Page 1
TM
DW Pro 2 ML
Page 2
TM
DW Pro 2 ML
Double-sided DECT headset
Enjoy your calls in HD voice clarity and get
natural high-definition sound for superior
voice clarity. Work safe in the knowledge
that the ActiveGard™ technology will
protect your hearing.
Imagine making every call in comfort, and
being able to focus on what’s important:
the conversation.
Benefits and Features:
Optimized for Microsoft Lync
Iconic design – crafted for best comfort
Sennheiser HD voice clarity – wideband
sound for natural listening experiences
Ultra
noise-canceling microphone filters
out unwanted background noise
Pairing for desk sharing and phone
conferences – intuitive and easy to set up
Microphone mute and volume up and
down – intuitive user interface
Full workday talk time – 8 hours in wideband sound mode and 12 hours in
narrowband sound mode
Re-charge 50% of your battery in
20 minutes – intelligent fast charging
Long distance wireless range – in typical
office building: up to 55 m and in
line of sight: up to 180 m
ActiveGard™ technology – protects your
hearing against acoustic shock
Product name
DW Pro 2 ML- EU DW Pro 2 ML- UK DW Pro 2 ML - US DW Pro 2 ML - AUS
Order name
EAN No.
DW 30 ML – EU DW 30 ML – UK DW 30 ML – US DW 30 ML – AUS
40 44155 05196 4 40 44155 05198 8 40 44155 05197 1 40 44155 05199 5
UPC No.
6 15104 18199 1 6 15104 18201 1 6 15104 18200 4 6 15104 18202 8
Art. No.
504462 504464 504463 504465
Technical Data
DECT for EU, UK, AUS
DECT CAT-iq (1.880 to 1.900 MHz)
DECT for US
DECT 6.0 (1.920 to 1.930 MHz)
GAP compatible
Yes (Headset)
Headset
Connect to Base
Base Station
Connect to desk phone and softphone
Headset Auto Link to Base
Yes, can be activated on the base station
Firmware Requirement
V. 89 or higher for headset and base
EHS (Electronic Hook Switch)
Yes (accessory – order EHS adapter separately)
Mechanical Hook Lifter
HSL 10 (accessory – order separately)
Call control
Plug and play
MS Communicator 2007 R2 certified/
optimized
Yes
MS Lync certified/optimized
Yes
Microphone
Frequency response Wideband
Mode
150 Hz – 6.8 KHz
Frequency response Narrowband
Mode
300 Hz – 3.5 KHz
Mute Microphone
Yes
Speaker
Speaker type
Neodynium Magnet Speaker
Frequency response Wideband
Mode
150 Hz – 6.8 KHz
Frequency response Narrowband
Mode
300 Hz – 3.5 KHz
All acoustic parts observe the TIA-920 wideband standards
Product Information
Page 3
Product Information
General Data
Operational temperature range
+5 °C to + 45 °C (+41 °F to +113 °F)
Storage temperature range
-20 °C to + 70 °C (-4 °F to +158 °F)
Weight Headset
85 g
Ear pad size
ø 50 mm / 1.96 inches
Battery (Lithium Polymer)
Exchangeable for service (see manual)
Personalization
Yes with nameplate on headset
Range – line of sight
180 m
Range – in typical office building
55 m
Automatic power adjustment
Yes (distance between headset and base)
Talk time in Wideband Mode
Up to 8 hours
Talk time in Narrowband Mode
Up to 12 hours
Stand by time
Up to 100 Hours
Auto – headset OFF when out of
range
Yes ➠ after 30 minutes
Charge time 0 – 50%
20 minutes
Charge time 0 – 100%
1 hour
Packaging
Package dimensions (H x W x D)
16.5 cm x 16 cm x 16 cm
Package weight
970 g
Units in distributor master carton
8
Master carton dimensions
(H x W x D)
36 x 38 x 38 cm
Master carton weight
9.09 kg
Safety
Automatic Acoustic Shock
Protection
YES ➠ ActiveGard™
EU/AUS Limiter
YES ➠ Activation by dip switch
Delivery content
Headset (with name plate)
Base Station
Power supply
USB cable
Audio phone cable
Printed QuickGuide
CD with Manual, QuickGuide, nameplate template and HeadSetup Installation Program
Printed safety guide
Accessories
Order name Art. No EAN No. UPC No.
