Sennheiser PXC 310 BT User Manual

Download

Travel

Silence For Your Aural Indulgence

PXC 310 BT

Instruction manual

Contents

Important safety instructions .......................................................... 2

PXC 310 BT ........................................................................................... 4

Delivery includes ................................................................................. 6

Product overview ................................................................................ 8

Putting the PXC 310 BT into operation ........................................... 9

Charging the battery pack ................................................................. 9

Adjusting the headband ................................................................. 11

Switching the PXC 310 BT on/off .................................................. 12

Connecting the PXC 310 BT to the audio source ........................ 13

Connecting the PXC 310 BT using the audio cable .................... 16

Using the PXC 310 BT ....................................................................... 17

Adjusting the PXC 310 BT to the listening situation ................. 17

Changing the volume ....................................................................... 18

Remote-controlling connected devices from the

PXC 310 BT ......................................................................................... 19

Resetting the settings of the PXC 310 BT ................................... 20

Transporting the PXC 310 BT .......................................................... 21

Cleaning and maintaining the PXC 310 BT ................................... 22

If a problem occurs ... ....................................................................... 23

Accessories and spare parts ............................................................ 24

Specifications .................................................................................... 25

apt-X audio coding ........................................................................... 26

Manufacturer Declarations .............................................................. 28

Important safety instructions

• Please read these instructions carefully and completely before using the headphones.

• Make these instructions easily accessible to all users at all times. Always include these instructions when passing the headphones on to third parties.

• Only use the headphones in aircraft where wireless Bluetooth mission is permitted.

• Do not use the headphones in situations which require special attention (e.g. in traffic or when performing skilled jobs).

• Always keep the headphones dry and do not expose them to extreme temperatures (normal operating temperatures: 10°C/50°F to 35°C/ 95°F).

– Use the headphones with care and store them in a clean, dust-free

environment.

– Switch off the headphones after use to conserve battery power.

Remove the batteries if the headphones will not be used for extended periods of time.

• The headphones contain magnets that generate a magnetic field which could cause dangerous interference with cardiac pacemakers and implanted defibrillators. Keep the headphones at least 1.2” (3 cm) from cardiac pacemakers or implanted defibrillators.

• Please protect your hearing from high volume levels. Sennheiser headphones also sound exceptionally good at low volumes.

• Only use the supplied mains unit and charging cable.

• To reduce the risk of fire or electric shock, do not use the device and the mains unit near water and do not expose them to rain or moisture.

• Unplug the mains unit from the wall socket

– to completely disconnect the device from the mains

– during lightning storms or

– when unused for long periods of time.

• Only operate the mains unit from the type of power source specified in the chapter “Specifications” (see page 25).

• Ensure that the mains unit is

– in a safe operating condition and easily accessible,

– properly plugged into the wall socket,

– only operated within the permissible temperature range,

– not covered or exposed to direct sunlight for longer periods of time

in order to prevent heat accumulation (see “Specifications” on page 25).

• Do not operate the device and the mains unit near any heat sources.

• Only use attachments/accessories specified by Sennheiser.

trans-

Important safety instructions

Intended use

Intended use of the headphones includes

• having read this instruction manual, especially the chapter “Important safety instructions” on page 2,

• using the headphones within the operating conditions and limitations described in this instruction manual.

“Improper use” means using the headphones other than as described in this instruction manual, or under operating conditions which differ from those described herein.

Safety instructions for the Lithium-Polymer battery pack

If abused or misused, the battery pack may leak. In extreme cases, it may even present

• a heat hazard,

•a fire hazard,

• an explosion hazard,

• a smoke or gas hazard.

Please understand that Sennheiser does not accept liability for damage arising from abuse or misuse.

Keep away from children. Do not pack charged batteries

loose – danger of shorting out/fire hazard.

Observe correct polarity. Do not short-circuit.

Dispose of the battery pack at special collection points or return it to your specialist dealer.

Only charge the battery pack with the appropriate Sennheiser chargers.

Only charge the battery pack at ambient temperatures between 10°C/50°F and 40°C/104°F.

Do not mutilate or dismantle. Do not continue to use a

Switch battery pack-powered devices off after use.

When not using the battery pack for extended periods of time, charge it regularly (about every 3 months).

Do not heat above 70°C/ 158°F, e.g. do not expose to sunlight or throw into a fire.

defective battery pack.

