Page 1

SAC MT9030C / SAC MT9031C

PORTABLE AIR CONDITIONER WI-FI

Translation of the original manual

Page 2

SAC MT9030C / SAC MT9031C

Page 3

5 6

Page 4

3 4

8910

2 7

Page 5

EN Portable Air Conditioner Wi-Fi

Important safety instructions

READ CAREFULLY AND STORE FOR FUTURE USE.

This symbol indicates that not adhering to instructions may result in death or serious injur ies.

WARNING : To prevent the death or injury of the user or other persons or damage to property, the following instructions must be adhered to. Incorrect use as aresult of not adhering to instructions may cause death, injuries or damage.

• This appliance may be used by children 8 years of

age and older and by persons with physical, sensory, or mental impairments or by persons with alack of experience or knowledge, if they are properly supervised or have been informed about how to use the product in asafe manner and understand the potential dangers.

• Cleaning and maintenance performed by the user must

not be performed by unsupervised children.

• Children must not play with the appliance.

- 1 -

Revision 12/2021

Page 6

• If the power cord is damaged, it must be replaced by an

authorised service centre or by another similarly qualified person, this will prevent the creation of adangerous situation. It is forbidden to use the appliance if it has adamaged power cord.

• The appliance must be stored in amanner that prevents its

mechanical damage.

• The appliance must be stored in awell-ventilated location,

where the dimensions of the room correspond to the dimensions specified for its operation.

• The appliance must be stored in aroom where an

open flame is not continuously in use (e.g. running gas appliance) or where there are not sources of ignition (e.g. running electrical heating element).

• Before connecting the appliance to apower socket, check

that the rated voltage on its rating label matches the electrical voltage in the power socket.

• Connect the appliance only to aproperly grounded socket.

• The power socket must be freely accessible so that it is

possible to quickly disconnect the power cord from the power source if necessary.

• The appliance is designed for use at home, in offices and

similar types of areas. Do not use it in very dusty or humid rooms such as laundries or bathrooms, in areas where chemical or explosive substances are stored, in industrial surroundings or outdoors.

• Do not place the appliance in the vicinity of an open flame

or appliances that are sources of heat.

- 2 -

Revision 12/2021

Page 7

• Do not place the appliance on unstable surfaces such as

carpets with very long and thick fibres.

• The appliance may only be used on adry, stable, smooth

and horizontal surface.

• The appliance is equipped with travel wheels, so pay

extra attention when handling it so that it does not fall downstairs or travel down from sloped areas. If necessary, secure the wheels using the stoppers.

• Only use original parts to assemble the appliance. Before

starting to assemble the appliance, make sure that it is turned off and disconnected from the power socket.

• Prior to connecting the appliance to apower socket, make

sure that the appliance is correctly assembled according to the instructions in this user’smanual.

• Do not touch the appliance with wet or damp hands. This

applies especially when it is connected to apower socket.

• Do not expose the appliance to dripping or spraying water

or submerge it in water or another liquid.

• Do not cover or insert anything into the air inlet or air outlet

openings. Otherwise, this could damage the appliance.

• During operation there needs to be sufficient space for air

circulation of at least 30 cm on all sides of the appliance.

• Do not expose yourself to acold air current for along time.

This could have anegative effect on your health.

• To turn the appliance on or off, always use the appropriate

buttons on the control panel or the remote control. Do not turn off the appliance by disconnecting the power cord from the power socket.

- 3 -

Revision 12/2021

Page 8

• Always turn off the appliance and disconnect it from the

power socket when leaving it without supervision, when not using it and before moving, disassembling, or cleaning it.

• Do not attempt to remove the outer case of the appliance.

• Disconnect the appliance from the power socket by pulling

on the plug, never pulling on the power cord. Otherwise, this could damage the power cord or the socket.

• If the power cord or power plug are damaged in any way,

do not use the appliance.

