SELF SLF SLT80-700IL Datasheet

Characteristics:

www.self-ecg.com

Standards:

Product description：

Constant Current LED Power Supply

FCC linear series

Constant Current LED Power Supply

FCC linear series

SLT80-700IL-EU

Product description

This type of power supply is an exclusively designed

stabilized power supply for LED lamp. With constant

current (CC) technology, it is suitable for constant current

lamps connected in a series. According to the switches

selection,the output current can change from 325mA to

700mA. The current step is 25mA.

The built-in protection circuit will shut down the power

supply in case of such faults as: open circuit, short circuit ,

over load or over temperature. The power supply will

restart automatically after fault correction.

Standards:

EN61347-1

EN61347-2-13

EN61547

EN55015

EN61000-3-2

EN61000-3-3

EN62384

EN62493

Official Version
Last update:13,May,2020
Page: 1 of 5

Characteristics:

• Built-in power supply for constant current LED lamp

• Plastic houseing with function ground

• Non-isolated design have high performance/cost ratio

• Quick connetion terminal for wire cross selection 0.5-0.75mm2

• Selectable output current according to the dipswitch from

325-700mA

• Open circuit，short circuit，over load and over temperature

protection

• Auto restart after fault conditions removal

• up to 94% efficiency

• Warranty:5years

Specifications

Specifications：

Input

Other

Note

Ambient
and Life

Protection

Output

Model

turn on time(S)

output current(mA)

output current tolerance

ripple current(mA)

working voltage range(V)

Max. output voltage(V)

dimming interface

dimming range

rated supply voltage(Vac)

voltage range(Vac)

line frequency(Hz)

input current(mA)

efficiency

power factor

inrush current(Ipk)

over voltage protection

short circuit protection

over temperature protection

automatic restart

over load protection

surge capacity

Ta(℃) )

Tc max. (℃)

audible noise(dB)

Storage Temperature(℃)

ambient humidity range

nominal life-time(hrs)

weight(g)

dimensions (L×W×H)(mm)

casing material

housing colour

type of protection

protection class

SLT80-700IL-EU

www.self-ecg.com

In

turn on time(S)

output current(mA)

output current tolerance

ripple current(mA)

working voltage range(V)

Max. output voltage(V)

dimming interface

dimming range

rated supply voltage(Vac)

voltage range(Vac)

line frequency(Hz)

input current(mA)

efficiency

power factor

inrush current(Ipk)

over voltage protection

short circuit protection

over temperature protection

automatic restart

over load protection

surge capacity

Ta(

Tc max. (

audible noise(dB)

Storage Temperature(

ambient humidity range

nominal life-time(hrs)

weight(g)

dimensions (L×W×H)(mm)

casing material

housing colour

type of protection

protection class

2

2

1

3

SLT80-700IL-EU

≤0.5

325 350 375

40-246 40-228 40-213 45-200 45-188 50-178 50-168 50-160 55-152 55-145 55-139 60-133 60-128 60-123 60-118 60-114

94.0% 93.9% 93.8% 93.6% 93.5% 93.4% 93.2% 93.0% 92.8% 92.6% 92.5% 92.5% 92.3% 92.2% 92.1% 92.0%

400 425

475

450

5%...85%RH，Not condensing

500 525 550 575

+/-5%

≤3%

420

No

n/a

110-270

198-264

50/60

470

0.90C

40A/140us

No

YES

YES

YES

YES

L-N: 1KV L,N-PE: 2KV

-20...50

90

25

-30...80

50'000@Tc=85℃

230

280x30x22

plastic

grey

IP20

Built-in

600 625

650 675

700

Note

Page: 2 of 5

1.Tolerance : includes set up tolerance, line regulation and load regulation.

2.Tested at full load,230Vac.Refer to"Power Factor" and "EFFICIENT"curve graphs.

3.Output LF current ripple (< 200 Hz)

4.All parameters NOT specially mentioned are measured at nominal voltage input, rated load and 25 of ambient
temperature.

5.The power supply is considered as a component that will be operated in combination with final equipment. Since
EMC performance will be affected by the complete installation, the final equipment manufacturers must re-qualify
EMC Directive on the complete installation again.

Dimensions(mm):

Dimensions(mm):

Wiring diagram:

www.self-ecg.com

22

30

264

280

Wiring diagram:

220-240VAc
50/60Hz

GND

L
N

LED+

LED-

Page: 3 of 5

Electrical curves:

Electrical curves:

0.60

0.65

0.70

0.75

0.80

0.85

0.90

0.95

1.00

40%

50%

60%

70%

80%

90%

100%

PF

70

75

80

85

90

95

40%

50%

60%

70%

80%

90%

100%

PF vs LOAD(230Vac)

LOAD

325mA
450mA
575mA
700mA

www.self-ecg.com

EFFICIENCY vs LOAD(230Vac)

325mA

450mA

575mA

700mA

EFFICIENCY(%)

LOAD

note
For constant current power supply,"LOAD" means the percentage of the maximum rated output voltage.
For constant voltage power supply,"LOAD" means the percentage of the maximum rated output current.

Page: 4 of 5

Order information:

Order information:

Sales & Technical Support:

www.self-ecg.com

Order.No.

1001-260156-0130

Sales & Technical Support:

Model Carton quantity(pcs) Carton dimension(mm) G.W./CTN(kg)

SLT80-700IL-EU 50 380x310x165 12
