTO BEAM.
LOCATION:INSIDE,NEAR THE DECK
MECHANISM.
CONTENT
Note: DVD is available only on certain models. Please refer to your original set
for specific details.
Safety Notice Items...................................................................................
Front Panel Controls..................................................................................
Connection Options...................................................................................
Remote Control ........................................................................................
Remote Control Key Functions...................................................................
.................................................................
Connection Instructions.............................................................................
Grounding..............................................................................................
External equipment Connections..............................................................
Antenna Connection.............................................................................
VGA Setup.............................................................................................
Component Setup................................................................................
VCR Setup...........................................................................................
HDMI Input.........................................................................................
Cable TV Setup....................................................................................
External Component Source Setup.......................................................
Basic Operating Instructions.......................................................................
Switch On/Off the TV set..........................................................................
Choose the input source..........................................................................
Audio Control..........................................................................................
Mute......................................................................................................
INFO.....................................................................................................
Select the TV Channel You Want.............................................................
Picture Mode...........................................................................................
Audio Mode............................................................................................
Sleep.....................................................................................................
GUIDE...................................................................................................
ARC button.............................................................................................
-button...................................................................................................
CH.LIST button.......................................................................................
FAV.LIST button......................................................................................
Menu Operations.......................................................................................
Video Menu Options...............................................................................
Video Menu Options Continued...............................................................
Audio Menu Options................................................................................
Audio Menu Options Continued................................................................
Channel Menu Options.............................................................................
Channel Menu Options Continued..............................................................
Function Menu Options.............................................................................
Function Menu Options Continued..............................................................
Lock Menu Options ..................................................................................
Lock Menu Options Continued..................................................................
PC Menu Options....................................................................................
DVD Features..........................................................................................
Special Function Playback.......................................................................
DVD System Setup...................................................................................
Playable Discs.........................................................................................
Disc Protection and DVD Characteristics...................................................
Troubleshooting Guide...............................................................................
Specifications...........................................................................................
Installing a wall mount bracket
1
2
3
4
5
7
8
8
8
8
9
9
10
10
11
11
12
12
12
12
12
12
13
13
13
13
13
13
14
14
14
15
15
16
17
18
19
20
21
22
25
25
30
31
33
34
38
39
40
41
Safety Notice Items
Incorrect usage may cause fire or electric shock.
ensure
Please keep this manual for later use;
Please comply strictly with the warning instructions on the machine and
in this book;
Before operation, please make sure that the operating voltage of your unit is
correct;
Do not remove the back cover. If service is needed, please contact an
Authorized service technician.
To prevent this, please do as
required when you are installing, using and cleaning this machine. To
your safety and extend the life-span of LCD-TV, please read the following items
carefully before using:
l Please read and understand all the instructions before operation;
l
l
l Please comply with the instructions provided;
l Please do not use additional devices that are not recommended by
manufacturer:
l
l Do not place the unit on unstable, dusty and humid places;
l Never put the unit in direct sunlight or near heat sources;
l Allow enough space for proper ventilation;
l Please keep water away from the LCD-TV . If water comes in contact with the
LCD-TV, disconnect the power cord from the power source, then wipe the set
with a dry soft cloth;
l
Front Panel Controls
Control Panel Function
1. Power
2. INPUT
3. MENU Press to select the main menu
4. VOL- Volume down / Left button to adjust the item in the OSD
VOL+ Volume up / Right button to adjust the item in the OSD
5. CH- TV channel down / to select the item in the menu
CH+ TV channel up / to select the item in the menu
6. Power indicator
7. Remote Sensor
Press to turn on your TV or to put it in standby mode.
To disconnect all power, unplug the power cord.
Lights red when your TV is in standby mode.
Lights blue when your TV is turned on.
Selects the input signals/In menu mode, press to enter.
Receives the signals from the remote control
INPUT MENU VOL- VOL+ CH- CH+ POWER
Connection Options
The above figure is for reference only, connections
may differ depending upon the models and terminals
of some models may be on the back bottom of the set
DVD insert
Label towards back
COMPONENT IN
Pr Pb Y
ATN IN R-AUDIO-L R-AUDIO IN-L
PC AUDIO IN
VGA IN HDMI 2 HDMI 1
S-VIDEO IN
VIDEO
1.ANT IN(Antenna Input)
Headphone
3.Audio in
Audio in
Video in
VGA
PC audio in
HDMI2
HDMI1
Component Input Connect a component video device to these jacks.
Connect cable or antenna signals to the TV, either
directly or through your cable box.
2.
Connect audio output from an external device to these jacks.
4.S-VIDEO Connect S-Video out from an S-Video device to the jacks.
5. Connect audio output from an external device to these jacks.
6. Connect video output from an external device to this jack.
7. Connect to the VGA 15PIN analog output connector of a PC
graphics card to use set as a PC display.
8. Connect the audio output from the pc to the PC audio input port.
9.
10.
Connect to HDMI output of other equipment.
Connect to HDMI output of other equipment.
11.
Please see the real set
of the DVD position
STOP
PLAY/PAUSE
OPEN/CLOSE
PREV
NEXT
DVD
Remote Control
Installing Batteries
Remove the battery cover.
Insert two size AA batteries matching
the +/-polarities of the battery to the +/marks inside the battery compartment
(see image 1-for remote of TV with
DVD) ..
Precautions
Make sure that there is no obstacle
between the remote controller and
television set.
As strong light may interfere with the
signals, change your position to operate
the remote control if the television
cannot be turned on or off as expected.
Keep the remote control away from
heat sources or humid areas to
ensure effective performance of
the remote.
Make sure that two AA 1.5V or AAA
depending up the model alkaline
batteries are loaded. The batteries must
be of the same type, must be inserted
properly, and must not be rechargeable.
Insert two size AAA batteries matching
the +/-polarities of the battery to the +/marks inside the battery compartment
(see image 2-for remote of TV without
DVD) .