Immediately remove the battery pack from an obviously defective device.

Only use the original Sennheiser battery pack.

When not using the device for extended periods of time, remove the battery pack from the device.

Do not expose to moisture.

PXC 310 BT

The PXC 310 BT headphones provide undisturbed music enjoyment in noisy environments – even without the constrictions of cables. Their supra-aural, closed design and the latest active noise compensation technology (NoiseGard) make the PXC 310 BT especially suitable for use with in-flight entertainment systems. Due to their active and passive attenuation of ambient noise, they let you enjoy music even in noisy environments.

Bluetooth

The PXC 310 BT comply with the new Bluetooth 2.1 standard. Via their Bluetooth interface, they can be connected to a wide variety of Bluetooth

enabled devices. Bluetooth wireless technology allows the PXC 310 BT to communicate with your Bluetooth enabled device (e.g. mobile phone, MP3 player, PC or PDA) within a range of up to 10 meters.

apt-X

With apt-X audio coding, you can be assured of crisp, pure and full stereo sound. It allows you to not only hear, but experience and feel the audio as it was intended. Utilizing apt-X, Bluetooth technology can now offer wireless audio quality that is indistinguishable from the highest quality wired connection.

From major public broadcasters to film production studios, apt-X is used throughout the world to transmit high quality digital audio from A to Z in real-time. It was developed to meet the exacting standards of musicians and audio engineers who love the exceptional dynamic range and high fidelity it provides.

Now available on selected consumer devices, the apt-X technology ensures that music lovers everywhere can stream the rich listening experience that only apt-X can deliver.

NoiseGard

The NoiseGard active noise compensation system is based on the principle of cancelling out sound using “anti-sound” (phase-inverted sound). Tiny microphones pick up low-frequency ambient noise (up to 1 kHz) near the ear. The NoiseGard electronics use this noise to generate a sound wave which is the exact opposite (IE: at the same level but polarity reversed – 180° out-of-phase), the effect being that the polarity reversed signal cancels most of the outside noise.

TalkThrough

The PXC 310 BT headphones have a TalkThrough function, which allows you to communicate with other people without having to remove the headphones. When TalkThrough is activated, professional quality microphones mounted on the outside of the headphones pick up all acoustic signals in the immediate vicinity. Annoying background noise is electronically filtered out, only allowing the voice of the other person to pass through the headphones clearly.

PXC 310 BT

Additional features

• Great for travel: comfortable, rugged and foldable headphone construction

• Optional connection via audio cable for music enjoyment without Bluetooth technology

• Outstanding sound quality due to patented adaptive baffle damping and Duofol diaphragms

• Optimum protection against ambient noise due to active and passive noise attenuation

Delivery includes

1 PXC 310 BT headphones

1 BA 370 PX battery pack

1 USB charging cable

1 PSC 03R-050 mains unit with country adapters

1 audio cable (2.5 mm to 3.5 mm jack plug)

1 audio adapter (6.35 mm jack plug)

1 in-flight adapter (3.5 mm double mono jack plug)

1 transport case

1 quick start guide

1 CD ROM with

– detailed instruction manual (PDF file)

– interactive instruction manual

Overview of the pictograms

Meaning of the pictograms for pressing a button

Pictogram Meaning

Briefly press this button.

Keep this button pressed for 4 seconds.

4 s

Keep this button pressed until the desired setting is made or the desired action is completed.

Meaning of the pictograms for the flashing of the LED

Delivery includes

Pictogram Meaning

This pictogram symbolizes a flashing.

This pictogram symbolizes an interruption.

This pictogram symbolizes an interval.

This pictogram symbolizes a continuous flashing.

Examples o f some of the pictograms that are used throughout this instruction manual:

Pictogram Meaning

The LED flashes once every 3 seconds.

The LED flashes 3 times per second.

The LED flashes in a rhythmic sequence.

The LED flashes blue 3 times and then goes off.

The pictogram “i”

This note provides important information!

Notes marked with the pictogram “i” provide important information on the use of the headphones.

Product overview

쐃

Bluetooth



쐎

쐊

쐃 Headband 쐂 Ear pad

쐇 Microphone 쐆 Microphone

쐋 NoiseGard button 쐊 Socket for charging cable

쐏 Socket for audio cable 쐎 Battery pack compartment

쐄 Bluetooth button

쐆



NoiseGard







Operating panel

햲 LED

햳 Fast-forward button 햶 Master button

햴 Volume button 햷 Volume button

햵 Rewind button

Putting the PXC 310 BT into operation

Before using the PXC 310 BT for the first time, remove the protection strip from the battery pack.