• Store the appliance in avertical position. It may be

transported in avertical position or tilted on the sided. If you have already used the appliance, check that all the condensate has been drained. After transporting it, wait at least 1 hour before using the appliance.

• Do not use the appliance if it is not working correctly if

it has been damaged or has been submerged in water. To avoid ahazardous situation arising, do not repair the device yourself or modify it in any way. Have all repairs or adjustments performed at an authorised service centre. By tampering with the appliance, you risk voiding your legal rights arising from unsatisfactory performance or quality warranty.

• Installation must be performed in accordance with the

installation instructions. Incorrect installation may result in awater leak, injury by electrical shock or fire.

• To prevent the risk of fire or injury by electrical shock, do

not use this appliance with atimer or any another similar device that could spontaneously start this appliance.

- 4 -

Revision 12/2021

Page 9

• The appliance must be installed in accordance with

national electrical codes.

• Only use this product for the purposes that are described

in this user’smanual. Otherwise, this may result in damage or excessive noise and vibrations.

• Use only the accessories and components that are

supplied together with the appliance and the tools explicitly intended for its installation. The use of nonstandard parts and accessories may result in awater leak, injury by electrical shock, fire, injury, or damage to property.

• DO NOT ADJUST the length of the power cord of the unit

and do not use an extension cord for its power supply.

• DO NOT CONNECT the unit to apower socket to which

other electrical appliances are already connected. The incorrect selection of an electrical power supply may result in afire or injury by electrical shock.

• Do not cover the cable with acarpet. Do not place carpets,

fillets, or any other floor coverings on the power cord. Do not locate the cable underneath furniture or appliances. Lead the cable where nothing will ride over it and where nobody can trip over it. If this occurs, immediately disconnect the unit from the power socket.

• If the unit is tipped over during use, turn it off and immediately

disconnect it from the main power supply. Visually check that the unit has not been damaged in any way.

• In the event of any doubts that the unit has been damaged

in any way, seek assistance from atechnician or customer service.

- 5 -

Revision 12/2021

Page 10

• The power supply must be disconnected during

athunderstorm to prevent damage to the appliance in the event of alightning strike.

• Disconnect the power supply to the appliance if it makes

astrange noise or if an odour or smoke is emitted.

Read this user‘smanual.

Warning: Fire hazard.

SPECIFIC INFORMATION FOR APPLIANCES USING REFRIGERANT GAS R290

Carefully study any warnings.

CAUTION :

For defrosting and cleaning, do not use any other tools than those recommended by the manufacturer.

• This appliance must be placed in an area without any

continuous source of ignition (for example an open fire, gas or electrical appliances in operation).

• Do not puncture or do not burn it.

• Refrigerant gases may be odourless.

• This appliance must be located in rooms with an area

greater than 13 m2.

- 6 -

Revision 12/2021

Page 11

• This appliance contains approx. 205g of refrigerant gas

R290.

• R290 is arefrigerant gas that complies with the European

directives on the environment. Do not puncture any part of the refrigerant circuit.

• If the appliance is installed, used and stored in anon-

ventilated area, the room must be designed to prevent the accumulation of refrigerant leaks resulting in arisk of fire or explosion due to ignition of the refrigerant caused by electrical heaters, stoves, or other sources of ignition.

• The appliance must be stored in such away as to prevent

mechanical failure.

• Individuals who operate or work on the refrigerant circuit

must have the appropriate certification issued by an accredited organisation that ensures competence in handling refrigerants according to aspecific evaluation recognized by associations in the industry.

• Repairs must be performed based on the

recommendations from the manufacturing company. Maintenance and repairs that require the assistance of other qualified personnel must be performed under the supervision of an individual specified in the use of flammable refrigerants.

• Check the rating label for the type of refrigerant gas used

in your appliance.

• Do not cover the ventilation slots.

• Compliance with national gas regulations shall be

observed.