Image 1
Image 2
Power
DVD Open/close
Input selection
TV Sleep button
TV/DVD
Mute
Return to previous channel in TV mode
Program Infromation
Program Number
Select MONO,STEREO, SAP in NTSC system
CC( closed caption) On / Off
Select additional channels
Adjust Picture Mode
Volume/Channel Selection
MENU
Confirm button
Adjust sound mode
DVD STOP
DVD SUBTITLE
DVD SETUP
DVD PAUSE/STEP
DVD FAST REVERSE
DVD FAST FORWARD
DVD MENU
DVD Next Chapter
DVD Previous Chapter
DVD REPEAT
DVD PLAY/ENTER
DVD A-B REPEAT
DVD Cursor Move button
DVD SLOW
DVD ANGLE
DVD SEARCH
DVD AUDIO Mode
DVD TITLE/PBC
DVD PROGRAM Zoom Function
DVD CALL DVD 10+
Exit On Screen Display
Select the aspect ratio
Shows program schedule in TV
Open the channel list in TV
Open the favourite channel list in TV
Remote Control Key Functions
When using the remote control, aim it
towards the remote sensor on the TV
Buttons on the remote control
UP
DOWN
LEFT
RIGHT
POWER TV/DVD
OPEN/CLOSE
SLEEP Q.VIEW
INFO
MUTE
1 2 3 4
5 6 7 8
9 0
CC
P.MODE
CH+
CH-
VOL
-
VOL
+
MENU
OK S.MODE
STOP
SETUP
PAUSE/STEP
REV FWD . PREV NEXT
D.MENU
REPEAT
A-B
PLAY/ENTER
SLOW
ANGLE
TITLE/PBC SEARCH
ZOOM
D.CALL
PROGRAM
EXIT ARC GUIDE
SUBTITLE
SAP
INPUT
AUDIO
CH.LIST FAV.LIST
10+
(For TV with DVD)
Remote Control Key Functions
When using the remote control, aim it
towards the remote sensor on the TV
Mute
Return to previous channel in TV mode
Input selection
Program Number
Select MONO, STEREO, SAP in NTSC system
Confirm button
Volume/Channel Selection
CC ( closed caption) On / Off
TV Sleep button
Shows program schedule in TV
Select the aspect ratio
Open the favorite channel list in TV
Open the channel list in TV
Adjust sound mode
MENU
Select additional channels
Adjust Picture Mode
Exit On Screen Display
Program Infromation
Power
Buttons on the remote control
MUTE
Q.VIEW INFO
INPUT EXIT
SAP P.MODE
CC
CH+
CH-
VOL
-
VOL
+
MENU
SLEEP S.MODE
GUIDE ARC CH.LIST
FAV.LIST
OK
(For TV without DVD)
Note: the instruction on this manual takes
remote of TV with DVD for example.
1.Remove the four M4 screws holding
your TV to the stand.
2.Secure the wall mount bracket to the
back of your TV using four M4 screws,
as indicated in the illustration.
To attach a wall mount bracket to your TV:
CAUTION
These servicing instructions are for use
by qualified service personnel only.
To reduce the risk of hazards do not
perform any servicing other than that
contained in the operating instructions
unless you are qualified to do so.
Installing a wall mount bracket
Connection Instructions
Ensure that you connect the grounding / earth wire to prevent possible
electric shock. If grounding methods are not possible, have a qualified
electrician install a separate circuit breaker. Do not try to ground the
unit by connecting it to telephone wires, lightening rods, or gas pipes.
Grounding
External Equipment Connections
Antenna Connection
Antenna or Cable Service with a Cable Box Connections
For optimum picture quality, adjust antenna direction if needed.
Multi-family Dwellings/Apartments
(Connect to wall antenna socket)
wall antenna
socket
VHF antenna
UHF antenna
outdoor
antenna
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Bronze Wire
Be careful not to bend the bronze
wire when connecting the antenna.
Bronze Wire
Turn clockwise to tighten.
RF coaxial wire (75 ohm)
To improve picture quality in a poor
signal area, purchase and install a
signal amplifier.
If the antenna needs to be split for two
Tvs, install a 2-Way Signal Splitter
in the connections.
If the antenna is not installed properly,
contact your dealer for assistance.
NOTE: Cables shown are not included with the TV
PC AUDIO IN
VGA IN
Connection Instructions
You can use your LCD-TV as a monitor for your personal computer using a VGA
cable (not supplied).
VGA Setup
Connection and use steps:
1.Read the user guide supplied with
your computer and ensure that it has
a VGA connector;
2.Make sure that the power of the LCD
-TV and the PC are off;
3.Connect a D type 15-pin PC interface
cable ( not supplied ) to the PC video
interface connector on the PC. Then
connect the other end to the PC video
interface connector on the back of the
LCD-TV.Tighten the screws on the PC
connectors once they are firmly
connected;
4.Turn on the power of the LCD-TV first ,
and then turn on the power of the PC;
5.Press INPUT button to set the video input mode of the LCD-TV to PC;
Once the input for PC is selected and if you see no image press function
F8 on you pc.
6.Check the image on your TV. There may be noise associated with the resolution,
vertical pattern, contrast or brightness in PC mode. If noise is present, change
the PC mode to another resolution, change the refresh rate to another rate or
adjust the brightness and contrast on the menu until the picture is clear. If the
refresh rate of the PC graphic card can not be changed, change the PC graphic
card or consult the manufacturer of the PC graphic card.
Component Setup
How to connect
Connect the DVD video outputs (Y, PB, PR)
to the Component(Y, Pb, Pr) IN jacks on
the TV and connect the DVD audio outputs
to the AUDIO IN jacks on the TV, as shown
in the figure.
NOTE: If your DVD player does not have
component video output,use S-Video.
How to use
1. Turn on the DVD player, insert a DVD.
2. Use button on the remote
control to select the proper input.
INPUT
Resolution
Mode
VGA
SVGA
XGA
Resolution
640x480
800x600
1024x768
Line frequency(KHz)
31.5
37.9
48.4
Frame frequency(Hz)
60
60
60
Note: All above listed are subject to VESA criteria.
COMPONENT IN
Pr Pb Y
R-AUDIO-L
S-VIDEO IN
HDMI 2 HDMI 1
COMPONENT IN
Pr Pb Y
ATN IN R-AUDIO-L R-AUDIO IN-L
S-VIDEO IN
VIDEO
Connection Instructions
VCR Setup
Connection and use steps:
1.Read the user guide supplied with your AV devices and ensure that it has
Composite or S-Video connectors;
2.Make sure that the power of the LCD-TV and the AV device are off;
.Turn on the LCD-TV first ; and then turn
on the power of the AV device;
4.Press INPUT button to set
the video input mode of the
LCD-TV to S-Video mode or
Video mode.
Connection Option 1
Set VCR output switch to 3 or 4 and then
tune TV to the same channel number.
Connection Option 2
1. Connect the audio and video cables from
the VCR's output jacks to the TV input jacks,
as shown in the figure.
When connecting the TV to VCR, match
the jack colors (Video = yellow, Audio
Left = white,and Audio Right = red).
If you connect an S-VIDEO output from
VCR to the S-VIDEO input, the picture
quality is improved; compared to conne cting a regular VCR to the Video input.
2. Insert a video tape into the VCR and press
PLAY on the VCR. (Refer to the VCR
owner s manual.)
3
To avoid picture noise (interference), leave an adequate distance between the
VCR and TV.