Charging the battery pack

왘 Before using the battery pack for the first time, charge it for at least

3hours.

When charging the battery pack, the LED 쐅 on the battery pack lights up red. When the battery pack is fully charged, the LED 쐅 on the battery pack lights up green.

쐅

When the battery pack is almost flat, the LED 햲 on the headphones flashes red. You hear a short, negative acknowledgement tone.

The operating time of the battery pack depends on the device settings, the listening situation and the audio sources used.

Type of use Operating time

NoiseGard and Bluetooth technology 8 hours

NoiseGard without Bluetooth technology 20 hours

Bluetooth technology without NoiseGard 10 hours

Remove the battery pack if the headphones will not be used for extended periods of time.

You can also charge the battery pack while using the headphones.

Putting the PXC 310 BT into operation

쐈

Possibilities of charging the battery pack

First, connect the charging cable 쐈 to the battery pack as described in section a and then connect the charging cable 쐈 to a power source as described in section b.

Connecting the charging cable to the battery pack

You can charge the battery pack either inside or outside the headphones. This is helpful if you are using a spare battery pack (to be ordered separately).

To charge the battery pack inside the headphones:

왘 Open the battery pack compartment cover 쐎 on the left ear cup.

왘 Connect the charging cable 쐈 to the socket for charging cable 쐊 on the

headphones.

쐊

To charge the battery pack outside the headphones:

쐆

쐈

왘 Open the battery pack compartment cover 쐎 on the left ear cup.

왘 Press the button next to the battery pack compartment and remove

the battery pack.

왘 Connect the charging cable 쐈 to the socket for charging cable 쐊 on the

battery pack.

Putting the PXC 310 BT into operation

Connecting the charging cable to the mains unit, to a PC or to other

USB devices

In order to charge the battery pack, you can connect the charging cable to either the USB socket of your PC or the supplied mains unit or to other USB devices.

쐈

To connect the charging cable to a PC:

왘 Connect the USB plug of the charging cable 쐈 to the USB socket of

your PC. The battery pack is being charged. The LED 쐅 on the battery pack

쐅

lights up red.

To connect the charging cable to the mains unit:

왘 Connect the charging cable 쐈 to the mains unit.

왘 Plug the suitable country adapter onto the mains unit.

왘 Plug the mains unit into a wall socket.

The battery pack is being charged. The LED 쐅 on the battery pack lights up red.

왘 After charging, unplug the mains unit from the wall socket.

If you have charged the battery pack outside the headphones:

왘 Insert the charged battery pack into the headphone’s battery pack

compartment until it locks into place.

왘 Close the battery pack compartment cover 쐎.

Adjusting the headband

For optimum transmission quality, good noise attenuation and best possible comfort, the headband has to be adjusted to properly fit your head:

왘 Wear the headphones so that the headband 쐃 runs over the top of

your head.

왘 Adjust the length of the headband so that

–the ear pads쐂 rest comfortably against the ears,

– you feel even, gentle pressure around your ears, – a snug fit of the headband 쐃 on the head is ensured.

왘 To ensure maximum noise attenuation, final adjustment is best made

in a noisy environment.

Putting the PXC 310 BT into operation

Switching the PXC 310 BT on/off

CAUTION! Hearing damage due to high volumes!

Listening at high volume levels for long periods can lead to permanent hearing defects. Please protect your hearing. Sennheiser headphones also sound exceptionally good at low volumes.

왘 Set the volume to a comfortable level.

Switching the PXC 310 BT on

왘 Press the Master button 햶 and keep it pressed until the LED 햲

flashes blue. You hear an ascending beep.

– When switching the headphones on for the first time, they will auto-

matically go into pairing mode. The headphones are waiting to be paired with a Bluetooth enabled device (see page 13).

– When the headphones are already paired with an audio source, the

Bluetooth connection is automatically established. You hear an ascending beep and then your audio source.

– When the headphones are already paired with an audio source but

the audio source is switched off or out of range, the LED 햲 flashes blue. The headphones will try for 3 minutes to connect to one of the up to 8previously paired audio sources. If this fails, the headphones automatically switch off after 60 minutes.

