USER’S GUIDE
Table of Contents:
Introduction .......................................................2
Precautions ........................................................3
Box Contents ....................................................3
Overview .......................................................4-9
Getting Started ........................................10-12
Basic Operation .......................................13-18
Setting Input Levels .....................................19
Setting Output Levels .........................20-24
Advanced Functions ............................ 25-29
Common Advanced Functions.........30-32
Frequency Chart ........................................... 33
Troubleshooting ..................................... 33-34
Specifications ................................................ 35
Warranty .......................................................... 36
AWS-2000
Thank you for choosing Senal.
The Senal AWS-2000 is a versatile, lightweight, yet rugged
wireless system that is ideal for a wide variety of professional
uses such as ENG, interviews, conferences, lectures, and
live theater production. The included AWS-2000T beltpack
transmitter, AWS-2000R camera mount receiver, and
optional AWS-2000P plug-on transmitter have an operating
range of up to 500 feet. Each component is packed with
features that will enable videographers and directors to
capture broadcast-quality audio. The intuitive design and an
uncomplicated menu structure make the AWS-2000 system
easy to set up and effortless to use.
The portable receiver features a one-touch frequency scan
and infrared sync that allows you to effortlessly find a clear
channel for your devices. This true-diversity receiver uses
dual antennas and reception circuits that eliminate audio
dropouts and RF interference. To further protect audio from
unwanted interference, the AWS-2000 system includes
3-level squelch and pilot tone. Other features such as
selectable mic/line input and variable RF power output give
this wireless system the ability to deliver clean, accurate, and
pristine audio.
Each component is powered by two AA batteries.
An integrated Micro-USB port can be used to charge
NiMH batteries without removing them from the battery
compartments. Advanced OLED display technology provides
easy-to-see screens, even in dim lighting conditions. Top
display orientation assures that the displays are easy to read
regardless of where they’re mounted or carried. Removable
antennas make this wireless system compact and easy to
transport, and allows you to easily change an antenna if
it’s damaged. Rugged metal housing on each component
makes the AWS-2000 system ideal for travel or location use
and able to withstand the rigors of the most demanding
environments.
2
Introduction
Precautions
• Please read and follow these instructions, and keep this
manual in a safe place.
• Keep this unit away from water and any flammable
gases or liquids.
• Use only the correct, recommended voltage.
• Do not attempt to disassemble or repair the
equipment—doing so will void the warranty, and Senal
will not be responsible for any damage.
• Clean the units with only a soft, dry cloth.
• Use only parts, accessories, and attachments provided
by the manufacturer.
• Make sure that this product is intact and that there are
no missing parts.
• To avoid damage to this product, be careful not to
overtighten or improperly thread any of the
threaded fittings.
• Exposure to high sound levels can cause permanent
hearing loss. Avoid listening at high volumes for
extended periods of time.
• All images are for illustrative purposes only.
Box Contents
• AWS-2000T Beltpack transmitter
• AWS-2000R Portable true-diversity receiver
• Balanced locking Mini-to-XLR output cable
• Locking Mini–to-Mini output cable
• Camera mount for AWS-2000R
• Dual mounting bracket
• Carry case
• Antennas (×2)
• AA batteries (×4)
Precautions / Box Contents
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
3
Overview AWS-2000T Body-Pack Transmitter
Microphone
input
Antenna
Mute switch
OLED
display
Power
button
IR port
Belt clip
Battery compartmentMicro-B USB port
4
Set
button
Up/Down
buttons
Overview
2
31
GR.06-CH.08
AWS-2000
MIC
LC PLT
4 987 105 6
1. Group number
2. Channel number
3. Transmission power indicator
4. Device name
5. Low cut filter
6. Input level indicator
7. Pilot tone indicator
8. Lock indicator
L
Overview
9. Battery level indicator
10. Audio input level meter
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
5
Overview AWS-2000R True Diversity Receiver
OLED
display
Antenna A
Antenna B
AFS button
IR port
Headphone
jack
Balanced 3.5 mm
output jack
6
Micro-B
USB port
RF
indicator
Peak
indicator
Power
button
Set
button
Up/Down
buttons
Battery
compartment
Overview
2
31
GR.06-CH.08
AWS-2000
T R
4 6 75
1. Group number
2. Channel number
3. Antenna reception level indicator
• Icons for left and right antenna reception
level should appear as pictured. If they
don’t, refer to the Troubleshooting
section at the end of this manual.
4. Device name
5. Transmitter battery level indicator
• The transmitter’s battery level indicator
will not appear on the receiver screen
unless pilot tone is turned on (see Pilot
Tone on page 25).
6. Receiver battery level indicator
7. Audio input level meter
Overview
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
7
Overview AWS-2000P Plug-On Transmitter
XLR connector
Locking ring
OLED
display
Power
button
Micro-B USB port
8
Battery
compartment
IR port
Set button
Up/Down
buttons
Overview
2
31
GR.06-CH.08
AWS-2000
MIC
LC
4 10 1187 965
1. Group number
2. Channel number
3. Transmission power indicator
4. Device name
5. Low cut filter
6. Input level indicator
7. Phantom power indicator
8. Pilot tone indicator
48V
PLT
L
Overview
9. Lock indicator
10. Battery level indicator
11. Audio input level meter
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
9
Getting Started
Installing the Batteries
1. Open the battery compartment by
sliding the battery compartment
door in the directions indicated by
the arrow.
2. Install the batteries into the
battery compartment. Make sure
to match the polarity indicated
on the inside of the battery
compartment door.
3. Press the battery compartment
door down, and slide it back into
place until it locks shut.
Selecting the Battery Type
The first time the batteries are installed, the battery
selection window will appear.
Select the setting that matches the type of battery you’re
using (Alkaline, Lithium, or rechargeable NiMH) by following
these steps:
1. Use the Up/Down buttons to scroll to the appropriate
battery type. [
BATTERY ALKALINE ]
2. Press the Set button.
Note: If you select the wrong battery type, the unit will still
function, but the battery meter will be inaccurate.
To change the battery type from the main menu during use,
see the Battery section under Common Advanced Functions
on page 31.
Powering On the Units
Press and hold the power button. The OLED screen and LED
indicators will illuminate.
10
Getting Started
The battery icon indicates the battery
level. The icon blinks to indicate a
critically low battery level.
Attaching the Antennas
Screw the antennas clockwise into the
threaded antenna sockets. Make sure
they are tightly attached.
Connecting the Receiver
The AWS-2000 microphone system includes two output
cables for devices with an XLR input or a 3.5 mm TRS input.
The output cables feature right-angled locking 3.5mm
connectors to allow for flexible positioning, whether the
receiver is mounted on a camera or used in a bag. Choose the
appropriate cable for your device, and follow these steps:
1. Plug the right-angle male 3.5
mm plug into the output jack on
the bottom of the AWS-2000R
receiver, and turn the locking sleeve
clockwise until tight.
2. Connect the other end of the cable
to your device.
Connecting the Microphone
1. Plug the microphone’s male 3.5 mm plug
into the input jack on the top of the
AWS-2000T transmitter.
2. Secure the cable by turning the locking
sleeve clockwise until tight.
Getting Started
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
11