.
VCR
1
2
HDMI
HDMI Input
How to connect
Connect the cables from the external equipment's
output jacks to the TV input jacks, as shown in the figure.
How to use
1. Select the input source by using button
on the remote control or on the TV.
2. Operate the corresponding external equipment.
Refer to external equipment operating guide.
INPUT
R-AUDIO IN-L VIDEO
Connection Instructions
Cable TV Setup
After subscribing to a cable TV service from a local provider you can watch cable
TV programming. The TV cannot display TV programming unless a TV tuner
device or cable TV converter box is connected to the TV.
For further information regarding cable TV service, contact your local cable TV
service provider(s).
Connection Option 1
1. Select 3 or 4 with channel switch on cable
box.
2. Tune the TV channel to the same selected
output channel on cable box.
3. Select channels at the cable box or with
the cable box remote control.
Connection Option 2
1. Connect the audio and video cables from
the Cable Box's output jacks to the TV
input jacks, as shown in the figure.When
connecting the TV to a Cable Box, match
the jack colors
(Video = yellow, Audio Left = white, and
Audio Right = red).
2. Select the input source by using the
button on the remote control.
3. Select your desired channel with the
remote control for cable box.
INPUT
External Component Source Setup
How to connect
Connect the audio and video cables from
the external equipment's output jacks to the
TV input jacks, as shown in the figure.
When connecting the TV to external equipment, match the jack colors (Video = yellow,
Audio Left = white, and Audio Right = red).
How to use
1. Select the input source by using the
button on the remote control.
2. Operate the corresponding external equi pment. Refer to external equipment ope rating guide.
INPUT
COMPONENT IN
Pr Pb Y
ATN IN R-AUDIO-L R-AUDIO IN-L
S-VIDEO IN
VIDEO
Basic Operating Instructions
Switch On/Off the TV set
When the POWER button is pressed and the LCD-TV is turned on, the
indicator light on the front of the LCD-TV changes from red to When the
LCD-TV is turned off using the power button, the LCD-TV will go into standby
mode and the indicator light turns red(or turns dark).
Blue.
Audio Control
1.Press VOL+ button to increase the volume. A number will appear
on screen indicating the volume level.
2.Press VOL- button to decrease the volume. A number will appear
On screen indicating the volume level.
Mute
1.Press MUTE button to mute the sound temporarily. A mute icon
Appears on the screen.
2.Press MUTE button or VOL+ again to restore the sound.
The mute icon disappears.
Change the picture source so you can watch your TV, VCR, DVD, Cable ,
or any other devices that are connected to your TV.
1. Press button to enter the Select Source menu and then use CH+/-
button to select the desired items TV, Video, S-Video, Component DVD, PC,
HDMI .
2. Press OK button to confirm .
INPUT
Choose the input source
NOTE: The color of the indicator light may differ based upon the model purchased.
INFO
Press INFO button to display current program information.
Basic Operating Instructions
Select the TV Channel You Want
You can use the number buttons and button on the remote control to directly
select TV channels and press OK to confirm.
And you can press the buttons(CH+/CH-) on the remote control or on the panel to
make a selection.
Picture Mode
Audio Mode
Press P.MODE button on the remote control for menu display . For desired mode
as follows:
Mild Standard Vivid Custom
Sleep
Press SLEEP button to set the time : Off
This function allows you to turn off the television after a pre-selected
minutes
-5 Min-10 Min-15 Min-30 Min- 45 Min
-60 Min-90 Min-120 Min-180 Min-240Min
number of
GUIDE(only available in digital signal)
Press GUIDE button in digital channels to display Guide menu.(This menu is
just for you to see the information and can not be changed)
Press CH+/CH- to select information for you to look over.
Off Concert Living Room Hall Bathroom Cave Arena Church
Press S.MODE button on the remote control for menu display . For desired mode
as follows:
S
ARC button
Press to select the aspect ratio among Normal, Wide, Zoom and Cinema.
(Display mode may differ from different inputs)
Basic Operating Instructions
button
Press to select additional channels (digital and analog) being broadcast by the
same station. For example, to select digital channel “11.1”, press “11”, then
press “ ” and “1”.
CH.LIST button
Press to display the channel list. Press VOL+/VOL- to turn to the next or previous
page, press CH+/CH- to select the item and OK button to select the channel you
desired.
FAV.LIST button
Adding favorite channels
Press FAV.LIST under one channel. The favorite channel list opens.
Press CH+ or CH– to select a blank box, then press OK to confirm .
The channel will be added to the favorites channel list.
Press OK again, the channel will be removed from the favorites channel list.
Tuning to a favorite channel
Press FAV.LIST. The favorite channel list opens.
Press CH+ or CH– to select the channel and press OK to confirm .
Your LCD TV automatically tunes to the channel you selected.
Menu Operations
Video Menu Options
1. Press MENU button to display the main menu, and CH+/CH- to select the
main menu function.
2. Press VOL+/OK button to enter the sub menu and CH+/CH- to go up and down
to select the desired option .
3. Press VOL+/OK button to confirm and VOL+/VOL- to make changes to
the parameters
4. Press the EXIT button to return to the main menu.
5. Press the MENU button to exit the menu screen.
* In this manual, the OSD (On Screen Display) may be differ from your TV
These are examples to illustrate the TV's operation.
Press TV/AV to select the input source. The menu for each source may be
different .
Picture quality can be adjusted for any input separately .
The picture quality on the screen can be adjusted as follows:
1. Press MENU button and CH+/CH- until the following menu appears on the
screen.
2. Press VOL+/OK button to enter the menu function and CH+/CH- to scroll up
and down to select the desired function.
3.Press VOL+/OK button to confirm and VOL+/VOL- increase and decrease
the level to adjust the selected option to your preference .
4. Repeat step 2 and step 3 until desired picture quality has been achieved .
Note:
1.The options may be different because of the inputs.
2.Symbols on top of the menu in this manual may differ from the actual set display.
3.The picture options can be changed only in Custom mode only, the other modes
are fixed.
Video
Audio
Channel
Lock
Function
Video
Mode Custom
Brightness
Contrast
Color
Tint
Sharpness
Color Temperature
Advanced Video
50
50
50
0
50
Select
BackAdjust
EXITOK
CH+/VOL+/-
Menu Operations
Function:
Mode: Select the type of picture which best corresponds to your viewing
requirements by selecting Picture Mode in Video menu. You may select the
picture mode directly by pressing the P.MODE button on the remote control.
Brightness :Press CH+/CH- button and OK to confirm, then press VOL+/VOL-
to adjust the brightness of the picture.
Contrast : Press CH+/CH- button and OK to confirm, then press VOL+/VOL- to
adjust the contrast of the picture.
