Bluetooth Interface Board User’s Manual

Features

The Bluetooth Interface board has the following features:

1) A built-in Bluetooth module

2) Bluetooth 2.1+EDR compatible

3) Power class: Class 2

4) External dimensions: 66 mm × 88 mm (aerial cover included)

Manufacturer: Seiko Epson Corporation
Model Name: M212B
Product Name: Bluetooth Interface board for POS printer

The antenna used this module is as follows;
Antenna Type: CHIP ANTENNA
Antenna Gain: 2 dBi

Integration to the end product

The Bluetooth Interface Board has to be installed and used in accordance with the technical
description/installation instructions provided by the manufacturer.

This Bluetooth interface board is exclusively for EPSON TM printers with a
slot dedicated for it. No devices other than EPSON TM printers can use
this.

The Bluetooth Interface Board is listed as a Limited Modular Transmitter device because its
radio elements don’t have its own shielding. Therefore, when it is installed in the printer, be
sure to push the board fully into the slot.

Note that any changes or modifications to this equipment not expressly approved by the
manufacturer could void the user’s authority to operate this equipment.

Bluetooth Interface Board User’s Manual

1

Regulatory Information

USA-Federal Communications Commission (FCC)

This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy. If not installed and used in
accordance with the instructions, it may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can
be determined by tuning the equipment off and on, the user is encouraged to try and correct
the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the distance between the equipment and the receiver.

-Connect the equipment to outlet on a circuit different from that to which the receiver is
connected.

-Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

Labelling

The Bluetooth Interface board labelled as below.
FCC ID:BKMFBM212B