- 7 -

Revision 12/2021

Page 12

Portable Air Conditioner Wi-Fi

User'smanual

• Prior to using this appliance, please read the user’smanual thoroughly, even in cases, when one has already familiarised themselves with previous use of similar types of appliances. Only use the appliance in the manner described in this user’smanual. Keep this user’smanual in asafe place where it can be easily retrieved for future use.

• We recommend saving the original cardboard box, packaging material, purchase receipt and responsibility statement of the vendor or warranty card for at least the duration of the legal liability for unsatisfactory performance or quality. In the event of transportation, we recommend that you pack the appliance in the original box from the manufacturer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE APPLIANCE A1 Air outlet

A2 Control panel A3 Handles (located along both

sides)

A4 Travel wheels A5 Air outlet

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF ACCESSORIES B1 Flexible air exhaust hose

B2 Window outlet B3 End piece B4 Remote control

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE CONTROL PANEL C2 Cooling mode indicator

C3 Dehumidification mode

indicator

C4 Fan mode indicator C5 Timer indicator C6 Display C7 Fan speed indicators (High,

Medium, Low, Auto)

W Wi-Fi indicator light

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

REMOTE CONTROL D1 Display

D2 On/Off button D3 MODE button for selecting an

operating mode

D4 TIMER button for setting the

timer

D5 SLEEP button

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INSTALLATION

Installation location for the portable air conditioner

• Locate the portable air conditioner on an even, dry and stable surface and within reach of agrounded power socket.

• For easier handling, the portable air conditioner is equipped with travel wheels A4. Do not use the travel wheels A4 when you need to move the air conditioner over carpets or similar surfaces. Avoid riding over objects.

• To achieve optimal efficiency, maintain adistance of at least 45 cm from the wall or other obstacles.

• To ensure sufficient efficiency of the portable air conditioner, keep all windows and doors closed and blinds and drapes drawn.

A6 Power cord A7 Top air inlet A8 Top drain outlet A9 Bottom air inlet A10 Removable pre-filter A11 Condensate drain hole

B5 Drain hose B6 Textile window gasket seal

(not shown)

C8 On/Off POWER button C9 FAN button for setting the fan

speed

C10 – button C11 + button C12 TIMER button for setting the

timer

C13 MODE button for selecting an

operating mode

D6 SWING button D7 ▲ button D8 ▼ button D9 FAN button for setting the fan

speed

D10 °C/ °F button for changing

the temperature units

• Make sure that there is no heat source located in the room. Do not locate the portable air conditioner in aroom with high humidity, e.g. laundry.

Note:

Do not use the portable air conditioner to cool aroom where computer servers, etc. are located. Installation, adjustment, maintenance and repairs must only be performed by aqualified person.

Installation of flexible hose on to the portable air conditioner

• The flexible hose B1 must be connected to the portable air conditioner and installed into awindow in accordance with the operating modes that you wish to set. Install the flexible hose B1 when you wish to select the operating modes: cooling, dehumidification or automatic mode. It is not necessary to install the flexible hose B1 when you wish to select the fan mode.

• Extend the flexible hose B1 to the required length. Put the end piece B3 on to the end of the flexible hose B1. Insert it into the air inlet A5 and turn it to the right to secure the hose B1 in place.

• Put the window outlet B2 on to the end of the flexible hose B1.

Installing the flexible hose using the textile gasket seal

• The textile gasket seal B7 is suitable for tilt-open, sash and roof windows. The textile gasket seal B7 is fitted with aVelcro zip tape to make its installation in the window easier. Open the window and into the created crevice install the textile gasket seal B7. We recommend that you thoroughly degrease the location (frame and sash) where you will be attaching the textile gasket seal B7 using an appropriate cleaning agent. Remove the protective paper strip and stick the tape on to the window frame. Never stick it on to the inner surface of the frame, otherwise you will not be able to close the window. Then stick on the second part of the textile gasket seal B7 on the inner or outer part of the window sash. Check that you can close the window.

