Sendo 200 User Manual

To enter 2 characters on the same key, enter
the first one and then wait for the cursor to
reappear before entering the second.

Example: To enter the name “Ross” when you
are in lower case mode:

Press to enter upper case mode,
Press three times, to display "R",
you will then return to lower case mode,
Press three times, to display "o",
Press four times, to display "s",
Then press four times, to display "s".

Entering symbols

A long press on displays a table
showing all the symbols available to you.
Scroll down the table to display more symbols.

To enter a symbol:
1 Scroll to the row containing the symbol

you want.

2

Press the numeric key ( to )

to reach the the symbol you want.

Example: To enter the symbol , scroll to
the 4th row then press .

Splash

Go into the Extras menu and select Splash.
You will see an animated display.

An incomplete curly pipeline is displayed
starting at the top left of the screen and
water is slowly flowing towards the open
end. The goal is to connect the open end
of this pipe to the outlet at the bottom right
of the screen before the water overflows!

To do this you are supplied with pieces
of straight and bent pipe, which are shown
at the right of the screen. The piece at the
top of these is the next piece that you must
place on the board.
You move the cursor using the keys on the
grid below, the key drops your
bombs.

Messages

Predictive Text Input

To save time when you are writing a text
message, your phone has a feature which
guesses the letters that you are typing and tries
to complete the word.

This input method allows you to simply press
each key once. For example, to write the
name “Ross”, press , then , then

, then just once each.

The word may change as you type, but
don’t worry about what is on the screen
until you have finished the word.

Sometimes
different words share the same sequence of
key presses. If the finished word is wrong,
press to scroll through other possibilities.
If the word that you are looking for is still
not there, press repeatedly to change
the text mode to and enter the

word

again.
After you have completed a word, press the

space key to enter the next word.
Press and hold to pick a symbol to
insert from the character table.
Some intelligent punctuation (including full
stops, hyphens and apostrophes) are also
available on . The punctuation mark is
completed when you enter the next keystroke.

Your phone

Extras

Setting time and date

Enter the Settings menu to set the time
and date. Go to Set date and press ,

Select. Enter the date, Press , OK,

Go to Set time and press , Select. Enter
the time in 24 hour format, Press , OK.
The date and time will be stored.

Alarm clock

You can use your phone as an alarm clock.
Enter the Settings menu and press ,

Alarm. Set the alarm to On and enter the

time (in 24hr format) when you require the
phone to ring. When it rings press

, Off, to switch it off, or
, Snooze, to stop the alarm for ten

minutes. The alarm will then sound again.

Note: The alarm will sound even if the
phone is switched off. The phone will
power on but you will not be able to
receive or make calls. Once the alarm
finishes the phone will switch off.

Equalizer

Enter the Sounds menu and select Equalizer.
This menu allows you to alter the
earpiece audio settings of your phone.
Choose from these 3 settings for optimum
audio quality:

• Treble

• Normal

• Bass

Shortcuts

To lock/unlock the keypad, press ,
then from the main screen.

To enter/exit silent mode press then

from the main screen.

To enter a pause while dialling press and
hold until the letter p appears.
This will insert a pause of 3 seconds.

☛☛

1

2

3

4

Up and down keys

Located on the front of your
phone - these can increase
volume or scroll through menus
and options.

Soft keys

These keys perform the function
indicated by the text immediately
above them on the display.

Quick Access key

The function of this key will vary
depending on the model of your
phone. It provides quick access to
a certain function such as SIM
Toolkit or messaging.

Clear key

This erases characters or text or
takes you back to your previous
step, depending on the context.
A long press on this key takes you
back to the main screen.

FlippIT

Go into the Extras menu and select FlippIT.
There are 6 levels; 3x3 is the easiest.
The objective of the game is to change the
white discs to black discs. You do this by
selecting one of the white discs by pressing
the key. This turns the white disc to
black, but also turns all of the discs directly
above, below, to the left and to the right of
the selected discs to black.
You can move the cursor from one to another
using the keys in the grid below.

Calling your voice mail

When you have a new message in your
voice mailbox, your phone displays either the
voice mail icon in the main screen or
a text message sent from the network.
This depends on your service provider.

Press and hold . If the phone asks for
the voice mailbox number, enter it and press

, Call. The number can be obtained from

your service provider.

