Cat. No. 004513
Microphones | Dynamic Microphone
General Description
The e 835 S is a cardioid lead vocal stage microphone specially designed to
perform under pressure.
Features
j
Rugged metal body
j
Excellent feedback rejection
j
High sound pressure handling capability
j
Shock-mounted capsule provides excellent suppression of handling noise
j
Uniform on- and off-axis response
j
Cardioid pick-up pattern provides isolation from other on-stage signals
j
Hum compensating coil
j
Delivery includes: 1 e 835
1 microphone clip
1 pouch
Technical Data
Pick-up pattern ...................................................................... cardioid
Frequency response .................................................40 – 16,000 Hz
Sensitivity (free field, no load, 1 kHz)...........................2.7 mV/Pa
Nominal impedance ................................................................. 350 Ω
Min. terminating impedance.....................................................1 kΩ
Dimensions ................................................................Ø 48 x 180 mm
Weight ........................................................................................ 330 g
Profile
Cardioid vocal microphone, hum compensating coil, frequency
response 40 Hz – 16 kHz, sensitivity (free field, no load) 2.7
mV/Pa at 1 kHz, nominal impedance 350 Ω, min. terminating
impedance 1 kΩ , dimensions Ø 48 x 180 mm, weight 330 g.