Switching the PXC 310 BT off

왘 Press the Master button 햶 and keep it pressed until the LED 햲

flashes 3 times red.

You hear a descending beep. The Bluetooth connection is automatically deactivated. The headphones switch off.

Putting the PXC 310 BT into operation

Connecting the PXC 310 BT to the audio source

CAUTION! Danger of malfunction!

The transmitted radio waves can impair the operation of sensitive and unprotected devices.

왘 Only use the headphones in aircraft where wireless

Bluetooth transmission is permitted or use the audio cable instead (see “Connecting the PXC 310 BT using the audio cable” on page 16).

The headphones comply with the Bluetooth 2.1 standard. In order that data can be transmitted wirelessly using Bluetooth technology, you have to register your headphones with your audio source (pairing).

The headphones can save the connection profiles of up to 8 Bluetooth devices with which they have been paired. After switch-on, the headphones automatically connect to one of these devices.

If you pair the headphones with a ninth audio source, the saved connection profile of the first Bluetooth device will be overwritten. If you want to reestablish a connection with the first audio source, you have to pair the headphones with this audio source again.

If your audio source does not have a Bluetooth interface, use an optional dongle (see “Accessories and spare parts” on page24). In addition to adding Bluetooth capability to your audio source, this dongle uses apt-X, a technology that ensures crisp, pure and full stereo sound. With apt-X, Bluetooth can now offer wireless audio quality that is indistinguishable from the highest quality wired connection.

A connection to the headphones is only possible if your audio source supports the A2DP profile.

Putting the PXC 310 BT into operation

Pairing the PXC 310 BT with an audio source

왘 Make sure that your headphones are switched off (see

“Switching the PXC 310 BT on/off” on page 12).

When switching the headphones on for the first time, they will automatically go into pairing mode. The headphones are waiting to be paired with a Bluetooth enabled device (see page 13).

왘 Press the Master button 햶 and keep it pressed until the LED 햲

alternately flashes blue and red.

왘 On your audio source, activate the Bluetooth function “Add a new

device”.

왘 Proceed as described in the instruction manual of the audio source.

If a suitable audio source is found, the devices will exchange device identification information. The LED 햲 flashes 3 times blue and you hear an ascending beep. The devices have identified each other and the headphones are paired with the audio source.

PIN code

When the audio source prompts for a password or PIN code, enter the default PIN code “0000”.

If a connection is established, the LED 햲 continues to slowly flash blue.

If no device is found within approx. 5 minutes, the LED 햲 flashes 3 times red and you hear a descending beep. The headphones will then try for 3 minutes to connect to one of the up to 8 previously paired audio sources. If this fails, the headphones automatically switch off after 60 minutes.

왘 In this case, repeat the necessary steps to pair the headphones with the

audio source again.

Switching the “Bluetooth connection” flashing on/off

왘 Switch the headphones off (see “Switching the PXC 310 BT on/off” on

page 12).

To switch the flashing on during a Bluetooth connection:

왘 Press the Master button 햶 and keep it pressed until the LED 햲

alternately flashes blue and red.

왘 Briefly press the Volume  button 햷.

To switch the flashing off during a Bluetooth connection:

왘 Briefly press the Volume  button 햴.

Disconnecting the Bluetooth connection

The Bluetooth button 쐄 is backlit, indicating the current setting. The backlighting goes off after a short time to conserve energy.

Putting the PXC 310 BT into operation



왘 Press any button on the headphones to display the current

setting of the Bluetooth function.

To disconnect the Bluetooth connection to the audio source, you can switch off the headphones or the Bluetooth function. This setting is retained until the Bluetooth function is switched on again.

To switch the headphones off:

왘 Press the Master button 햶 and keep it pressed until the LED 햲

flashes 3 times red. You hear a descending beep. The Bluetooth connection is automatically deactivated. The headphones switch off.

To switch the Bluetooth function off:

왘 Press the Bluetooth button 쐄 and keep it pressed until the LED 햲

flashes 3 times red. You hear a descending beep. The Bluetooth button 쐄 goes off. The Bluetooth function is switched off.

Putting the PXC 310 BT into operation

Connecting the PXC 310 BT using the audio cable

Connecting the audio cable

You can connect the headphones to the audio source using the audio cable if

• you do not want to use the Bluetooth function,

• you are not allowed to use the Bluetooth function (some airlines do not

allow Bluetooth transmission) or

• the battery pack is flat.