Reading a text message

When you receive a text message, the
envelope icon is displayed at the top
of the main screen.

1 Press , Read, to display the new

message directly from the main screen.

2 To read old messages select read from

the messages menu.

3 Use the up and down keys and to

scroll through the message.

4 Press , Options, to access the

following message options:

Delete Removes the message.
Reply

Sends a text message to the sender.

Call Calls the sender (or, if there is a

number in quotes in the message,
this number is called instead).

Save no. Adds the sender’s phone number

to your contact list.

Time/date Displays the date and time of the

message.

Forward

Sends the message to someone else.

Sending a text message

You can send messages of up to 160
characters to another GSM phone.
1 Enter the Messages menu and select

the option Send.

2 Type in a new message or select a

message from a list of saved messages.

3 When you have entered the text, press

, Send.

4 Enter the destination phone number, or

press , Contacts, and select a
name from your contact list.

5 Press , Send, to send the message.

Note: If you reply to a message, you do not
have to re-enter the number. This is done
automatically.

☛☛

Sending a Smiley SMS

Send a picture with your text message to

compatible phones. All other phones will display
an Internet style Smiley. Choose , Smiley.

1. Emotions 2. Celebrations

3. Sports 4. Animals 5. Others

Select the Smiley you would like to use from
one of these categories and press , Select.
The text is restricted to 156 characters to allow
space for the Smiley.

Reading a Smiley SMS

When you choose a message that has a Smiley
in it, the Smiley appears on the screen for 3
seconds or until a key is pressed. Then the
message appears. After this time the message
reads as normal. A message with a smiley
attached has a icon if new and a

if read.

Note: If replying to or forwarding an SMS the
Smil

ey

will not display and only appears on a

new message.

Message settings

This menu offers three options:

Status report

Allows you to set whether or not you wish to
be

informed when your correspondent has

received

the text message.

Centre number

Allows you to enter or change the service
centre number for text messaging.

Voice mail

Allows you to enter or change your voice
mail number.

☛☛

2

4

2

3

1

Declaration of conformity

We: Sendo International Ltd
Of: 10th Floor AIA Plaza, 18 Hysan Avenue,

Causeway Bay, Hong Kong.

Declare under our sole responsibility that the product:
SND200, Known as S200 Identified by IMEI numbers
in the range:
TAC: 350156 FAC: 01
SNR: From: 000001 To: 499999

To which this declaration relates, is in conformity with the
following standards:
EN60950 (Electrical Safety Standard, IT equipment)
ETS 300 342-1 (Product standard for EMC)
ETS 300 607-1 (GSM Phase 2 MS test specification)
as defined in:
TBR19 (as interpreted by GT01 version 4.6)
TBR20 (as interpreted by GT01 version 4.6)
TBR31 (as interpreted by GT01 version 4.6)
TBR32 (as interpreted by GT01 version 4.6)
ES 59005 (European Council recommendation 1999/519/EC)

We hereby declare that the above named product
is in conformity to all the essential requirements of
Directive 1999/5/EC.

The conformity assessment procedure referred to in Article 10
and detailed in Annex IV of directive 1999/5/EC has been
followed with the involvement of the following notified body:

BABT, Claremont House, 34 Molesey Road,
Walton-On-Thames, KT12 4RQ. England.
Identification Mark: 168 (notified body number)

The technical documentation relevant to the above
equipment will be held at: Sendo Ltd,
Centrelink House, Talbot Way, Small Heath Industrial
Estate, Birmingham, B10 0HJ England.

The authorised EU representative is:

Mike Roper

Senior Approvals Engineer

30/03/01

Dialling a number

1 Key in the area code and number that

you want to call then press , Call,

to dial.
To delete the entire number and return to
the main screen, press and hold .

2 You can adjust the earpiece volume in

a call by using the front keys .

3 To end the call, press , End.

Making an international call

1 Press and hold until the plus sign

"+" is displayed. This replaces the

international access code.

2 Enter the country code, area code,

and phone number.

3 Press , Call, to dial.

Making an emergency call

1 Enter 112 (or the local emergency

number).
Press , Call, to dial.

Making calls from the contact list

1 Press from the main screen, you can

also press , Contacts then select
the Search option.

2 Type in the first letters of the name or

scroll and find the one that you want.

3 Press , Call, to dial.

Speed dialling

Allows you to dial a number simply
by pressing and holding the assigned key
from the main screen.

