CAL. V011, V041
ALARM CHRONOGRAPH
●Analogue time and digital time/calendar
●Regular alarm
●Stopwatch
●Illuminating light (for Cal. V011)
1
DISPLAY AND CROWN/BUTTONS
B
Pulsar
QUARTZ
CROWN
A
● With each press of button A, the digital display changes as follows:
TIME/CALENDAR
SETTING display
➮
➮
➮
2
ALARM display
STOPWATCH display
➮
CALENDAR display
➮
TIME display
SCREW DOWN CROWN
[for models with screw down crown]
Unlocking the crown
1 Turn Crown counterclockwise until you no
longer feel the threads turning.
2 Crown can be pulled out.
Locking the crown
1 Push Crown back in to normal position.
2 Turn Crown clockwise while pressing it lightly
until tight.
3
B
A
✽ Selection of the digits
TIME/CALENDAR
SETTING display
4
DIGITAL TIME/CALENDAR SETTING
Press to show TIME/CALENDAR
A
SETTING display.
▲
▲
Select the digits to be adjusted.✽
➾
Month
B
▲
Set the flashing digits.
A
▲
Press to show TIME/CALENDAR
B
SETTING display.
▲
Press to show CALENDAR display.
A
Date
➾
12-/24-hour indication
➾
Pulsar
QUARTZ
➾ Seconds ➾ Minutes ➾ Hour
➾
Day
➾
ANALOGUE TIME SETTING
● Be sure to set the digital time first before setting the analogue time.
CROWN
Pulsar
QUARTZ
1
3
1 Pull out when Second hand is at the
12 o’clock position.
2
2 Turn to set Hour and Minute hands.
3 Push back when the seconds in the
digital time display count “00”.
ILLUMINATING LIGHT (for Cal. V011)
● The illuminating light is activated by continuously pressing button B in the TIME
or CALENDAR display.
* The light intermittently illuminates the display to save the energy of the battery, and
this is not a malfunction.
5
ALARM TIME SETTING
B
Pulsar
QUARTZ
A
ALARM display mark
✽ Selection of the digits
ALARM display ➾ Hour ➾ Minutes
6
➾
ALARM
Press to show ALARM display.
A
▲
Press to activate the alarm setting
B
function.
▲
▲
Select the digits to be adjusted.✽
B
▲
Set the flashing digits.
A
▲
Press to show ALARM display.
B
ENGAGEMENT/DISENGAGEMENT OF ALARM AND HOURLY TIME SIGNAL
Press to show CALENDAR or
A
TIME display.
B
Pulsar
QUARTZ
A
Hourly time signal mark
Alarm mark
* The alarm rings at the designated
time for 20 seconds. To stop it
manually, press button A or B.
▲
With each simultaneous press,
and
B
A
alarm and hourly time signal are
engaged and disengaged in order:
Both engaged
➮
Alarm disengaged
Hourly time signal engaged
➮
Alarm engaged
Hourly time signal disengaged
➮
Both disengaged
7
STOPWATCH
● The stopwatch measures up to 60 minutes in 1/100 second increments.
Press to show STOPWATCH display.
A
B
Pulsar
QUARTZ
A
▲
Start.
B
▲
Stop.
B
▲
Reset.
B
Minutes
1/100 seconds
Seconds
8
NOTES ON OPERATING THE WATCH
DIGITAL TIME/CALENDAR SETTING
● When setting the flashing digits, they are advanced quickly by keeping button A
pressed, except the seconds and 12-/24-hour indication.
● Seconds digits setting:
The seconds are reset to “00” by pressing button A.
* When the seconds count any number from “30” to “59” and button A is pressed, one
minute is added and the seconds are reset to “00”.
● The changeover between 12- and 24-hour indications is made alternately with each
press of button A.
● When setting the hour in the 12-hour indication, check that AM/PM is properly set. Only
“P” (PM) is displayed. For the AM setting, there is no indication.
● When the time function is displayed in the 24-hour indication, the alarm function is also
displayed in the 24-hour indication.
● If the watch is left untouched in the TIME/CALENDAR SETTING display with the digits
flashing, it will automatically return to the CALENDAR display in 1 to 2 minutes.
● The calendar automatically adjusts for odd and even months except February of leap
years.
➾
➾
9
ANALOGUE TIME SETTING
● When setting the minute hand, first advance it 4 to 5 minute ahead of the desired time
and then turn it back to the exact minute.
● When the crown is pushed in, the minute hand may move slightly. However, this is not
a malfunction.
ALARM
● By pressing button B with the alarm setting function activated, the alarm mark is
displayed and the alarm is automatically engaged.
● When setting the alarm in the 12-hour indication, check that AM/PM is properly set.
Only “P” (PM) is displayed. For the AM setting, there is no indication.