When the audio cable is connected to the headphones, the Bluetooth function cannot be switched on.

씉

쐉

씈

If the headphones are already connected to the audio source via the Bluetooth interface, the Bluetooth connection is automatically disconnected when you connect the audio cable. The LED 햲 flashes 3 times red and you hear a descending beep.

왘 Connect the 2.5 mm jack plug of the audio cable to the socket 쐏 of the

headphones.

왘 Connect the 3.5 mm jack plug of the audio cable 쐉 to

– the headphone socket of your audio source or – the audio adapter for 6.35 mm jack socket 씈 if the 3.5 mm jack plug

of the audio cable is too small or

– the in-flight adapter 씉 if you want to use the headphones with an

in-flight entertainment system.

When the audio cable is connected to your audio source, you hear the sound from your audio source and the LED 햲 flashes blue.

Detaching the audio cable

If you want to use the PXC 310 BT as Bluetooth headphones or as NoiseGard active noise compensation headphones, you can detach the audio cable 쐉.

왘 Pull the 2.5 mm jack plug of the audio cable 쐉 from the socket 쐏 of

the headphones.

When detaching the audio cable, the Bluetooth function is not automatically switched on.

왘 Switch the Bluetooth function on again (see “Switching

the Bluetooth function on/off” on page 18).

Using the PXC 310 BT

Adjusting the PXC 310 BT to the listening situation



The headphones have a NoiseGard function, a Bluetooth function and a TalkThrough function. Depending on the listening situation, you can switch these functions on or off.

Switching the NoiseGard function on/off

The NoiseGard button 쐋 is backlit, indicating the current setting. The backlighting goes off after a short while in order to conserve energy.

왘 Press any button on the headphones to display the current

setting of the NoiseGard active noise compensation.

The NoiseGard function has to be switched on to be active. If the NoiseGard function is switched off, the PXC 310 BT can also be used as conventional headphones.

To switch the NoiseGard function on:

왘 Press the NoiseGard button 쐋 for 2 seconds.

The button is backlit in red and the NoiseGard function is switched on.

To switch the NoiseGard function off:

왘 Press the NoiseGard button 쐋 for 2 seconds.

The red backlighting goes off and the NoiseGard function is switched off.



Conserving energy

Switch the NoiseGard function off after use to conserve energy.

Switching the TalkThrough function on/off

The PXC 310 BT provide excellent attenuation of ambient noise. The TalkThrough function allows you to communicate undisturbed with other people without having to remove the headphones even when NoiseGard is switched on.

To switch the TalkThrough function on:

왘 Briefly press the NoiseGard button 쐋.

The LED 햲 lights up red. The TalkThrough function is switched on.

To switch the TalkThrough function off:

왘 Briefly press the NoiseGard button 쐋.

The LED 햲 goes off. The TalkThrough function is switched off.

When the TalkThrough function is switched on, you cannot listen to music.

Using the PXC 310 BT



Switching the Bluetooth function on/off

Via the Bluetooth interface, the headphones can be connected to a wide variety of Bluetooth enabled devices.

To switch the Bluetooth function on:

왘 Press the Bluetooth button 쐄 and keep it pressed until the LED 햲

flashes 3 times blue. The Bluetooth function is switched on.

To switch the Bluetooth function off:

왘 Press the Bluetooth button 쐄 and keep it pressed until the LED 햲

flashes 3 times red. You hear a descending beep. The Bluetooth button 쐄 goes off. The LED 햲 flashes blue and the

Bluetooth function is switched off.

Changing the volume

The PXC 310 BT allow you to change the volume of the audio signal:

Button Duration Function Button Duration Function

Incrementally increases the volume

Continuously

1 s 1 s

increases the volume

Incrementally reduces the volume

Continuously reduces the volume

If you press the respective button briefly, the volume is changed incrementally; if you hold down the button, the volume is changed continuously.

When the minimum or maximum volume is reached, you hear an acknowledgement tone.

Using the PXC 310 BT

Remote-controlling connected devices from the PXC 310 BT

You can directly remote-control any device supporting the AVRCP profile and connected to the PXC 310 BT by using the buttons on the headphones. Please refer to the instruction manual of your audio source for information on whether your device supports the AVRCP profile.

If your device does not support the AVRCP profile, you can use an optional dongle. Using the iPod dongle or the USB dongle, you can remote-control the connected devices from the headphones.