To assign a contact list entry to a key:

Press , then press and hold one of the
keys to until the key number
appears on the left of the screen, beside
the name. This indicates that the speed
dial is successfully assigned.

Making a call from the calls list

The phone stores a list of your recent
incoming, outgoing and missed calls.
The list stores up to 30 entries.

An icon on the left of the screen indicates
the type of call:

Incoming call

Missed call

Outgoing call

To dial a number from the redial/calls list:

Press to access the list. Scroll and
find the one that you want and press

, Call, to dial.

Making a call

Answering a call

Answering a call

To answer a call, press , Accept.
To reject a call, press , Reject.

Call waiting

This feature means you are informed of a
second incoming call by an audible tone
in the earpiece.
Press , Reject, to reject the second call.
Press , Accept, to put the current call
on hold and activate the second call.
To end the active call and return to the
held call, press , End.
To switch between calls, press ,

Options, then select the Swap option.

Note: Your network may not support call
waiting. If it does not, accepting a second
call will end the first call. You will not be
able to switch.

In call options

When you are in a call, you can press

, Options, these could be:

Contacts

Gives you access to the contact list.

Hold/Unhold

Puts the active call on hold/reactivates
the held call.

Mute/Unmute

Switches the microphone off/on.

Send message

Allows you to send a text message.

SIM Toolkit

Gives you access to the SIM Toolkit.

Swap

Swaps between the current call and the
call on hold.

End all

Ends all calls.

☛☛

Useful tips

Key List of characters available

1 1. , @ ‘ ? ! “ : ; ¿ ¡
2 a b c 2 à ä å æ ç
3 d e f 3 é è
4 g h i 4 ì
5 j k l 5
6 m n o 6 ñ ò ö ø 6
7 p q r s 7 ß
8 t u v 8 ü ù
9 w x y z 9
0 0
# space

Key List of characters available

123456789

.,-!

?

@( ) :
&'"/_;$%+
*=<>#£¥ ∆

§ ΓΘΛΞΠΣΦ

ΨΩ

¿ ¡

адежз
йимДЕЙтсЖ
цшЯьщСЦШЬ

C

C

On the right of the screen you will see the
number of moves that you have made so
far, and also the smallest number of moves
that it is possible to complete the level in.
With each higher level the grid gets bigger
and bigger, and harder!

The key places the section in the
position of the flashing cursor. However,
be careful, once you have put down a
piece you cannot move it.

You are provided with 3 bombs. These
bombs will delete the piece where the
cursor is positioned. Use them wisely.

Once you have managed to complete you
can press to speed up the pipeline to
the outlet, you can press the key to speed up
the water, to finish the level. With each level
it gets faster and faster. Good luck!

Scizzors

Go into the Extras menu and select Scizzors.
You will see an animated display.
In order to select the stone, press .
To select the paper press .
To select the scissors press .
The object of the game is to try to beat
the computer by selecting one of the

3 objects. When you do this the computer
also selects one of the 3 objects.

The rules are simple:

Scissors (2 fingers out) cuts paper,

therefore scissors wins,

Paper (flat palm) wraps stone,

therefore paper wins,

Stone (fist) blunts scissors,

therefore stone wins,
Two of the same result in a draw.

When you drop a counter, it will fall all
the way to the bottom or sit on top of any
other counters that are in that column. So,
think carefully before you play!

You move the flashing cursor left and
right along the top of the screen using
the and keys.
Pressing will drop the counter into
the column.

Quaddro

Go into the Extras menu and select

Quaddro. You can select the

number of players:

Demonstration mode lets you watch

the computer play against itself.
You against the computer.
You against a friend.

The objective of the game is to drop your
counters into the slots along the top of the
board, in the attempt to create a line of
four, horizontally, vertically or diagonally.

Changing the editing mode

The current editing mode is indicated at the
bottom of the screen by one of these icons:

Lower case text mode
Upper case text mode
Numeric mode
T9 Text Input (lower case)
T9 Text Input (upper case)

You can switch between upper case, lower
case, and numeric modes by repeatedly
pressing . You can switch to predictive
T9 Text Input by repeatedly pressing .

These are the characters which come on to the
screen when you press the numeric keypad.
They are featured in the table below:

Ringer tone composer

Go into the Sounds menu and press ,

Composer.