• In order to be able to insert he flexible hose B1, the gasket seal is fitted with an integrated zip. Open the zip in such alocation that will enable you to easily insert the flexible hose B1.

• It is not necessary to remove the textile gasket seal B7 from the window when not using the portable air conditioner. The window can be closed even with the gasket seal installed.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

CONTROLS OF THE PORTABLE AIR CONDITIONER

A. CONTROL PANEL

• Insert the power plug into apower socket. Now the portable air conditioner sets itself to the stand-by mode.

Turning the portable air conditioner on and off

• To turn on the portable air conditioner, press button POWER C8. Press it again to turn the portable air conditioner off.

Note:

Never turn off the portable air conditioner by pulling the power cord out of the power socket. Turn off the portable air conditioner using button POWER C8, wait afew minutes and then pull out the power cord.

- 8 -

Revision 12/2021

Page 13

OPERATING MODES

1. Cooling mode

• Repeatedly press button MODE C13 until the cooling indicator C2 is lit. Use buttons –/+ C10 aC11 to set the desired temperature. You can set the temperature in the range from 18 to 32 °C.

• Using button FAN C9, set the fan speed. Repeatedly press button FAN C9 to switch the speed in the following order: High (high speed) – Medium (medium speed) – Low (low speed) – Auto (automatic speed). Each time the button is pressed, the respective indicator will be lit on

the control panel.

2. Fan mode

• Repeatedly press button MODE C13 until the fan mode indicator C4 is lit. Using button FAN C9, set the fan speed. Repeatedly press button FAN C9 to switch the speed in the following order: High (high speed) – Medium (medium speed) – Low (low speed). Each time the button is pressed, the respective indicator will be lit on the control panel and, likewise, agraphical indicator will show the selected speed on the display C6. In this mode, it is not possible to set the temperature, nor is it necessary to connect the flexible hose B1 to the portable air conditioner.

3. Dehumidification mode

• Make sure that the flexible hose B1 is connected to the air conditioner and goes into the window. Repeatedly press button MODE C13 until the dehumidification indicator C3 is lit. The display C6 will show It is not possible to set the temperature or fan speed in this mode. The fan speed is automatically set.

4. Automatic mode

• If you select an automatic mode, the portable air conditioner will automatically select an operating mode based on the temperature in the room.

• Repeatedly press button MODE D3 until the arrow on the display D1 stops at the symbol

• Use button FAN D9 to set the fan speed. Repeatedly press button FAN D9 to switch the speed in the following order: High (high speed) – Medium (medium speed) – Low (low speed) – Auto (automatic speed). Each time the button is pressed, the arrow at the speed bar on the display D1 will switch.

• The portable air conditioner will start in the fan mode, when the temperature in the room is less than 23 °C, and in the cooling mode when the temperature in the room is higher than 23 °C.

Functions of the portable air conditioner

1. Automatic start function

• Start the portable air conditioner by pressing button POWER C8. Using button MODE C13, select the operating mode in which you wish to turn on the portable air conditioner. Use buttons –/+ C10 and C11 to set the desired temperature and use button FAN C9 to select afan speed as required. Turn off the portable air conditioner using button POWER C8.

• Now press button TIMER C12, awristwatch icon together with aflashing time will appear on the display C6. Use the buttons –/+ C10 andC11 to set the time after which the portable air conditioner will turn on automatically. The automatic start time can be set in the range between 30 minutes and 24 hours (set in 30 minute intervals until 10 hours, and one hour intervals until 24 hours).

• After afew seconds, the time is saved to the memory of the air conditioner and the automatic start indicator appears on the display C6. Once the set time elapses, the portable air conditioner will start automatically.

• If button TIMER C12 or POWER C8 are pressed after the automatic start is set, then this setting will automatically be cancelled.

2. Automatic shut-off function

• When the portable air conditioner is running, press button TIMER C12, awristwatch icon together with aflashing time will appear on

the display C6. Use the buttons –/+ C10 andC11 to set the time after which the portable air conditioner will automatically stop.