EHS Avaya adapter
CEHS-AV 01 504100 40 44155 047387 6 15104 17407 8
EHS Avaya adapter
CEHS-AV 03 504536 40 44155 081671 6 15104 23371 3
EHS Snom adapter
CEHS-SN 01 504101 40 44155 047394 6 15104 17408 5
EHS Snom adapter
CEHS-SN 02 504188 40 44155 074574 6 15104 22297 7
EHS Alcatel adapter
CEHS-AL 01 504102 40 44155 047400 6 15104 17422 1
EHS Cisco adapter
CEHS-CI 01 504103 40 44155 047417 6 15104 17423 8
EHS Cisco adapter
CEHS-CI 02 504533 40 44155 080230 6 15104 23183 2
EHS Polycom adapter
CEHS-PO 01 504104 40 44155 047424 6 15104 17424 5
EHS DHSG adapter
CEHS-DHSG 504105 40 44155 047431 6 15104 17425 2
Headset charger
CH 10 504366 40 44155 050998 6 15104 18053 6
Headset charger (only cable)
CH 10 USB 504365 40 44155 051001 6 15104 18055 0
Handset Lifter
HSL 10 500712 40 44155 047387 6 15104 17407 8
Interface box for AEI EHS
TCI 01 500275 40 44155 047394 6 15104 17408 5
Multi USB Power Source
MCH 7 504348 40 44155 050820 6 15104 18030 7
Single components
Headset and base station can be purchased separately. This allows a 2nd headset to be added to any DW Series base station or used as a spare.
Order name Art. No EAN No. UPC No.
Single headset of DW 30
DW 30 HS 504326 40 44155 050608 6 15104 17998 1
DW Base set for DW ML series
DW BS ML - EU 504478 40 44155 052121 6 15104 18217 2
DW Base set for DW ML series
DW BS ML - UK 504480 40 44155 052145 6 15104 18219 6
DW Base set for DW ML series
DW BS ML - US 504479 40 44155 052138 6 15104 18218 9
DW Base set for DW ML series
DW BS ML - AUS 504481 40 44155 052152 6 15104 18220 2
Base including power supply, audio cable and USB cable
Page 4
Product Information
Spare parts
Order name Art. No EAN No. UPC No.
Power supply US
UNI PS US 01 92893 40 12418 928933 6 15104 92893 0
Power supply AUS
UNI PS AUS 01 520334 40 44156 023083 6 15104 13459 1
Power supply UK
UNI PS UK 01 92892 40 12418 928926 6 15104 92892 3
Power supply EU
UNI PS EU 01 94707 40 12418 947071 6 15104 94707 8
Spare battery
DW BATT 03 504374 40 44155 051087 6 15104 18067 3
Earpad
HZP 27 DW 20+30 504350 40 44155 050844 6 15104 18032 1
Name plate set
Name plate set, DW 20+30 504351 40 44155 050851 6 15104 18033 8
Audio cable RJ 45 – RJ 9
RJ 45 - RJ9 - DW 504364 40 44155 050981 6 15104 18052 9
USB cable
USB cable - DW 504363 40 44155 050974 6 15104 18051 2
Head Pads
Head Pads, DW Pro2 504377 40 44155 051117 6 15104 18075 8
Mic foam
Spare Mic foam, DW 20/30 504362 40 44155 050967 6 15104 18049 9
Battery Lid
Battery Lid, DW Pro2 504376 40 44155 051100 6 15104 18074 1
Fixation kit for Handset Lifter
Type approvals
Worldwide
TCO ‘07
EMC - EN 301489-6
RADIO - EN 301406
Safety - EN 60950-1
SAR (headset) - EN 50360 ref. EN 62209-1
This product meets the safety requirements of CSA
No. 231437
Europe
CE
USA:
Approved by
Canada:
Industry Canada RSS 213 Issue 2
IC ID 2099 D-TDB1 (base station)
IC ID 2099 D-TDH1 (headset)
FCC 47 CFR Part 15 (d)
FCC ID: DMOCDBDIB (base station)
FCC ID: DMOCDHDFC (Pro 1 headset)
FCC ID: DMOCDHDEC (Pro 2 headset)
AS/ACIF S004
USA:
Australia