Color : Press CH+/CH- button and OK to confirm, then press VOL+/VOL- to
adjust color saturation.
Tint : Adjust the tone of the picture .
Sharpness : Adjust the amount of the detail enhancement , the image
sharpness rises as the number increases (By increasing the level, it will show
cleaner and clearer images and by decreasing the level, it will make the picture
smoother).
Color Temperature: This will increase or decrease Warm (red) and Cool (blue)
colors to suit personal preferences.Select Cool to give the white colors a blue tint,
Standard to give the white colors a neutral tint, Warm to give the white colors
a red tint. Custom to allow you change the color manually.
Contrast, Brightness, Sharpness , Color Temperature and Tint can only be adjusted when
Mode in Custom mode.
Advanced Video:To adjust the picture in advanced level:
DNR: Digital Noise Reduction. To adjust to reduce the appearance of digitizing
error caused by the compression:Medium,Strong,Auto,Off and weak.
Black Level Extender: To adjust the ability in the black areas detail of the
picture:On and Off.
White Peak Limiter: To adjust the ability in the white areas detail of the
picture:On and Off.
CTI: Color Transient Intensity.To adjust the picture for color errors:Medium,Strong,
Off and weak.
Flesh Tone:To adjust the flash colors:On and Off.
Adaptive Luma Control: To adjust changes in the luminance of the picture:On and Off
Video Menu Options continued
Menu Operations
You can adjust sound options to the levels you prefer.
2. Press VOL+/OK button to enter the Audio menu and CH+/CH- to go up and
down to select the desired option .
3.Press VOL+/OK button to confirm and VOL+/VOL- increase and decrease
the level to adjust the selected option to your preference .
4. Repeat step 2 and step 3 until desired audio quality has been achieved .
Function :
Balance : Press CH+/CH- button and OK to confirm, then press VOL+/VOL- to
adjust the audio output between left and right speakers.
Bass : Press CH+/CH- button and OK to confirm, then press VOL+/VOL- to
increase or decrease the level of the lower-pitched sounds .
Treble : Press CH+/CH- button and OK to confirm, then press VOL+/VOL- to
increase or decrease the level of the higher-pitched sounds
Sound Surround: To turn the simulated surround sound on and off.
Mode : Press VOL+/VOL- to select the type of sound which best
corresponds to your lightning requirements by selecting Mode in Audio
menu.
Equalizer: To adjust the equalizer: Off, Rock, Pop, Live, Dance, Techno, Classic
and Soft.
Audio Menu Options
Audio
Balance
Bass
Treble
Sound Surround On
Mode Off
Equalizer Off
AVL Off
Audio Only
0
50
50
Video
Audio
Channel
Lock
Function
Select
BackAdjust
EXITOK
CH+/VOL+/-
Sound can be adjusted for any input as follows:
1. Press MENU button and CH+/CH- until the following menu appears on the
screen.
Menu Operations
Audio Menu Options Continued
AVL This will reduces the differences in volume level among broadcasters.
Audio Only: Press VOL+/OK button to confirm, the following display will appear
on the screen:
Press VOL- to select OK , then press OK to confirm. The TV screen will
be black and no picture , but the sound is still normal.
You can press POWER button to reveal the picture on the screen.
SAP Broadcasts Setup:
This TV can receive MTS stereo programs and SAP
(Secondary Audio Program) that accompanies the stereo program;
if the station transmits an additional sound signal as well as the original one.
When having selected SAP button on the remote control, this TV can only
receive the signal when the TV station transmits the proper signals.
Mono sound is automatically received if the broadcast is only in Mono; even
though Stereo or SAP has been selected.
Select Mono if you want to listen to mono sound during stereo/SAP
broadcasting.
Stereo or SAP can be received in a Analog channel.
1. Use the SAP button to select your desired MTS mode in a analog signal.
Each time you press the SAP button, Mono, Stereoor SAP appear.
If other languages are available on the digital signal, select them with the
SAP button.
2. Press EXIT button to save and return to TV viewing.
If enter Audio Only mode, press POWER to exit!
OK Cancel
Menu Operations
Channel Menu Options
1. Press MENU button and CH+/CH- until the following menu appears on the
screen.
2. Press VOL+/OK button to enter the Channel menu and CH+/CH- to go up and
down to select the desired option .
3.Press VOL+/OK button to confirm and VOL+/VOL- increase and decrease
the level to adjust the selected option to your preference .
4. Repeat step 2 and step 3 until desired quality has been achieved .
Function:
Tuner: Press VOL+/VOL- button to select Antenna or Cable .
Channel Scan: Press VOL+/OK button to start to scan, press EXIT to cancel
All channels now available will be
automatically preset in order .After the search has finished, the first program
number will display on the screen. This search automatically adds only the
active channels in your area to the TV's memory. It deletes any channels on
which there is no broadcast or a poor signal. The channels found are
automatically saved.
Channel
Channel Scan
Status: Scanning... Antenna
Analog Channels: 4
Digital Channels: 3
Cancel
EXIT
40%
Video
Audio
Channel
Lock
Function
Select
Back
EXIT
CH+/VOL+/-
Tuner Antenna
Channel Scan
Channel Skip
Channel Label
Video
Audio
Channel
Lock
Function
Note: Channel menu will appear in main menu only in TV mode.
Menu Operations
Channel Menu Options Continued
Channel Skip
2 Analog
3 Analog
4 Analog
5 Analog
5-1 Digital
6 Analog
7 Analog
8 Analog
9 Analog
10 Analog
Select
Back
EXIT
CH+/VOL+/-
Set
OK
Channel Label: Allows you to name the channel that is selected.
INPUT
Press VOL+/OK button to enter the submenu.
Then press CH+/CH- to select Channel Index and Channel Label and
VOL+/VOL- to select the position of the item that you want to change, afterward
press to input the numbers and symbols and OK button to confirm.
Channel Skip: Press VOL+/OK button to enter the submenu then press CH+/
CH- to select the channel number (eg.2) and press OK to confirm, a mark will be
display in the pane as follows and this channel will be skipped next time you
press CH+/CH- but you can press digits button to select the channel. If you want
to resume the channel, press OK button again.
Video
Audio
Channel
Lock
Function
Channel Label Set
Channel Index
Channel Label
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
1
Menu Operations
Function Menu Options
1. Press MENU button and CH+/CH- until the following menu appears on the
screen.
2. Press VOL+/OK button to enter the Function menu and CH+/CH- to go up and
down to select the desired option .
3.Press VOL+/OK button to confirm and VOL+/VOL- increase and decrease
the level to adjust the selected option to your preference .