• The automatic shut-off time can be set in the range between 30 minutes and 24 hours.

• After afew seconds, the time is saved to the memory of the air conditioner and the automatic shut-off indicator appears on the display C6. Once the set time elapses, the portable air conditioner will shut off automatically.

• If button TIMER C12 or POWER C8 are pressed after the automatic shut-off is set, then this setting will automatically be cancelled.

3. Wi-Fi function (valid only for Wi-Fi models)

• You can also control the mobile air conditioner directly from your smart phone thanks to the “Sencor HOME” application.

• Install the “Sencor HOME” application on to your smart phone. The application is available for operating systems iOS (App Store) and Android (Google Play). Further follow the instructions in the application.

• In order to control the mobile air conditioner using the installed application, it is necessary the Wi-Fi is turned on.

• While the mobile air conditioner is off (it is in stand-by mode), press the

button C9 six times within four seconds to reset the Wi-Fi

signal. An audible alert sounds. If the function is on, the indicator C2 will be lit.

• For simpler installation of the control panel of the air conditioner, you can use the following QR code!

B. REMOTE CONTROL

Inserting and replacing batteries

• Slide out the battery compartment cover, which is located on the rear side of the remote control. Place two AAA/LR03 (2× 1.5 V) alkaline batteries into the battery compartment and close the cover.

• When inserting the batteries ensure the correct polarity as shown in the battery compartment.

• When replacing the batteries, always use batteries of the same type, never combine old and new batteries or batteries of various types.

Note:

Removing the batteries from the remote control will delete all the settings. After new batteries are inserted the default remote control settings as programmed by the manufacturer will be renewed.

• If you will not be using the remote control for longer than 2 months, remove the batteries.

Using the remote control

• For the remote control to work correctly, ensure that the maximum distance of the remote control from the portable air conditioner is not greater than 7 m and that there is no obstacle between the remote control and the portable air conditioner that could prevent the transmission of the signal.

• Point the remote control directly at the portable air conditioner. The transmission of the signal is confirmed by ashort sound signal.

• Do not expose the remote control to direct sunlight or high temperatures. Otherwise the signal may not be transmitted.

Turning the portable air conditioner on and off

• To turn on the portable air conditioner, press button D2 once. Press button D2 again to turn the portable air conditioner off.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

OPERATING MODES

1. Cooling mode

• Repeatedly press button MODE D3 until the arrow on the display D1 stops at symbol

- 9 -

. Use buttons ▲/▼ D7 and D8 to set the desired

Revision 12/2021

Page 14

temperature. You can set the temperature in the range from 18 to 32 °C.

display D1 will switch.

2. Fan mode

• Repeatedly press button MODE D3 until the arrow on the display D1 stops at symbol

• Use button FAN D9 to set the fan speed. Repeatedly press button FAN D9 to switch the speed in the following order: High (high speed) – Medium (medium speed) – Low (low speed). Each time the button is pressed, the arrow at the speed bar on the display D1 will switch.

Note:

In the fan mode, it is not possible to set the temperature, therefore no temperature information will be shown on the display D1.

3. Dehumidification mode

• Repeatedly press button MODE D3 until the arrow on the display D1 stops at symbol

• It is not possible to change the fan speed in the dehumidification mode.

4. Automatic mode

• If you select an automatic mode, the portable air conditioner will automatically select an operating mode based on the temperature in the room.

• Repeatedly press button MODE D3 until the arrow on the display D1 stops at symbol

• The portable air conditioner will start in the fan mode, when the temperature in the room is less than 23 °C, and in the cooling mode when the temperature in the room is higher than 23 °C.

Functions of the portable air conditioner

1. Sleep function

• The sleep function is used to reduce overnight power consumption, when aconstant temperature is not necessary.

• Selecting an operating mode – cooling – see previous part of the user’smanual.

