Page 1
SD Office
Page 2
Headband
Ear hook
Product name SD Office - US
Order name
EAN No.
SD 10 – US
40 44155 088328
UPC No.
6 15104 247390
Art. No.
506006
Technical Data
DECT for US
DECT 6.0 (1.920 to 1.930 MHz)
GAP compatible
Yes (Headset)
Headset
Connect to Base
Base set
Connect to desk phone and softphone
Headset Auto Link to Base
Yes, can be activated on the base station
EHS (Electronic Hook Switch)
Yes (accessory – order EHS adapter separately)
Mechanical Hook Lifter
HSL 10 (accessory – order separately)
Soft phone call control Software
HeadSetup (included on CD)
Microphone
Frequency response Wideband
Mode
150 Hz – 6.8 KHz
Frequency response Narrowband
Mode
300 Hz – 3.5 KHz
Mute Microphone
Yes
Speaker
Speaker type
Neodynium Magnet Speaker
Frequency response Wideband
Mode
150 Hz – 6.8 KHz
Frequency response Narrowband
Mode
300 Hz – 3.5 KHz
All acoustic parts observe the TIA-920 wideband standards
Product Information
SD Office
Single-sided DECT headset
Enjoy your calls in HD voice clarity and get
natural high-definition sound for superior voice
clarity. Work safely ensured that the Active
-
Gard™ technology will protect your hearing.
Imagine making every call in comfort, and
being able to focus on what’s important:
the CONVERSATION.
Benefits and Features:
Premium design – crafted for best comfort
Sennheiser HD voice clarity – wideband
sound for natural listening experiences
H
igh comfort wearing styles - choose between ear hook and headband wearing style
Noise-canceling microphone filters out
unwanted background noise
One touch on the base station to select the
channel you wish to call from - between
desk phone and softphone
Pairing for desk sharing and phone
conferences – intuitive and easy to set up
Microphone mute and volume up and
down – intuitive user interface
Full workday talk time – 8 hours in wideband sound mode and 12 hours in
narrowband sound mode
Re-charge 50% of your battery in
20 minutes – intelligent fast charging
Long distance wireless range – in typical
office building: up to 180 ft and in line of
sight: up to 590 ft
ActiveGard™ technology – protects your
hearing against acoustic shock
Page 3
Product Information
General Data
Operational temperature range
+41 °F to +113 °F
Storage temperature range
-4 °F to +158 °F
Weight, ear hook version
0.78 oz
Weight, headband version
1.76 oz
Ear pad size
ø 1.96 inches
Battery (Lithium Polymer)
Exchangeable for service (see manual)
Personalization
Yes with nameplate on headset
Range – line of sight
590 ft
Range – in typical office building
180 ft
Automatic power adjustment
Yes (distance between headset and base)
Talk time in Wideband Mode
Up to 8 hours
Talk time in Narrowband Mode
Up to 12 hours
Stand by time
Up to 100 Hours
Auto – headset OFF when out of
range
Yes ➠ after 30 minutes
Charge time 0 – 50%
20 minutes
Charge time 0 – 100%
1 hour
Packaging
Package dimensions (H x W x D)
6.5 x 6.3 x 6.3 in
Package weight
30 oz
Units in distributor master carton
8
Master carton dimensions
(H x W x D)
14 x 15 x 15 in
Master carton weight
294 oz
Safety
Automatic Acoustic Shock
Protection
YES ➠ ActiveGard™
EU/AUS Limiter
YES ➠ Activation by dip switch
Delivery content
Headset (with name plate for ear hook and distance holder)
Base Station
Power supply
USB cable
Audio phone cable
Headband
1 bendable ear hook (mounted on headset)
2 additional ear hooks: small and large sized
Name plate holder for headband and name plate instruction
Printed QuickGuide
CD with Manual, QuickGuide, nameplate template and HeadSetup Installation Program
Printed safety guide
Accessories
Order name Art. No EAN No. UPC No.
