SELFSAT Snipe User Manual

The World Smallest Automatic Satellite Antenna
Background
Plenty of good contents come from the sky. More and more people in Europe are getting bigger demand for satellite broadcasting. People want to use ONE ANTENNA which can cover every occasions and can be easily used everywhere.
The size of conventional dish type antenna is too big to carry. And its size does not allow easy installation anywhere. So, we have to consider the antenna with small size and high efficiency.
We want to satisfy all these requirements with SNIPE. The name of SNIPE comes from a small bird which can fly 10,000km without resting, which refers to compact design but powerful performance of our product.
1
Concept
SMALLEST
&
FULL
AUTOMATIC
POWERFUL
PORTABLE
“Full Automatic” Satellite Antenna Don’t spend your energy for struggling to install the antenna
“World’s Smallest & Powerful” Satellite Antenna No competitors with the best design & performance
“Portable” Satellite Antenna Don’t miss your favorite live TV programs while away from home
Don’t worry about the space and package for carrying out
2
Product Description
•LNB
• Skew pivot : -60° ~ +60°
• Elevation : 17° ~ 75°
SELFSAT
flat antenna
technology
• Main body : 360° turning
• Sustain body
• port 1 : power cable
• port 2 : to receiver
• port 3 : for F/W update, additional satellite programing & outside control box connection for vehicle installation
satellite indicators &
simple 4 buttons
Automatic
3 axis movement
(skew adjustment)
3
Key Features
Smallest & Slimmest Design
Just put your SNIPE at your convenient place with open sky
It only occupies the minimum space as Seflsat does
Portable & Universal
SNIPE can replace normal dish in your home
Thanks to its folding design and lightness, you can bring it out easily
Firm and light carry-out carrier
510mm 357mm
MAX 405 mm MIN 191 mm
4
Key Features
Fully Automatic Positioning
SNIPE acknowledges your location with its inside GPS solution, wherever you are
3 axis movement brings you the best quality
Multi Satellite Reception
Already major satellites pre-programed. You only choose your target satellite
You can program 2 additional satellites
You can watch your favorite local channel far away from your home location
High Efficiecy
It is real tiny, but the performance is beyond your imagination
Don’t need to consider big dish for your home and vehicle
Automatic
Skew
Adjustment
+ 60°-60°
5
Key Features
Easiness Itself
Just connect signal cable to your receiver
Power-on, then it is ready to lock to a signal. No mounting, no positioning
User Friendly Operation
LED indicator shows your target satellite
Only 4 buttons to operate. You can enjoy your live TV with simple touching of button
6
Various Usage
Home
Camping
Cabin
RV
Backyard Barbecue
Outing
7
Operation
STEP 2
SNIPE sets elevation angle
STEP 3
SNIPE adjusts skew angle for the best reception
STEP 1
On control panel, select target satellite
Repeat
STEP 4
SNIPE turns face to the satellite position
8
Coverage
SNIPE, with its great quality, can receive the signal from major satellites in whole Europe
9
Competitiveness
Manual / Dish Type
No complicated
installation
Easy carry-out size
Difficult to carry outSpend too much time and effort to set up Difficult to adjust the position manually
Automatic / Dish Type
Solved all by SNIPE
Smart Skew adjustmentCompact designFirm carry box
Big size
Additional external control box
Long search time to target satellite
Two axis movement (manual skew)
Automatic / Dome Type
No bulky looksPortable useA/S service convenientPrice value
Bulky & dull designNo skew adjustmentHigh costHard installation to the rooftop
10
Specification
Weight
LNB Input Frequency
LNB Output Frequency
Angle Range
Dimensions
Antenna Only
Full Package
Work Condition
Antenna Gain
Min EIRP Polarization LNB Output
Elevation
Azimuth
Skew
510 x 357 x 180 mm
7.0 kg
9.0 kg Stationary
33.7 dBi @ 12.7GHz 50 dBw Linear (Horizontal / Vertical) 1 output
10.7 ~ 12.75 GHz 950 ~ 2,150 MHz 15°~ 75
unlimited (360°)
-60°~ +60
°
°
* package included
• Snipe antenna (with Carrier box)
• Signal cable, Power cable, Serial cable
• Manual
Search Speed
Satellite Searching Time
Operating Temperature
Elevation
Azimuth
Skew
Power Requirement
Power Consumption
30° / s 30° / s 20°/ s 60 seconds (average) DC 12~24V 30W (in searching)
-30°C ~ +60°C
11