Change your ringer tones to personalise
your phone. Create your own tones with
our ring tone composer.

You have 2 entry methods.

Text notes are entered textually
Graphic notes are entered on a musical

score

Both entry methods use the same key
presses unless stated.

In this menu the keys represent the
following notes:

CG
DA
EB
F
Enters a rest (text mode)
Enters a rest (graphic mode)
Changes the scale of the note

between the range 1-4

Changes the duration of the
note. Each press decreases the

duration of the note between the

range: full note, half note, quarter
note, eighth note, sixteenth note
and thirty-second note.
Changes a normal note to a sharp
and a sharp back to a normal note.
Changes a normal note to a dotted,
double dotted or 2/3 note.
Erases the previous note. A long
press will clear all notes.

Tip: A short press of the and keys
will move you between notes in either
entry mode.

Once you have composed the tone press

, Options to enter the menu screen.

The available options are:

Tempo: Allows you to choose from a list

of tempos at which to play your

tone.

Play: Allows you to play your melody.
Save: Allows you to save your melody.
Delete: Allows you to delete the tone.
Send: Allows you to send your tone to

one of your friends.

Receiving a ringer tone

If you have received a ringer tone press

, Options to enter the menu from
where you can play, save or delete the
tone. If you press the ring tone and
message will be deleted.

Note: It is only possible to save 5 ringer
tones whether you have composed them
yourself or received them as a message.
To save more you will have to overwrite
an existing ringer tone.

☛☛

☛☛

O587-Sendo-UK-12pp-insert 17/10/01 1:10 pm Page 1

Troubleshooting

Getting started SettingsSounds Using the contact list

To use your phone, you must first insert the
miniature SIM card supplied by your service
provider, and then charge the battery.

Removing the back cover

Press down on the ridges below the clip
and slide the cover back. Lift off.

Inserting the SIM card

Place the SIM in the phone, starting with the
right side first, making sure that the golden
contacts of the card are touching the
contacts of the phone. Hold the SIM card in
place and slide the metal plate to the right,
in order to cover the left hand side of the
SIM card.

Fitting the battery

Insert the battery with the label facing down.
Align the tabs on the battery with the tabs
on the back of the phone. Clip into place.
To remove press on the clip and lift the
battery out.

Charging the battery

Insert the connector on the charger lead
into the connector at the base of the phone.
Plug the charger into a mains AC socket.
When charging commences, the battery
icon will change into a charger cable icon.
When the battery is fully charged, the
battery icon will reappear and you can
disconnect the charger.

Powering up/down

To switch the phone on: Press .
If the phone asks for a PIN code:
Enter the code that is supplied with the SIM
card. The code will be displayed as asterisks.
When complete, press , OK.
Wait a few seconds while the phone
searches for the network. Once the network
has been found, the main screen appears
and your phone is ready to be used.
The main screen shows the network name
and two icons giving the signal strength
(top right) and battery level (top left).
To switch the phone off, press and hold .

Broadcast messages

Your service provider may offer Cell
Broadcast. This could be information on
the traffic, weather, events, or local
information which is broadcast by the
network to all mobiles in a specific area.
When you activate this feature, you may
receive messages about the selected
topic. Contact your service provider for
more details.

Contact list options

When you have selected a name you
can open a list of options by pressing

, Options which will allow you to
change, delete, give details and send a
message.

Fixed names

This service allows you to restrict your
outgoing calls to certain selected numbers
from your SIM card. This feature is
dependent on your service provider.
Your phone will ask for the PIN2 code to
activate this function. You can obtain this
code from your service provider. When
this feature is activated, a new contact
list is made visible in place of your
standard one. Only numbers from this
contact list can be dialled. You can add
numbers to this contact list in the same
way as adding numbers to your normal
contact list, with the exception that you
have to enter the PIN2 code.

Using the contact list

The names and numbers you enter into

your
contact list are stored on the SIM card.
To access your contact list entries, press
from the main screen.

Storing a name and number

1 Press , Contacts, from the main

screen.

2 Use the up and down keys and

to scroll to the Add new option, then
press , Select.

3 Enter the area code and phone number,

then press , OK.

4 Enter the name you wish to store in the

contact list, then press , OK. Use
the keypad as explained in the table
overleaf to enter the characters and to
switch between lower case, upper case,
and numeric modes.