• Press button D5, symbol portable air conditioner will run in the last selected mode.

• For the cooling mode, within two hours, the temperature will increase by 2 °C. This new temperature will be maintained for aperiod of 6 hours and then the portable air conditioner will turn itself off.

• The sleep function can be cancelled at any time by pressing button D5, D3 or D9.

• The sleep function cannot be set in the fan and dehumidification modes.

2. Automatic start and shut-off function

Automatic start

• The automatic start function makes it possible to set atime after which the portable air conditioner will start automatically.

• Start the portable air conditioner by pressing button D1. Using button D3, select the operating mode in which you wish to turn on the portable air conditioner. Use buttons ▲/▼ D7 and D8 to set the desired temperature and use button D9 to select afan speed as required. Turn off the portable air conditioner using button D1.

• Press button D4 twice, the time and symbol the display D1. Use buttons ▲/▼ D7 andD8 to set atime after which the portable air conditioner will automatically start. The automatic start time can be set in the range between 30 minutes and 24 hours

. “dH” is shown on the display D1.

will appear on the display D1. The

will appear on

(set in 30 minute intervals until 10 hours, and one hour intervals until 24 hours).

• Press button D4 once to confirm the setting. The set time will appear on the display D1 and symbol

• Once the set time elapses, the portable air conditioner will start automatically. If button D4 or D2 are pressed after the automatic start is set, then this setting will automatically be cancelled.

Automatic shut-off

• The automatic shut-off function makes it possible to set atime after which the portable air conditioner will shut off automatically.

• While the portable air conditioner is turned on, press button D4 once. The time and symbol

• Use buttons ▲/▼ D7 andD8 to set atime after which the portable air conditioner will automatically turn off. The automatic shut-off time can be set in the range between 30minutes and 24 hours (set in 30 minute intervals until 10 hours, and one hour intervals until 24 hours).

• Press button D4 once to confirm the setting. The set time will appear on the display D1 and symbol

• Once the set time elapses, the portable air conditioner will shut off automatically. If button D4 or D2 are pressed after the automatic shutoff is set, then this setting will automatically be cancelled.

3. Flap angle function

• Button D7 can be used to select either left or right air flow. Press button D7 once, an arrow and symbol D1. Pressing button D7 will cause the arrow to disappear and the function to be cancelled.

Changing temperature units

• While the air conditioner is in stand-by mode, press button D10 to toggle the temperature units from °Cto °F and vice versa.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

MAINTENANCE AND CLEANING

• Before cleaning the portable air conditioner, turn it off and wait afew minutes, and then pull the power cord out of the power socket.

Cleaning the air filters

• If the portable air conditioner is used regularly, it is necessary to clean the air filters at least once every 14 days to avoid the fan from becoming clogged with dust. Based on the model of your air conditioning unit, clean the following filters:

– Clean both the air filter located behind the removable protective

grille of the top air inlet A7, as well as the air filter located behind the removable grille of the bottom air inlet A9.

• Carefully remove the protective grille and take out the respective filters. To remove the dust, use avacuum cleaner. In the event of greater soiling, wash the filter by hand in asolution of lukewarm water (max. 40 °C) and neutral detergent. Then thoroughly rinse it under running water and allow it to dry naturally. Do not dry it in aclothes dryer or in direct sunlight. Once the filter is dry, you can install it back in its place.

Note:

Do not use aportable air conditioner without the air filters properly installed and do not use it with wet or damp air filters.

• The water collection (condensation) tank must be drained immediately when the code “Ft” appears on the display C1 and also before this appliance is stored in order to prevent the formation of moulds.

• In households with pets, it is necessary to wipe the grille regularly to prevent it from becoming clogged by animal fur.

Cleaning the outer case

• To clean the outer case, use asoft wiping cloth dipped in asolution of lukewarm water and neutral detergent. Then wipe the surface dry.