Remote-controlling the audio source from the PXC 310 BT

If your headphones have a Bluetooth connection to an audio source (e.g. iPod, MP3 or CD player), you can use the PXC 310 BT to remote-control the audio source as follows:

Button Duration Function Button Duration Function

Incrementally increases the volume

Continuously

1 s 1 s

These functions are not supported by all connected Bluetooth devices.

increases the volume

Skips to the next track

Fast-forwards the track

Plays and repeats the track

1 s

Incrementally reduces the volume

Continuously reduces the volume

Skips to the previous track

Rewinds the track

Stops the track (acknowledgement tone)

Using the PXC 310 BT

Resetting the settings of the PXC 310 BT

You can reset all settings of your headphones to the factory default settings. This allows you to prevent that other users of the headphones can access your Bluetooth enabled devices. You can then pair five new devices with the headphones.



왘 Press the Master button 햶 and keep it pressed until the LED 햲

flashes 3 times red. The headphones switch off (see “Switching the PXC 310 BT off” on page 12).

왘 Press the Master button 햶 and keep it pressed until the LED 햲

alternately flashes blue and red.

왘 Press the Bluetooth button 쐄 and keep it pressed until the settings of

the headphones are reset.

Transporting the PXC 310 BT

For space-saving transportation, the headphones can be folded up flatly and compactly.

왘 Rotate the ear cups by 90°.

왘 Tuck the ear cups between the headband.

왘 Place the headphones flat into the transport case.

Your accessories can be transported in front bag of the transport case:

• Audio adapter (6.35 mm jack plug)

• In-flight adapter (3.5 mm double mono jack)

Cleaning and maintaining the PXC 310 BT

Cleaning the PXC 310 BT

CAUTION! Liquids can damage the electronics of the device!

Liquids entering the housing of the device can cause a shortcircuit and damage the electronics.

왘 Keep all liquids far away from the device.

왘 Do not use any cleansing agents or solvents.

For reasons of hygiene, you should clean the headphones regularly:

왘 Before cleaning, make sure that the headphones are not recharged via

the mains.

왘 Only use a soft, slightly damp cloth to clean the headphones.

Replacing the ear pads

You can replace the ear pads. Spare ear pads are available as accessories (see “Accessories and spare parts” on page 24).

왘 Grasp the edge of the ear pad 쐂 behind the ear cup and peel it up and

away from the ear cup.

쐂

왘 Slide the new ear pad 쐂 onto the ear cup.

If a problem occurs ...

Problem Possible cause Solution

No operation indicator – headphones cannot be switched on

No audio signal when the audio cable is connected

No audio signal during Bluetooth connection

Headphones cannot be paired

No audio signal during NoiseGard operation

Headphones do not react to any button press

Bluetooth connection is suddenly interrupted

The battery pack is flat. Recharge the battery pack

(see page 9).

The jack plug of the audio cable is not properly connected.

The headphones are switched off.

The headphones are not paired with an audio source.

The Bluetooth function on the headphones is switched off.

The audio cable is connected to the headphones.

The volume is adjusted too low.

The pairing does not work.

The audio source is switched off.

The headphones are switched off.

The TalkThrough function is switched on. When in TalkThrough mode, the audio signal is not available.

The operation of the headphones is faulty.

The Bluetooth button has been pressed too long.

Check the connection to your audio source (see page 16).

Switch the headphones on (see page 12).

Check if the headphones are paired. If necessary, pair the headphones with the audio source again (see page 14).

Switch the Bluetooth function on the headphones on (see page 18).

The connection of the audio cable automatically switches off the Bluetooth connection. Remove the audio cable and then switch the Bluetooth function on again (see page 18).

Increase the volume (see page 18).

Check if the audio source supports the A2DP profile. If not, use one of the optional dongles.

Switch the audio source on (see page 13).

Switch the headphones on (see page 12).

Switch the TalkThrough function off (see page 17).

Remove the battery pack from the headphones. Reinsert the battery pack into the headphones. Switch the headphones on again.

Switch the Bluetooth function on (see page 18).

If a problem occurs ...