4. Repeat step 2 and step 3 until desired quality has been achieved .
Function:
Language: Press VOL+/VOL- button to select language of the OSD.
OSD Timeout: Press VOL+/VOL- to select Middle, Short and Long to change the
time of the OSD display.
OSD Transparency: Press VOL+/VOL- to select among Low, High and Middle
to change the transparency of the OSD. To select Low, the OSD is opacity.
Screen Mode: Press VOL+/VOL- to select among Normal, Wide, Zoom and
Cinema to change the display mode. ( display mode may differ from different
inputs)
Blue Screen: Press VOL+/VOL- to select On , the screen will be in blue after
3 seconds if there is no signal.
DPMS: PC Power Management. To set On, the set will be in standby mode
automatically if no signal in 2 minutes; if signal input , the set will be on again
automatically.
Time Setup: Press VOL+/OK to enter the submenu.
Time Zone: Press VOL+/VOL- to select the appropriate time zone.
Function
Language English
OSD Timeout Short
OSD Transparency Middle
Screen Mode Full screen
Blue Screen On
DPMS On
Time Setup
Closed Caption
Default
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
Menu Operations
Function Menu Options Continued
Time Setup
Time Zone Central
Date/Time
Sleep Timer Off
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
Date/Time: Press VOL+/OK to enter the submenu.
Date/Time
Auto Off
Date 2000/01/01
Time 01:00 AM
Timer On
On Time 01:00 AM
Off Time 01:00 AM
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
Auto: Press VOL+/VOL- to select On or Off . When Auto mode on , the time
can not be adjusted. Select Off , you can operate to set the time manually.
Date: Press VOL+/VOL- to select the position and digits button to set the date.
Time: Press VOL+/VOL- to select the position and digits button to set the time.
Timer: Press VOL+/VOL- to select On or Off.To select Off, the time can not be
adjusted.
On Time/Off Time: Press VOL+/VOL- to select the position and digits button to
set the time.
Closed Caption: Press VOL+/OK to enter the submenu.
Closed Caption
NTSC Caption Off
DTV Caption Off
DTV Caption Style
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
Menu Operations
Function Menu Options Continued
NTSC Caption: Press CH+/CH- to select the Closed Caption options. It helps the
hearing impaired with the broadcast program, as well as helping children
learn how to read. A built in decoder displays the audio portion of a program as text
on the screen when this option is selected.
CC1: When CC1is displayed on TV means CC mode is turned on.
CC2 to CC4: For other modes of video related broadcast information.
Text1: For program guide and other information displayed by broadcasters.
(This blocks a large portion of the picture on your screen).
Text2 to Text4 :For other modes of information displayed by broadcasters.
(This blocks a large portion of the picture on your screen).
IMPORTANT: Closed captioning availability entirely depends on broadcasters
supplying the signal. Therefore, closed captioning might not always be
available and language availability will differ by broadcast.
DTV Caption: Press VOL+/VOL- to select Service1/Service2/Service3/Service4/
Service5/Service6/Off.
DTV Caption Style: Press VOL+/OK to enter the submenu.
DTV Caption Style
Style
Size
Text Color
Text Opacity
BG Color
BG Opacity
Window Color
Window Opacity
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
Custom
Large
White
Solid
Black
Solid
Black
Solid
Style: Press VOL+/VOL- to select one of Default and Custom. When you select
default, the others are disable and can not be adjusted. When you adjust the
following system,A mark of ABC in a pane will be on the right of the OSD to
display the effect.
Size: Press VOL+/VOL- to select
Text Color: Press VOL+/VOL- to select the text color or the opacity of the text box of
caption display according to your own preference.
Select a color and one of the opacity options.
Text Opacity: Press VOL+/VOL- to specify the opacity for the text color.
BG Color: Press VOL+/VOL- to select a background color.
the size of caption display according to your own
preference.
ABC
Menu Operations
Function Menu Options Continued
BG Opacity: Press VOL+/VOL-to select the opacity for the background color.
Window Color: Press VOL+/VOL- to select according your own preference
Window Opacity: Press VOL+/VOL- to select the edge color according your own
preference.
Default: Press VOL+/OK to enter the submenu.
Press VOL+/VOL- to select OK or Cancel then OK to confirm. If OK, the parameter
will return to the factory set.
Are you sure?
OK Cancel
Lock Menu Options
Lock
Enter Password
Back
EXIT
Video
Audio
Channel
Lock
Function
1. Press MENU button and CH+/CH- until the following menu appears on the
screen.
2. Press VOL+/OK to enter and then press digits button to input the digits( The
initial password is 0000. If you forget your password, you can always input 9443
to regain control) . The menu will display as follows:
Lock
Channel Block
Program Block
Password
Clean All
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
Enter
OK
Menu Operations
Lock Menu Options Continued
Channel Block: Press VOL+/OK to enter the submenu as follows.
Channel Lock
10-1 Digital
11 Analog
11-1 Digital
12 Analog
13 Analog
14 Analog
14-1 Digital
14-2 Digital
14-3 Digital
15 Analog
Select
Back
EXIT
CH+/VOL+/-
Set
OK
Video
Audio
Channel
Lock
Function
WCAU-DT
MBC DTV
ATSC-1
ATSC-2
ATSC-3
Press CH+/CH- to select the channel you want to lock, then press OK to confirm.
The channel is locked and a lock mark appears in the pane. If you want to unlock
the channel, repeat the operation above again. Then press EXIT to exit step by
step.
Program Block: Press VOL+/OK to enter the submenu as follows.
Program Block
Parental Lock
Parental Guide
MPAA Rating
CA Eng Rating
CA Fren Rating
Block Unrated
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
On
On
Parental Lock: Press VOL+/VOL- to select On or Off. Used to lock all the system
following . To set Off, the system following can not be available.
Parental Guide: Press VOL+/OK to enter the submenu as follows.
Press CH+/CH-/VOL+/VOL- to select the item you want to lock. Then press OK
to confirm to lock and press again to resume it.
Parental Guide Technology:
The "P.L. Technology" allows you to use U.S. and Canadian Movies and TV
PROGRAMS Guide ratings to block certain types of TV programs and movies.
To clearly understand TV program rating codes, read the following information:
Menu Operations
Lock Menu Options Continued
U.S. TV Program Ratings
TV-Y: For all children - these types of rated programs are designed for a very young
audience, including children from ages 2-6.
TV-Y7: Directed towards older children - this type of rated programs may include
comedic violence of mild physical, or may frighten children under the age of 7.
TV-G: General audience - these types of rated programs contains little or no
violence, no strong language, and little or no sexual dialogue and situations.
TV-PG:Parental Guidance Suggested-this type of rated programs may contain
limited violence, some suggestive sexual dialogue and situations, and rare
language.
