SEMAK VITABLEND STICK BLENDER
MODEL VB180
OPERATION AND WARRANTY BOOKLET
SEMAK AUSTRALIA: FACTORY 18, 87-91 HALLAM SOUTH ROAD, HALLAM VIC 3803
PH 03 9796 4583 FAX 03 9796 4586 WEB WWW.SEMAK.COM.AU
Table of Contents
Important Safety Instructions .............................................................................. 4
Electrical Compliance ........................................................................................... 5
Operating Instructions ......................................................................................... 6
Cleaning and Maintenance Instructions .............................................................. 7
Service & Maintenance ........................................................................................ 7
Spare Parts ........................................................................................................... 7
Warranty .............................................................................................................. 7
Warranty Registration ......................................................................................... 9
Notes ..................................................................................................................10
Page | 2
RETAIN THESE SAFETY INSTRUCTIONS
Page | 3
Important Safety Instructions
Please read all of the instructions before using the Vitablend and ensure that other
operators also read and are made to understand all safety and operating
instructions. Save these instructions for Future reference.
Thank you for purchasing a Semak Vitablend Stick Blender.
1. Important notice: Ensure that the Vitablend’s push button switch is not depressed
and that the power supply is switched off before connecting to the electric outlet.
2. Use only on AC 220-240V – 50 Hz only.
3. Do not use an extension cord.
4. To avoid risk of electric shock, do not immerse cord, plug or motor end of the
appliance in water or any other liquid. Never put the Vitablend in a dishwasher.
5. Always switch off at the power outlet before removing the plug. Remove by
holding the plug - do not pull on the cord. When the appliance is not in use, or
prior to cleaning, always switch off the power and removes the plug.
6. Disconnect power cord from the electrical outlet when the blender is not in use.
7. The Vitablend should not be used by children or infirm persons and care should be
taken when used near these persons. The Vitablend blender should not be used
outdoors. Young children should be supervised to ensure that they do not play
with the appliance. Never leave the blender unattended.
8. Avoid physical contact with moving parts. The cutting blades are very sharp and
care is needed when handling cutting blades, and only when the Vitablend
blender is disconnected from the power supply. Never attempt to touch the
cutting assembly when the blender is in operation.
9. Do not use on the stove or let the cord come into contact with any hot surface.
10.Keep hands and utensils out of the container while using the Vitablend to prevent
the possibility of severe injury to persons or damage to the unit. A scraper may be
used only when the unit is not in operation.
11.Never operate the Vitablend unless the shaft is immersed in blending ingredients.
Never operate the Vitablend in an empty container.
Page | 4
12.When blending liquids, especially hot liquids, use a tall container (no more than
half-full) or make small quantities at a time to reduce the risk of spillage.
13.Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions, is dropped or damaged in any way. Return the appliance to Semak
Australia. (Manufacturer) or its Authorised Service Agent for repair. Do not
attempt to repair the machine.
14.For Safety reasons and to avoid maintenance by unskilled persons, the appliance
should always be returned to Semak Australia. (Manufacturer) for adjustment or
repair if required.
WARNING – This appliance should be used according to the
instructions.
MISUSE of this appliance will cause HAZARD.
Electrical Compliance
Semak Vitablend complies with the following electrical standards
Compliance
CISPR 14
Page | 5
Operating Instructions
The Semak Vitablend chops, blends and mixes quickly and efficiently. Use it to make
sauces, soups, purees etc.
1. Before connecting to electrical outlet, clean blade end of Vitablend by wiping with
a damp cloth.
2. Ensure that the Vitablend’s push button switch is not depressed and that the
power supply is also switched off before connecting to the electrical outlet.
3. Please note that although this is a heavy duty appliance, it is not meant for
prolonged use in heavy mixtures that a larger model should handle. The Vitablend
should be used intermittently in the following way, one minute on and one minute
off with the task completed within three minutes. If the handle/motor body of the
Vitablend begins to feel warm, it is being overused and should be turned off
immediately and allowed to cool down before resuming operation.
4. The Vitablend will only operate while pressure is applied to the rubber capped
push button switch on the handle. To stop Vitablend, release pressure from the
switch.
5. Insert the blade end of the Vitablend into the container and submerge in the
contents, then press the switch in for the required duration. Care should be taken
not to stand the Vitablend in the container. Standing the appliance on the bottom
of the container interrupts the appliances operation and risks placing undue
pressure on the seals. Doing this causes pressure around the blade as mixture is
sucked towards the blade but is prevented from moving away therefore the
mixture has nowhere to go but up. Avoid using the blender this way as it can lead
to bearing and electrical problems. Rather than standing the blender in the
mixture, hold the blender suspended in the mixture so that a vortex action occurs.
6. Motor cuts off automatically once the switch is released. To prevent splashing, do
not lift blade end out of mixture whilst still in operation.