Accessories and spare parts

The following PXC 310 BT accessories are available from your specialist dealer:

Cat. No. Accessory/spare part

531404 Ear pads, 1 pair

531405 Headband padding, 1 pair

525776 PSC 03R-050 mains unit with 4 country adapters

(EU/UK/US/AU)

531406 Audio cable

(2.5 mm jack plug to 3.5 mm jack plug)

088526 In-flight adapter

(3.5 mm double mono jack)

077046 Audio adapter

(3.5 mm jack socket to ¼" (6.35 mm) jack plug)

531407 USB cable

(microUSB to USB)

535105 BA 370 PX battery pack

502388 BTD 300 Audio

502390 BTD 300 USB

502389 BTD 300i

Specifications

Transducer principle dynamic, closed

Ear coupling supra-aural

Frequency response 15–22,000 Hz

Nominal impedance active/passive 590/100 Ω

Sound pressure level at 1 kHz and 1 Volt 107 dB SPL

THD at 1 kHz < 0.1%

Audio connection 3.5 mm stereo jack socket

Audio adapter 6.35 mm stereo jack plug

In-flight adapter 3.5 mm double mono jack plug

Cable length

Audio cable Charging cable

Weight 105 g

BA 370 PX battery pack

Charging time Operating time

Operating temperature range 0°C to +40°C

Storage temperature range –10°C to +70°C

Passive noise attenuation 25 dB

NoiseGard active noise compensation 23 dB

1.4 m

0.8 m

3.7 V; 250 mAh Lithium-Polymer 3 hrs 8 hrs/10 hrs/20 hrs

PSC 03R-050 mains unit

Nominal input voltage 110–240 V~

Nominal input current max. 0.2 A

Mains frequency 50–60 Hz

Nominal output voltage 5 V

Nominal output current max. 0.5 A

Operating temperature range 0°C to +45°C

Storage temperature range −40°C to +85°C

Relative humidity 20 to 90%

Weight approx. 61 g

Bluetooth

Range up to 10 m

Transmission frequency 2.4 GHz

Transmission power 8 dBm

Protocoles A2DP, AVRCP

Codecs SBC, apt-X

version 2.1 + EDR

apt-X audio coding

Outstanding audio quality apt-X technology is what wireless audio has been waiting for. With apt-X

audio coding, you can be assured of crisp, pure and full stereo sound. It allows you to not only hear, but experience and feel the audio as it was intended. Utilizing apt-X, Bluetooth can now offer wireless audio quality that is indistinguishable from the highest quality wired connection.

Professional grade sound Until now, apt-X has been the best-kept secret of the professional audio

industry. From major public broadcasters to film production studios, apt-X is used throughout the world to transmit high quality digital audio from A to Z in real-time. It was developed to meet the exacting standards of musicians and audio engineers who love the exceptional dynamic range and high fidelity it provides.

Now available on selected consumer devices, the technology ensures that music lovers everywhere can stream the rich listening experience that only apt-X can deliver.

Revolutionizing Bluetooth

listening

apt-X legacy If you have ever been to the movies or listened to the radio then chances

Bluetooth technology has revolutionized our communications and life-

style by eliminating troublesome wires and letting us get on with life “on the move”. Listening to a mobile phone conversation on a Bluetooth earpiece sounds just fine but when it comes to delivering full stereo sound, a little extra help is required. apt-X works within Bluetooth to deliver CD quality audio, ensuring you are getting the most from your wireless listening experience.

In order to deliver two-channel digital sound within the Bluetooth A2DP profile, audio compression is necessary. While traditional audio compression technologies struggle to provide full-bandwidth, high-fidelity audio over Bluetooth, apt-X works to ensure you enjoy the fullest, richest sound your music collection has to offer.

are you’ll already have heard apt-X in action. Over 20,000 radio stations across the world and thousands of cutting-edge film studios rely on apt-X for high quality audio delivery.

The digital compression technology now known as apt-X was originally developed in Queen’s University, Belfast, Northern Ireland. The technology was first brought to market for radio automation applications to store CD quality audio on computer hard drives for direct playout during radio shows, hence automating the process of the disc jockey.

The acclaim the technology received lead to further research and development and throughout the 1990s the technology was used by Broadcast and Post-production studios worldwide to deliver high-fidelity, low latency audio in situations where bandwidth was limited. The same core principles that have earned apt-X worldwide acclaim in the Broadcast and PostProduction markets make it the perfect solution for delivering high quality audio on wireless devices. apt-X is leading the way in bringing pro-audio quality to the discerning consumer.

apt-X audio coding

apt-X key features:

• Blind listening tests with industry reference audiences have shown that apt-X over Bluetooth is indistinguishable from audio delivered over wired technology. Unlike psychoacoustic-based technologies such as MP3 or AAC, apt-X can be used to transport audio without degrading the audio quality. With MPEG/AAC compression, the encoding process is destructive and content perceived as “irrelevant” is discarded. apt-X’s transparent, non-destructive approach ensures that every frequency present in the original signal is preserved in the encoded and decoded signal.