TV-14: Parents strongly cautioned-these types of rated programs may contain sexual
content, strong language and more intense violence.
TV-MA:Mature audience only these types of rated programs may contain sexual
violence, explicit sexual content and profane language.
(A)All: Blocks all available sub_ratings.
(D)Dialogue: This type of rated programs contain dialogue with sexual content.
(L)Languag: This type of rated programs contain offensive language.
(S)Sex: This type of rated programs contain sex.
(V)Violence: This type of rated programs contain violence.
(FV)Fantasy Violence : This type of rated programs contain Fantasy and cartoon
violence.
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
A D L S V FV
Allowed Rating Blocked Rating
Parental Guide
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
Set
OK
Menu Operations
Lock Menu Options Continued
MPAA Rating: Press VOL+/OKto enter the submenu as follows.
Press CH+/CH- to select the item you want to lock. Then press OK to confirm to
lock and press again to resume it.
Allowed Rating Blocked Rating
MPAA Rating
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
Set
OK
G
PG
PG-13
R
NC-17
X
To understand clearly about movie rating codes, read the following list:
U.S. Movie Rating Chart
G: General Audience-this type of movie rating means all ages admitted to see
the movie.
PG: Parental guidance suggested. Some material may not be suitable for children.
PG-13:Parents Strongly Cautioned - this type of movie rating means some material
may not be appropriate for children under13.
R:Restricted- This type of movie rating means children under 17 of age require
to be with parent or guardian.
NC-17:This type of movie rating means no one 17 and under admitted.
X: This type of movie rating means adults only.
CA Eng Rating: Press VOL+/OK to enter the submenu as follows.
Press CH+/CH- to select the item you want to lock. Then press OK to confirm to
lock and press again to resume it.
Menu Operations
Lock Menu Options Continued
To clearly understand Canadian program rating codes, read the following list:
Canadian English Rating Chart
C: This type of programming is intended for children under age 8. There is no
offensive language, nudity or sexual content.
C8+:These types of rated programs are generally considered acceptable for children
8 years and over. There is no profanity, nudity or sexual content.
G: These types of rated programs are generally suitable for all audiences.
PG: Parental Guidance Suggested -in these types of rated programs, some material
may not be suitable for children.
14+: In these types of rated programs, some content may not be suitable for viewers
under the age of 14.Parents are strongly cautioned not to have their children
view 14+ rated programs by pre-teens and early teens.
18+: Adults Only-these types of rated programs are only for adult viewers only.
CA Fren Rating: Press VOL+/OKto enter the submenu as follows.
Press CH+/CH- to select the item you want to lock. Then press OK to confirm to
lock and press again to resume it.
Allowed Rating Blocked Rating
CA Eng Rating
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
Set
OK
C
C8+
G
PG
14+
18+
Allowed Rating Blocked Rating
CA Fren Rating
Select
Back
EXIT
CH+/VOL+/-
Video
Audio
Channel
Lock
Function
Set
OK
G
8 ans+
13 ans+
16 ans+
18 ans+
Menu Operations
Lock Menu Options Continued
PC Menu Options
1. Press MENU button and CH+/CH- button to select Video menu in PC mode.
2. Press VOL+/OK button to enter the Video menu and CH+/CH- to go u p
and down to select the desired option .
Canadian French Rating Chart
G:These types of rated programs are generally suitable for all audiences.
8 ans+: Children 8 years and above (French)
13 ans+: 13 years old and above(French)
16 ans+: 16 years old and above(French)
18 ans+: Adults Only-these types of rated programs are only for adult viewers only.
Blocked Unrated: Press VOL+/VOL- to select On or Off.
Used to lock all the channel not rated .
Password: Press VOL+/OK to enter the submenu , press digits button to input
the number of 0-9 twice in the New Password and Confirm Password. Then you
can change the password when you input the same number twice.
Clean All: Press VOL+/OK to enter the submenu:
Are you sure?
OK Cancel
Press VOL+/VOL- to select OK or Cancel then OK to confirm. If OK, the parameter
will return to the factory set.
Note: if there is any lock mark on the top of the set such as channel lock, parental
lock and so on, you can press OK to resume it .( Press OK to display password
menu and input your password.)
Menu Operations
PC Menu Options Continued
3.Press VOL+/OK button to confirm and VOL+/VOL- increase and decrease
the level to adjust the selected option to your preference .
4. Repeat step 2 and step 3 until desired quality has been achieved .
Video
Audio
Lock
Function
Video
Mode Custom
Brightness
Contrast
Color Temperature
Advanced Video
PC
50
50
Select
BackAdjust
EXITOK
CH+/VOL+/-
Video
Audio
Lock
Function
PC
Auto Sync
H Position
V Position
Phase
Clock
50
50
Select
BackAdjust
EXITOK
CH+/VOL+/-
50
50
Note: In PC mode, Advance Video is no useful.
PC: Press CH+/CH- button to select and VOL+/OK to confirm, the PC
menu as below:
Auto Sync: Press CH+/CH- button and then press VOL+ to auto adjust that
automatically adjusts the available options for the best viewing configuration.
H Position: Press CH+/CH- button and then press VOL+/VOL- to adjust the
horizontal position of the picture.
V Postion:Press CH+/CH- button and then press VOL+/VOL- to adjust the
vertical position of the picture.
Phase: Press CH+/CH- and then press VOL+/VOL- to adjust the phase of the
picture.
Clock: Press CH+/CH- button and then press VOL+/VOL- to adjust the clock of
the picture.
DVD Features
Basic Playback
Preparations
1.Place the DVD in the disc slot. The disc will be
loaded automatically after one to two seconds
then the DVD player reads the DVD and displays
the opening menu If there is no disc placed in
DVD mode, OPEN will display on the screen all
the times)
Do not place a disc that is unplayable in this
DVD player.
2. Some discs may start playback with a menu. Use
the cursor buttons on the remote control to select
menu options and press PLAY/ENTER to start. You
may also press the digit buttons to select a menu
option directly. Many DVDs will not allow this during
start-up.
1. Press PAUSE/STEP to pause playback (still mode).
The sound will be muted during still mode.
2. Press PLAY/ENTER to resume normal playback.
Pause playback
1. Press STOP button to go to stop mode, the TV
screen will show the start logo. With some discs,
such as DVD or CDs, the player can resume
playback from the point where it was stopped.
2. Press PLAY/ENTER to resume playback from the
location where the playback was stopped.
3. Press STOP twice to stop completely.
Stop playback
Previous and Next
Fast forward and Fast reverse
1. Press FWD to fast forward through the disc.
Each time the FWD button is pressed, the
fast forward motion speed changes.