7. When used directly in a saucepan while cooking, always remove the saucepan
from the stove first.
8. When mixing or blending hot ingredients, the following precautions should be
observed:
a. Take care not to lift blender out of hot ingredients while motor is on, to
avoid splashing.
b. Do not stand directly over container of hot ingredients while operating
the Vitablend.
c. Use a tall container ensuring that it is no more than half full.
9. Do not leave the blender unattended or in the mixture when not in operation.
Page | 6
Cleaning and Maintenance Instructions
Always unplug the Vitablend from the power source before cleaning. The unit is easiest to
clean by placing the blade under hot running water immediately after completing the
blending task and wiping the blade dry to prevent tarnishing. Do not place Vitablend in a
dishwasher or immerse in water.
Do not attempt to remove the wand or blade assembly. Clean motor/handle body by
wiping with a barely damp cloth only. Never immerse the motor end, plug or cord in water
or any other liquid. The bearing should be lubricated occasionally with a HACCP approved
food grade lubricant by placing a couple of drops at the base of the cutting unit and drive
shaft. Spin the blade to assist in the dispersion of lubricant into the bearing.
Service & Maintenance
For Service and Repair, contact Semak for your nearest Authorised Service Agent
The Foodservice Industry is deemed a hostile environment within the scope of AS/NZS
3760:2003. Semak Vitablend MUST be routinely electrically tested for compliance with this
standard if used commercially.
It is recommended that a Food Safety program such as HACCP be employed and that
routine service and repair be undertaken at the time of electrical testing to ensure the
correct operation and function of all parts. The equipment MUST be serviced annually or
sooner depending of the hostility of the environment in which it is operated.
Spare Parts
Spare Parts, exploded views and wiring diagrams are available from our webpage. Go to
www.semak.com.au and locate the appliance in the product section for the above
information.
Warranty
Model VB180 is a Commercial Grade blender suitable for light commercial and domestic
use. This product is guaranteed for 12 Months from the date of purchase against
mechanical and electrical defects. If the fault is deemed caused by MISUSE/ABUSE the
terms of the warranty are invalidated. If the product has been opened or tampered with (ie.
In an attempt to repair it) the warranty is invalidated.
All warranty repairs should be undertaken by Semak Australia.
It is against company policy to authorize warranty repairs over the phone. Service Agents
will require a work order number from Semak to conduct warranty repairs.
Page | 7
SEMAK WARRANTY
Semak Australia
Factory 18
87-91 Hallam South Road
HALLAM VIC 3803
Ph 03 9796 4583
Fax 03 9796 4586
Email technical@semak.com.au
Web www.semak.com.au
THIS WARRANTY APPLIES ONLY TO PRODUCTS MANUFACTURED AND SOLD IN AUSTRALIA
The benefits conferred by this warranty are an alternative to all other rights and remedies
in respect of the product which the consumer has under the Trade Practices Act and similar
State and Territory Laws.
Semak Australia. Warrant each new SEMAK appliance manufactured by SEMAK to be free
from defects in materials or manufacturing process for a period of 1 Year from the date of
original purchase.
Should defects due to faulty materials or manufacturing process develop within the
warranty period, the appliance will be repaired without charge providing all conditions of
this warranty are observed.
1. Proof of Purchase and Warranty card must be retained and available on request.
2. This Warranty is void if the equipment has been damaged due to misuses neglect or is
used for a purpose for which it was not suited; and no repairs, alterations or
modifications have been attempted by other than Semak or its authorised Service
Agent.
3. Semak Australia. Reserves the right to reject a claim for warranty if service is required
due to misapplication, improper installation, inadequate wiring, and incorrect voltage
conditions. Under no circumstances shall SEMAK or its agents bear responsibility for
consequential damages of any kind.
4. Where required by Statute or local authority, equipment must be installed by qualified
person in accordance with all relevant regulations. Failure to do this will void product
warranty.
5. Cost of transport of any appliance or part to and from SEMAK or its Service Agent is to
be paid by the owner.
6. A charge will be made where failure is due to neglect, abuse or accidental damage on
the part of the operator, or when no fault can be found or the fault is due to causes
outside the control of Semak Australia.
7. The above does not preclude the purchaser from their Statutory rights as a consumer.
Page | 8
WARRANTY REGISTRATION
Retain for Future Reference
DO NOT SEND
Please complete one registration for each Semak appliance.
You may be required to provide this information when requesting after sales service. Please
staple your proof of purchase to this page.
Company Name: ________________________________________________
Company Address: ________________________________________________
Business Type: ________________________________________________
Contact: ________________________________________________
Phone: ________________________________________________
Fax: ________________________________________________
Email: ________________________________________________
Product: ________________________________________________
Serial Number: ________________________________________________
Date of Purchase: ________________________________________________
Place of Purchase: ________________________________________________
Page | 9
Notes
Page | 10
Page | 11
© Semak 2014
Page | 12