Correcting an entry

Pressing deletes the character
immediately to the left of the cursor.
Pressing and holding deletes all of
the text that you have entered.

Languages

This menu allows you to change the
language of the phone.

Auto redial

When this function is activated, the phone
will automatically redial a number when
the call attempt fails. If the other user’s
phone is busy, the phone will wait a few
seconds before each attempt, and then
beep when it succeeds.

Safety information

You should observe and follow these guidelines for the safe
and efficient use of your phone. Failure to comply with these
guidelines and requirements may void your warranty and may
invalidate any approvals given to your phone.

Radio Frequency Signals

Your phone transmits and receives radio frequency (RF) signals
whenever it is switched on. The design of your phone
complies with all relevant standards and recommendations for
human exposure to RF energy.
Your phone’s transmission power is controlled by the cellular
network at the lowest possible level to maintain a good signal.
You may also choose to reduce your exposure to RF signals by
controlling the duration of your calls or by using an accessory
such as a handsfree device. Your phone has been designed to
comply with applicable standards when used correctly in
accordance with the user instructions.
A sample of this phone model has been tested and found to
comply with the following directives, standards or
recommendations:

• 1999/5/EC • 89/336/EEC • 73/23/EEC as amended

by 93/68/EEC • 1999/519/EC

• AS/NZS 2772.1 (Int):1998 • IEEE Std C95.1, 1999 Edition

Antenna Care and Efficient Operation

Do not use your phone if the antenna is damaged. Replace
the antenna only with one approved by the manufacturer.
Unapproved antennas or modifications may damage your
phone, degrade its performance and violate local regulations.
Do not touch the antenna unnecessarily while a call is in
progress. Contact with the antenna affects call quality and may
cause your phone to transmit at a higher power level than
otherwise needed. Hold your phone as you would any other
phone. The antenna should point up and over your shoulder.

Batteries

All batteries can cause property damage, injury or burns if
a conductive material such as jewellery or keys comes into
contact with the exposed terminals. The material may
complete an electrical circuit and become quite hot.
Exercise care in handling your phone battery. For example,
avoid carrying your phone battery loose in a pocket or
purse. This product is designed for use with manufacturer­approved batteries only. Use of unapproved batteries may
be dangerous and may cause damage to the battery or the
phone and may void your warranty.

Accessories

Only use accessories approved by the manufacturer. Using
unapproved accessories with your phone may result in
degraded performance, fire, electric shock or injury, and may
void the warranty. Please check with your dealer for the
availability of approved accessories. Your phone is intended
for use only with chargers approved by the manufacturer.

Any other use will invalidate any approval given to your phone
and may be dangerous.
The mains (AC) charger is compatible only with power sources
indicated on its label. Do not connect the charger to a power
source of a different voltage or frequency. Do not use the
charger outdoors or in areas where it may become wet.
Unplug the charger from the wall socket using the body of the
charger, not the cord. Locate the cord so that it will not be
tripped over, stepped on or damaged. Do not use the charger if
it is damaged. Unplug the charger from the wall socket before
cleaning it. Use a slightly damp cloth for cleaning, and allow
the charger to dry fully before plugging it in.

Children

Your phone is not a toy. Do not allow children to play with it.
They could hurt themselves or others. Children could also damage
the phone or make calls that increase your telephone bill.

Electronic Devices

Most modern electronic equipment is shielded from RF signals.
However, certain electronic equipment may not be shielded
against the RF signals from your wireless phone.

Pacemakers

The Health Industry Manufacturers Association recommends
that a minimum separation of 20 cm (or 6 inches) be
maintained between a handheld phone and a pacemaker to
avoid potential interference with the pacemaker. The
recommendations are consistent with the independent
research by and recommendations of Wireless Technology
Research.

Persons with a pacemaker:

• Should always keep the phone more than 20 cm (or 6

inches) from their pacemaker when the phone is turned on.

• Should not carry the phone in a breast pocket.

• Should use the ear opposite the pacemaker in order to

minimize the potential for interference.

• Consult your doctor or the manufacturer of the medical

device if you have any questions.

Hearing Aids

Some digital wireless phones may interfere with some hearing
aids. In the event of such interference, you may want to consult
your cellular dealer or hearing aid manufacturer to discuss
alternatives.

