Sennheiser MP3128 User Manual

Digital Audio Player

128-6648

User’s Guide

MP3128

Content

2

Controls and Indicators 4 Inserting the Battery 5 LCD Indicators and Icons 6 MENU LIST 7 Playback/ Stop Function 8 Adjusting the Volume 10 Scanning Through a Music File 11 To search for a desired music track during playback 12 Menu Mode 14 Repeat Track Mode 15 Setting the Equalizer(EQ) 16 Setting the Hold Function 17 Deleting a file 18 MP3128Setting Options 19 Installing the Software on a Personal Computer(PC) 23

MP3128

3

Connecting the MP3128 to a PC 24 Installing the USB Driver 25 Confirming the USB Driver Installation 26 How to use Groove Software 27 Transferring a file to the MP3128 28 Transferring a file to the PC 29 Deleting a file 30 Changing a file name 31 Formatting the MP3128 32 Moving the location of a file 33 Setting options 34 Cautions 35 Troubleshooting 36 Specifications & Accessories 38 Warranty 39

Controls and Indicators

4

Earphone Jack

LCD Display

Volume Adjustment button

Connector for Holder

PLAY/STOP/( ) FF/REW button ( )

Menu/Mode Setup button

Battery Cover

USB cable port

MP3128

5

Inserting the Battery

Press and pull the battery cover downward in the direction of the arrow to open.

Insert one AA battery observing polarity and push the battery cover upward in the direction of the arrow to close.

LCD Indicators and Icons

6

Repeat Icon

HOLD Icon

Battery Capacity Icon

Elapsed Playing Time

Equalizer(EQ) Icon

Current File Information

Track Number

MP3128

7

MENU LIST

Playback / Stop Function

8

To playback

Insert the battery and press the PLAY/STOP button( ), the "Audiovox" logo and memory information will be displayed on the LCD screen. The first track will be played automatically.

Current File Information

- Title_Singer Information

- Etc. Information display

MP3128

9

To stop

During playback, press the PLAY/STOP button( ) once. Playback will be stopped.

Note : If the MP3128is inactive for 10 seconds in the STOP mode,

the power will be automatically shut off.

Adjusting the Volume

10

To adjust the Volume

Press the VOLUME buttons located on the front of the unit to adjust volume.

You can adjust volume from 0to 20.

- To Adjust Volume Slowly : Momentarily Press and Release the front panel buttons in the direction desired to adjust the volume 1 interval at a time(0-20) until the desired volume is reached.

- To Adjust Volume Rapidly : Press and Hold the front panel buttons

in the direction desired until the desired volume is reached .

11

Scanning through a music file

To return the beginning of current file after play ends, press and release the FF/REW button( ) down during playback.

To search a track during playback, press and HOLD the FF/REW button( ) up to fast forward through the track. Press and the HOLD FF/REW button( ) down to fast rewind through the track. Release the button to playback again.

Fast Forward For the first 5 seconds : 5 times faster After 5 seconds : 10 times faster

MP3128