• Dynamic range of >92 dB for 16 bit audio and >120 dB for 24 bit audio.

• The overall framework of apt-X ensures a high degree of resilience to random bit errors, with the bit error response well matched to the auditory response of the human ear. apt-X employs connection and synchronization techniques to ensure a robust connection and enable delivery of audio even under stressful conditions.

• Shortest processing delay of any professional audio compression technology. Many current wireless devices suffer from unwanted delays which cause lip-sync issues, apt-X can enable real-time delivery of wireless audio ensuring seamless integration when used with video devices.

• apt-X encoded audio fits neatly within the available bandwidth of wireless transmission standards to offer an efficient solution for bandwidth-restricted connections.

Manufacturer Declarations

Warranty

Se nnheiser electron ic GmbH & C o. KG gives a war ran ty of 24 mo nths on th is product. For the current warranty conditions, please visit our website at www.sennheiser.com or contact your Sennheiser partner.

CE Declaration of Conformity

These devices comply with the basic requirements and other relevant provisions of the following directives:

• R&TTE Directive (1999/5/EC)

• EMC Directive (2004/108/EC)

• Low Voltage Directive (2006/95/EC)

• RoHS Directive (2002/95/EC)

• WEEE Directive (2002/96/EC)

• Battery Directive (2006/66/EC)

The declaration is available on the internet at www.sennheiser.com. Before putting the devices into operation, please observe the respective countryspecific regulations!

Statements regarding FCC and Industry Canada

FC C Declara tion of C onformity (DoC)

SENNHEISER Model No: PXC 310 BT

We, Sennheiser Electronic Corporation Strat. Marketing • Stefanie Reichert One Enterprise Drive • Old Lyme • CT 06371 • USA Tel: + 1 (860) 434 9190, ext . 144 Fax : + 1 (860) 434 1759

declare the above device comply with t he requirements of Federal Communic ations Commis sion.

This device compli es with Part 15 of the FCC rules . Operation is s ubjected to t he following two c onditions :

1) This device may not cause harm ful interference, and

2) This device must accept any interference received, inc luding int erference that m ay c ause undesi red operation.

Responsible Party : John Falcone

This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Manufacturer Declarations

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This class B digital apparatus complies with the Canadian ICES-003.

Changes or modifications made to this equipment not expressly approved by Sennheiser electronic Corp. may void the FCC authorization to operate this equipment.

In compliance with:

USA FCC ID: DMOCBSSAB

Since the radiated output power of this Class1 BT device is far below the FCC radio frequency exposure limits, it is not subjected to routine RF exposure evaluation as per Section 2.1093 of the FCC rules.

Canada IC: 2009A – MMBTX

Europe

Australia / New Zeeland

Singapore

Korea

China

Japan

Taiwan

Russia

SE9-PXC310BT

CMIIT ID: 2009DJ3547

R 203WWJN000008

CCAB09LP4110T2

ME61

Manufacturer Declarations

Trademarks

Sennheiser and NoiseGard

are registered trademarks of Sennheiser

electronic GmbH & Co. KG.

The Bluetooth

word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sennheiser electronics GmbH & Co. KG is under license.

and iPhone® are registered trademarks of Apple Computer, Inc.

iPod

Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark, Germany Publ. 11/09 www.sennheiser.com 540029/A01

Sennheiser PXC 310 BT User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Important safety instructions

PXC 310 BT

Delivery includes

Product overview

Putting the PXC 310 BT into operation

Charging the battery pack

Adjusting the headband

Switching the PXC 310 BT on/off

Connecting the PXC 310 BT to the audio source

Connecting the PXC 310 BT using the audio cable

Using the PXC 310 BT

Adjusting the PXC 310 BT to the listening situation

Changing the volume

Remote-controlling connected devices from the PXC 310 BT

Resetting the settings of the PXC 310 BT

Transporting the PXC 310 BT

Cleaning and maintaining the PXC 310 BT

If a problem occurs ...

Accessories and spare parts

Specifications

apt-X audio coding

Manufacturer Declarations