Other Medical Devices

Operation of any radio transmitting equipment, including your
cellular phone, may interfere with the functionality of
inadequately protected medical devices. Consult your doctor or
the manufacturer of the medical device if you have any
questions. Turn your phone off in health care facilities when any
regulations require that you do so. Hospitals or health care
facilities may be using equipment that could be sensitive to
external RF energy.

Icons

Problem Possible cause Possible corrective action

Phone does not power on Battery empty Fully charge the battery and then press .

Battery contacts dirty Clean contacts on battery and phone with a dry cloth, attach battery, wait a few seconds

and press .

Phone does not charge Battery empty Charge for 2 hours. Don’t worry if the battery icon does not change immediately.

Disconnect and try again.

Charger incorrectly connected

Check the mains socket, and the connection to the phone.
Battery How long should I charge the battery the first time? 12 hours continuous.
I don’t get as much battery life as I expected The phone uses battery power when it is switched on even if it is not in a call. Charge the phone regularly.

Making calls and playing with the different functions of the phone will run down
the battery faster. The stated battery life is under optimum conditions.

“Insert SIM” is displayed when SIM card is incorrectly inserted or missing

Check that the SIM card is positioned correctly, and that the metal clip is slid across. Try again.
I switch on the phone SIM card is damaged or dirty Visually check the SIM and clean the contacts with a dry cloth. Try again.
The PIN code is blocked 3 incorrect entries

Enter the unblocking code supplied with the SIM card. If you do not have this code,

contact your service provider.
The PIN2 code is blocked 3 incorrect entries

Enter the PIN2 unblocking code supplied with the SIM card

. If you do not have this code,

contact your service provider.
Poor display Low temperature Move to a warmer place and let the phone warm up.
Can’t connect to network Weak signal Move into an area of better coverage. If you are in a building, move towards a window.

Invalid SIM card Contact your ser vice provider.
Network not allowed Try reselecting the network. Switch off and then back on.

Can’t make/receive calls Weak signal Check that the service provider name is displayed on the screen. If not try to reconnect to

the network.

Phone is switched off Press for a few seconds.
Check the number Use the full area code and country code in the number.
Call key not pressed After dialling the number you must press , Call.
Network is busy If you hear rapid beeps, then the network is busy. Hang up and try again.
Call barring or fixed dialling is activated Check the fixed dialling settings. Otherwise check the call barring settings with your

service provider.

Not registered with service provider After purchasing your phone, you may need to call your service provider to activate the line.

No credit left on your prepaid card Recharge your credit.
Low earpiece volume Low setting Press when you are in a call to increase the volume.
Low ringer tone Low setting Go into the Sounds menu, select Volu me and increase the setting.
Cannot enter some words Wrong entry mode Your phone has T9 text input (i.e. it guesses what words you are trying to enter).

To enter a special word press repeatedly to change to normal multi tap mode.
“Message list full” is displayed Your SIM card memory is full of text messages, therefore Go into the Read menu of the message menu and delete
in the main screen you can not receive any more messages. some of your messages.
Some features do not work Feature not supported by the operator or your subscription. Call your service provider.
Some menus are missing There are restrictions on your SIM card or subscription. Call your service provider.

Symbol description

Main screen

Battery indicator

Empty icon indicates a very weak
battery level. Solid icon indicates
a fully charged battery level

Battery charging

Signal strength indicator

No bars indicates a very weak
signal. Four bars indicates a very
strong signal

New text message

All incoming calls are diverted

Keypad locked

New voice mail message

(this icon is network dependent)

Silent mode active

Alarm clock set

In calls list

shows that a call was incoming

shows that a call was outgoing

shows that a call was missed

In messages list

indicates the messages which
have not yet been read

indicates the messages which
have been read

indicates the smiley messages
which have not yet been read

indicates the smiley messages
which have been read

Lists

In lists shows the option
that is currently activated

Vehicles

Using your phone in a vehicle demands special considerations.
The fitting of any accessories to a vehicle should only be
undertaken by a suitably qualified person to ensure that vehicle
systems are not adversely affected, and that the accessory gives
optimum performance.

Interference

RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles (e.g., electronic fuel
injection systems, antilock braking systems and air bag systems).
Check with the manufacturer or representative regarding your
vehicle. You should also consult the manufacturer of any
equipment that has been added to your vehicle.