● If the watch is left untouched in the ALARM display or with the digits flashing, it will
automatically return to the CALENDAR display in 1 to 2 minutes.
● Alarm test:
Press and hold buttons A and B at the same time in the TIME or CALENDAR display.
STOPWATCH
● After the stopwatch has measured 60 minutes, it starts counting again from “00' 00"
oo” as many times as necessary until it is stopped.
● When measuring a long period of time, return the STOPWATCH to the CALENDAR or
TIME display after the stopwatch starts, to prevent any possible mistaken operation.
10
BATTERY CHANGE
Battery life : Approx. 2 years
2
Years
●
If the alarm is used for more than 20 seconds a day and/or the hourly time signal
more than 24 times a day, the battery life may be less than the specified period.
●
As the battery is inserted at the factory to check the function and performance of
the watch, its actual life once in your possession may be less than the specified
period.
●
When the battery expires, be sure to replace it as soon as possible to prevent any
malfunction.
●
We recommend that you contact an AUTHORIZED PULSAR DEALER for battery
replacement.
Battery : SEIKO SR726W
11
WARNING
● Do not remove the battery from the watch.
● If it is necessary to take out the battery, keep it out of the reach of
children. If a child swallows it, consult a doctor immediately.
● Never short-circuit, tamper with or heat the battery, and never expose
it to fire. The battery may burst, become very hot or catch fire.
CAUTION
● The battery is not rechargeable. Never attempt to recharge it, as this
may cause battery leakage or damage to the battery.
12
TO PRESERVE THE QUALITY OF YOUR WATCH
WATER RESISTANCE
● Non-water resistant
• If the watch becomes wet, have it checked by an AUTHORIZED
PULSAR DEALER or SERVICE CENTER.
● Water resistant 5/10/15/20 bar
• Do not operate the crown or buttons when the watch is wet or in
water.
5 bar WR
10/15/20
bar WR
If used in sea water, rinse the watch in fresh water and dry it
completely.
• When taking a shower with the water resistant 5 bar watch, or
taking a bath with the water resistant 10, 15 or 20 bar watch, be
sure to observe the following:
* Do not operate the crown or buttons when the watch is wet with
soapy water or shampoo.
* If the watch is left in warm water, a slight time loss or gain may
be caused. This condition, however, will be corrected when the
watch returns to normal temperature.
13
* Pressure in bar is a test pressure and should not be considered as corresponding
to actual diving depth since swimming movement tends to increase the pressure
at a given depth. Care should also be taken on diving into water.
** We recommend that you wear a PULSAR Diver’s Watch for scuba diving.
TEMPERATURES MAGNETISM
Your watch works with
+50°C
stable accuracy within a
temperature range of 5°
-5°C
C and 35° C (41° F and
Temperatures over 50° C (122° F) or
below –5° C (+23° F) may cause a
slight time loss or gain or battery
leakage or shorten the battery life.
However, the above conditions will
be corrected when the watch returns
to normal temperature.
95° F).
14
affected. Keep the watch away from
close contact with magnetic objects.
The analogue unit of your
watch will be adversely
affected by strong
S
N
magnetism, though the
digital unit will not be
CARE OF CASE AND BRACELET
To prevent possible
rusting of the case and
bracelet caused by dust,
moisture and perspiration,
wipe them periodically
with a soft dry cloth.
SHOCKS & VIBRATION
Light activities will not
affect your watch, but be
careful not to drop your
watch or hit it against hard
surfaces, as this may
cause damage.
CHEMICALS
Be careful not to expose
the watch to solvents,
mercury, cosmetic spray,
detergents, adhesives or
case, bracelet, etc. may become
discolored, deteriorated or damaged.
paints. Otherwise, the
PERIODIC CHECK
It is recommended that the
2 - 3
Years
DEALER or SERVICE CENTER to
ensure that the case, crown, buttons,
gasket and crystal seal remain intact.
watch be checked once
every 2 to 3 years. Have
your watch checked by an
AUTHORIZED PULSAR
PRECAUTION REGARDING
CASE BACK PROTECTIVE FILM
If your watch has a
protective film and/or a
sticker on the case back,
be sure to peel them off
before using your watch.
15
STATIC ELECTRICITY
The IC (Integrated
Circuit) used in your
watch will be affected
by static electricity
display. Keep the watch away
from close contact with objects
such as TV screens which emit
strong static electricity.
16
which may disturb the
LIQUID CRYSTAL PANEL
The normal life expectancy for
the liquid crystal panel of the
watch is approximately 7 years.
7 Years
read. If the watch is left at a temperature
of more than 50°C for a long time, the
quality of the liquid crystal panel may
deteriorate. Please contact your
AUTHORIZED PULSAR DEALER or
SERVICE CENTER if you wish to have a
new panel fitted (guaranteed one year).
After that it may decrease in
contrast, becoming difficult to