• When cleaning it, do not spray the portable air conditioner with water or any other liquid, do not pour water on it or submerge it in water or in any other liquid.

• Do not use abrasive cleaning products, solvents, petrol, etc. for cleaning.

will remain lit.

will be shown on the display D1.

will remain lit.

will appear on the display

- 10 -

Revision 12/2021

Page 15

Storing the portable air conditioner

• In order to dry it and to prevent the formation of moulds, leave the portable air conditioner running in awarm room in the fan mode for approximately 12 hours.

• Disconnect the flexible hose B1 and store it in asafe place out of the reach of children.

• Drain all the condensate from the condensate tank – see chapter “Condensate drain outlet”.

• Clean the air filters and reinstall them. Wipe the outer case of the portable air conditioner. Remove the batteries from the remote control.

• Store the air conditioner in acool, dry and dark location.

Condensate drain outlet

• If the water level inside the condensate tank reaches apredetermined level, the portable air conditioner will show “Ft” (full condensate tank) on the display C6. In order to drain the condensate from the air conditioner, proceed as follows:

1. Disconnect the power plug from the power socket.

2. Carefully re-locate the portable air conditioner to alocation where

the water may be drained.

3. Underneath the drain outlet A1 1, place acontainer into which the

condensate will flow. Carefully remove the plug of the drain outlet A11. Connect the drain hose B6 and allow the condensate to flow out.

4. Once the condensate tank is empty (condensate has stopped

flowing), disconnect the drain hose B6 and put the plug back into the drain outlet A11.

5. Insert the power plug into apower socket and turn on the portable air

conditioner.

• If you need to ensure the condensate to be continuously drained from the portable air conditioner, it is possible to connect the drain hose B6 to awaste water drain. Proceed as follows:

1. Disconnect the power plug from the power socket.

2. Remove the plug of the top drain outlet A8. Connect the drain

hose B6. If the length of the drain hose B6 is insufficient, then it is necessary to purchase alonger hose of the same type. Never extend the length of the drain hose B6 using extensions.

3. Connect the end of the drain hose B6 to the waste water drain.

4. Insert the power plug into apower socket and turn on the portable air

conditioner.

Note:

The drain hose B6 should be installed at the same height or lower than the top drain outlet A8. Otherwise, the condensate will not be properly drained from the condensate tank.

Putting into operation again

• Check that the power cord and plug are not damaged and that the air filters are clean. Insert anew set of batteries into the remote control. Proceed according to the instructions in section “Inserting and replacing batteries”. Install the portable air conditioner according to the instructions contained in the preceding part of this user’smanual “Installation”.

TROUBLESHOOTING

Error messages

Shown on the display

Meaning Solution

Low temperature

Defect of the heat sensor

The portable air conditioner has asystem that prevents freezing at very low temperatures. The air conditioner will start again once the internal system is defrosted.

Contact an authorised service centre.

Note:

In the event that one of the aforementioned faults occurs, turn off the portable air conditioner and check for the cause of the fault. Turn it on again, and if the fault reoccurs, turn it off, disconnect the power cord from the power socket and contact the manufacturer, an authorised service centre or aperson with relevant qualifications and have the unit repaired.

Troubleshooting

• Before contacting an authorised service centre, please check the appliance according to the following instructions:

Problem Possible cause Remedy

The portable air conditioner did not turn on.

The portable air conditioner runs only for ashort time.

The portable air conditioner is on, but is not cooling.

An unpleasant odour is sensed while it is running.

The portable air conditioner turns off approx. 3minutes after it is turned on again.

An error message appeared on the display C1.

There is no current in the power socket.

The power plug is not inserted in apower socket.

The internal safety fuse is disengaged.

The flexible air exhaust hose B1 is not connected or it is blocked.

Air inlets A7 and A9 are blocked.

The windows and doors of the room are open.

There are heat sources inside the room.

The flexible air exhaust hose B1 is not connected.