Driving

Always obey local laws and regulations regarding the use of a
cellular phone in the areas where you drive. In some areas, it is
illegal to use a cellular telephone while driving, and handsfree
operation is required in many other areas. Do not hold your
phone in your hand while driving. Give your full attention to
driving. Use handsfree operation if possible. Pull off the road
and park before making or answering a call if it is safe and
legal to do so.

Airbags

Do not place your phone or any accessories in the area over
an airbag or in the airbags deployment area. An airbag
inflates with great force, and serious injury could occur.

Aircraft

Switch off your phone when in an aircraft and follow any
instructions from the aircraft crew. The use of cellular telephones
in an aircraft may be dangerous to the operation of the aircraft,
may disrupt the cellular network and is often illegal. Failure to
observe this instruction may lead to suspension or denial of
cellular telephone service to the offender, or legal action or both.

Blasting Areas

To avoid interfering with blasting operations, turn your phone
off when in a “blasting area” or in areas posted “turn off two­way radio”. Obey all signs and instructions.

Potentially Explosive Atmospheres

Turn your phone off and do not remove its battery when in an
area with a potentially explosive atmosphere. It is rare, but your
phone or its accessories could generate sparks. Sparks in such
areas could cause an explosion or fire resulting in property
damage, bodily injury or even death. Areas with potentially
explosive atmospheres are often, but not always, clearly
marked. They include:

• Fuelling areas, such as petrol stations, below deck on boats,

and fuel or chemical transfer and storage facilities.

• Areas where fuel odours are present, such as when a gas leak

occurs in a home.

• Areas where the air contains chemicals or particles, such as

grain, dust or metal powders.

• Any other area where you would normally be advised to turn

off your vehicle engine.

Posted Facilities

Turn your phone off in any area where posted notices so require.

Emergency Calls

Some networks may require that a valid SIM card be properly
inserted in your phone before you can make an emergency
call. Also, emergency numbers vary by location. Check with
your service provider or the local cellular network in advance if
you are not sure. To make an emergency call, enter the valid
emergency number for your location (e.g., 112 in many
countries) and press the CALL key.
You may need to turn off features such as keypad lock before
making the call. Consult this user manual for details.

Never rely solely on your mobile phone to make an emergency
or essential communications.

Taking Care of your Phone

Use a slightly damp cloth to clean your phone. Never use any
chemical or abrasive cleaners, as they could damage the
phone. Avoid exposing your phone to any severe shocks,
extreme (hot or cold) temperatures or moisture. Keep your
phone away from open flames such as lit candles or cigarettes.

Servicing

Do not attempt to disassemble or repair your phone, as you
may damage the phone or injure yourself and will void your
warranty. Only qualified personnel at an authorized service
centre should perform repairs. Your phone does not contain any
consumer serviceable parts.

Disposal

Your battery and other components may require precautions to
be taken for safe disposal. The battery type is indicated on the
battery label. Please ensure that all local and/or governmental
regulations are followed when you dispose of this product or its
packaging. Refer to your point of sale or local government for
information on regulations that apply to this product.

Licensing

Your phone is authorised for use in GSM networks in countries
where it is approved. Use in other areas may be illegal and
may disrupt other radio communications.

Menu navigation

To enter the main menu, press , Menu,
from the main screen.

Scrolling

You can scroll from one menu to another
using the front keys and . When you
find the menu that you are looking for,
press , Select to go in. Press End, back
or to return to the previous level.

SIM Toolkit

Your service provider may offer some
special services or applications. The name
of the menu may change to indicate the
type of service, for example “Information”.

For more details, please contact your
service provider.

© 2001 Sendo. All rights reserved.
The Sendo logo and D are trademarks of Sendo
International Ltd. Sendo reserve the right to change
any specifications without prior notice.

T9

®

Text Input is a registered trademark of Tegic
Communications. All rights reserved.
T9

®

Text Input is licensed under one or more of the
following U.S. Patents:
5,818,437, 5,953,541, 5,187,480, 5,945,928,
6,011,554 and additional patents are pending
worldwide. Both the GSM logo and the GSM letter
mark are trademarks of the GSM Association.
Localised by WHP.

www.sendo.com

8E30-02010-11003

Auto answer

This function is only applicable when certain
handsfree accessories (e.g., a personal
hands-free headset) are connected to the
phone. When you receive an incoming
call with this feature activated, the phone
rings three times before automatically
accepting the call.