2. Press PLAY/ENTER to resume normal playback.
3. Press REV to fast reverse through the disc.
Each time the REV button is pressed, the
fast reverse motion speed changes.
4. Press PLAY/ENTER to resume normal playback.
Basic playback
1. When paused, press PAUSE/STEP continuous
to single step forward to the next frame in the
video.
2. Press PLAY/ENTER to resume normal playback.
Single step playback
Preparations
Press the TV/DVD button on the remote control
to enter the DVD status.
Note: Do not insert a disc until the DVD input states
open
Pause playback
Stop playback
Previous and Next
Fast forward and Fast reverse
Basic playback
Single step playback
Some discs do not start automatically. Press
PLAY/ENTER to start playback.
During Playing, pressing the PREV key will
restart the last chapter and skip chapters
backwards with each subsequent press until the
start of the disc is reached.
Each press of NEXT key during playing will
skip the current chapter and play the next one.
DVD Features(Continued)
Advanced Playback
PROGRAM
When playing discs, press "PROGRAM" to enter
program mode. Press the digit buttons to select the
program number that you want. When finished move
the cursor to select "START" . Press PLAY/ENTER
to confirm. This will start the program playback.
REPEAT
Press " REPEAT " and Chapter repeat will be
displayed on screen, the second press will display
Title repeat, the third press will display All repeat,
the fourth press will cancel this function.
Press " SUBTITLE ", the screen will display "SUBTITLE 01/XX XXXXX", "01" indicates the ordinal
number of this language; "XX" indicates total number
of language; "XXXXXX" indicates the language of
country. (The number of language depends on disc.)
This function can select up to 32 languages displayed on screen.
A-B
Press " A-B " to begin start-point, press again
to set an end point and complete setting. The
selected section A-B will be repeated. The third
press will cancel this function.
SEARCH
SLOW
D.MENU
Press this key to display the root menu, select
items according to your preference. (This
function will work on a DVD with a multi-layer
menu.)
ANGLE
When enjoying sports, concert or theatre, press this
key to watch same actions in different angles. (Valid
for discs possessing this function. Using a disc
recorded in multi-angle you can view the scene from
different angles,for example,front, side, whole view
and exterior scene).
Press this key can change the mode of audio.
such as: Audio 1/2: AC 3 2 CH English
Audio 2/2: AC 3 5.1 CH English
Press this button to cycle between Mono Left, Mono
Right, Mix-Mono and Stereo.
AUDIO
TITLE/PBC
With some DVD discs pressing this key will display
the title menu. You can then use the digit buttons
to select the item you prefer.
D.CALL
PROGRAM
REPEAT
SUBTITLE
A-B
Press " A-B " to begin start-point, press again
to set an end point and complete setting. The
selected section A-B will be repeated. The third
press will cancel this function.
SEARCH
Press "SEARCH" once to display the search
menu. Press the button again to select. Press
the program number buttons to input the item
you require. Press PLAY/ENTER to confirm.
SLOW
Press SLOW to play a disc in slow motion. Each
time the SLOW button is pressed, the slow
motion speed changes.
Press PLAY/ENTER to resume normal playback;
Note: This function dose not work for CD .
D.MENU
ANGLE
AUDIO
TITLE/PBC
Pressing this key will cycle through "Title Elapsed",
"Title Remain", "Chapter Elapsed", "Chapter Remain"
and "Display off ".
D.CALL
ALL DESCRIBED FUNCTIONS A FOR DVD DISCS. IF YOU PLAY OTHER DISC
FORMATS THE OPERATION AND ON SCREEN DISPLAY WILL BE DIFFERENT.
IMPORTANT NOTE:
Note: When press this button continuously, you must
allow a 3 second interval between selections.
Special Function Playback
JPEG DISC PLAYBACK
This unit employs a screen saver mode to help protect the tube during static video pictures. This can
be turned off on the GENERAL SETUP PAGE.
When a disc containing standard JPEG picture files is inserted into the player, a
navigation menu will be displayed automatically. Use the UP and DOWN cursor
buttons to select a file then press PLAY/ENTER. The slide show will commence.
Press PREVIOUS or NEXT to move between pictures. Press pause to stop on the
current picture. Press PLAY/ENTER to resume normal playing.
A JPEG disc contains JPEG (.jpg) format picture information that can be decoded
by a micro-computer software and displayed through the video output interface or on
the television screen.
This function has many applications. For example one can save files from a scanner
or digital camera in the JPEG format, record these on a CD-R disc and present them
to an audience through this player.
The JPEG format is a convienient method to store images in a small amount of
memory space, and is ideal for archiving information.
SCREEN SAVER FUNCTION
DVD System Setup
DVD System Setup
General Setup Process
1.Press the setup button, the
general set up page will be
displayed press twice the
preference page will be displayed
2.Press CH+/- b to select, the
item, then press to enter the
submenu.
3.Press CH+/- bu to select then
press PLAY/ENTER to confirm.
4.Press SETUP repeatedly to
exit the set-up menus.
or
or
..General Setup Page..
Tv Display LB
Angle Mark On
Osd Lang ENG
Caption On
Screen Saver Off
4 3/Ps
4 3/Lb
16 9
Parental
Password
Default
..Preference Page..
General Setup Page
When using the DVD with the internal TV,
select 4 3/LB.
The following information applies only
when the DVD output is connected to an
external TV.
4:3/PS (PS = Pan and Scan)
You may select if you have a normal aspect
ratio (4:3) TV, although the NORMAL/LB
(letter box) is a more common choice. In PS
mode, widescreen material will fill the screen, but at the expense of chopping
off extreme left and right edges of the original film picture. For this feature to
work, the disc must be specially coded. Such discs are uncommon.
4:3/LB (LB = Letter Box)
You may select this if you have a normal aspect ratio (4:3) TV. Widescreen
material will be shown in pure unaltered form, allowing the entire picture area
of the original film to be viewed without any side cropping. Black bars will
appear above and below the picture.
16:9
You may select this if you have a widescreen (16:9) TV. Back bars may still
appear above and below the picture even if using a widescreen TV. This is
because some film directors prefer to use ultra widescreen aspect ratios e.g.
2.35:1. This will normally be indicated on the DVD packaging.
ASPECT RATIO DESCRIPTION
..General Setup Page..
Tv Display LB
Angle Mark On
Osd Lang ENG
Caption On
Screen Saver Off
4 3/Ps
4 3/Lb
16 9
1 Kid Saf
2 G
3 Pg
4 Pg 13
5 Pgr
6 R
7 Nc17
8 Adult
SETUP
PLAY/ENTER
SETUP
PLAY/ENTER
NOTE: Preference page will be
displayed when there is no DVD in
the unit. To access this page, press
SETUP button twice.
