Bedienungsanleitung
Instructions for use
Notice d‘emploi
Istruzioni per l‘uso
Instrucciones para el uso
Gebruiksaanwijzing
602-
II
602-II
The cardioid 602-II is a dynamic microphone especially
suitable for use with kick drums, bass guitar cabs, tubas
and other low frequency instruments.
Its lightweight high-performance voice coil construction
delivers fast transient signals. The low frequency
extension and mid band attenuation produce an ultrasmooth pre-shaped signal.
direct use on the most problematic bass signal sources
The microphone is ideal for
.
Features
y Rugged, lightweight aluminium body for stable
positioning on long microphone boom arms
y Lightweight high-performance voice coil construction
for fast transient response
y Low frequency extension
y
Ideal for direct use on the most problematic bass signal
sources
y
Frequency-independent directivity provides effective
rejection of incidental rear noise
y Humbucking coil
y Integral stand mount
3
Delivery includes
y
602-II microphone
y
Pouch
y
Instructions for use
y Warranty Certificate
Removing the sound inlet basket
4
Positioning the microphone
Kick drums
Position Resulting sound Commentary
Much attack,
little resonance,
dry
Position the microphone
at a distance of a few
centimeters from the
batter head.
Less attack,
much resonance,
smooth,
voluminous
Less attack Position the microphone
Position the microphone
at the level of the
resonant head.
in the middle between
the batter head and the
re-sonant head. For less
attack in all three
positions,
turn the microphone
away from where the
beater strikes.
In order to prevent interference due to crosstalk between
adjacent sound sources, try to position the microphone so
that the interfering sound source is located in the angle
area of the highest cancellation of the microphone
(approx. 180°; see polar diagram).
5
Polar diagram
60°
90°
30°
0°
0
5
10
15
20
25
dB
30°
60°
90°
120°
150°
125 Hz
180°
250 Hz
500 Hz
1000 Hz
Frequency response curve
dBv
- 40
- 50
- 60
- 70
- 80
- 90
6
50
20
0°, 1 m
100
200
500
0°, 5 cm
1000
16000 Hz
2000
150°
2000 Hz
4000 Hz
8000 Hz
5000
10000
120°
20000
Hz
Specifications
Transducer principle dynamic
Frequency response 20.....16,000 Hz
Pick-up pattern cardioid
Sensitivity 0.9 mV/Pa (at 50 Hz)
(free field, no load) 0.25 mV/Pa (at 1 kHz)
Nominal impedance (at 1 kHz) 350 Ω
Min. terminating impedance 1 kΩ
Connector XLR-3
Dimensions Ø 60 x L 153 mm
Weight 318 g
Pin assignment of XLR-3 connector
+
+
12
3
XLR
+
1
2
3
+
12
3
XLRXLR
7
Overview of microphone applications
Variant
e602-II
e604
e606
e608
e614
e815
e825
e835
Application
Vocals x x x x x x
Choirs x
Studio,
acoustic instruments
Orchestra x
Brass / Saxophone x x x
Acoustic guitar x
Acoustic bass x
Guitar amplifiers x
Bass amplifiers x
Leslie x x x
Piano, grand piano x
Kick drums x
Snare drums x x x
Rack toms x x x
Floor toms x x x
Congas x x x
Cymbals x
Percussion x x x x
Overheads x
x
e840
e845
e865
8
Manufacturer declarations
Warranty
2 years
Approval
Sennheiser electronic GmbH & Co. KG declare that
this device is in compliance with the applicable CE
standards and regulations.
WEEE Declaration
Please dispose of this product at the end of its operational lifetime by bringing it to your local collection point
or recycling centre for such equipment.
9
10
Sennheiser electronic GmbH & Co. KG
30900 Wedemark, Germany
Phone +49 (5130) 600 0
Fax +49 (5130) 600 300
www.sennheiser.com
Printed in Germany Publ. 03/06 515863/A02