Any key answer

When this function is activated, you can
answer an incoming call by pressing any
key, except , Reject.

Animations

This menu allows you to switch your menu
animations off or on.

Security

Your PIN (Personal Identity Number) code is a
code which you can use to protect unwanted
users from using your phone. This is the
number that the phone asks for at switch on.

PIN Code:
1 Activate PIN entry requirement at switch

on (if your SIM card supports this).

2 Deactivate PIN entry requirement at

switch on (if your SIM card supports this).

3 Change PIN.
4 Change PIN2.

Some network services require a separate
security code. This code is the PIN2.
This menu allows you to change the PIN2
code that the mobile asks for when using
certain features.
To activate the PIN code requirement or
change the PIN code, you need to enter the
current PIN code.

If you don’t know your PIN code, contact your
service provider.

This menu allows you to configure the
various tones that the phone plays when
you receive a call or a new text message,
or some other event occurs.

Ringer

Select this option to set the ringing tone
for incoming calls.

Volume

Select this option to change the volume
setting for the different tones that the
phone plays.

Key tones

This menu allows you to set the type of
keypad tones that you would like to hear
when pressing the keys.

You have three options:

Off No sound emitted upon a key press.
On Short, low volume tones.
DTMF These are standard tones, as used

in touch tone phones. Each number
has its own specific tone.

Vibrator

Select this menu to set the vibrator for
incoming calls or text messages.

You have three options:

Off Deactivates the vibrator function.
On Sets the phone to vibrate for an

incoming call or text message.

Vibrate Sets the phone to vibrate for a
then ring few seconds before the phone

starts to ring.
This option is not available on all models.
None of the above settings affects any of

the sounds settings.

Events

This option allows you to set the alert tones
to on or off for the following options:

New message
New broadcast
Low battery
Low credit

This is only with certain subscriptions.

Divert

This network feature allows you to divert
your incoming calls to your voice
mailbox or to another number.

This menu offers four options:

If busy: When activated, calls will be

diverted if you are already in a call.

If no answer: When activated, calls will

be diverted if you do not answer your
phone.

Unreachable: When activated, calls will

be diverted if your phone is off or if you
are out of coverage.

All calls: When activated, all of your

incoming calls will be diverted.
For each of the above, you can:
Check, activate or cancel the service.

Service numbers

Your service provider may have pre­programmed some useful numbers into
your SIM card. These numbers normally
give access to special services. For more
information contact your service provider.

1 Press , Contacts to display the

contact list menu, scroll using .

2 Scroll to the Service no. option, then

press , Select.

Call waiting

This menu allows you to activate or
deactivate the call waiting feature.

Network selection stays manual until you
switch to automatic mode.

Send number

This menu allows you to select whether
you hide your identity or not when
you call someone.

There are three options:

Network Setting returns to Network

default setting

On Your telephone number is sent

to your correspondent when
you call.

Off Your telephone number is not

sent to your correspondent
when you call.

Cost/timers

This menu contains all information on the
amount of time you have spent on calls.

This menu offers five options:

Balance: Displays the amount of credit

that you have left on your prepaid card.

Outgoing: Displays the total time that

you have spent on your phone on
outgoing calls.

Incoming: Displays the total time that

you have spent on your phone on
incoming calls.

Limit: Allows you to view and set the

maximum cost limit that you can go up to.

Rate: Allows you to set the price per unit,

and enter the currency in which you wish
the call costs to be displayed.

Services

Commands

This menu allows you to send special
commands to the network to get specific
information. This could be information such as
the time and date, your own phone number,
or the amount of credit remaining on your SIM
card. The commands, and whether this feature
is available, can be obtained from your service
provider. You can store the number of the
command and a name. Once stored, scroll to
the command and press , Send to get the
required information from the network.

Network selection

This menu allows you to choose how the
phone searches for the network.

Mode:
Manual sets the search mode to manual
Automatic

sets the search mode to automatic

Search:

Searches for and then displays all available
networks. If you are in manual mode then the
selected network will become your default
network.

You have two options:

Automatic: The phone searches all available

networks and automatically selects one.

Manual: The phone searches all available

networks and, when finished, displays a list of
all the networks found.
You can scroll up and down with to
select the network that you wish to use.
Once you select a network, your phone will
always try to select this network.

O587-Sendo-UK-12pp-insert 17/10/01 1:10 pm Page 2