DVD System Setup(Continued)
DVD System Setup
General Setup Page
CAPTION: This function allows you to display or
hide the caption.
SCREEN SAVER: If the screen saver is on, then
there will be an animated picture of DVD on the
screen whenever the DVD player is idle for more
than 3 minutes .
..General Setup Page..
Angle Mark On
Osd Lang ENG
Caption On
Screen Saver Off
On
Off
Tv Display LB
This item allows you to set Angle Mark ON or OFF.
ANGLE MARK: Users can select a particular
camera angle when playing a DVD which offers
multiple angles.
On Screen Display (OSD) Language: Users
can select on-screen display language.
.
..General Setup Page..
Tv Display LB
Angle Mark On
Osd Lang ENG
Caption On
Screen Saver Off
On
Off
..General Setup Page..
Tv Display LB
Angle Mark On
Osd Lang ENG
Caption On
Screen Saver Off
English
Spanish
..General Setup Page..
Angle Mark On
Osd Lang ENG
Caption On
Screen Saver Off
On
Off
Tv Display LB
DVD System Setup(Continued)
DVD System Setup
The Preference Page is only available when there is no disc
in the player.
Preference Page
PARENTAL: The parental
control function works in
conjunction with the
different censorship classes
assigned to DVDs. These
classes help to control the
types of DVDs that the family
watches, There are up to 8
censorship classes for DVDs.
Note:
1 To change this setting you must enter your password.
(Initial password is 1234)
2 When set to OFF, all discs may be viewed.
..Preference Page..
Parental
Password Change
Default
Old Password
New Password
Confirm Pwd
PASSWORD CHANGE:
You can change your password
by entering 4 digits. You must
confirm the 4 digits before the
new password can be accepted.
..Preference Page..
Parental
Password
Default
1 Kid Saf
2 G
3 Pg
4 Pg 13
5 Pgr
6 R
7 Nc17
8 Adult
SETUP
PLAY/ENTER
SETUP
PLAY/ENTER
NOTE:
If you forget your password
or a password is accidentally
set enter 1369 as the password.
This will enable you to regain
control.
DVD System Setup(Continued)
DVD System Setup
DEFAULT: Resets all settings
(except password and parental
lock status) for this DVD player
back to the manufacturers
original settings. Press ENTER
to perform the reset.
Note:
Some functions may not be available depending on the
type of disc.
Parental
Password
Default
..Preference Page..
Reset
SETUP
PLAY/ENTER
Playable Discs
The following discs can be played:
1.You cannot play discs other than those listed above.
2.You cannot play non-standardized discs, even if they may be labelled as above.
3.The performance of CD-R or CD-RW disc depends on the way the disc was burned. In
a few cases, their performance may not be consistant or may not even operate at all.
This DVD Player is designed and manufactured according to the Region
Management Information that is recorded on a DVD disc. If the Region number
described on the DVD disc does not correspond to the Region number of this DVD
Player, this DVD player will not play that disc.
This Region number of this DVD Player is .
11
Disc Protection and DVD Characteristics
Compare DVD disc with other discs:
DVD LD
SVCD
VCD CD
Encode
method
Digital/MPEG
Analog
Digital
Digital/
MPEG
Digital
Capacity
650MB 650MB 650MB
133
minutes
242
minutes
266
minutes
484
minutes
Playing Time
Single-side
60 minutes
double-side
120 minutes
45 minutes
74 minutes 74 minutes
12cm 12cm
Disc diameter
30cm/20cm
12cm 12cm
Horizontal
resolution
More than 500 line
No more than
430 line
No more than
350 line
No more than
250 line
Multiple kinds
proportion
One kind
One kind
One kind
Subtitle
32 kinds
16 kinds
at most
4 kinds
at most
4 kinds
at most
4 kinds
2 kinds 2 kinds
Language
8 kinds
Sound quality
48KHz, 96KHz/
6, 20, 24bit
44.1KHz/
16bit
44.1KHz/
16bit
44.1KHz/
16bit
44.1KHz/
16bit
Singleside
singlelayer
4.7G
Double
-side
single
-layer
8.5G
Singleside
doublelayer
9.4G
Doubleside
doublelayer
17G
I
Troubleshooting Guide
To assist in location possible faults use help guide below.
Note:
1.If the fault can not be repaired using the above guide consult with your local authorized
service center.
2.The TV set must only be repaired by a qualified registered service person. Never attempt to
remove the back cover as the TV set has dangerous voltages levels inside that may be
fatal or cause fire.
Troubleshooting
No picture, no sound
Verify if the television is properly plugged in.
Verify if the television is properly supplied with power.
Verify that electricity is available.
Blank screen
Verify if correct signals are input.
Press INPUT button to change signal input to TV input.
Restart the television of power supply is interrupted.
No sound
Press MUTE button and verify if Mute mode is on.
Switch to another channel and verify if the same problem
happens.
Press VOL+ button to see if the problem can be solved.
Poor sound
Verify if sound system is functional. Refer to chapter on
adjusting.
No picture in some
channel
Verify if correct channel is selected.
Adjust the antenna.
No color for some channel
program (black and white)
Verify if the same problem exists in other channels.
Check picture and sound systems.
Refer to relative instructions in the Manual for color
adjust.
Spots with some or
all pictures
Verify if the antenna is correctly connected.
Verify if the antenna is in good condition.
Make fine adjustment of channel.
Abnormal functioning
Disconnect the television from power supply and, 10
seconds later, reconnect to the power supply.
If the problem still exists, contact an authorized
service depot for technical assistance.
Specifications
Accessories
Picture, sound
system
Audio output
External input port
Power requirements
Temperature
1.5W+1.5W
AV input PC input S-VIDEO input PC audio input
YPbPr input Antenna input HDMI input
~120V 60Hz
NTSC, ATSC, Clear QAM
Working:+5 ~+35
Storage:-15 ~+45
Power consumption
60W
Model
15 without DVD
Remote control
Batteries
User manual
Warranty card
NOTE
Design and specifications are subject to change without notice.
Dimensions quoted in this manual are approximate.
40W
Humidity
Working:20% ~ 80%
Storage: 5% ~ 90%
50W
19 without DVD 19 with DVD
Dimensions
HxWxD
18.2x7.5x13.4 in.
(40.6x19.1x34.0 cm)
18.5x7.5x15.2 in.
(47.1x19.1x38.5 cm)
18.5x7.5x15.2 in.
(47.1x19.1x38.5 cm)
Weight
7.3 lbs.
(3.3 kg)
10.8 lbs.
(4.9 kg)
10.8 lbs.
(4.9 kg)
01
0090507699