The room area is too large.

The air filters are clogged with dirt and dust or animal fur.

Then compressor'ssafety fuse is protecting the air conditioner against damage if turned on sooner than after 3 minutes.

Engage the circuit breaker or, alternatively, try adifferent power socket.

Connect the power plug to the power socket.

Wait 30 minutes, and if the problem persists, please contact an authorised service centre.

Turn off the air conditioner, disconnect the hose, check that it is not blocked and reconnect the hose.

Remove the obstacles preventing air supply to the inlets.

Make sure that all doors and windows are closed.

If possible remove these heat sources.

Attach the flexible hose B1.

Perform adoublecheck of the cooled area.

Turn off the air conditioner and clean the filters according to the provided instructions.

Wait several minutes and then turn the air conditioner on again.

Proceed according to the instructions in section "Error messages".

Full condensate tank

Empty the condensate tank. Proceed according to the instructions in section "Condensate drain outlet" described previously in this user'smanual.

- 11 -

Revision 12/2021

Page 16

TECHNICAL SPECIFICATIONS

SAC MT9030C / SAC MT9031C

Power supply ........................................................................220–240 V~ / 50 Hz

Cooling power ................................................................................ 9,000 Btu / hour

Power input / Cooling power ..................................................1,200 W/ 1,000 W

El. current draw / Cooling draw .....................................................5.21 A/ 4.35 A

EER cooling factor......................................................................................................2.6

Dehumidification capacity ........................................................................ 28 l / hour

Capacity of the built-in condensate tank ......................................................... 0.5 l

Refrigerant type and weight ...........................................R290 / 205 g / GWP 3

Air flow volume .............................................................................................290 m

Noise level ............................................................................65 dB (A) (high setting)

Maximum permitted value of excess operating pressure:

Suction / exhaust part of the cooling circuit ....................................1.2/2.3 MPa

Dimensions of the portable air conditioner (w× d × h) ......440 × 325 × 695 mm

Weight ............................................................................................................29 kg (net)

Operating temperature (cooling) ...............................................................18–32 °C

Recommended room area (Central Europe) ........................................31/ 35 m

Recommended room size (Central Europe) ........................................80-91 m

*applies for the calculated climatic conditions value typical for Central Europe. For standard rooms with ceilings at standardised heights. The provided values may differ when the appliance is used in sectioned areas, in areas with multiple heat sources, heavily glazed or/and poorly insulated areas. If you know that you are purchasing the air conditioner for an area with the above-described characteristics, select amodel with ahigher power output for the given area.

The declared noise emission level of the appliance is 65 dB(A), which represents alevel Aof sound power with respect to areference sound power of 1 pW.

Note:

The efficiency of the portable air conditioner may be reduced in the event that it is used outside the above described operating temperature range.

We reserve the right to change text and technical specifications.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS

Dispose of used packaging material at asite designated for waste in your municipality.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT

This symbol on products or original documents means that used electric or electronic products must not be added to ordinary municipal waste. For proper disposal, renewal and recycling, hand over these appliances to determined collection points. Alternatively, in some European Union states or other European countries you may return your appliances to the local retailer when buying an equivalent

valuable natural resources and prevents potential negative effects on the environment and human health, which could result from improper waste disposal. Ask your local authorities or collection facility for more details. In accordance with national regulations penalties may be imposed for the incorrect disposal of this type of waste.

new appliance. Correct disposal of this product helps save

For business entities in European Union states

If you want to dispose of electric or electronic equipment, ask your retailer or supplier for the necessary information.

Disposal in other countries outside the European Union.

This symbol is valid in the European Union. If you wish to dispose of this product, request the necessary information about the correct disposal method from the local council or from your retailer.

This product meets all the basic requirements of EU directives related to it.

- 12 -

Revision 12/2021

Page 17

FAST ČR, a.s.

U Sanitasu 1621

CZ-251 01 Říčany

www.sencor.eu