EHS Avaya adapter
CEHS-AV 03 504536 40 44155 081671 6 15104 23371 3
EHS Avaya adaptor
CEHS-AV 04 504589 40 44155 087987 6 15104 24686 7
EHS Avaya adaptor
CEHS-AV 05 506037 40 44155 090291 6 15104 25053 6
EHS Snom adapter
CEHS-SN 01 504101 40 44155 047394 6 15104 17408 5
EHS Snom adapter
CEHS-SN 02 504188 40 44155 074574 6 15104 22297 7
EHS Alcatel adapter
CEHS-AL 01 504102 40 44155 047400 6 15104 17422 1
EHS Cisco adapter
CEHS-CI 01 504103 40 44155 047417 6 15104 17423 8
EHS Cisco adapter
CEHS-CI 02 504533 40 44155 080230 6 15104 23183 2
EHS Cisco adaptor
CEHS-CI 03 506038 40 44155 090307 6 15104 25054 3
EHS Polycom adapter
CEHS-PO 01 504104 40 44155 047424 6 15104 17424 5
EHS DHSG adapter
CEHS-DHSG 504105 40 44155 047431 6 15104 17425 2
Handset Lifter
HSL 10 500712 40 44156 012384 6 15104 11795 2
EHS ShoreTel
CEHS-SH 01 504590 40 44155 088038 6 15104 24692 8
Mobile adaptor cable
CEHS-MB 01 506033 40 44155 089165 61 5104 24889 2
Interface box for AEI EHS
TCI 01 500275 40 44156 001913 6 15104 10232 3
Headset Charger
CH 10 504366 40 44155 050998 6 15104 18053 6
Spare Headset Charger - USB
CH 10 USB 504365 40 44155 051001 6 15104 18055 0
Multi USB Power Source
MCH 7 504348 40 44155 050820 6 15104 18030 7
Spare earhook set
EH set DW 10 F 504352 40 44155 050868 6 15104 18035 2
Single components
Headset and base station can be purchased separately. This allows a 2nd headset to be added to any SD Series base station or used as a spare.
Order name Art. No EAN No. UPC No.
SD Office, Headset
SD 10 HS 506000 40 44155 08826 7 6 15104 24728 4
SD base set
SD BS - US 506021 40 44155 088472 6 15104 24769 7
Base including power supply, audio cable and USB cable
Page 4
Product Information
Spare parts
Order name Art. No EAN No. UPC No.
Power supply US
UNI PS US 01 92893 40 12418 928933 6 15104 92893 0
Spare battery
DW BATT 03 504374 40 44155 051087 6 15104 18067 3
Headband
SHS 04 SD10 spare 506060 40 44155 090741 6 15104 25156 4
Earpad
HZP 25 DW 10 504349 40 44155 050837 6 15104 18031 4
Earhook bendable
EH DW 10 B 504370 40 44155 051049 6 15104 18062 8
Name plate set
Name plate set, SD 10 506061 40 44155 090710 6 15104 25150 2
Audio cable RJ 45 – RJ 9
RJ 45 - RJ9 - DW 504364 40 44155 050981 6 15104 18052 9
USB cable
USB cable - DW 504363 40 44155 050974 6 15104 18051 2
Fixation kit for Handset Lifter
Fixation kit - HSL10 504032 40 44155 046984 6 15104 17342 2
Type approvals
Worldwide
TCO ‘07
EMC - EN 301489-6
RADIO - EN 301406
Safety - EN 60950-1
SAR (headset) - EN 50360 ref. EN 62209-1
This product meets the safety requirements of CSA
No. 231437
Europe
CE
USA:
Approved by
Canada:
Industry Canada RSS 213 Issue 2
IC ID 2099 D-TDB1 (base station)
IC ID 2099 D-TDH1 (headset)
FCC 47 CFR Part 15 (d)
FCC ID: DMOCDBDIB (base station)
FCC ID: DMOCDHDKB (headset)
AS/ACIF S004
USA:
Australia
